ROBOTIC BuBBle
Fig. 1
HOw tO PUt tOGEtHER YOUR ROBOtIc BUBBLE BLOwER
Fig. 2
1. Insert the motor (7) into the gearbox (3) until it
clicks into the right position. Make sure the small
extending part is at a right angle to the motor.
(Fig. 2)
BlOweR
1. 1 Fan
2. 1 Fan cover
3. 1 Gearbox
4. 1 Liquid tank
5. 1 Wheel
6. 1 Base plate
7. 1 Motor
8. 1 Battery compartment
9. 1 Switch
10. 3 Spring connectors
• Batteries required: 2 AA (not included)
• Bubble liquid required (not included)
2. Attach the fan (1) over the drive wheel of the
motor (7), see Fig. 3.
Fig. 3
