4900 Industry Drive, Central Point, OR 97502 * www.ergoindemand.com * 800.888.6024 (Toll Free)
541.779.3763 (Office) * 541.779.0829 (Fax) * info@ergoindemand.com (Email)
ASSEMBLY INSTRUCTIONS
1859
®
Impromptu
Deluxe Machine Stand with Doors
PRODUCT WARRANTY REGISTRATION is available online at: www.safcoproducts.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Impromptu 1859 and is the answer not in the manual?

Questions and answers

Related Manuals for Safco Impromptu 1859

Summary of Contents for Safco Impromptu 1859

  • Page 1 4900 Industry Drive, Central Point, OR 97502 * www.ergoindemand.com * 800.888.6024 (Toll Free) 541.779.3763 (Office) * 541.779.0829 (Fax) * info@ergoindemand.com (Email) ASSEMBLY INSTRUCTIONS 1859 ® Impromptu Deluxe Machine Stand with Doors PRODUCT WARRANTY REGISTRATION is available online at: www.safcoproducts.com...

  • Page 2: Parts List

    TOOLS REQUIRED: Phillips Screwdriver Two People Recommended. Parts List Code/ Qty. Part No. DESCRIPTION Side Panel 1858-03GR Back Frame 1858-04GR Back Panel 1858-12NC Front Frame 1859-02GR Left Door 1859-09GR Right Door 1859-10GR Bottom Shelf 1859-06GR Center Shelf 1858-07GR Top Panel 1858-01GR Hardware Pack Hardware Pack...
  • Page 3 (12)
  • Page 4 If necessary, complete this step: Sides are ush with each other Insert screws only 2/3 of length SUPPORT OPENS UPWARD IMPORTANT: Orient the parts as shown! TOP FLANGE TOP OF LEG IS OPEN...
  • Page 5 IMPORTANT: Orient the parts as shown! Insert screws only 2/3 of length SUPPORT OPENS UPWARD TOP FLANGE TOP OF LEG IS OPEN End anges of shelf remain visible Back ange of shelf tucks behind back frame...
  • Page 6 Insert screws only 2/3 of length Place the door hinge between the side panel and front frame.
  • Page 7 Place the door hinge between the side panel and front frame. Close doors and adjust for proper alignment, then tighten all door screws Place the top, facing down, onto carpet or the inside of the carton; turn the frame assembly upside- down, align holes, and insert screws Tighten the top screws, then the back leg screws...
  • Page 8 Engage all four supports If doors have become misaligned, loosen door screws, realign doors, then tighten all door screws 4900 Industry Drive, Central Point, OR 97502 * www.ergoindemand.com * 800.888.6024 (Toll Free) 541.779.3763 (Office) * 541.779.0829 (Fax) * info@ergoindemand.com (Email)
