Alga Science ROBOTIC BUBBLE BLOWER Manual page 3

3. Attach the fan cover (2) to the gearbox (3) as
shown in Fig. 4. Make sure the locks on both sides
click securely into place.
5. Attach the wheel (5) to the wheel axle in the
middle of the gearbox (3). (Fig. 6)
Fig. 4
4. Fit the liquid tank (4) onto the base plate (6), see
Fig. 5. Make sure it clicks securely into place.
Fig. 6
6. Fit the wheel and gearbox assembly onto the base
plate (6) until it clicks into the right position. The
bottom rings of the wheel should be inside the liquid
tank (Fig. 7).
Fig. 5
Fig. 7
