Packaging: The following table shows the package numbers included with the boiler to be installed. The packages are presented in the order in which they should be opened for assembly. EC-10 Contains the boiler instructions Contains the control panel instructions Control Panel Boiler Boiler Casting Sub-Assembly...
Packagees Put a protective piece of cardboard on the floor in front of the boiler casting sub-assembly. Take the body off the pallet and put it down vertically on the burner door. 3/8” Bolt, Nut & Washers Installing the base Attach the base onto the front of the boiler.
Page 4
Reverse the direction of opening of the burner door if necessary (opening at left). When the burner leaves the factory, the burner door opens towards the right. Perform operations 4.1, 4.2 and 4.3 below to open the burner door towards the left (if absolutely necessary). 8575N019 - Remove the cast iron hinge pin for the burner door...
Page 5
Installing the insulating material notch in front 8575N021A - Pass the strap between the cast iron body and the base. - Install the insulation around the body, folding the bottom on each side of the boiler inside the base. - 1 strap on the 3 and 4 section versions, - 2 straps on the 5 and 6 section versions 8575N022 - Put the back insulation into place and fix it onto the pre-...
Page 6
EC-13 EC-14 EC-15 EC-16 Installing the control panel support cross bar - Put the support cross bar into place on the boiler body, - Fix it at the front with 2 HM8 flanged nuts positioning it on : - Fix the 3rd section with : •...
Page 7
Honeywell Aquastat Putting the burner cable in place Cable clamp. Cable Attach one end of the burner wiring harness (cable) to control box, and route other end through hole in control panel support cross bar. (Shown with Honeywell aquastat control.) Attach cable clamp (from bag of screw) to cable to limit travel of cable through hole in control panel support cross bar.
Installing the side panels 8575N025B Put the front of the side panel into place, engaging the lower notch of the panel in the cross bar of the base. Make sure that the lower fold in the panel is cor- rectly positioned under the fold of the cross bar. Straighten the side panel and pull it upwards.
Installing the cover Installing the rear panel Hang up the rear panel on the side panels. Put the cover into place and push it forwards to fix it in the two side panel bushings. Fix it using four self tapping screws + serrated Fix it at the back with 2 ø...
Assembling the burner Fix the gasket with the flange on the burner door using four 3/8”–16 studs, supplied. (screw shorter length of metric thread into burner door.) Push the burner into the burner door until it will not go any further. Cable clamp.
Page 11
Assembling the front cap Lift the window. Attach the front cap in the openings near the bot- tom of the side panels. Slide the two lugs of the front cap into the notches of the side panels and then fix it in the two spring clips. Push the front cap into contact with the side panels and fix it using the two black RLS M 6 x 10 screws (S/F part no.
