thomann Ignition WAL-L310 Par User Manual

thomann Ignition WAL-L310 Par User Manual

Led par
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WAL-L310 Par,
WAL-L710 Par,
WAL-L710 Par W-DMX
LED PAR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ignition WAL-L310 Par and is the answer not in the manual?

Questions and answers

Related Manuals for thomann Ignition WAL-L310 Par

Summary of Contents for thomann Ignition WAL-L310 Par

  • Page 1 WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 10.08.2020, ID: 474388_474390_477173...

  • Page 3: Table Of Contents

    Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 8 Safety instructions..........................11 Features............................... 17 Installation..............................19 Starting up..............................23 Connections and controls........................26 Operating..............................32 7.1 Starting the device........................... 32 7.2 Operating on the unit........................
  • Page 4 Table of contents 7.6 Functions in 9-channel DMX mode................... 55 Technical specifications........................61 Plug and connection assignment....................67 Troubleshooting............................68 Cleaning............................... 70 Protecting the environment......................71 WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...

  • Page 5: General Information

    Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX...

  • Page 6: Further Information

    General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly.

  • Page 7: Notational Conventions

    General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’...

  • Page 8: Symbols And Signal Words

    General information Instructions The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual.
  • Page 9 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
  • Page 10 General information Warning signs Type of danger Warning – dangerous optical radiation. Warning – suspended load. Warning – danger zone. WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...

  • Page 11: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended for use as an electronic lighting effect by means of LED technology. The device is designed for professional use and is not suitable for use in households. Use the device only as described in this user manual. Any other use or use under other operating con‐ ditions is considered to be improper and may result in personal injury or property damage.
  • Page 12 Safety instructions Safety DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit.
  • Page 13 Safety instructions DANGER! Electric shock caused by short-circuit Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a registered electrician. DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present.
  • Page 14 Safety instructions WARNING! Eye damage caused by high light intensity Never look directly into the light source. WARNING! Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. WARNING! Risk of burns The surface of the device can become very hot during operation.
  • Page 15 Safety instructions NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker.
  • Page 16 Safety instructions NOTICE! Fire hazard due to exceedance of the maximum current The device can power other devices. The current consumption of all serially con‐ nected other devices must not exceed the values indicated in the technical speci‐ fications, otherwise you risk injuries and irreparable damages of the device. Connect just so many devices to the output socket that the maximum current consumption is not exceeded.

  • Page 17: Features

    Features Features Splash-proof LED par, ideal for ambient lighting outdoors, for lighting buildings and stages. Special features of the device: Item no. 474388: 3 × 4-in-1 LEDs (RGBW, 10 W each) Item no. 474390 and 477173: 7 × 4-in-1 LEDs (RGBW, 10 W each) Control via DMX, via RDM and via buttons and display on the unit Built-in automatic show programmes Master / Slave operation...
  • Page 18 Features Remote Device Management The device supports RDM protocol communication (Remote Device Management) according (RDM) to ANSI / ESTA E1.20. It can exchange information with an RDM-compatible controller. Also observe the instruction manual of the controller. Information about protection Equipment with protection class IP65 are dust-tight and completely protected against contact class IP65 (first code number).

  • Page 19: Installation

    Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 20 Installation NOTICE! Risk of overheating Always ensure sufficient ventilation. The ambient temperature must not exceed the limits stated in the chapter Tech‐ nical Specifications of the User Manual. NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand.
  • Page 21 Possible damage due to moisture Moisture entering into open connectors (plugs and couplers) of DMX or power cords can cause short circuits. Close unused connectors with end caps intended for this purpose (www.thomann.de). WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 22 Installation Mounting options You can install the unit in hanging or standing position. When in use, the device must always be attached to a solid surface or an approved truss. Use the openings provided on the two- piece bracket for attaching. Always work from a stable platform whenever installing, moving or servicing the unit.

  • Page 23: Starting Up

    Starting up Starting up Create all connections while the device is off. Use the shortest possible high-quality cables for all connections. Take care when running the cables to prevent tripping hazards. WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 24 Starting up Connections in DMX mode Connect the DMX input of the device to the DMX output of a DMX controller or another DMX device. Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain.
  • Page 25 Starting up Connections in master/slave When you configure a group of devices in master/slave mode, the first unit will control the mode other units for an automatic, sound-activated, synchronized show. This function is ideal when you want to start a show immediately. Connect the DMX output of the master device to the DMX input of the first slave device.

