DIP switch settings

There are four small DIP switches on the reverse of the
HeadMouse Nano. These switches are numbered and control
several functions of the camera. You will need to use a small tool,
such as a paper clip or tweezers to toggle the switches.
Default setting
All switches are in the ON position.
Switch 1
Mouse gain. Toggling Switch 1 to OFF will increase
the mouse gain (or speed). This is useful if you have
a limited amount of head movement as the mouse
will be far more sensitive.
Switch 2
Enable Infrared receiver. When switch 2 is OFF the
inbuilt infrared receiver is toggled off.
Switch 3
Tilt Sensor toggle. The built in tilt sensor can be
toggled on and off.
Switch 4
When Switch 3 is off, Switch 4 will control which
way up the HeadMouse Nano is tracking. ON is the
standard rotation and OFF reverses the orientation.
