USER GUIDE
LG Digital
Signage
(MONITOR SIGNAGE)
L14
Please read this manual carefully before operating your set and retain it for future
reference.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L14 and is the answer not in the manual?

Questions and answers

Related Manuals for LG L14

Summary of Contents for LG L14

  • Page 1 USER GUIDE LG Digital Signage (MONITOR SIGNAGE) Please read this manual carefully before operating your set and retain it for future reference. www.lg.com...

  • Page 2: Table Of Contents

    In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.

  • Page 3: Using The Monitor

    USING THE MONITOR Using the Input List Press INPUT to access the input source list. Press the navigation buttons to scroll to one of the input sources and press OK. : Watch video from a VCR or other external devices. Component : Watch the content from a DVD or other external devices, or through a digital set-top box.
  • Page 4 16:9 This selection will allow you to adjust the picture horizontally, in linear proportion, to fill the entire screen (useful for viewing 4:3 formatted DVDs). Just Scan This Selection will allow you view the picture of best quality without loss of original picture in high resolution image.

  • Page 5: Entertainment

    ENTERTAINMENT Connecting to a Wired Network To set up the network settings: (Even if your display has already connected automatically, running setup again will not harm anything), Connect the display to a local area network (LAN) via the LAN port as shown on the following illustration Press SETTINGS to access the main menus.

  • Page 6: Network Status

    Press the navigation buttons to select service. For details, contact your ISP. Network Status. LG is not responsible for any malfunction of the display and/or the Internet connection feature Press to check the network status.

  • Page 7: Using The My Media

    Using the My Media Tips for Using USB Storage Devices Only a USB storage device is recognizable. Connecting USB Storage Devices If the USB storage device is connected through a USB hub, the device is not recognizable. Connect USB storage devices such as a USB flash A USB storage device using an automatic recog- memory, external hard drive to the display and use nition programme may not be recognized.
  • Page 8 If the USB HDD does not have an external power source, the USB device may not be detected. So be sure to connect the external power source. - Please use a power adaptor for an external power source. We do not guarantee an USB cable for an external power source.

  • Page 9: Browsing Files

    Browsing Files Browse files saved in a USB storage device. SETTINGS Press to access the main menu. Press the search button to scroll to MY MEDIA and press OK. Press the Search button to go to the Movie List, Photo List or Content List that you want, and press OK. Supported file format Type Supported file format...

  • Page 10: Viewing Movies

    Viewing Movies Plays movie files saved in the USB storage device. SETTINGS Press to access the main menu. Press the navigation button to scroll to MY MEDIA and press OK. Press the navigation button to scroll to Movie List and press OK. Press the navigation buttons to scroll to a folder you want and press OK.
  • Page 11 Tips for using playing video files Some user-created subtitles may not work properly. Some special characters are not supported in subtitles. HTML tags are not supported in subtitles. Subtitles in languages other than the supported languages are not available. A damaged movie file may not be played correctly, or some player functions may not be usable. Movie files produced with some encoders may not be played correctly.
  • Page 12 Select Set Video Play. to access the following menus: Menu Description Picture Size Selects your desired picture format during movie play. Subtitle Language Turn on/off the subtitle. Language Activated for SMI subtitle and can select the language within the subtitle. Code Page Can select the font for subtitle.

  • Page 13: Viewing Photos

    Viewing Photos View image files saved in the USB storage device. SETTINGS Press to access the main menu. Press the navigation button to scroll to MY MEDIA and press OK. Press the navigation button to scroll to Photo List and press OK. Press the navigation buttons to scroll to a folder you want and press OK.
  • Page 14 Photo options Press SETTINGS to show the Option menus. Press the navigation buttons to scroll to Set Photo View, Set Video. and press OK. NOTE The option values changed in Movie List do not affect Photo List. Therefore, they are not affected by option values changed in Photo List.

  • Page 15: Viewing The Contents List

    Viewing the Contents List Plays back the stored files using the Export option in SuperSign Manager. Press SETTINGS to access the main menu. Press the navigation button to scroll to MY MEDIA and press OK. Press the navigation button to scroll to Contents List and press OK. Press the navigation buttons to scroll to a folder you want and press OK.

