Summary of Contents for Falcon Fusion
-
Page 3: Table Of Contents
2.1 Reporting Options ..............2.2 Interfaces ..................2.3 Programming ................2.4 Indicators & Controls ..............3. INSTALLATION ..............3.1 Falcon Fusion Wiring ..............................3.1.1 Power Supply ..................3.1.2 Antennas ..................3.1.3 Check AC ................ 3.1.4 Dry Contact Inputs ................ - Page 4 4. PROGRAMMING ..............4.1 Onboard Push-Button ..............4.2 PC-based programmer ..............APPENDIX A Serial Interface ..........APPENDIX B Programming Cable & Software ....
-
Page 5: Introduction
GSM. The Falcon Fusion has a universal Contact ID interface to alarm panels as well as a serial interface to some leading panels. It also has seven dry contact input triggers. -
Page 6: Features & Functions
Serial alarm interface to leading control panels Ÿ Over-the-air panel uploading and downloading on the Rhino Ÿ and Texecom Premier control panels through the serial interface 2.3 Programming Full programming and software updating via a computer serial Ÿ Falcon Fusion Installation and Operation Manual... -
Page 7: Indicators & Controls
Programming over-the-air via GPRS Ÿ 2.4 Indicators and Controls Status and error indication via a seven segment display Ÿ Serial port selection via the onboard push-button Ÿ Falcon Fusion Installation and Operation Manual... -
Page 8: Installation
3. INSTALLATION 3.1 Falcon Fusion Wiring Connections to the Falcon Fusion are shown below: - + T R CAC 12V GND 1 TIP RING SERIAL Falcon Fusion Installation and Operation Manual... -
Page 9: Power Supply
3.1.1 Power Supply The Falcon Fusion must be connected to a stable 12V DC (nominal 13.2V) power supply. If a battery is available in the alarm panel, it must preferably be powered directly from the battery. 3.1.2 Antennas The Falcon Fusion is supplied with two antennas. One for GSM connection (short antenna) and one for UHF connection (long antenna). -
Page 10: Check Ac
DO NOT connect this line to the mains. The CAC input will detect AC voltages between 10 and 24V. If the CAC line is not connected, the Falcon Fusion should not be programmed to send AC Failure or Restoral signals. -
Page 11: Serial Port
3.1.7 Relay Outputs Two dry-contact relay outputs are available on the Falcon Fusion. These outputs can be commanded to turn on and off via the GSM network. The outputs are rated at 24V AC or DC, up to a maximum current of 5A. -
Page 12: Falcon Fusion Installation
The performance of the Falcon Fusion depends on the quality of its connection to the GSM network. The Falcon Fusion will send alarms quicker and more reliably if it has a strong connection to the GSM service provider. When the Falcon Fusion has powered up, it will start connecting to the network, displaying its status as it initialises and connects (see section 3.5 –... -
Page 13: Changing The Default Sim Card
3.4 Changing the Default SIM Card (Applicable to dual SIM Falcon Fusions only) The Falcon Fusion has the option of changing the default SIM card to be used. The default SIM card should be changed to the one with the highest signal strength. -
Page 14: Selecting The Alarm Panel Serial Port Format
Wait until the Falcon Fusion has re-connected to the GSM Ÿ network on the new SIM card and displays the signal strength. If the Falcon Fusion displays an error message (E1 or E4), the Ÿ selected SIM card is not working and the other one should be selected The minimum signal strength required is 5. - Page 15 Risco LightSYS 2 Ÿ Refer to Appendix A To change the serial port format: Remove power from the Falcon Fusion Ÿ Hold down the push-button and re-apply power Ÿ Push the button to cycle through the panel serial port settings Ÿ...
- Page 16 DISPLAY SERIAL FORMAT Rhino Texecom Premier Paradox Pima Hunter Pro DSC Neo Series Sherlotronics DSC Power Series IDS805 FSK Key-bus Falcon Fusion Installation and Operation Manual...
-
Page 17: Indicators And Controls
DISPLAY SERIAL FORMAT Risco LightSYS 2 3.6 Indicators and Controls The Falcon Fusion has a seven segment display which indicates the current operating status. Falcon Fusion Status CHARACTER FLASHED STATUS DESCRIPTION communicator re-starting the GSM Restarting modem The communicator is... - Page 18 All alarms sent, disconnecting from the necting server from server Falcon Fusion Errors If the Falcon Fusion detects an error it will flash the error code on the seven segment display. CHARACTER FLASHED STATUS DESCRIPTION The communicator has not detected a...
