Summary of Contents for WHISPER KOOL SLIMLINE LS
- Page 1 SLIMLINE LS OWNER’S MANUAL...
- Page 2 Conforms to ANSI/UL Std 427 Certified to CAN/CSA Std C22.2 No. 120 We manufacture, test and certify 100% of our wine cooling units in the USA. By sourcing the best components and closely controlling our manufacturing processes, we can assure the highest-quality, lowest defect manufacturing rates in the industry.
-
Page 3: Table Of Contents
System Operation ........15 Slimline LS Wiring Diagram ......16 Controller Functions . -
Page 4: Introduction
INTRODUCTION The Slimline LS was designed to mount in a living area, fitting into the often unused space between the cellar door and ceiling, giving the collector maximum storage capacity. The system is equipped with WhisperKOOL’s Platinum Series controller, which utilizes Advanced System Protection Technology. A series of strategically placed monitoring probes ensures efficient performance and long cooling unit life. -
Page 5: Before You Start
Slimline LS 1-800-343-9463 BEFORE YOU START 1. Inspect the unit before installation. If damage is found, please contact your distributor or WhisperKOOL Customer Service at 1-800-343-9463. 2. The unit should remain in an upright position for 24 hours prior to operation. -
Page 6: Receiving & Inspecting The Unit
If any items listed on the packing slip do not match your order information, contact WhisperKOOL Customer Service immediately. Check the shipped box for the following contents: Slimline LS • (1) Slimline LS cooling unit • (2) Mounting brackets Accessory Kit #1: •... -
Page 7: Quick Reference Guide
Slimline LS QUICK REFERENCE GUIDE Bottle probe Front / Side View (in cellar / evaporator) Evaporator grille Bottle probe input Power cord Drain port Bottom View Rear / Side View (out of cellar / condenser) Bottle probe input Controller Condenser grille Power cord www.whisperkool.com | Page 5... -
Page 8: Unit
Compressor is On Alarm is present Unit is in Anti-Frost Temperature Measurement Mode Fans are On UNIT SPECIFICATIONS Slimline LS - Low Speed Slimline LS - Medium Speed Cellar Size (cu. ft.)* BTU/h w/60°F condenser 2601/1961 3032/2413 (total/sensible) (total/sensible) air intake temperature BTU/h w/75°F condenser... -
Page 9: Preparing The Wine Cellar
Slimline LS PREPARING THE WINE CELLAR The performance and life of your system is contingent upon the steps you take in preparing the wine cellar. Improp- erly preparing your enclosure or incorrectly installing your unit may cause unit failure, leaking of condensation, and other negative side effects. - Page 10 Mounting the Unit The unit must be mounted within 18 inches of the ceiling in order to achieve sufficient cooling. As the room cools down, the warm air will rise to the ceiling. Mounting the unit high in the room will create a consistently cool environment by capturing the warm air and replacing it with cool air.
- Page 11 Slimline LS Ventilation The necessity of dissipating heat away from the unit is critical to the unit’s performance and cannot be overstated. As the unit operates and cools, a greater amount of heat is generated on the exhaust side of the unit. Adequate ventilation is required in order to dissipate heat away from the unit.
-
Page 12: Pre-Installation
PRE-INSTALLATION Skill level: Moderate Follow local building codes and/or consult a licensed contractor Electrical Needs The Slimline system requires a dedicated 115V, 15-amp circuit. The unit draws a large amount of amps during its initial startup. By designating a dedicated circuit breaker, you will guarantee that the unit has enough power to run effectively. -
Page 13: Preparing The Installation Location
Slimline LS PREPARING THE INSTALLATION LOCATION Minimum Tools Needed Level Hammer Screwdriver Note: The following installation examples are for reference only. Door header construction and framing may vary. When not installing above a door, you must have adequate framing inside of the wall. WhisperKOOL recommends consulting a licensed contractor for framing and construction needs. -
Page 14: Installation
INSTALLATION STEP 4 Slide the cooling unit into the hole from the cellar side with the controller facing outward. Mounting bracket location Front of Unit Front of Unit STEP 5 Foam tape needs to be placed on bracket surfaces which will be in direct contact with the wall. STEP 6 From the outside of the cellar, secure the two brackets to the corresponding side of the cooling unit on exterior side of the cellar. - Page 15 Slimline LS INSTALLATION (continued) STEP 6 Slide the cooling unit back in towards the cellar and secure it to the wall through the pre- drilled holes on the brackets. The screws should penetrate the studs and/or frame. Seal all cracks and gaps around the unit with an airtight sealant or caulking to prevent air leakage.
