Page 1: Table Of Contents
Dino-Lite CONNECT WF-20 Instruction Manual Contents FCC Statement Instroduction System Requirement Package Contents Overview and Function Getting Started DinoConnect APP Overview Battery Information Specifications... -
Page 2: Fcc Statement
We, AnMo Electronics Corporation, of 5F-1, No. 76, Sec. 2, Tung-Da Rd., Hsinchu 300, Taiwan, declare under our sole responsibility the product, WF-20 to which this declaration relates, complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may... -
Page 3: Instroduction
Introduction The WF-20 is a Wi-Fi streamer, as well as a wireless router, to use combinedly with Dino-Lite Edge AF series for viewing and sharing observation without wire. With high quality image transmission and long battery life, the WF-20 is well suited for field applications. -
Page 4: Overview And Function
Overview and Function Interface release button Wi-Fi signal LED indicator Battery LED indicator On / Off power button Reset pinhole button Mini USB port (for charging purpose) Button usage and description: Buttons Description On / Off Press and hold for 1.5 seconds to turn on/off power button Reset Press and hold the pinhole button for 3 seconds... -
Page 5: Getting Started
Getting Started Charging the Battery Charge the WF-20 by connecting to a computer or a USB charger using the Mini USB charging cable. Assembling the Device The WF-20 needs to be used with Dino-Lite AF series. The assemble procedure is as described below. - Page 6 Powering on Press the power button for 1.5 seconds to power on. The startup process may take about half minute until the Dino-Lite’s LED lit up. To power off Press the power button again for 1.5 seconds. Setting the Network iOS/Android 1.
- Page 7 & android WF-20 Access Points devices Note: The WF-20 can be possibly connected up to 10 mobile devices at the same time, but it is recommended to keep less than 5 connections for retaining image fluency.
-
Page 8: Dinoconnect App Overview
DinoConnect on iOS Swipe the toolbar of DinoConnect on iPhone to display more tools. Function Description Battery indicator Battery level of the WF-20. Resolution setting To choose resolutions. LED switch To control Dino-Lite’s LED lighting. Exposure control To adjust exposure. Magnification To input magnification. - Page 9 To change text color and size. To delete measurement and text on the Trash bin image. To view captured images or recorded Gallery videos of Dino-Lite. Record button To start or stop video capture. Shutter button To capture an image. To change settings of connections, Settings MicroTouch, etc.
- Page 10 DinoConnect on Android Function Description LED switch To control Dino-Lite’s LED light. Refresh button To refresh preview image. Exposure control To adjust the exposure. To view captured images or recorded Gallery videos of Dino-Lite. Record button To start or stop video recording.
-
Page 11: Battery Information
The WF-20 was designed to have more than 2.5 hours battery life, but may vary with different Dino-Lite model and the way of using. Charging the WF-20 may take 3-4 hours by a USB charger or a power bank. The WF-20 can still be used while charging, but be noted that extra heat will be generated and may affect circuit performance under poor ventilation. -
Page 12: Specifications
Product name WF-20 Support protocol Wi-Fi IEEE802.11b / g / n Antenna 2.4GHz Wi-Fi FPCB antenna Frequency 2.412GHz~2.485GHz SSID (default) Dino-Lite WF-20 Battery 1600mAh Power consumption 2.5W Battery continuous 2.5 hours operation time (tested by using with AF4915) Operation temperature 10~45°C (50~113°F)
