FCI FireVac 7200 Series Installation/Operating Addendum

Emergency voice/alarm fire alarm control
Hide thumbs
Table of Contents

Advertisement

Quick Links

Copyright 1998
All Rights Reserved
Published in the U.S.A.
301 2nd Ave. Waltham, MA 02451-1133 USA TEL: (781) 487-0088 FAX: (781) 370-4132
Technical Manuals Online! - http://www.tech-man.com
®
FireVac
7200 SERIES
EMERGENCY VOICE/ALARM
FIRE ALARM CONTROL
INSTALLATION/OPERATING
ADDENDUM
Part Number: 9000-0405
Version: 1.3

Advertisement

Table of Contents
loading

Summary of Contents for FCI FireVac 7200 Series

  • Page 1 ® FireVac 7200 SERIES EMERGENCY VOICE/ALARM FIRE ALARM CONTROL INSTALLATION/OPERATING ADDENDUM Copyright 1998 Part Number: 9000-0405 All Rights Reserved Version: 1.3 Published in the U.S.A. 301 2nd Ave. Waltham, MA 02451-1133 USA TEL: (781) 487-0088 FAX: (781) 370-4132 Technical Manuals Online! - http://www.tech-man.com...
  • Page 2 Technical Manuals Online! - http://www.tech-man.com...

  • Page 3: Table Of Contents

    1.9 Basic System Amplifier ......................12 1.10 Peripheral Devices.........................12 1.10.1 Addressable Output Modules...................12 1.10.2 Remote Amplifiers......................12 1.10.3 Power Supply Module for Amplifiers (FCI-PSM) ..............12 1.10.4 Addressable Amplifier Interface Module................13 1.10.5 Remote Command Center ....................13 A. Push-to-Talk Driver Module (PTT-D) ..................13 B. Push-to-Talk Receiver Module (PTT-R)................13 1.11 Amplifier Driver Card (ADC)....................13...
  • Page 4 A. Single Channel Distributed Amplification ................36 B. Dual Channel Distributed Amplification................36 C. AAI Addressing Information ....................36 2.5.2 Power Supply Module & Transformer (FCI-PSM) ...............40 2.6 Remote Command Center.......................42 2.6.1 Push-to-Talk Driver Module (PTT-D) ..................43 2.6.2 Push-to-Talk Receiver Module (PTT-R) ................45 A.

  • Page 5: Important Information/Foreword

    This equipment is Listed by various listing agencies for use in fire alarm systems. Use only components which are compatible with the FCI system. The installation MUST be in accordance with the instructions in this manual. THEREFORE: •...
  • Page 6 We do not recommend the use of overhead or outside aerial wiring due to the increased susceptibility to nearby lightning strikes. Consult with the FCI Technical Support Department if any problems are anticipated or encountered.
  • Page 7 FCI reserves the right to change hardware and/or software design, which may subsequently affect the contents of this manual. FCI assumes no responsibility for any errors that may appear in this manual. Neither this manual nor any part of it may be reproduced without the advance written permission of Fire Control Instruments, Inc.
  • Page 8 FOREWORD The information in this manual is organized as follows: ® Chapter 1: Overview: Provides an overview of the FireVac 7200 system audio specific components and related NFPA Standards. ® Chapter 2: Installation/Terminal Descriptions: Furnishes descriptions of each major FireVac 7200 System component requiring installation and typical interequipment drawings.
  • Page 9 SECTION ONE OVERVIEW 9000-0405 7 of 61 Technical Manuals Online! - http://www.tech-man.com...
  • Page 10 8 of 61 9000-0405 Technical Manuals Online! - http://www.tech-man.com...

  • Page 11: Section One: Overview

    For a description of how to create general alarm lists, input-to-output relationships and how to store these instructions in non-volatile mem- ory, refer to FCI manual P/N 9000-0360, Field Configuration Program (FCP). 1.2 Configurations ®...

