Installation Instructions for
*MES96*U Ultra Low NOx Gas Furnace
(Type FSP CATEGORY IV Direct
(Type FSP CATEGORY IV Direct
or Non Direct Vent Air Furnace)
(Type FSP CATÉGORIE IV Direct
ou four á air soufflé non direct)
These furnaces comply with requirements
embodied in the American National Standard/
National Standard of Canada ANSI Z21.47·C-
SA-2.3 Gas Fired Central Furnaces.
s a professional installer you have an obligation to know
A
the product better than the customer. This includes all safety
precautions and related items.
Prior to actual installation, thoroughly familiarize yourself
with this Instruction Manual. Pay special attention to all
safety warnings. Often during installation or repair it is
possible to place yourself in a position which is more
hazardous than when the unit is in operation.
Remember, it is your responsibility to install the product
safely and to know it well enough to be able to instruct a
customer in its safe use.
Safety is a matter of common sense...a matter of thinking
before acting. Most dealers have a list of specific good safety
practices...follow them.
The precautions listed in this Installation Manual are
intended as supplemental to existing practices. However,
if there is a direct conflict between existing practices and
the content of this manual, the precautions listed here take
precedence.
RECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION.
IOG-2013D
05/2020
Installer:
Affix all manuals
adjacent to the unit.
19001 Kermier Rd.
Waller, TX 77484
www.goodmanmfg.com • www.amana-hac.com
© 2014-2020 Goodman Manufacturing Company, L.P.
is a registered trademark of Maytag Corporation or its related companies
and is used under license. All rights reserved.
O
NLY PERSONNEL THAT HAVE BEEN TRAINED TO INSTALL
(
, "
")
REPAIR
HEREINAFTER
SERVICE
THE EQUIPMENT SPECIFIED IN THIS MANUAL
. T
SHOULD SERVICE THE EQUIPMENT
HE MANUFACTURER WILL NOT BE RESPONSIBLE
FOR ANY INJURY OR PROPERTY DAMAGE ARISING FROM IMPROPER SERVICE OR
. I
SERVICE PROCEDURES
F YOU SERVICE THIS UNIT
FOR ANY INJURY OR PROPERTY DAMAGE WHICH MAY RESULT
JURISDICTIONS THAT REQUIRE ONE OR MORE LICENSES TO SERVICE THE EQUIPMENT
,
SPECIFIED IN THIS MANUAL
ONLY LICENSED PERSONNEL SHOULD SERVICE THE
. I
EQUIPMENT
MPROPER INSTALLATION
THE EQUIPMENT SPECIFIED IN THIS MANUAL
SERVICE OR REPAIR THE EQUIPMENT SPECIFIED IN THIS MANUAL WITHOUT PROPER
TRAINING MAY RESULT IN PRODUCT DAMAGE
.
INJURY OR DEATH
PROP 65 WARNING
FOR CALIFORNIA CONSUMERS
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
TABLE OF CONTENTS
Safety Considerations .............................................2
Shipping Inspection .................................................4
To The Installer ......................................................5
Product Application ..................................................5
Location Requirements & Considerations..............5
Clearances and Accessibility ...............................6
Existing Furnace Removal .....................................7
Thermostat Location ..............................................7
Combustion & Ventilation Air Requirements .........8
Installation Positions ...............................................8
Horizontal Applications & Considerations ............8
Furnace Suspension ...............................................8
Drain Trap and Lines ............................................10
Leveling ..................................................................10
Drain Pan ................................................................10
Freeze Protection ................................................10
Materials ................................................................10
Installation ............................................................ 11
Pipe Sizing ..............................................................12
,
,
ADJUST
SERVICE OR
,
YOU ASSUME RESPONSIBILITY
. I
,
N ADDITION
,
,
ADJUSTMENT
SERVICING OR REPAIR OF
,
,
OR ATTEMPTING TO INSTALL
ADJUST
,
,
PROPERTY DAMAGE
PERSONAL
-
0140M00517-A
IN
,
