E lec t r if i e d L o c k s, Re l ay s a n d Tim ers
CX-12 PLUS
Door Interface Relay
Installation INSTRUCTIONS
1. GENERAL DESCRIPTION
Camden CX-12 PLUS Door Interface Relay provides all the functionality of the CX-12 and the CX-22 combined into 1 package.
In addition, a new Ratchet Relay mode is provided, making the CX-12 PLUS one of Camden's most versatile door control
relays available.
Used as a make/break relay (or Switching Network), it eliminates the binding of locked automatic doors, by delaying the door
operator until the strike or maglock de-activates first.
2. SPECIFICATIONS
Input Voltage
Current Draw
Inputs
Electrical Life
Time Delay
3. OPERATION
There are 8 modes of operation, selectable by DIP switches:
DIP SWITCH
SW1
SW2
OFF
OFF
ON
OFF
ON
ON
OFF
ON
OFF
OFF
ON
OFF
OFF
ON
ON
ON
Page 1 of 15
12/24V AC/DC
20 mA Idle | 60 mA Operating
2 Wet & 2 Dry, N.O.
(3-30V AC/DC, Optically isolated,
non-polarity sensitive)
100,000 @ Rated Capacity
D.0.R #1: 1-30 Seconds
D.0.0 #2: 1-30 Seconds
D.0.R #3: 1-30 Seconds
SW3
ON
1a & 1b
ON
ON
ON
OFF
OFF
OFF
OFF
Contact Rating
Response Time
Outputs
Modes
Dimension
MODE
Momentary & Momentary Apartment
2
3
4
5
Bi-Directional Sequencer - Momentary
6
Bi-Directional Sequencer - Maintained
7
Restroom Control - Normally Unlocked
8
3 Amps @ 30 VDC
0.3 Seconds
2 x Form C (SPDT)
8
3-1/4" W x 2-5/16" H x 11/16" D
(83mm x 59mm x 18mm)
DESCRIPTION
Access Control (Maintained)
Smoke Evac.
Latching / Ratchet Mode
Restroom Control - Normally Locked
Advertisement
Table of Contents
Related Manuals for CAMDEN CX-12 PLUS
Summary of Contents for CAMDEN CX-12 PLUS
- Page 1 1. GENERAL DESCRIPTION Camden CX-12 PLUS Door Interface Relay provides all the functionality of the CX-12 and the CX-22 combined into 1 package. In addition, a new Ratchet Relay mode is provided, making the CX-12 PLUS one of Camden's most versatile door control relays available.
- Page 2 The inputs to the CX-12 PLUS may be either dry or wet (powered), meaning that 3-terminal radio receivers may be connected directly We offer a low-cost board-only regulated power supply - CX-PS13 V3, which can be powered from a small 24VAC to the CX-12 PLUS without fear of malfunction.
- Page 3 RELAY2 will activate and stay latched. A second open time. In this case adjust the CX-12 PLUS to send just a activation of WET/DRY2 will release both relays.
- Page 4 “Lock” button. 4. Strongly recommend to the owner that the complete entry be The CX-12 PLUS will energize the lock, and remove the outside inspected twice a year as part of the service agreement.
- Page 11 Radio...