  • Page 12: Fire Alarm System With Manually Controllable Process Monitoring

    SIGNAL ALARM SILENCE SUPERVISORY PROGRAM 1 MENU RESET/ SILENCE ACKNOWLEDGE PREVIOUS NEXT GROUND SYSTEM LAMPTEST EVENT EVENT TROUBLE DEGRADE FAULT PROGRAM 2 < < < < < < < < < < < < < < < < < < <...

  • Page 13: System Backplane

    1.5 System Backplane The System Backplane accepts individual modules. The modules plug into connectors on the backplane, which holds seven (7) modules. It also furnishes connections for the telephone handset and microphone, if re- quired. There are two types of backplanes, depending on the type of communication service. The first backplane has six (6) module connectors and one (1) TCU connector if the FireVac7200 System is providing two-way tele- phone service.

  • Page 14: Circuit Switch Input Module-Phone Circuit (Sim-P)

    Addressable Amplifier Input module (AAI). 1.10.3 Power Supply Module for Amplifiers (FCI-PSM) Each distributed and dual channel amplifier requires a power supply (FCI-PSM). The integral battery charger can maintain batteries up to 17-AH capacity, and the remote amplifier cabinet can house two 17-AH batteries.

  • Page 15: Addressable Amplifier Interface Module

    1.11 Amplifier Driver Card (ADC) The Amplifier Driver Card (ADC) replaces the FCI-AAM-25 Amplifier Module in systems requiring higher power audio amplifiers. It provides the interface with the Bulk Amplifier Unit (BAU). 1.12 Bulk Amplifier Unit (BAU) The Bulk Amplifier Unit (BAU) controls the operation of 120 and 250 watt audio amplifiers in systems using large, rack mounted amplifiers.
  • Page 16 14 of 61 9000-0405 Technical Manuals Online! - http://www.tech-man.com...
  • Page 17 SECTION TWO INSTALLATION/TERMINAL DESCRIPTIONS 9000-0405 15 of 61 Technical Manuals Online! - http://www.tech-man.com...
  • Page 18 < < < < < < < < < < < < < < DISCONNECT ALARM TROUBLE Audio Evacuation Unit (AEU) 16 of 61 9000-0405 Technical Manuals Online! - http://www.tech-man.com...

  • Page 19: Section Two: Installation/Terminal Descriptions

    SECTION TWO: INSTALLATION/TERMINAL DESCRIPTIONS 2.1 Audio Evacuation Unit (AEU) The Audio Evacuation Unit (AEU) provides one (1) Class A, Style 6/7 or Class B, Style 4 signaling line circuit (SLC). The signaling line circuit can accommodate 20 CCU/SIM (Switch Input Modules) with 5 points each and 99 addressable modules (AOM-2, AAI, PTT-R), for a maximum of 199 points per AEU.

  • Page 20: Audio Signaling Line Circuit Wiring

    2.1.2 Audio Signaling Line Circuit Wiring A. Class A Wiring Instructions (similar to NFPA Style 6) • Connect an electronic EOL device (consisting of an AMM-2 module, Address “99") (red and black wires) to the AEU as shown in Figure 2-1. (Yellow and violet wires are not used.) •...

  • Page 21: Class A, Style 7 Wiring Instructions

    B. Class A, Wiring Instructions (alternate wiring methods using isolators, NFPA 72 Style 7) Style 7 operation can be accomplished by isolating each addressable output device. The portion of the SLC to be protected must also have a Fault Isolator Module (M-500X) at each end as shown in Figure 2-2. NFPA 72 Style 7 wiring can only be accomplished by installing two M500X Fault Isolators close-nippled to the single device being protected.