  • Page 16: Divx® Vod Guide

    DivX® VOD Guide DivX® VOD Registration In order to play purchased or rented DivX® VOD contents, you should register your device with 10 digit DivX registra- tion code from your device at www.divx.com/vod. SETTINGS Press to access the main menus. Press the navigation buttons to scroll to MY MEDIA and press OK.

  • Page 17: Customizing Settings

    CUSTOMIZING SETTINGS Accessing Main Menus SETTINGS Press to access the main menus. Press the navigation buttons to scroll to one of the following menus and press OK. Press the navigation buttons to scroll to the setting or option you want and press OK. When you are finished, press EXIT.

  • Page 18: Picture Settings

    PICTURE Settings SETTINGS Press to access the main menus. Press the navigation buttons to scroll to PICTURE and press OK. Press the navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT.
  • Page 19 Setting Description Screen Customizes the PC display options in RGB mode. (In RGB Option Mode Only) Resolution Selects a proper resolution. Auto Configure Sets to adjust the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress.
  • Page 20 Advanced Control Picture Mode (Standard/ APS/ Sport/ Game) Setting Description Dynamic Contrast Adjusts the contrast to the optimal level according to the brightness of the image. Dynamic Color Adjusts color for more natural-looking colors. Color Gamut Selects the range of colors that can be expressed. Skin Color Skin Color spectrum can be separately set to implement the skin color as defined by the user.

  • Page 21: Time Settings

    TIME Settings SETTINGS Press to access the main menus. Press the navigation buttons to scroll to TIME and press OK. Press the navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT.

  • Page 22: Option Settings

    OPTION Settings SETTINGS Press to access the main menus. Press the navigation buttons to scroll to OPTION and press OK. Press the navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT.
  • Page 23 Tile Mode This monitor can be tiled with additional monitors to create a large tiled display. When using 2 monitors When using 4 monitors When using 9 monitors When the Tile Mode option is disabled ID 2 ID 3 ID 2 ID 1 ID 2 ID 1...

  • Page 24: Network Settings

    NETWORK Settings Press SETTINGS to access the main menus. Press the navigation buttons to scroll to NETWORK and press OK. Press the navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT.

  • Page 25: Ir Codes

    IR CODES All models do not support the HDMI/USB function. Some key codes are not supported depending on the model. Code (Hexa) Function Note ( Power) R/C BUTTON INPUT R/C BUTTON MONITOR ON R/C BUTTON MONITOR OFF R/C BUTTON ENERGY SAVING R/C BUTTON R/C BUTTON 10 to 19...

  • Page 26: Picture Id

    PICTURE ID NOTE For example, if the Picture ID is assigned to Picture ID is used to change the settings of a specific 2, the upper right display (Set ID: 2) can be display using a single IR receiver for multi-vision. The controlled by IR signals.

  • Page 27: Controlling The Multiple Product

    CONTROLLING THE MULTIPLE PRODUCT Use this method to connect several products to a single PC. You can control several products at one time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 255 (or from 1 to 1000) without being duplicated. Connecting the cable Connect the RS-232C cable as shown in the picture.

  • Page 28: Command Reference List

    Command Reference List COMMAND DATA (Hexadecimal) Power 00 to 01 Select input See [Select input] Aspect ratio See [Aspect ratio] Energy saving See [Energy saving] Picture mode See [Picture mode] Contrast 00 to 64 Brightness 00 to 64 Sharpness 00 to 32 Color 00 to 64 Tint...
  • Page 29 COMMAND DATA (Hexadecimal) Power On Delay 00 to 64 Tile Mode 00 to 01 Tile Mode Check Tile ID Refer to ‘Tile ID' . Tile H Position 00 to 32 Tile V Position 00 to 32 Tile H Size 00 to 32 Tile V Size 00 to 32 Natural Mode (In Tile mode)