  • Page 26: Connections And Controls

    Connections and controls Connections and controls WAL-L310 Par (Item number 474388) WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 27 Connections and controls 1 Locking screws for the brackets. 2 Two-piece bracket for hanging or floor setup 3 Omega bracket with quick lock 4 LED 5 Infrared sensor for optional remote control 6 Safety cable eyelet. 7 Display and keypad [MODE] Activates the main menu, toggles between the menu levels or closes a submenu.
  • Page 28 Connections and controls [SET] Confirms a value. 8 [DMX OUT] DMX cable with 5-pin XLR connector (IP65) 9 Pressure compensation element 10 [POWER OUT] Power cord with Power Twist TR1 cable connector for powering further devices 11 [POWER IN] Power cord with Power Twist TR1 cable connector for the power supply of the device 12 [DMX IN] DMX cable with 5-pin XLR connector (IP65) WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX...
  • Page 29 Connections and controls WAL-L710 Par (Item number 474390), WAL-L710 Par W-DMX (Item number 477173) WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 30 Connections and controls 1 Locking screws for the brackets. 2 Two-piece bracket for hanging or floor setup 3 Omega bracket with quick lock 4 LED 5 Infrared sensor for optional remote control 6 Safety cable eyelet. 7 Display and keypad [MODE] Activates the main menu, toggles between the menu levels or closes a submenu.
  • Page 31 Connections and controls [SET] Confirms a value. 8 [DMX OUT] DMX output, designed as 5-pin XLR panel socket (IP65) 9 Pressure compensation element 12 [DMX IN] DMX input, designed as 5-pin XLR panel plug (IP65) 13 [POWER OUT] Lockable output socket (Power Twist TR1 IP65) for powering further devices 14 [POWER IN] Lockable input socket (Power Twist TR1 IP65) for the power supply of the device WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX...

  • Page 32: Operating

    Operating Operating 7.1 Starting the device Connect the device to the power supply to start operation. The currently set operating mode, version and temperature are displayed. The device is operational. If no button is pressed within 30 seconds, the screen is automatically locked. To lock the screen manually, press [MODE] and [SET] simultaneously for 3 seconds.
  • Page 33 Operating Press again [MODE] to call up further menu items. To activate the respectively shown menu item, press [SET]. To return to the previous menu level without change, press [MODE]. WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 34 Operating Setting the DMX address Press [MODE] and use [UP] or [DOWN] to select the menu item ‘DMX’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Address:’ . Confirm with [SET]. Use [UP] or [DOWN] to select a value between ‘001’ and ‘512’ . Confirm with [SET]. This setting is only relevant when the device is controlled via DMX.
  • Page 35 Operating Setting the DMX mode Press [MODE] and use [UP] or [DOWN] to select the menu item ‘DMX’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Channels:’ . Confirm with [SET]. Use [UP] or [DOWN] to select the desired DMX mode (4, 6 or 9 channels). Depending on the selected mode, the display shows ‘4-CH’...
  • Page 36 Operating Connecting the W-DMX mode (available only for item no. 477173 Ignition WAL-L710 Par W-DMX) Press [MODE] and use [UP] or [DOWN] to select the menu item ‘DMX’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘W-DMX Unlock:’ to disconnect the device from a transmitter and to establish the connection to another transmitter.
  • Page 37 Operating Activating Slave mode Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Slave’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Yes’ . Confirm with [SET]. ð The device is now working in slave mode, i.e. it will exactly copy the movement of the controlling master device, correct wiring provided.
  • Page 38 Operating Activating automatic pro‐ gramme sequence Press [MODE] and use [UP] or [DOWN] to select the menu item ‘AUTO’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Yes’ . Confirm with [SET]. ð Automatic programme sequence is activated. Automatic programmes 2 to 17 run with the preset settings.