  • Page 22: Backplane

    2.2 Backplane Two Backplanes are available. • The Main Backplane - has six (6) CCU/SIM connectors and one (1) TCU connector. • The Expansion Backplane - has seven (7) CCU/SIM connectors. The backplane is mounted inside the card cage and is the connection point for all of the plug-in SIMs, CCUs and TCUs.
  • Page 23 TB4-1 Amplifier Pwr. Positive, (+) power limited. Connects to FCI-MB TB3. TB4-2 24 VDC (nom.) Negative, ( - ) power limited. Connects to FCI-MB TB3. TB4-3, -4 Not used. TB4-5 Amp. 2 Activation Dual Channel Ampl. Output, negative ( - ), internal, power limited, connects to FCI-MB TB5-4.
  • Page 24 AOM-2s USED AS TELEPHONE-SYSTEM CALL-IN / CONNECTION COMPONENTS OPTIONAL CLASS-A WIRING SHOWN DOTTED. 24K, 0.5W (P/N 4700-0505) CLASS-B ONLY TO AEU FIELD MODULES AUDIO-SYSTEM BACK PLANE JUMPER TERMINALS 9 & 14 IF MICROPHONE AND NO TCU 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 1 2 3 4 TB2 TERM.
  • Page 25 POWER POWER POWER NOTE: THE SECONDARY-CHANNEL AMPLIFIER ASSEMBLY REQUIRES AN FCI-PSM POWER SUPPLY AND AN FVXFMR TRANSFORMER. REFER TO SECTION 2.5.2. MICROPHONE CABLE EXCEPTION: DUAL-CHANNEL SYSTEMS USING THE AMPLIFIER DRIVER CARD (ADC) AND BULK AMPLIFICATION UNIT (BAU) DO NOT REQUIRE A SEPARATE POWER SUPPLY FOR THE SECONDARY CHANNEL.

  • Page 26: Card Cage Modules

    2.3 Card Cage Modules The modules that can be mounted in the card cage are as follows: Module Reference CCU-S (Command Control Unit-Single Channel) Figure 2-10 CCU-D (Command Control Unit-Dual Channel) Figure 2-11 SIM-SS (Switch Input Module-Speaker, Single Channel) Figure 2-12a SIM-SD (Switch Input Module-Speaker, Dual Channel) Figure 2-12b...
  • Page 27 Table 2-3 Switch Input Module Addresses Rotary Switch Position (Tens) Two Position Jumper (Ones) SIM Addresses 00 through 04 Down SIM Addresses 05 through 09 SIM Addresses 10 through 14 Down SIM Addresses 15 through 19 SIM Addresses 20 through 24 Down SIM Addresses 25 through 29 SIM Addresses 30 through 34...
  • Page 28 ALL-CALL SWITCH MOVE TO "ALARM" POSITION TO ACTIVATE ALL SPEAKER CIRCUITS LED ILLUMINATES TO CONFIRM ACTIVATION VOICE/ALARM COMMUNICATIONS MOVE TO "NORMAL" POSITION TO DEACTIVATE ALL SPEAKER CIRCUITS ACTIVATED BY MOVE TO "ALARM" POSITION. ALARM LED EXTINGUISHES TO CONFIRM DEACTIVATION CALL NORMAL MANUAL-SELECT SWITCH MOVE TO "ON"...
  • Page 29 ALL-CALL SWITCH VOICE/ALARM MOVE TO "CHANNEL 1" POSITION TO ACTIVATE COMMUNICATIONS ALL SPEAKER CIRCUITS AND BROADCAST ALARM TONE LED ILLUMINATES TO CONFIRM ACTIVATION (CHANNEL 1) ALARM NORM MOVE TO "CHANNEL 2" POSITION TO ACTIVATE CALL ALL SPEAKER CIRCUITS AND BROADCAST AUXILIARY TONE. (CHANNEL 2) ALERT LED ILLUMINATES TO CONFIRM ACTIVATION...
  • Page 30 SPEAKER-SELECT SWITCH SPEAKER MOVE TO "ON" POSITION TO ACTIVATE SELECT SPEAKER-SELECT SWITCH SPEAKER ASSOCIATED SPEAKER CIRCUIT SELECT MOVE TO "CHANNEL 1" POSITION TO ACTIVATE ASSOCIATED LED ILLUMINATES TO CONFIRM ACTIVATION SPEAKER CIRCUIT AND BROADCAST ALARM TONE CHANNEL 1 LED ILLUMINATES TO CONFIRM ACTIVATION MOVE TO "AUTO"...
  • Page 31 COMMAND-PHONE-ACTIVE LED ILLUMINATES TO CONFIRM OFF-HOOK CONDITION OF COMMAND-CENTER HANDSET COMMAND PHONE ACTIVE PHONE-PATCH SWITCH MOVE TO "ON" POSITION TO PERMIT LIVE VOICE PHONE INSTRUCTIONS FROM DESIGNATED REMOTE TELEPHONE. PATCH LED ILLUMINATES TO CONFIRM ACTIVATION FOR REMOTE-TELEPHONE INSTRUCTIONS Fig. 2-12e Telephone Control Unit (TCU, TCU-R) Fig.

