X-Fusion Velvet R 2008 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Velvet R
owner's manual
www.x-fusion-shox.com

Advertisement

Table of Contents
loading

Summary of Contents for X-Fusion Velvet R 2008

  • Page 1 Velvet R owner's manual www.x-fusion-shox.com...

  • Page 2: Table Of Contents

    Velvet R explained....3 welcome to x-fusion ....4 important safety information .

  • Page 3: Velvet R Explained

    Velvet R explained... luminum teeReR ebound oRged luminum Rown RessuRe djust PPeR ubes Agnesium oweRs RessuRe PRing ystem...

  • Page 4: Welcome To X-Fusion

    Before riding, please read INITIAL SETUP (QUICKSTART) proper setup and use of your new X-Fusion fork. If you are unsure of the proper use or function of your new fork, please call your nearest X-Fusion Service Center for further information.
  • Page 5 If the bicycle ever tilts or falls from a bicycle carrier, do not ride it until it is examined by X-Fusion or an Authorized X-Fusion Service Center. A fork leg or dropout failure can cause loss of control and serious or fatal injuries.

  • Page 6: Suspension Terminology

    Suspension terminology Shock Sag The amount by which the shock compresses with the rider seated in the normal riding position. The recommended amount of sag is generally 20-30% of the total shock travel. Compression Damping The damping force generated by the shock as it is being compressed. Generally, compression damping is speed sensitive, meaning the faster the shock travels the higher the force of compression damping it produces.

  • Page 7: Initial Setup (Quickstart)

    Initial Setup (quickstart) Your VELVET R is simple to use and setup. X-Fusion recommends that you consult the AIR PRESSURE SETTINGS TABLE on the next page and fill the air chamber with the air pressure corresponding to your body weight, and set the REBOUND knob to 6 clicks IN from FULL OPEN.
  • Page 8 Remove the aircap from the top of the left fork leg. TIGHTEN REMOVE Attach an X-Fusion High Pressure Pump the Schrader Valve on the aircap. Pump the air chamber to the desired setting. If you need to bleed air from the air chamber, use the bleed button on the Pump.

  • Page 9: Setting Sag

    Setting Sag Sag is the compression of the fork caused by the rider’s weight. A proper sag setting is crucial for the performance of your fork. If sag is not properly set, your fork is not able to follow the contours of the trail. In the INITIAL SETUP (QUICKSTART) section, you ensured your VELVET R is pumped up to 70 psi.

  • Page 10: Setting Rebound

    Sag is determined by rider weight, and is adjusted by setting the pressure in the air chamber on the left leg of the VELVET R. Using an X-Fusion High Pressure Pump, you either add or remove air to obtain the correct pressure setting, and thus sag.

  • Page 11: Maintenance

    So, try to find a rebound setting that is in between. As stated in INITIAL SETUP (QUICKSTART), X-Fusion recommends that you set your rebound to 6 clicks IN from full OUT. Or put another way, turn your rebound knob fully counterclockwise until it stops; now turn it clockwise 6 clicks.

  • Page 12: Service

    Every 200 hours or 18 months warranty information The warranty period for all X-Fusion forks is 24 months starting from the original date of purchase and is valid for all countries of the European Community. A copy of the original purchase receipt must accompany each fork that is sent for repair under these warranty terms.
  • Page 13 All 50 hours: maintenance and cleaning of the fork if used in dry and dusty conditions. To maintain valid the general warranty conditions, it is also necessary for all products to be set up and used in accordance with the X-Fusion user manual and the Bicycle Manufacturer’s user manual.

  • Page 14: Warranty Q And A

    ‹ and reducers, seals, and suspension fluids. X-Fusion makes no other warranty of any kind, expressed or implied. All implied warranties of merchantability and fitness for a particular purpose which exceed the obligations and time limits stated in this warranty are hereby disclaimed by X-Fusion and excluded from this warranty.

  • Page 15: Disclaimer

    X-Fusion is not responsible for any damages to you or others arising from riding, transporting, or other use of your fork or bicycle. In the event that your fork breaks or malfunctions, X-Fusion shall have no liability or obligation beyond repair or replacement of your fork,...
  • Page 16 Campbell, CA 95008 USA Phone: 408-866-0188 Phone: 408-866-0188 Fax: 408-866-0100 Fax: 408-866-0100 Toll-free: 866-319-SHOX (7469) Toll-free: 866-319-SHOX (7469) E-mail: usinfo@x-fusion-shox.com E-mail: usinfo@x-fusion-shox.com Switzerland Italy 475 W. Sunnyoaks Avenue 475 W. Sunnyoaks Avenue Campbell, CA 95008 USA Campbell, CA 95008 USA...
