Teledyne PROTEGE ZM User Manual

Portable, zero-maintenance, single-gas monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

PROTÉGÉ ZM
PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR
USER GUIDE
PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR
WARNING: ALL INDIVIDUALS WHO HAVE OR WILL HAVE RESPONSIBILITY FOR
USING, MAINTAINING, OR SERVICING THIS PRODUCT, MUST READ
THIS ENTIRE MANUAL CAREFULLY. FAILURE TO USE THIS EQUIP-
MENT PROPERLY COULD RESULT IN SERIOUS INJURY OR DEATH.
087-0047, Rev. G/December 2019
PROTÉGÉ ZM
USER GUIDE 087-0047, Rev. G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROTEGE ZM and is the answer not in the manual?

Questions and answers

Related Manuals for Teledyne PROTEGE ZM

Summary of Contents for Teledyne PROTEGE ZM

  • Page 1 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR USER GUIDE PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR USER GUIDE 087-0047, Rev. G WARNING: ALL INDIVIDUALS WHO HAVE OR WILL HAVE RESPONSIBILITY FOR USING, MAINTAINING, OR SERVICING THIS PRODUCT, MUST READ THIS ENTIRE MANUAL CAREFULLY. FAILURE TO USE THIS EQUIP- MENT PROPERLY COULD RESULT IN SERIOUS INJURY OR DEATH.
  • Page 2 Purpose Number Installation, configuration, operation, mainte- nance and troubleshooting information on the Protégé ZM System Guide 087-0048 Protégé ZM monitor, test station, applicable soft- ware and firmware. Copyright © Teledyne Gas Measurement Instruments Ltd, December 2019 087-0047, Rev. G/December 2019...
  • Page 3 LEGAL STATEMENT Teledyne, the Teledyne Logo, Gas Measurement Instruments, GMI, and Protégé are registered and/or unregistered marks of Teledyne Gas Measurement Instruments Ltd, referred to hereafter as “the Company.” All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from the Company.
  • Page 4 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR This page is intentionally left blank. 087-0047, Rev. G/December 2019...

  • Page 5: Table Of Contents

    PROTÉGÉ ZM PORTABLE, ZERO MAINTENANCE, SINGLE-GAS MONITOR TABLE OF CONTENTS TABLE OF CONTENTS Sect. # Section Title Page # ABOUT THIS GUIDE ....................1-1 1.1. Guide Conventions..................... 1-1 1.2. Certifications and Approvals..................1-2 1.3. General Safety Information ..................1-3 1.4. Warnings and Cautions –...
  • Page 6 PROTÉGÉ ZM PORTABLE, ZERO MAINTENANCE, SINGLE-GAS MONITOR LIST OF FIGURES LIST OF FIGURES Fig. # Figure Title Page # Major Parts of the Monitor .....................2-2 Monitor LCD Indicators....................3-1 Bump Test - Calibration Adapter Attached..............4-2 Manual Bump Test - Apply Gas ..................4-2 087-0047, Rev.
  • Page 7 PROTÉGÉ ZM PORTABLE, ZERO MAINTENANCE, SINGLE-GAS MONITOR LIST OF TABLES LIST OF TABLES Table # Table Title Page # Certifications and Approvals..................1-2 Available Monitor Options ..................... 2-1 Monitor Power-Up Sequence ..................3-2 Monitor Alerts and Alarms Descriptions ................ 3-3 Self-Test Procedure.......................
  • Page 8 PROTÉGÉ ZM PORTABLE, ZERO MAINTENANCE, SINGLE-GAS MONITOR LIST OF TABLES This page is intentionally left blank. viii 087-0047, Rev. G/December 2019...

  • Page 9: About This Guide

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR ABOUT THIS GUIDE 1. ABOUT THIS GUIDE This guide instructs gas detection personnel on the features and usage of the Protégé ZM Portable, Zero-Maintenance, Single-gas Monitor (also referred to as “the monitor”). It also provides informa- tion on configuration, operation, maintenance, specifications and trouble shooting.