  • Page 32: Basic System Amplifier

    7200. This module is “DIP" switch programmed and can house 1 or 2 amplifiers, each capable of supplying 25 Watts. These amplifiers (FCI-AAM-25) are activated either by hardwired input or, in the case of a distributed amplification system, via the AAI unit. Recorded messages are held in EEPROM memory on the FCI-MB.
  • Page 33 DO NOT INSTALL FOR REMOTE AMPLIFIER WITH FCI-PSM POWER SUPPLY. MICROPHONE CONNECTOR Figure 2-13 Mother Board (FCI-MB) CAUTION: Disconnect all sources of power before servicing, removing, or inserting any circuit boards. Control unit and associated equipment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while the unit is energized.
  • Page 34 25-watt amplifier module can also be mounted on the FCI-MB for an additional 25 Watt output. Primary amplifier operation is determined by the settings of DIP Switches S1 and S5 on the FCI-MB. DIP Switch S1 selects the tone that the amplifier broadcasts, determines whether the tone is broadcast before and after a recorded message, and sets the number of tone and/or message repetitions.

  • Page 35: Audio Amplifier Module, 25-Watt (Fci-Aam-25)

    The Audio Amplifier Module provides 25 watts at 25 VRMS for powering speakers, AOMs and AAIs that are mounted in distributed amplifiers. It attaches to connector P4 on the FCI-MB. See Figure 2-16. A second Audio Amplifier Module can be attached to Connector P3 and used to back up the primary 25-watt amplifier supply or for an additional 25 watts of power from the FCI-MB.
  • Page 36 Shields must be terminated on each FCI-AAM-25 at TB1-1 or TB1-2. All amplifier output power is inherently power limited.
  • Page 37 AT ALL ELECTRICAL CONNECTION BOXES AND LEAVE THE CONNECTION FLOATING. DO NOT CONNECT SHIELDS TO EARTH GROUND. UNSHIELDED WIRE CAN BE USED IF FCI-AAM-25 CIRCUIT IS NOT RUN IN THE SAME CONDUIT OR RACEWAY AS EITHER THE ALU OR AEU SLCs.

  • Page 38: Distributed Amplification

    2.5.1 Addressable Amplifier Interface (AAI) A. Single-Channel Distributed Amplification In a Single-Channel application, the main amplifier (FCI-MB & FCI-AAM- 25) is used to create an “audio riser”. Remote Distributed Amplifiers are installed along this audio riser supplying audio power to AOM-2’s distributed throughout the area .
  • Page 39 Class A, Style 6 return (+). TB2-1 Amplifier Positive (+), power limited, to FCI-MB TB2-3 TB2-2 Activation Negative ( - ), power limited, to FCI-MB TB2-4. TB2-3 Amplifier Positive (+), power limited, to FCI-MB TB1-1 TB2-4 Supervision Negative ( - ), power limited, to FCI-MB TB1-3.
  • Page 40 WIRING FOR CLASS A, STYLE Z SHOWN DOTTED. 4.7K, 0.5W CLASS B, STYLE Y 1 2 3 1 2 3 4 1 2 3 4 1 2 3 4 5 6 7 8 9 101112 AC LOSS RELAY MASTER AUX. NOTES: CMD1 IN CMD2 IN...
  • Page 41 NOTE: USE TWISTED, UNSHIELDED WIRE. (MAX. 40 OHMS, 0.5 MICROFARADS) ASSIGN EACH AAI MODULE A UNIQUE ADDRESS 1 2 3 4 5 6 7 8 9 101112 1 2 3 1 2 3 4 5 6 1 2 3 4 1 2 3 4 5 6 1 2 3 4 1 2 3 4...

