ASSEMBLY INSTRUCTIONS
Sort and count your parts!
PARTS LIST
LETTER
DESCRIPTION
CODE
A
Lower Post
B
Base
C
Bolt (fully threaded)
D
Upper Post
E
Knob, Long Stem
F
Adjustment Bracket
G
Retaining Bracket
H
Top Platform
I
Small Screw
J
Paper Stop/Pencil Ledge
K
Pivot Bolt
L
Nut
M
Star Washer
N
Knob, Short Stem
TOOLS REQUIRED: Phillips Screwdriver, Flat Screwdriver
When ordering replacement parts, please specify color.
For questions or concerns, please call
Safco Consumer Hot Line 1-800-664-0042
available Monday-Friday 8:00 AM to 4:30 PM (Central Time)
(English-speaking operators)
1
Insert the A Lower Post into
the B Base and fasten with
the C Bolt (fully threaded)
from the underside of the
Base.
B
8921-37: 1 of 2; 06/02
Adjustable Speaker Stand
QTY.
PART NO.
1
8921-04
1
8921-05
1
8921-27
1
8921-03
2
8921-25
1
8921-02
1
8921-09
1
8921-01
6
8921-22
1
8921-08
1
8921-23
1
8921-24
1
8921-21
1
8921-26
A
C
Safco Products Company, New Hope, MN 55428
J
L
G
F
I
D
B
2
Insert the D Upper Post into
the Lower Post, line up the
holes in one post with the
holes in the other post at an
appropriate height, and fasten
with two E Knobs with Long
Stems.
USE TWO HOLES
8921
MODEL NUM-
BER
H
K
N
M
E
A
C
ASSEMBLED UNIT
MODEL 8921
D
E