  • Page 10: Certifications And Approvals

    3M™ PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR ABOUT THIS GUIDE 1.2. Certifications and Approvals Table 1: Certifications and Approvals details the monitor’s certifications and approvals. Table 1: Certifications and Approvals Mark Class I, Groups A, B, C, D, and T4 -50°C to +50°C (O -40°C to +50°C (H -30°C to +50°C (CO)

  • Page 11: General Safety Information

    Directive 2006/66/EC. These directives dictate how to dispose of the electronic and battery elements of the product after use. For Protégé products sold in the UK, contact Teledyne Gas Mea- surement Instruments Ltd for further information. For other parts of Europe, please contact your local provider of GMI products.

  • Page 12: Warnings And Cautions - Monitor Use And Care

    3M™ PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR ABOUT THIS GUIDE 1.4. Warnings and Cautions – Monitor Use and Care WARNING: ONLY QUALIFIED PERSONNEL — AS DEFINED ACCORDING TO LOCAL, COUNTY, STATE, FEDERAL AND INDIVIDUAL COMPANY STANDARDS — MAY OPERATE AND SERVICE THIS EQUIPMENT. READ AND UNDERSTAND THE GUIDE COMPLETELY BEFORE OPERATING OR SERVICING.

  • Page 13: Warnings And Cautions - Sensor Use And Care

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR ABOUT THIS GUIDE 1.5. Warnings and Cautions – Sensor Use and Care WARNING: EXTENDED EXPOSURE OF THE MONITOR TO HIGH CONCENTRATIONS OF TOXIC GASES MAY RESULT IN DEGRADED SENSOR PERFORMANCE. IF AN ALARM OCCURS DUE TO HIGH CONCENTRATION OF TOXIC GASES, EXIT TO A SAFE AREA AND BUMP TEST OR RECALIBRATE AS NECESSARY.
  • Page 14 3M™ PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR ABOUT THIS GUIDE This page is intentionally left blank. 087-0047, Rev. G/December 2019...

  • Page 15: Introduction

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR INTRODUCTION 2. INTRODUCTION 2.1. Monitor Overview The Protégé ZM is a portable, single-gas, disposable monitor that operates with a single button and has a two (2) year life span (typical). It comes ready for use with a lithium-based battery, a filter and a sensor.
  • Page 16 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR INTRODUCTION Figure 2-1: Major Parts of the Monitor shows the major parts of the monitor. Figure 2-1: Major Parts of the Monitor NOTE: The monitor is shipped with a calibration adapter (refer to C.1. Applicable Parts List).

  • Page 17: Operation

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR OPERATION 3. OPERATION 3.1. Operating the Monitor WARNING: IF THE MONITOR FAILS TO RESPOND PROPERLY UPON START UP, OR IF CALIBRATION IS OUT OF DATE, DO NOT USE THE DEVICE UNTIL IT HAS BEEN PROPERLY CALIBRATED. FAILURE TO DO SO COULD RESULT IN DEATH OR INJURY.

  • Page 18: Powering Up The Monitor

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR OPERATION 3.2. Powering Up the Monitor WARNING: DO NOT USE THE MONITOR IF IT DOES NOT OPERATE AS DESCRIBED HERE. Table 3-1: Monitor Power-Up Sequence Action LCD Display Results The monitor starts and runs through a self-test: •...

  • Page 19: Monitor Lcd Alerts & Alarms

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR OPERATION 3.3. Monitor LCD Alerts & Alarms Table 3-2: Monitor Alerts and Alarms Descriptions Reason Beeps Vibration 1 slow flash every 1 slow beep every 1 slow vibration Low Alarm second second every second High Alarm and 2 fast flashes 2 fast beeps every...
  • Page 20 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR OPERATION This page is intentionally left blank. 087-0047, Rev. G/December 2019...

