Page 1: Table Of Contents
Dino-Lite CONNECT WF-20 Instruction Manual Contents FCC Statement Instroduction System Requirement Package Contents Overview and Function Getting Started DinoConnect APP Overview Battery Information Specification... -
Page 2: Fcc Statement
We, AnMo Electronics Corporation, of 5F-1, No. 76, Sec. 2, Tung-Da Rd., Hsinchu 300, Taiwan, decline under our sole responsibility the product, WF-20 to which this declaration relates, complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may... -
Page 3: Instroduction
Introduction The WF-20 is a piggyback design of Wi-Fi streamer, as well as a wireless router, to use with Dino-Lite Edge AF series for viewing and sharing observation in the fields. System Requirement Mobile device or computer with operating system: iOS 10.X or later... -
Page 4: Overview And Function
Overview and Function Interface release button Wi-Fi signal LED indicator Battery LED indicator On / off power button Reset pin-hole button Mini USB port (for charging purpose) Button usage and description: Buttons Description On / off Press and hold for 1.5 seconds to turn on/off power button Reset Press and hold the pinhole button for 3 seconds to... -
Page 5: Getting Started
The battery should be fully charged before first use. Assembling the Device To use with the WF-20, the USB adapter cap needs to be removed from AF series and replaced with WF-20. 1. Pressing the two interface release buttons at the same time to release the USB interface adapter cap. - Page 6 WF-20’s SSID and password in DinoConnect settings for distinguishing purpose. Note: The WF-20 can be possibly connected up to 10 mobile devices at the same time, but it is recommended to keep less than 5 connections for retaining image fluency.
- Page 7 Joining the WF-20 to another wireless network iOS & android WF-20 Access Points devices You may further setup WF-20 as a router to build connection between your mobile device and existing wireless network. Open DinoConnect settings Tap “Choose a network”. Choose a network, then enter password.
-
Page 8: Dinoconnect App Overview
DinoConnect APP Overview DinoConnect on iOS Function Description Battery indicator Battery level of the WF-20. Resolution setting To choose resolutions. LED switch To control Dino-Lite’s LED lighting. To adjust exposure. Exposure control Magnification To input magnification. (AMR models doesn’t require) - Page 9 Tap anywhere to complete the measurement. DinoConnect on Android Function Description LED switch To control Dino-Lite’s LED light. Refresh button To refresh preview image. Exposure control To adjust the exposure. To view captured images or recorded videos of Gallery Dino-Lite.
-
Page 10: Battery Information
The WF-20 was designed to have more than 2.5 hours battery life, but may vary with different Dino-Lite model and the way of using. Charging the WF-20 may take 3-4 hours by a USB charger or a power bank. The WF-20 can still be used while charging, but be noted that extra heat will be generated and may affect circuit performance under poor ventilation. -
Page 11: Specification
Product name WF-20 Support protocol Wi-Fi IEEE802.11b / g / n Antenna 2.4GHz Wi-Fi FPCB antenna Frequency 2.412GHz ~ 2.485GHz SSID Dino-Lite WF-20 Battery 3.7V / 1600mA Power consumption 2.5W Continuous operation time 2.5 hours (Li battery) Operation temperature 10~45°C (50~113°F) Dimensions 58mm x 36.5mm x 32mm... - Page 12 P/N:WF12101...
