Installing the cashless solution into touchtunes entertainment systems

Advertisement

CONNECTING THE INTERFACE CABLE TO THE TOUCHTUNES SYSTEM WITH A COIN ACCEPTOR
If the TouchTunes entertainment system has a Coin Acceptor, then the following instructions should be used to prop-
erly connect the ePort G9 Telemeter. Entertainment systems with Coin Acceptors require an additional Adapter Board
and cable. Please refer to the tables at the beginning of this document for the proper cables and adapter boards.
Follow the instructions below for the TouchTunes system that you have.
Virtuo, Ovation II, MX-1 systems with the white connector on the door.
1. Disconnect the coin acceptor from the cable (squid) on the door, and discard. It will not be used in the remainder
of this installation.
2. Connect the coin acceptor to J2 of the USAT adapter 1 board using cable 300200-008.
3. Connect the interface cable VXXUC0101303 from the ePort G9 Telemeter to J3 of the adapter board.
4. Connect J1 of the adapter board directly to the cable (squid) on the door. See FIG. 24.
MX-1 systems with the black connector on the door
1. Disconnect the coin acceptor cable from the connector on the door.
2. Connect the coin acceptor cable to J2 of the adapter board.
3. Connect the interface cable VXXUC0101303 from the ePort G9 Telemeter to J3 of the adapter board.
4. Connect one end of the cable 300987-006 to J1 of the adapter board, and the other end to the black connector
on the door. See FIG. 25.
Playdium systems
1. Disconnect the coin acceptor cable from the backplane.
2. Connect the coin acceptor cable to J2 of the adapter board.
3. Connect the interface cable VXXUC0101303 from the ePort G9 Telemeter to J3 of the adapter board.
4. Connect one end of the cable, 300987-006, to J1 of the adapter board, and the other end to the coin acceptor
connection of the backplane. See FIG 26.
Systems with an IO Board
1. Disconnect the coin acceptor cable from the IO board.
2. Connect the coin acceptor cable to J2 of the adapter board.
3. Connect the interface cable VXXUC0101303 from the ePort G9 Telemeter to J3 of the adapter board.
4. Connect one end of the cable shown below to J1 of the adapter board, and the other end to the coin acceptor
connection of the IO board. See FIG. 27 and FIG. 28.
USA TECHNOLOGIES CUSTOMER CARE
Contact USA Technologies Customer Care for techni-
cal support and to request additional parts, informa-
tion, and pre-authorization forms.
Phone: 888.561.4748
FAX: 610.989.9695
Email: customersupport@usatech.com
Online Store: http://store.usatech.com
USA TECHNOLOGIES WEBSITE ADDRESSES
Customer Website Login
https://usalive.usatech.com
Company Site
http://www.usatech.com
3103 Phoenixville Pike
Malvern, PA 19355
#VXXUDTUN1900 REV B
All contents © Copyright 2016 USA Technologies, Inc.
All rights reserved.