  • Page 42: Power Supply Module & Transformer (Fci-Psm)

    17-AH capacity. The remote-amplifier cabinet can house two 17-AH batteries. Primary AC power is monitored by the FCI-PSM. The AC loss relay contacts change state and the “AC ON” LED extinguishes upon loss of AC power or brown-out. Switch S1 is used to select immediate or 6 hour delay of AC loss relay transfer.
  • Page 43 Table 2-7 Power Supply Module (FCI-PSM) Designation Description Comments FIELD WIRING CONNECTIONS TB1-1 Not used. TB1-2 AC Hot 120/240 VAC connection , Non-Power Limited. TB1-3 AC Neutral 120 VAC Neutral/240 VAC hot connection, Non-Power limited TB1-4 Earth Ground 120 VAC Earth ground connection/240 VAC neutral TB1-5 Not used.

  • Page 44: Remote Command Center

    2.6 Remote Command Center ® The FireVac 7200 System can accommodate up to five (5) Remote Command Centers, which communicate ® with the main command center via the FCINET The AEUs and manual controls at the remote Command Center(s) are referred to as “shadow” AEUs. The system can support a maximum of five (5) remote Command Centers.

  • Page 45: Push-To-Talk Driver Module (Ptt-D)

    2.6.1 Push-to-Talk Driver Module (PTT-D) The PTT Driver Module (PTT-D) conditions and amplifies instructions generated at a remote Command Center for transmission to the Command Center. A PTT-D is needed only when a microphone is installed in a Remote Command Center. The PTT-D is mounted in the Remote Command Center enclosure below the card cage.
  • Page 46 REMOTE COMMAND CENTER BACK PLANE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 1 2 3 4 1 2 3 4 5 6 7 8 PTT DRIVER BOARD IN REMOTE COMMAND CENTER CABLE CONNECTION...

  • Page 47: Push-To-Talk Receiver Module (Ptt-R)

    Command Center. A PTT-R is needed only when a microphone is installed in a remote Command Center. The PTT-R is mounted in the main Command Center on the FCI-MB. One (1) PTT-R is required per system with a maximum of five (5) PTT-Ds allowed.
  • Page 48 SEE FIGURE 2-25 FOR PPT-DRIVER-BOARD CONNECTIONS TO BACK PLANE IN REMOTE COMMAND CENTER END-OF-LINE RESISTOR 24K, 0.5W 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 P/N 4700-0505 PTT DRIVER MODULE (IN REMOTE COMMAND CENTER)