  • Page 30: Transmission / Receiving Protocol

    Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command1]: First command to control the set. * [Command2]: Second command to control the set. [Set ID]: Used for selecting a set you want to control. A Set ID can be assigned to each set from 1 to 255 (from 01H to FFH), or from 1 to 1,000 (from 001H to 3e8H) in certain models, under OPTION in the OSD menu.
  • Page 31 01. Power (Command: k a) 04. Energy saving (Command: j q) Controls the power on/off of the set. Sets the energy saving function. Transmission Transmission [k][a][ ][Set ID][ ][Data][Cr] [j][q][ ][Set ID][ ][Data][Cr] Data 00: Off Data 00: Off 01: On 01: Minimum 02: Medium Acknowledgement...
  • Page 32 Brightness (Command: k h) Tint (Command: k j) Adjusts the screen brightness. Adjusts the screen tint. Transmission Transmission [k][h][ ][Set ID][ ][Data][Cr] [k][j][ ][Set ID][ ][Data][Cr] Data Data 00 to 64: Brightness 0 to 100 00 to 64: Tint red 50 to green 50 Acknowledgement Acknowledgement [h][ ][Set ID][ ][OK/NG][Data][x]...
  • Page 33 V position (Command: f r) Balance (Command: k t) Adjusts the vertical position of the screen. Adjusts the sound balance. This function is only available when the Tile Mode is set Transmission to Off. [k][t][ ][Set ID][ ][Data][Cr] * The operational range varies depending on the RGB Data 00 to 64: Left 50 to right 50 input resolution.
  • Page 34 Volume (Command: k f) Off time schedule (Command: f c) Adjusts the playback volume. Enables/disables the on time schedule. Transmission Transmission [k][f][ ][Set ID][ ][Data][Cr] [f][c][ ][Set ID][ ][Data][Cr] Data Data 00 to 64: Volume 0 to 100 00: Off 01: On Acknowledgement Acknowledgement...
  • Page 35 Off timer (repeat mode/time) (Command: f e) On timer (repeat mode/time) (Command: f d) Configures the off time (repeat mode/time) settings. Configures the on time (repeat mode/time) settings. Transmission Transmission [f][e][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] [f][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] Data1 Data1 1.
  • Page 36 On timer input (Command: f u) Adds a new schedule entry by selecting input for the Auto off (Command: f g) current on timer setting. Configures the automatic off settings. Transmission Transmission [f][g][ ][Set ID][ ][Data][Cr] [f][u][ ][Set ID][ ][Data1][Cr] Data 00: Off (Will not turn off after 15 minutes) [f][u][ ][Set ID][ ][Data1][Data2][Cr]...
  • Page 37 Reset (Command: f k) Time elapsed (Command: d l) Resets settings for Picture, Screen and Audio or restores Checks the elapsed time. factory settings. Transmission (Screen reset can only be performed in RGB input mode.) [d][l][ ][Set ID][ ][Data][Cr] Transmission Data FF: Read status [f][k][ ][Set ID][ ][Data][Cr]...
  • Page 38 White balance red gain (Command: j m) Backlight (Command: m g) Adjusts the white balance red gain value. Adjusts the back light brightness. Transmission Transmission [j][m][ ][Set ID][ ][Data][Cr] [m][g][ ][Set ID][ ][Data][Cr] Data 00 to FE: Red gain 0 to 254 Data 00 to 64: Back light brightness 0 to 100 Acknowledgement...
  • Page 39 46. Tile H Position (Command: d e) 43. Tile Mode (Command: d d) To adjust the Tile Horizontal position. To set a Tile Mode and Tile Column/ Row * This function is available only when the Natural option values. of the Tile Mode is set to Off while the Tile Mode set to Transmission [d][d][ ][Set ID][ ][Data][Cr] Transmission...
  • Page 40 49. Tile V Size (Command: d h) To adjust the Tile Vertical size. *Set Tile V Position to 0x00 before setting Tile V Size. * This function is available only when the Natural option of the Tile Mode is set to Off while the Tile Mode set to Transmission [d][h][ ][Set ID][ ][Data][Cr] Data...