  • Page 39 Operating Configuring an automatic pro‐ gramme: Static colour This setting can only be made for the automatic programme ‘Mode:01’ . Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Program’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Color’ . Confirm with [SET]. Use [UP] or [DOWN] to select a value between ‘00’...
  • Page 40 Operating Configuring an automatic pro‐ gramme: Running speed This setting can only be made for the automatic programmes ‘Mode:02’ bis ‘Mode:17’ . Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Program’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Speed’ . Confirm with [SET]. Use [UP] or [DOWN] to select a value between ‘001’...
  • Page 41 Operating Setting the dimmer Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Dimmer’ . Confirm with [SET]. Use [UP] or [DOWN] to select the colour whose intensity you want to adjust (display shows ‘Red’ , ‘Green’ , ‘Blue’ , and ‘White’ ). Confirm with [SET]. Use [UP] or [DOWN] to select a value between ‘000’...
  • Page 42 Operating Selecting the dimmer curve Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Settings’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Curves Select’ . Confirm with [SET]. Use [UP] or [DOWN] to select the desired dimmer curve. The following table shows the available options.
  • Page 43 Operating Selecting the dimmer response Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Settings’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Dimmer Speed’ . Confirm with [SET]. Use [UP] or [DOWN] to select the desired setting for the dimmer response. The following table shows the available options.
  • Page 44 Operating Rotating the display Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Settings’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Display’ . Confirm with [SET]. Use [UP] or [DOWN] to select the desired display orientation. The following table shows the available options.
  • Page 45 Operating Setting the LED repetition rate (PWM) Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Settings’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘PWM Frequency’ . Confirm with [SET]. Use [UP] or [DOWN] to set the value of the LED repetition rate. The following table shows the available options.
  • Page 46 Operating Setting the behaviour on DMX control failure Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Settings’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘DMX Fail’ . Confirm with [SET]. Use [UP] or [DOWN] to select the device behaviour on DMX signal failure.
  • Page 47 Operating Activating / deactivating DMX With DMX synchronization you can synchronize the settings of the device with those of other synchronization DMX-controlled devices. Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Settings’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Dmx Sync’...
  • Page 48 Operating Resetting the device to factory defaults Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Settings’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Factory Reset’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Yes’ to reset the device to factory defaults select the menu item ‘NO’...
  • Page 49 Operating Showing the software version and the device temperature Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Information’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘Version’ . Confirm with [SET]. ð...
  • Page 50 Operating Showing the operating hours Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Information’ . Confirm with [SET]. Use [UP] or [DOWN] to select the menu item ‘PowerTime’ . Confirm with [SET]. ð The display shows the hours which the device has been connected to the power supply.
  • Page 51 Operating RDM function This device has an RDM function and supports the DMX512 standard. Any device with RDM can be recognized by the built-in UID code. Press [MODE] and use [UP] or [DOWN] to select the menu item ‘Information’ . Confirm with [SET].
  • Page 52 Operating Parameter ID Recognition Sent Command Received command Command DMX_START_ADDRESS IDENTIFY_DEVICE SUPPORTED_PARAMETERS SENSOR_DEFINITION SENSOR_VALUE DMX_PERSONALITY DMX_PERSONALITY_DESCRIPTION RESET_DEVICE FACTORY_DEFAULTS WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...

