- Page 1 ELECTRIC HOIST MODEL NO: CH2500B, CH4000B PART NO: 7630386, 7630391 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS LS0220 - ISS 6...
-
Page 2: Introduction
INTRODUCTION Thank you for selecting this Clarke Electric Hoist. The electric hoist is designed for lifting and lowering loads suspended on hooks over predetermined distances. Read this manual before use. The warnings and cautions in this manual help you operate the Electric Hoist safely. -
Page 3: Table Of Contents
CONTENTS Introduction ................2 Important ..................2 Guarantee .................. 2 Contents..................3 Environmental Protection............3 General safety rules ..............4 Electrical Connections .............. 5 Unpacking .................. 6 Installation ................... 6 Operation ................... 7 Maintenance................8 Troubleshooting................9 Parts and servicing..............9 Specifications ................ -
Page 4: General Safety Rules
11. Make sure that the load is balanced, stable and that personnel stay clear of the raised load. 12. Speak to the Clarke service department for any spare parts relating to the hoist. 13. Make sure that the switches are in good condition. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS FULLY BEFORE CONNECTING THE HOIST TO THE MAINS SUPPLY. This hoist is provided with a standard 13 amp, 230 volt (50Hz), BS 1363 plug, for connection to a standard, domestic electrical supply. Should the plug need changing, make sure that a plug of identical specification is used. -
Page 6: Unpacking
• 2 x Bracket • 1 x bag of fixings • 1 x Instruction manual If a part is damaged, speak to your Clarke supplier immediately. INSTALLATION To attach the hoist to box section, use the brackets supplied. The box section must be able to hold the maximum load plus the weight of the hoist and brackets. -
Page 7: Operation
OPERATION HOIST CONTROL LIFT/LOWER BUTTON EMERGENCY STOP 1. Push the Lift button to lift the load. LIFT 2. Push the Lower button to lower the load. LOWER 3. To stop the hoist release the button. NOTE: The load will not stop immediately when you release the lower button. -
Page 8: Maintenance
HOIST CAPACITY In the basic setup (shown on the right) the lifting capacity is 125 kg, (200 kg for the CH4000B) It is possible to increase the capacity to 250 kg (400 kg for the CH4000B). To do this: 1. Loop the cable around the pulley supplied. -
Page 9: Troubleshooting
Replace the cable. kinked unwound or in bad conditions. If this does not solve your problem, please speak to the Clarke service department. See below PARTS AND SERVICING For Parts & Servicing, please contact your nearest dealer, or CLARKE International, on one of the following numbers. -
Page 10: Specifications
SPECIFICATIONS CH2500 CH4000 Load Capacity (Single Cable) 125 kg 200 kg Lifting Speed (Single Cable) 10 m/min 10 m/min Lifting Height (Single Cable) 12 m 12 m Load Capacity (Double Cable) 250 kg 400 kg Lifting Speed (Double Cable) 5 m/min 5 m/min Lifting Height (Double Cable) Cable Length... -
Page 11: Exploded Diagram & Parts List
EXPLODED DIAGRAM & PARTS LIST... - Page 12 EXPLODED DIAGRAM & PARTS LIST Description Description Description Hexagon Bolt Gear Case Handle Switch -Up Spring Washer Spring Washer Rise & Fall Switch Flat Washer Flat Washer 3-Prong Plug Fixing Ring 2nd Gear Wheel Hook Locknut Support Frame Cushion Board Hook Washer Support Panel Front Cover...
-
Page 13: Declaration Of Conformity
DECLARATION OF CONFORMITY... -
Page 14: Notes
NOTES... -
Page 15: Notes
NOTES...
