!!STOP!!
Before proceeding make sure the upper door is the correct item for the vehicle you are installing it on.
DO NOT INSTALL THIS ITEM ON ANY VEHICLE OTHER THAN ONE LISTED ABOVE
The material may have contracted, depending on at what temperature it has been stored. It is highly recommended that you remove the
upper doors from the box; lay it out flat at a temperature above 72F and let it relax for at least 24 hours. As well the installation should be
done only in an environment where the air temp is above 72F.
To avoid improper installation of this item it is imperative that you read and follow these guidelines completely. Failure to install the upper
door skins correctly may result in a dangerous situation for the vehicle occupants as well as other motorists.
SIERRA OFFROAD TAKES NO RESPONSIBILITY FOR THE ACCURACY OR COMPLETENESS OF THESE
INSTALLATION GUIDELINES. THEY ARE PROVIDED ONLY FOR INFORMATION PURPOSES. IT IS
THE SOLE RESPONSIBILITY OF THE INSTALLER TO ENSURE THAT THE INSTALLTION HAS BEEN
PERFORMED CORRECTLY, THERE ARE NO LOOSE OR MISSING PARTS AND THE VEHICLE HAS BEEN
ROAD TESTED AFTER INSTALLATION OF THE REPLACEMENT TOP AND DEEMED SAFE TO OPERATE.
PARTS LIST
Fabric Sun Top
TOOLS REQUIRED
None
THESE UPPER DOORS ARE INTENDED TO BE FIT OVER THE FACTORY ORIGINAL HARDWARE AND FRAME. IF THE FRAME
IS DAMAGED OR MISSING PARTS DO NOT ATTEMPT THIS INSTALLATION BEFORE REPAIRS ARE MADE TO THE VEHICLE.
It is important to read the complete instruction guideline manual BEFORE beginning the installation of your new replacement upper doors.
This will familiarize you with all aspects of the installation and help to avoid mistakes. It will be helpful if you keep this guideline manual for
future reference.
Jeep Wrangler TJ SUN TOP
Installation Guidelines
For:
1997-2006 Jeep Wrangler TJ Sun Tops
PN:
10-40-TJS
Qty 1
FACTORY REPLACEMENT JEEP SOFT TOPS
SIERRA OFFROAD
Advertisement
Table of Contents
Related Manuals for SIERRA OFFROAD TJ Sun Top
Summary of Contents for SIERRA OFFROAD TJ Sun Top
- Page 1 SIERRA OFFROAD TAKES NO RESPONSIBILITY FOR THE ACCURACY OR COMPLETENESS OF THESE INSTALLATION GUIDELINES. THEY ARE PROVIDED ONLY FOR INFORMATION PURPOSES. IT IS...
- Page 2 1997-2006 Jeep Wrangler TJ SUN TOP Installation Wrangler must have the Windshield Channel Header to install the SunTop. Check Your Windshield Channel Position the Windshield Channel Header on top of the soft top latches and use an adjustable wrench to secure them onto the windshield.
- Page 3 1997-2006 Jeep Wrangler TJ SUN TOP Installation Unscrew the two round support pins to remove the door surrounds from vehicle. Remove Door Surrounds Position the Bikini Top over the roll bars and insert the front edge plastic retainer into the windshield channel.
- Page 4 1997-2006 Jeep Wrangler TJ SUN TOP Installation Stretch back the rear edge of the Sun Top over the roll bars, run the rear center strap behind the roll bar and forward to the windshield’s support bracket. Guide Rear Center Strap Run the rear center strap end through the buckle and pull to secure in position.
- Page 5 1997-2006 Jeep Wrangler TJ SUN TOP Installation Position the rear corners of the Sun Top over the roll bar, run the longer corner strap end from under the roll bar to the buckle to secure. Position over Roll Bar Position the rear center straps (with buckle...
- Page 6 1997-2006 Jeep Wrangler TJ SUN TOP Installation Wrap the side support flaps around the roll bars and attach the Velcro edges to secure. Wrap Side Support Straps Wrap and connect the two front corner Velcro straps around the roll bar to secure.
