Centraverse Desktop Base

Installation

1. Install two screws into the mounting surface, exactly
14 mm (9/16 in.) apart. Leave a 5 mm (3/16 in.) gap
between the screw head and the mounting surface.
Only use screws with a flat-bottom head.
2. Place the microphone onto the screws and slide
backwards to lock into place. The cable can be rout-
ed through either the back or the bottom of the base.
3. Connect the gooseneck microphone to the base (mi-
crophone sold separately).
4. Connect the integrated XLR cable to a mixer or P.A.
system.
Note: This microphone requires +48V phantom
power to operate.
For additional information on product use, see
the user guide for the Shure Centraverse CVG
Gooseneck microphone.
©2013 Shure Incorporated
27A20376 (Rev. 1)
The Shure Centraverse CVD is a sleek desktop base that is compatible with all Centraverse 12" and 18" gooseneck
microphones. Featuring CommShield® technology, it provides RF intereference immunity and transparently passes
audio from the gooseneck microphone to a sound reinforcement system.

Features

• Black finish that blends unobtrusively with most surroundings
• Attached 12 ft XLR cable can run through the back or bottom of the base
• Mounting holes for secure installation
• Compatible with all Centraverse gooseneck microphones
14 mm
(9/16 in.)
5 mm
(3/16 in.)
4
Centraverse™ Series
Installed Sound Microphones
CVD
