Summary of Contents for HILLTOPPER SUMMIT

  • Page 1 I N S T A L L A T I O N G U I D E...

  • Page 2: Let's Get Started

    Hilltopper community of electric bike enthusiasts. The Summit is our most advanced kit so we have created a step-by-step guide to help you install your kit. The install should take around an hour depending on your mechanical skills and enthusiasm. You can also take your bike and kit to a local bike shop to have them install your kit.
  • Page 3 C. Align the disc brake rotor with the holes on the MOTOR. D. Attach the rotor to the MOTOR using the disc screws provided. NOTE: Your brake may need some adjusting after you have installed your SUMMIT kit to avoid rubbing. STEP 2: Slide the THIN WASHER over the axle on both side of the MOTOR.

  • Page 4: Drive Side

    FIG. 1 TORQUE ARM (NOT TO SCALE) AXLE THIN THICK WASHER WASHER WASHER WASHER DRIVE SIDE (CHAIN SIDE) LEFT RIGHT FORK FORK AXLE AXLE DISC BRAKE MOTOR ROTOR CABLE (IF BIKE HAS DISC BRAKES) MOTOR IMAGE ORIENTATION LOOKING FORWARD WHILE SEATED ON BIKE SADDLE FORKS POINTING TOWARDS THE GROUND “TAB”...

  • Page 5: Installing The Battery

    INSTALLING THE BATTERY: The BATTERY can be mounted to either your bike’s “water bottle mount” on the downtube of the frame. See FIG. B NOTE: On the frame is the easiest and generally considered ideal placement but if your bike does not have a place to mount on the frame then a front or rear bike rack will work.
  • Page 6 INSTALLING THE LCD SCREEN KEYPAD AND VARIABLE MOTOR THROTTLE We recommend putting the LCD SCREEN KEYPAD on the LEFT side of the handlebars and the VARIABLE MOTOR THROTTLE on the RIGHT. Placing them between the handlebar grip and the brake/shifter levers. NOTE: You may set up your placement differently depending on your preference and bike set up.

  • Page 7: Installing The Lights

    CONNECTING THE CABLES: THROTTLE / LCD SCREEN CONNECTOR The Summit 48V BATTERY has 5 cable connections. You will also be provided with five (5) cables and extension cables. PAS CONNECTOR These will be used to connect the VARIABLE SPEED THROTTLE, LCD SCREEN/KEYPAD, HUB MOTOR, PAS and FRONT AND REAR LIGHTS to the battery.
  • Page 8 USING YOUR SUMMIT Using your new kit is simple. Follow the steps below to get to know your new Summit! NOTE: You will need to charge your new Hilltopper battery before using it for the first time. A. Plug your charger into the wall socket and wait for the light to turn GREEN.
  • Page 9 Assumption of Risk, Release of Liability, Indemnity, and Hold Harmless Agreement By purchasing these Products, I understand and agree to the following: Bicycling and related activities are hazardous and injuries are common and ordinary occurrences during these activities. I agree to assume all risks of death or injury to any part of the user’s body while using the Products.
  • Page 10 sa le s@h i l l top p e r b i ke s .c om su p por t @h i l l top p er b i ke s .c om SALE S: 85 5. 743 .3 279 S U PP ORT : 20 6 .6 8 2.