- Page 19 Server The communicator cannot GPRS settings are correct. connect to the server to route The GSM network may the GPRS message to the be experiencing technical control room problems. Contact the manufacturer. Falcon Fusion Installation and Operation Manual...
-
Page 20: Programming
Ÿ Test the UHF signal transmission (hold down for more than 10 Ÿ seconds). The event code sent is E603 (RF periodic test) Select the default sim (only applicable to dual sim Falcon Ÿ Fusions) 4.2 PC-based Programmer Falcon Fusion configuration software utility is a Windows-based programmer which is used as the primary means of programming the Falcon Fusion. - Page 21 The unit will stay in this mode for 20 seconds to allow Ÿ programming If the unit exits programming mode, repeat the process Ÿ Falcon Fusion Installation and Operation Manual...
-
Page 22: Appendix A Serial Interface
APPENDIX A SERIAL INTERFACE The Falcon Fusion uses a standard interface cable along with an adapter to connect to various alarm panels except the DSC Power Series and the IDS805 which use a key-bus module. The cable ends are interchangeable. - Page 23 Falcon Fusion Serial Interface Cable TEXECOM SERIAL INTERFACE Set the serial port format to Texecom on the Falcon Fusion (Refer to Section 3.4). Connect the Falcon Fusion to Com1 on the alarm panel using the serial interface cable with the TEXECOM-IDS adapter board .
- Page 24 Falcon Fusion’s serial port. PIMA SERIAL INTERFACE Set the serial port format to Pima on the Falcon Fusion (Refer to Section 3.4). Plug the adapter marked PIMA into the serial port on the Pima alarm panel. Plug the other end into the Falcon Fusion’s serial port.
- Page 25 The Pima serial interface will send the standard FSK Contact ID alarm codes. DSC NEO SERIAL INTERFACE Set the serial port format to DSC PowerSeries Neo on the Falcon Fusion (Refer to Section 3.4). The Falcon Fusion can send alarms received from the PC LINK_2 header of the DSC PowerSeries Neo panel.
- Page 26 The Falcon GSM can send alarms received from the keypad-bus of the IDS805 alarm panel. Set the serial port format to IDS on the Falcon GSM if using an IDS-supplied key-bus module or to IDS805 FSK Key-Bus if using an FSK-supplied DSC Power Series/IDS805 FSK Key-Bus Module (Refer to Section 3.4).
- Page 27 App Set-up Guide provided, for alarm signals to be sent and/or for app connectivity. Falcon Fusion Installation and Operation Manual...
-
Page 28: Appendix B Programming Cable & Software
APPENDIX B PROGRAMMING CABLE AND SOFTWARE The Falcon Fusion is programmed using the FSK USB Programming Cable and FSK DVD kit which contains the programming software (FSK Item Code 40027). Installing the drivers for the FSK USB to UART Programmer Install the drivers before plugging the USB Programmer into the computer’s USB port. - Page 29 In the FSK DVD, navigate to the following directory: \FUSA FSK USB Serial Adapter Drivers For 64 bit operating systems, double click on: CP210xVCPInstaller_x64.exe Otherwise, double click on: CP210xVCPInstaller_x86.exe Follow the instructions on DRIVER software to install. Falcon Fusion Installation and Operation Manual...
- Page 30 Upon opening the software for the first time it will require an initial setup. The following window will pop up: Select the folder where the templates will be saved for Falcon Fusion devices. Falcon Fusion Installation and Operation Manual...
- Page 31 Select the COM port that will be used to communicate with the device. From there the following window will appear: Connect the Falcon Fusion to the correct COM port and click on the read button. Falcon Fusion Installation and Operation Manual...
- Page 32 Upon completion, the window will look like this. All the settings that are greyed out cannot be changed. Falcon Fusion Installation and Operation Manual...
- Page 33 All the input and output settings can be changed by clicking on the Input/Output Settings Tab. Falcon Fusion Installation and Operation Manual...
- Page 34 This warranty replaces any previous warranties and is the only warranty made by seller on this product. No increase or alteration, written or verbal, of the obligations of this limited warranty is authorised. Note: Specifications are subject to change without notice. Patents issued and pending worldwide. Falcon Fusion Installation and Operation Manual...
- Page 36 helpdesk@fsk.co.za +27 11 477 7705 (technical support) Amecor House, 14 Richard Road, Industria North, 1709...