  • Page 21: Maintenance

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR MAINTENANCE 4. MAINTENANCE 4.1. Bump Testing / O Calibration WARNING: OPERATING A MONITOR THAT HAS EXCEEDED ITS CALIBRATION DATE CAN CAUSE FALSE GAS READINGS. THESE READINGS MAY BE INVALID AND COULD LEAD TO DEATH OR INJURY. The monitor must be operated and maintained correctly.

  • Page 22: Clearing A Bump Test Interval Alarm Alert

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR MAINTENANCE Regulator Ensure Arrow Points Right Test Gas Cylinder Tygon Tubing Calibration Adapter Monitor Figure 4-1: Bump Test - Calibration Adapter Attached 5. Verify monitor responds to target gas and activates the visual, audible, and vibrating alarms. 6.

  • Page 23: Self-Test

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR MAINTENANCE 4.1.3. O CALIBRATION USING THE FRONT BUTTON WARNING: ONLY PERFORM CALIBRATION IN NORMAL AIR (20.9% OXYGEN) THAT IS FREE OF HAZARDOUS GASES. 1. Press and hold the front button for four (4) seconds. 2.
  • Page 24 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR MAINTENANCE Table 4-1: Self-Test Procedure LCD Display Steps If alarms have not been previously activated and the self-test was suc- cessful: • check mark is displayed, • monitor returns to the original screen, • one short audible beep sounds.

  • Page 25: Error Codes

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR MAINTENANCE CAUTION: If the battery self-test fails five (5) consecutive times the LCD goes blank. Remove from service. 4.3. Error Codes Table 4-2: Error Codes lists the monitor’s error codes. Table 4-2: Error Codes Error Code Fault Configuration memory...
  • Page 26 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR MAINTENANCE This page is intentionally left blank. 087-0047, Rev. G/December 2019...

  • Page 27: Specifications

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR SPECIFICATIONS A. SPECIFICATIONS Table A-1: Monitor Specifications Category Specifications Battery Life 2 years, assuming a maximum 4 minutes of alarm time per day Alarms Visual, vibrating, & audible (95 dB) Self-test on activation and every 20 hours. Tests Continuous, automatic battery tests.
  • Page 28 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR SPECIFICATIONS This page is intentionally left blank. 087-0047, Rev. G/December 2019...

  • Page 29: Gas Interferences

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR GAS INTERFERENCES B. GAS INTERFERENCES B.1. Gas Interferences The monitor may respond to other gasses or interference gasses. Table B-1: Gas Interferences provides some of the known gas interferences. NOTE: Table B-1: Gas Interferences details selected gas interferences.

  • Page 30: Gas Interferences

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR GAS INTERFERENCES This page is intentionally left blank. 087-0047, Rev. G/December 2019...

  • Page 31: Parts

    PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR PARTS C. PARTS C.1. Applicable Parts List Table C-1: Applicable Parts List details replacement parts and accessories for the monitor. Table C-1: Applicable Parts List Part Number Category Item Description Americas / APAC EMEA Carbon Monoxide (CO) 096-3459-01 2025938...
  • Page 32 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR PARTS This page is intentionally left blank. 087-0047, Rev. G/December 2019...

  • Page 33: Technical Support

    TECHNICAL SUPPORT D. TECHNICAL SUPPORT This Teledyne Gas Measurement Instruments product is designed to provide you with reliable trou- ble-free service. Contact your regional Technical Support if you have technical questions, need support, or if you need to return a product. Details can be found at: www.teledynegasandflamedetection.com...
  • Page 34 PROTÉGÉ ZM PORTABLE, ZERO-MAINTENANCE, SINGLE-GAS MONITOR TECHNICAL SUPPORT Teledyne Gas Measurement Instruments Ltd. Inchinnan Business Park Renfrew Scotland, UK PA4 9RG Phone: +44 (0) 141 812 3211 www.teledynegasandflamedetection.com 087-0047, Rev. G/December 2019...
