Summary of Contents for jobmate YT5302
-
Page 2: Table Of Contents
CONTENTS Know Your Product....................3 Technical Specifications..................3 Description of Symbols................... 4 Contents of Electric Hedge Trimmer...............5 General Safety Instructions..................6 Additional Safety Instructions for Electric Hedge Trimmer........8 Operation........................9 Connecting to Power Supply ................9 Starting and Stopping ..................9 Cutting ...................... -
Page 3: Know Your Product
KNOW YOUR PRODUCT 1 Front handle 2 Hand safety switch 3 Switch trigger 4 Rear handle 5 Guard 6 Cable strain relief 7 Opening 8 Cable 9 Blade TECHNICAL SPECIFICATIONS Voltage: 230V ~ 50Hz Power input: 500W No load speed: 3300/min Blade length: 600mm... -
Page 4: Description Of Symbols
DESCRIPTION OF SYMBOLS The rating plate on your tool may show symbols. These represent important information about the product instruction on its use. Denotes risk of personal injury, loss of life, or damage to the tool in case of nonobservance. Use eye protection. -
Page 5: Contents Of Electric Hedge Trimmer
DESCRIPTION OF SYMBOLS (CONT.) Disconnect from power supply when for repair. This symbol is known as the ’Crossed-out Wheelie Bin Symbol’. When this symbol is marked on a product or battery, it means that it should not be disposed of with your general housed hold waste. Some chemicals contained within electrical/electronic products or batteries can be harmful to health and the environment. -
Page 6: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS WARNING! Read all instructions. Failure to follow all the instructions listed in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. SAVE THESE INSTRUCTIONS 1) Work area •... - Page 7 GENERAL SAFETY INSTRUCTIONS (Cont.) that have the switch may cause an accident. • Remove any adjusting key or wrench before turning the power tool on. A wrench or key left attached to a rotating part of the power tool may result in personal injury.
-
Page 8: Additional Safety Instructions For Electric Hedge Trimmer
Additional Safety Instructions for Electric Hedge Trimmer • Use non-slip, heavy-duty protective gloves when operating the hedge trimmer and when installing or removing blades. • Replace any blade that has been damaged. Always make sure blades are installed correctly and securely fastened before each use. Failure to do so can cause serious injury. -
Page 9: Operation
OPERATION Connecting to power supply (Fig. 2) This product is designed with a cable strain relief (6) that prevents the extension cord from being pulled loose while using. 1. Form a loop with the end of the extension cord. 2. Insert loop portion of extension cord through opening (7) in the bottom of the rear handle and place over cable strain relief. - Page 10 OPERATION (Cont.) WARNING: Always keep both hands on the hedge trimmer handles. Never hold shrubs with one hand and operate hedge trimmer with the other. Improper handling of hedge trimmer could result in serious injury. WARNING: Clear the area to be cut before each use. Remove all objects such as cords, lights, wire, or loose string which can become entangled in the cutting blade and create a risk of electric shock and serious personal injury.
-
Page 11: Tips For Using Your Electric Hedge Trimmer
OPERATION (Cont.) Tips for Using Your Electric Hedge Trimmer • Attention! Reverse blade. Before all maintenance and cleaning work, pull out the power plug. Do not touch moving blades. • Clean the hedge shears with a dry towel, particularly the ventilation slits, after each use or using a brush in the case of heavy soiling. - Page 12 MAINTENANCE (Cont.) WARNING: Do not operate the trimmer with dull or damaged cutting blades. This may cause overload and will give unsatisfactory cutting results. Cleaning the hedge trimmer Stop the motor and disconnect from power supply. Clean dirt and debris from the body of the hedge trimmer using a damp cloth with a mild detergent.
-
Page 14: Warranty
WARRANTY POLICY Congratulations on your purchase of Electric Hedge Trimmer. In order to get maximum benefit from your new purchase, please be aware of the warranty provisions outlined in this document. 2 YEAR [REPLACEMENT/REPAIR] WARRANTY Your Electric Hedge Trimmer is guaranteed for a period of 24 months from the original date of purchase. - Page 15 Mitre 10 or Mitre 10 MEGA store where the product was purchased from, for the warranty to be applicable. Please retain your Proof of Purchase. Only the original owner is covered by the manufacturer’s warranty and must have purchased the product from a Mitre 10 or Mitre 10 MEGA store in New Zealand. What is not covered under warranty? •...
