In-situ TROLL RDO 9500 Information Sheet

TROLL
9500 with Cable Connect
®
RDO
®
The instrument's Viton
than 12 months old or appear worn, dried, nicked, stretched, cracked, or otherwise
damaged, replace them promptly. The kit includes the following:
Part Qty.
A
1
B
1
C 1
D
2
E
2
F 3
G
2
H
1
I 1
J 1
K 10
L 2
M
1
N 2
O
2
P 2
A
F
K
N
O-ring Maintenance Kit
o-rings help ensure a water-tight seal. If the o-rings are more
®
Description
Red plug for restrictor
Red RDO dust cap
®
Connector dome
Orange o-rings
Restrictor o-rings
Sensor port plugs
RDO sensor o-rings for cable end (2) and (1) below restrictor plug (A)
O-ring below sensor ports
Set screw
Lens wipe for RDO lens
Port plug o-rings
RDO sensor o-rings (cap end)
O-ring lubricant
O-ring for backend cable connector
(0.5 in diam.; slightly larger than K)
O-rings for top of battery compartment (1.3 in diam.)
O-rings for bottom of battery compartment (1.6 in diam.)
B
C
G
H
L
O P
TROLL
Accessories
®
Information Sheet
Catalog Number 0080800
E
D
I
J
M
