SHIFT4 HARBOURTOUCH ECHO Installation Quick Reference Manual

ECHO™ POS INSTALLATION QUICK REFERENCE GUIDE
STEP ONE
Connect the Harbortouch router to a power outlet using the supplied power cable.
Then connect the Harbortouch router to your business's modem using an Ethernet cable.
IMPORTANT: Do not connect the Harbortouch router to an existing router. The Harbortouch router must be connected
directly to the modem.
HARBORTOUCH ROUTER
STEP TWO
Connect the Echo station to the router using an Ethernet cable.
ECHO STATION ETHERNET PORT
STEP THREE
Connect the keyboard by plugging it into one of the USB ports on either the front or back of the Echo station.
USB PORTS ON FRONT OF ECHO STATION
STEP FOUR
Connect the receipt printer to the Echo station with the powered USB cable.
POWERED USB PORT ON BACK OF ECHO STATION
A SHIFT4 COMPANY
ETHERNET CABLE
HARBORTOUCH ROUTER
USB PORTS ON BACK OF ECHO STATION
RECEIPT PRINTER PORTS
ETHERNET CABLE
POWERED USB CABLE
HT2071_02062019