  • Page 49: Fire Alarm System With General Voice Evacuation

    2.7 Fire Alarm System with General Alarm Voice Evacuation Figure 2-28 shows the general arrangement of a system that primarily uses horns and strobes for alarm notification. The building has one or more areas of assembly that require voice signaling with microphone override.
  • Page 50 1 2 3 4 5 6 1 2 3 1 2 3 TROUBLE RELAY REMOTE MIC RECORD BYPASS REG. MAIN IN. POWER POWER 1 2 3 4 "ON" "ON" "OFF" "OFF" "ON" "OFF" "OFF" "OFF" Figure 2-28 General Alarm Voice Evacuation System...
  • Page 51 PHONE JACK REQUIRED WIRING (ALL WIRING RUN IN SAME CONDUIT OR RACEWAY) TWISTED, SHIELDED PAIR WARDEN (2-WAY TELEPHONE SYSTEM) STATION TWISTED, UNSHIELDED PAIR PHONE JACK (AEU SIGNALING LINE CIRCUIT) COMMAND CENTER WARDEN AEU SLC STATION PHONE JACK KDU/KDU-L TELEPHONE SYSTEM CONNECTIONS CONNECT CONNECT...
  • Page 52 Figure 2-30 AEU SLC and Telephone Riser Connections...
  • Page 53 Figure 2-31 AOMs & Phone Jack/Warden Station Connections...
  • Page 54 AUT O AUT O AUT O AUT O AUT O AUT O AUT O CA LL MAN UA L AUT O AUT O AUT O AUT O AUT O AUT O AUT O SE LEC T AUT O AUT O AUT O AUT O AUT O...
  • Page 55 Figure 2-33 AEU SLC Connections...

  • Page 56: Notification Appliances

    Strobes used in the FireVac 7200 System installations operate on 24 VDC (nominal) and are powered from the notification appliance circuits of the SCU, DIU, or DSU units. Use only the Listed, FCI approved strobes indicated in FCI Addendum, P/N 9000-0427.

  • Page 57: Power Limited Field Wiring Circuits

    2.12 Power Limited Field Wiring Circuits U.L. Standard 864 requires that a minimum of 1/4 inch separation be maintained between power limited and non-power limited circuits. The control unit is designed so the separation between power limited and non- power limited circuits is maintained at the field wiring terminals. To comply with these requirements, however, the minimum 1/4 inch separation must also be maintained between the field wiring conductors of power limited and non-power limited circuits.
  • Page 58 1 2 3 4 FCI-PSM-TXF AC LOSS MASTE RELAY AUX. CMD1 IN CMD OUT POWER TRANSFORMER 1 2 3 4 AUDIO MOTHER BOARD BATTERY (FCI MB) GRND BATT AC ON FAULT TRBL REG. MAIN IN. TRANSFORMER/PWR SUPPLY POWER POWER EXT. AUDIO SPKR...

  • Page 59: Section Three: Power Up/Test Procedure

    SECTION THREE POWER UP/TEST PROCEDURE 9000-0405 57 of 61 Technical Manuals Online! - http://www.tech-man.com...
  • Page 60 58 of 61 9000-0405 Technical Manuals Online! - http://www.tech-man.com...

  • Page 61: General

    A complete system test of all system devices and functions should be performed on a regular basis per NFPA 72, Inspection, Testing and Maintenance, and/or the local codes/local authority having jurisdiction. • FCI recommends that this test be witnessed by the building owner/operator and the local authority having jurisdiction/fire services. 3.5 Dual Mode Walk Test Procedure 3.5.1 General...

  • Page 62: Walk Test Activation (Kdu/Kdu-L)

    3.5.2 Walk Test activation (KDU/KDU-L) 1. Press the MENU switch. 2. Enter the Level 2 (or higher) password on the numeric keypad. 3. Press the NEXT EVENT switch to “Enter” the password (Notice the word “Enter” appears above this switch on the display).

  • Page 63: Fire Drill Procedure

    3.6 Fire Drill Procedure 3.6.1 General The Fire Drill Program is available in two modes: • The Drill mode energizes all notification appliances via the system power supply. • The Drill Test mode energizes all notification appliances directly from the standby batteries. 3.6.2 Fire Drill Activation (KDU) 1.
  • Page 64 Technical Manuals Online! - http://www.tech-man.com...
  • Page 65 Technical Manuals Online! - http://www.tech-man.com...
  • Page 66 301 2nd Ave. Waltham, MA 02451-1133 USA TEL: (781) 487-0088 FAX: (781) 370-4132 Technical Manuals Online! - http://www.tech-man.com...
