- Page 1 User SMART WIFI MODEM manual For LCAC units...
-
Page 2: Table Of Contents
SMART WiFi modem for LCAC units WIFI MODULE FOR LCAC UNITS Contents PRECAUTIONS ........................................3 PART 1. SAFETY PRECAUTION ................................. 4 PART 2. APPLICATION ....................................5 PART 3. INSTALLATION AND CONFIGURATION ..........................6 Installation accessory ....................................6 Installation method ....................................6 Specification .......................................10 User registration ......................................10 Network Configuration ...................................11... -
Page 3: Precautions
SMART WiFi modem for LCAC units PRECAUTIONS WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury. -
Page 4: Part 1. Safety Precaution
SMART WiFi modem for LCAC units PART 1. SAFETY PRECAUTION Read the safety precautions carefully before installing the unit. Stated below are important safety issues that must be obeyed. Applicable system: IOS, Android. Suggest: IOS 10.3, Android 6.0 NOTE • APP can not support the lastest software version of Android and IOS system. •... -
Page 5: Part 2. Application
SMART WiFi modem for LCAC units PART 2. APPLICATION Download and install application: • Android Phone users: scan QR Code A or go to google play, search ‚Nethome Plus’ app and download it. • Iphone Users: scan QR Code B or go to App Store, search ‚Nethome Plus’ app and download it. QR Code A QR Code B CAUTION... -
Page 6: Part 3. Installation And Configuration
SMART WiFi modem for LCAC units PART 3. INSTALLATION AND CONFIGURATION 1. INSTALLATION ACCESSORY 1.1. Select the installation location Don‘t install at the place which is covered with heavy oil, vapor or sulfureted gas, otherwise, this product would be deformed that would lead to system malfunction. 1.2. - Page 7 SMART WiFi modem for LCAC units PART 3. INSTALLATION AND CONFIGURATION 2.2. Wiring principle sketch: Applicable to WF-60A1 only Applicable to WF-60A1 only black black yellow yellow brown brown 4-Core Shield Cable, the length is decided Wifi control box by installation Fig.
- Page 8 SMART WiFi modem for LCAC units PART 3. INSTALLATION AND CONFIGURATION 2.5. Fasten the back plate of the smart port • For exposed mounting, fasten the back plate on the wall with the 3 screws (M4×20) and plugs. (Fig.2.5) Back plate Screws (M4×20) Fig.
- Page 9 SMART WiFi modem for LCAC units PART 3. INSTALLATION AND CONFIGURATION Fig. 2.9 CAUTION Avoid the water enter into the smart port, use trap and putty to seal the connectors of wires during wiring installation. (Fig. 2.9) When under installation, reserve certain length of the connecting wire for convenient to take down the smart port while during maintenance.
-
Page 10: Specification
SMART WiFi modem for LCAC units PART 3. INSTALLATION AND CONFIGURATION NOTE Connection for wired control function by KJR-120C/TF-E KJR-120G2/TFBG-E. 3. SPECIFICATION Model WF-60A1 Standard IEEE802.11b/g/n Antenna Type External omnidirectional antenna Frequency WiFi:2.4G Maximum Transmitted Power 15dBm Max Operation Temperature 0OC~45OC/32OF~113OF. -
Page 11: Network Configuration
SMART WiFi modem for LCAC units PART 3. INSTALLATION AND CONFIGURATION 5. NETWORK CONFIGURATION CAUTION • It is necessary to forget any other around network and make sure the Android or IOS device just connect to the WIFI network you want to configure. •... -
Page 12: Using Ios Device To Do Network Configuration
SMART WiFi modem for LCAC units PART 3. INSTALLATION AND CONFIGURATION Jan Kowalski Username Mirai Add Device 7. Select your own WiFi network, for example 9. Configuration Success, you “My Home” (the picture is only for reference). can see the device on the list. 8. - Page 13 SMART WiFi modem for LCAC units PART 3. INSTALLATION AND CONFIGURATION 8. Click settings to enter the 9. Choose net_ac_XXXX. 10. Type defult password: 12345678 setting page, select WLAN/WIFI. and click “Join “. Jan Kowalski Username Mirai Add Device 11. Return to APP and click Next. 12.
-
Page 14: Part4. App Function And Using
Please ensure both your mobile device and air conditioner are connected to the Internet before using app to control the air conditioner via internet, please follow the next steps: Jan Kowalski Username jankowalski@rotenso.com Mirai Tenji 1. Type your own account and 2. - Page 15 SMART WiFi modem for LCAC units PART4. APP FUNCTION AND USING 2.1. TIMER ON/ TIMER OFF Weekly, user can make an appointment to turn on or off AC on specific time. User also can choose circulation to keep the AC under schedule control every week. 2.2.
- Page 16 SMART WiFi modem for LCAC units PART4. APP FUNCTION AND USING 2.4. CHECK User can simply check the AC running status with this function. When finishing this procedure, it can display the normal items, abnormal items, and detail information. CAUTION •...
- Page 17 SMART WiFi modem for LCAC units NOTES ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................User manual...
- Page 18 SMART WiFi modem for LCAC units NOTES ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................User manual...
- Page 19 SMART WiFi modem for LCAC units NOTES ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................User manual...
- Page 20 Pieczęć Instalatora...