  • Page 53: Menu Overview

    Operating 7.3 Menu overview WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...

  • Page 54: Functions In 4-Channel Dmx Mode

    Operating 7.4 Functions in 4-channel DMX mode Channel Value Function 000…255 Intensity red (0 % to 100 %) 000…255 Intensity green (0 % to 100 %) 000…255 Intensity blue (0 % to 100 %) 000…255 Intensity white (0 % to 100 %) 7.5 Functions in 6-channel DMX mode Channel Value...

  • Page 55: Functions In 9-Channel Dmx Mode

    Operating Channel Value Function 000…255 Intensity blue (0 % to 100 %) 000…255 Intensity white (0 % to 100 %) Strobe effect 000…010 open 011…255 Strobe with increasing frequency 7.6 Functions in 9-channel DMX mode Channel Value Function 000…255 Master dimmer (0 % to 100 %) 000…255 Intensity red (0 % to 100 %) 000…255...
  • Page 56 Operating Channel Value Function 000…255 Intensity blue (0 % to 100 %) 000…255 Intensity white (0 % to 100 %) Preset colour 000…015 Without function 016…021 R(255)G(000)B(000)W(000) 022…027 R(255)G(015)B(000)W(000) 028…033 R(255)G(050)B(000)W(000) 034…039 R(255)G(125)B(000)W(000) 040…045 R(255)G(170)B(000)W(000) 046…051 R(255)G(210)B(000)W(000) 052…057 R(255)G(255)B(000)W(000) 058…063 R(200)G(255)B(000)W(000) 064…069 R(160)G(255)B(000)W(000)
  • Page 57 Operating Channel Value Function 070…075 R(110)G(255)B(000)W(000) 076…081 R(070)G(255)B(000)W(000) 082…087 R(000)G(255)B(000)W(000) 088…093 R(000)G(255)B(010)W(000) 094…099 R(000)G(255)B(025)W(000) 100…105 R(000)G(255)B(040)W(000) 106…111 R(000)G(255)B(070)W(000) 112…117 R(000)G(255)B(120)W(000) 118…123 R(000)G(255)B(255)W(000) 124…129 R(000)G(100)B(255)W(000) 130…135 R(000)G(000)B(255)W(000) 136…141 R(020)G(000)B(255)W(000) 142…147 R(050)G(000)B(255)W(000) WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 58 Operating Channel Value Function 148…153 R(080)G(000)B(255)W(000) 154…159 R(130)G(000)B(255)W(000) 160…165 R(180)G(000)B(255)W(000) 166…171 R(225)G(000)B(255)W(000) 172…177 R(255)G(000)B(255)W(000) 178…183 R(255)G(000)B(220)W(000) 184…189 R(255)G(000)B(070)W(000) 190…195 R(255)G(000)B(020)W(000) 196…201 R(255)G(000)B(007)W(000) 202…207 R(000)G(000)B(000)W(255) 208…213 R(255)G(000)B(000)W(255) 214…219 R(125)G(000)B(000)W(255) 220…225 R(000)G(255)B(000)W(255) WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 59 Operating Channel Value Function 226…231 R(000)G(120)B(000)W(255) 232…237 R(000)G(000)B(255)W(255) 238…243 R(000)G(000)B(100)W(255) 244…255 R(000)G(000)B(050)W(255) Programmes 000…015 Without function 016…030 Programme 2 031…045 Programme 3 046…060 Programme 4 061…075 Programme 5 076…090 Programme 6 091…105 Programme 7 106…120 Programme 8 WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 60 Operating Channel Value Function 121…135 Programme 9 136…150 Programme 10 151…165 Programme 11 166…180 Programme 12 181…195 Programme 13 196…210 Programme 14 211…225 Programme 15 226…240 Programme 16 241…255 Programme 17 000…255 Speed from slow to fast (programmes 2 to 17) Strobe effect 000…010 open...

  • Page 61: Technical Specifications

    Technical specifications Technical specifications WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 62 Technical specifications Item no. 474388 474390 477173 Light source 3 × 4in1 RBGW LED, 7 × 4in1 RBGW LED, 7 × 4in1 RBGW LED, 10 W each 10 W each 10 W each Optical properties Beam angle 10° (without filter) Colour temperature 6500 K Luminous flux...
  • Page 63 Technical specifications Item no. 474388 474390 477173 Output connections Voltage supply Power cord with Lockable output socket Power Twist TR1 Power Twist TR1 IP65 cable connector Output current max. 12 A Output current max. DMX control DMX cable with 5-pin XLR panel socket (IP65), 5-pin XLR connector Power consumption...
  • Page 64 Technical specifications Item no. 474388 474390 477173 Ambient conditions Temperature range –20 °C…+45 °C Relative humidity 50 %, non-condensing WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 65 Technical specifications Further information Item no. 474388 474390 477173 Construction Outdoor housing, Outdoor housing, Outdoor housing, Flat PAR Flat PAR Flat PAR Number of LEDs Colour mixture RGBW RGBW RGBW LED type x-in-1 x-in-1 x-in-1 Floor housing Fanless Remote control optional optional optional...
  • Page 66 Technical specifications Item no. 474388 474390 477173 Diffusion filter 25° Diffusion filter 25° Diffusion filter 25° (item no. 476828) (item no. 476832) (item no. 476832) Diffusion filter 40° Diffusion filter 40° Diffusion filter 40° (item no. 476830) (item no. 476831) (item no.

  • Page 67: Plug And Connection Assignment

    Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment so that a perfect light experience is guaranteed. Please take our tips, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into a socket, the result of an incorrect connection may be a destroyed DMX controller, a short circuit or ‘just’...

  • Page 68: Troubleshooting

    Troubleshooting Troubleshooting NOTICE! Possible data transmission errors For error-free operation make use of dedicated DMX cables and do not use ordi‐ nary microphone cables. Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation.
  • Page 69 DMX interface circuits. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...

  • Page 70: Cleaning

    Cleaning Cleaning Optical lenses Clean the optical lenses, that are accessible from the outside, regularly in order to optimize the light output. The frequency of cleaning depends on the operating environment: wet, smoky or particularly dirty surroundings can cause more accumulation of dirt on the optics of the device.

  • Page 71: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
  • Page 72 Notes WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 73 Notes WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 74 Notes WAL-L310 Par, WAL-L710 Par, WAL-L710 Par W-DMX LED PAR...
  • Page 76 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
