- Page 1 9" (23 cm) Single Line Bump Feed Electric Grass Trimmer 060-3053-2 Instruction Manual 3084514 Conforms to UL STD 82 Certified to CAN/CSA STD. Read all safety rules and instructions carefully before operating this tool. C22.2 No. 147-M90...
-
Page 2: Table Of Contents
CONTENTS Contents............................2 Product Specifications......................2 General Safety Rules........................3 Electrical Information......................6 Symbols........................... 9 Know Your Grass trimmer....................10 Assembly ..........................11 Operation..........................12 Troubleshooting..........................16 Exploded View ........................17 Parts List ..........................18 Warranty ............................. 19 Notes............................20 PRODUCT SPECIFICATIONS 9” (23 cm) GRASS TRIMMER Voltage...................... -
Page 3: General Safety Rules
GENERAL SAFETY RULES WARNING When using the machine the safety rules must be followed. For your own safety and that of bystanders please read these instructions before operating the machine. Do not use the machine without reading the instructionsheet. Save these instructions. •... - Page 4 GENERAL SAFETY RULES • Do not wear loose clothing or jewelry. They can be caught in moving parts. Use of rubber gloves and footwear is recommended when working outdoors. • Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts. WARNING Use outdoor extension cords marked SW-A, SOW-A, STW-A, STOW-A, SJW-A, SJTA, SJTW-A, or SJTOWA.
- Page 5 GENERAL SAFETY RULES DO NOT TOUCH THE CORD BEFORE DISCONNECTING THE SUPPLY; - Do not use the grass trimmer, if the cord is damaged or worn. W A R N I N G - Cutting elements continue to rotate after the motor is switched off. - Keep extension cords away from cutting elements.
-
Page 6: Electrical Information
ELECTRICAL INFORMATION WARNING TO AVOID ELECTRICAL HAZARDS, FIRE HAZARDS, OR DAMAGE TO THE TOOL, USE PROPER CIRCUIT PROTECTION. YOUR GRASS TRIMMER IS WIRED AT THE FACTORY FOR 120 V OPERATION. CONNECT TO A 120 V, 15 A CIRCUIT, AND USE A 15 A TIME-DELAYED FUSE OR CIRCUIT BREAKER. - Page 7 ELECTRICAL INFORMATION WARNING DOUBLE INSULATION DOES NOT TAKE THE PLACE OF NORMAL SAFETY PRECAUTIONS WHEN OPERATING THIS GRASS TRIMMER. WARNING TO AVOID ELECTROCUTION: 1. Use only identical replacement parts when servicing a tool with double insulation. Servicing should be performed by a qualified technician. 2.
- Page 8 ELECTRICAL INFORMATION GUIDELINES FOR USING EXTENSION CORDS USE THE PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause overheating. The table below shows the correct size to use depending on cord length and nameplate ampere rating.
-
Page 9: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) -
Page 10: Know Your Grass Trimmer
KNOW YOUR GRASS TRIMMER Know Your Grass Trimmer (Fig. 2) The safe use of this product requires an understanding of the information on the product and in this instruction manual as well as a knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules. -
Page 11: Assembly
ASSEMBLY Functional description This portable hand-held grass trimmer is powered by an electric motor. This trimmer features a single-line bump feed head that is used for safe and efficient grass cutting. After the safety guard is installed it will protect the user during trimming operations. The following describes the functions of the operating parts. -
Page 12: Operation
OPERATION WARNING Danger of injury! Never use the trimmer without its safety guard. Always check the operability of the trimmer before it is used. Check that the electrical voltage is the same as indicated on the rating plate. Always wear goggles when working with the trimmer. - Page 13 OPERATION Cutting device —— advancing the trimmer line (Fig. 6) In order to advance a length of trimmer line, firmly tap the bump cap on the lawn while the trimmer is running. This will automatically advance a new length of trimmer line and trim the line to the correct length.
- Page 14 OPERATION WARNING Danger of injury! • Do not cut moist or wet grass. • Before starting the trimmer check that the cutting head will not come into contact with stones, rubble or other foreign bodies. • Switch on the trimmer before you approach the grass that is to be cut. •...
- Page 15 OPERATION Cleaning and maintenance WARNING Always disconnect the plug from the power source before working on the trimmer. WARNING Any work that is not described in these instructions must be carried out by an authorized service agency. Only use original parts and be very careful with the line cutter during installation work.
-
Page 16: Troubleshooting
OPERATION Disposal And Protection Of The Environment NOTE: Dispose of the trimmer, its accessories and the packaging in an environmentally friendly manner. Electrical grass trimmers must not be disposed of with domestic waste. Hand in a redundant trimmer to a recycling centre. The plastic and metals can then be sorted out and graded for recycling. Our Service Centre will be happy to answer any questions in this respect. -
Page 17: Exploded View
EXPLODED VIEW... -
Page 18: Parts List
PARTS LIST ITEM NO. PART NO. DESCRIPTION TODXD1.43.UL.X1.01 Power Lead TOQTGX.01.YX.X1.02 Power Lead Retainer GT21FM.10.03.X0.01 On/off Button GT27FM.30.00 Spool TOTHYL.01.09 Spring GT27FM.50.00 Debris Guard w/ Screws GT21FM.00.04.02 Flower Guard TM5863.00.00.X1.01 Motor Assembly GT21FM.20.01.W2.00 Spool Head GT21FM.00.03 Spool Cover TOTHYY.04.12 Spring GT21FM.00.01.X0.01 Lower Motor Housing GT22FM.10.01.X0.01... -
Page 19: Warranty
WARRANTY This JobMate product is guaranteed for a period of 1 year from the date of original retail purchase against defects in workmanship and materials. Subject to the conditions and limitations described below, this product, if returned to us with proof of purchase within the stated warranty period and if covered under this warranty, will be repaired or replaced (with the same model, or one of equal value or specification), at our option. -
Page 20: Notes
NOTES MADE IN CHINA IMPORTED BY TRILEAF DISTRIBUTION TRIFEUIL TORONOTO, CANADA M4S 2B8...
