Summary of Contents for Rugged Radios GMR5-M

  • Page 1 GMR5-M P.N. GMR5-M...
  • Page 2 TYT Electronics Co., Ltd. Thank you for purchasing a Rugged Radios 2-Way Radio. This radio was pre-programmed and fully optimized before being shipped to you. Please use caution before changing any settings on this radio. For questions, please call the Rugged Radios Tech Department at 888-541-7223.

  • Page 3: Table Of Contents

    Contents FCC NOTICE The GMR5-M Radio operates on GMRS (General Mobile Radio Service) frequencies which require a Federal Communications Commission (FCC) license. You must be licensed prior to operating on channels 1-7, USAGE TIPS ----------------------------------------------------------------------------- 2 15-22 or RP15-22, and RUGGED which comprise the GMRS channels of the GMR5-M. Serious penalties UNPACKING &...

  • Page 4: Usage Tips

    • Turn off the radio before getting close to blasting zones or detonation areas. • Do not use a radio with a damaged antenna. Touching a damaged antenna may cause heat injury. GMR5-M Radio Radio Mount Speaker Mic Magnetic Roof •...
  • Page 5 Configuration Antenna Placement Example of Radio Placement • Antenna should be mounted as high up on the vehicle as possible, centered on the roof if possible. • Carefully route the coax cable as to not have any pinches MAGNETIC or coils. ROOF MOUNT ANTENNA NOTE: Avoid interaction between the coax cable and power...
  • Page 6 M2.5x5 screws. Loosen the screws to remove the mounting clip. 2. Secure the GMR5-M to the radio mount as shown. 2) Push the power adapter lock to release the power adapter and slide it toward the bottom of the...

  • Page 7: Getting Familiar

    Speaker Mic Getting Familiar Volume Dial With the radio turned off, open the cover of the microphone/speaker jack and insert the speaker mic plug into the jack. Toggles tranceiver power Remote Antenna on/off and adjusts audio Connector levels. 1-10 BFG RLY Busy/TX Indicator turns green Internal Speaker...
  • Page 8 LCD Display The following table defines the icons that display on the radio LCD. Mounting Clip Microphone/Speaker Jack Press to transmit and release Icons Description of Functions The jack provides connection to receive after your Operating Band Signal & Power Meter points for microphone audio, transmission is completed.
  • Page 9 Keypad Functions Icons Description of Functions Squelch Active Beep Tone Active Battery Power Indicator Press Enter Menu Upper menu Lower menu Switch Set CTCSS Tone mode/confirm item, channel item, channel between VFL Set DCS Tone the setting or frequency or frequency Mode and MR Mode/exit Operating A Band Indicator...

  • Page 10: Operation Modes

    4) FM Radio Mode ON/AUTO/OFF LED Display Mode GMR5-M provides 76.00-108.00MHz FM radio. In FM mode, you can choose the frequency you BACKLIT COLOR 1/COLOR 2/COLOR 3 Background Light Color need directly, scan frequency range, and store your favorite channels.

  • Page 11: Menu

    ] key again to exit the scanning function. 2) Squelch Adjustment (SQL --- MENU 2) Functions: The GMR5-M Squelch system allows you to mute background noise when no signal is being received. The Squelch system significantly reduces battery consumption. Enter Menu 2 to set SQL level. Default: 5 3) Dual Wait/Standby (DUALDSP --- MENU 6) Functions: Receive a sub band signal even while working on the operating band.
  • Page 12 ] / [ 9) Voice Prompt (VOICE --- MENU 9) keys to choose the right group you need. Functions: Enable/disable voice prompt. • Press [ ] key to select DCS direction. The GMR5-M has 50 CTCSS groups and 104 normal/inverted DCS groups.
  • Page 13 Privacy Tones Frequency Chart (Hz) DCS Codes CTCSS 67.0 91.5 118.8 156.7 210.7 218.1 71.9 94.8 123.0 162.2 74.4 97.4 127.3 167.9 225.7 77.0 100.0 131.8 173.8 233.6 79.7 103.5 136.5 179.9 241.8 82.5 107.2 141.3 186.2 250.3 85.4 110.9 146.2 192.8 88.5...

  • Page 14: Advanced Functions

    Advanced Functions FM Radio Search In FM radio mode, press [ ] + [ ], then press [ ] again to enter FM radio scanning. On the "RADIO" screen, press [ ] or [ ] to change scanning 1) Keypad Lock Settings direction.

  • Page 15: Technical Parameters

    Technical Parameters Transmitter Modulation Mode 11K0F3E General Maximum Deviation < 5kHz / < 2.5KHz Listen Only Frequency Range 462.550-462.7250MHz,462.5625-462.7125MHz, Spurious Radiation < 7.5μW 467.550-467.7250MHz Adjacent Ch. Power < -65dB / < 60dB Channel No. 2x128 Pre-emphasis Characteristics Current < 1.6A(5W) Frequency Stability ±2.5PPm CTCSS/DCS...

  • Page 16: Warranty Registration

    Notes Warranty Registration Rugged Radios Intercoms, Radios, and Headsets are backed by a 3-year warranty. For more information, or to register your product, please visit our website. Product Registration: www.ruggedradios.com/warranty Questions: 888.541.7223 Model Number: Serial Number: Purchase Date: Purchase Location:...