-
Page 16: Liquid-Measuring Thermostat System
LIQUID-MEASURING THERMOSTAT SYSTEM (BOTTLE PROBE) WhisperKOOL cooling units come with a liquid-temperature-measuring thermostat. The self-calibrating bottle probe contains a sensor which communicates back and forth with the thermostat. This results in a consistent temperature setting and accuracy. Wine should be kept at a very precise, controlled temperature and humidity. Setting up the Bottle Probe: 1. -
Page 17: System Operation
Slimline LS SYSTEM OPERATION Initial Startup “Def” will be displayed during the Anti-Frost Cycle. If the When power is applied to the unit, the control will briefly cycle is less than five minutes, the controller will prevent the display all symbols, and the snowflake symbol will be compressor from starting until five additional minutes have displayed (if unit is calling for cooling). -
Page 18: Slimline Ls Wiring Diagram
SLIMLINE LS WIRING DIAGRAM EwPlus 974 NTC Probe 1 2 3 4 5 6 7 8 9 10 11 Slimline LS Wiring Diagram BROWN BLACK BLUE WHITE WHITE WHITE CONDENSATE WHITE HEATER BLACK WHITE BLUE BLACK POWER SUPPLY WHITE 115 VAC-60 Hz, 20A... -
Page 19: Controller Functions
Slimline LS CONTROLLER FUNCTIONS Button/Symbol Normal Functions ON/OFF • Press and hold the ON/OFF button for approximately 3 seconds to turn the unit on or off. Note: This does not disconnect power from the unit. In order for the power to be shut off from the unit, the power cord must be unplugged from the power outlet. - Page 20 ALARM CODES Message Cause Solution Bottle probe is unplugged Attach bottle probe to unit Faulty bottle probe connection 1. Check bottle probe attachment at circular connector “E1” 2. Check bottle probe connection at the back of controller Defective bottle probe Replace the bottle probe Faulty evaporator probe Check evaporator probe connection at the back of controller...
-
Page 21: Maintenance Schedule
Slimline LS MAINTENANCE SCHEDULE Monthly 1. Check for unusual noise or vibration 2. Check the drain line to see if it is above the waterline (if draining into a vessel) 3. Check the external drain line to make sure there are no clogs or obstructions. if drain line is clogged, blow out with compressed air. - Page 22 NOTES Page 20 | 1-800-343-9463 SL 072820...
-
Page 23: Troubleshooting Guide
Slimline LS TROUBLESHOOTING GUIDE Ice is forming on the evaporator coil Possible Cause Solution Evaporator coil is dirty Clean coil with a vacuum brush attachment or blow out with compressed air There is something blocking the supply and/or return air... - Page 24 TROUBLESHOOTING GUIDE Unit leaks water Possible Cause Solution Unit is not level Unit should be level in wall to prevent leaking Drain line clogged or kinked Check drain line to make sure water can flow freely Drain is clogged, preventing water from escaping Disconnect drain and clear it out Drain line does not have a downward slope Fix drain line so there is a downward slope from the unit to the drain...
-
Page 25: Technical Assistance & Accessories
Slimline LS TECHNICAL ASSISTANCE WhisperKOOL Customer Service is available Monday through Friday from 6:00 a.m. to 4:00 p.m. Pacific Standard Time. Your customer service representative will be able to assist you with your questions and warranty information more effectively if you provide them with the following: •... -
Page 26: Installation Terms & Conditions
PRODUCT WARRANTY INFORMATION The Coolest Thing In Wine Storage WhisperKOOL Product Terms and Conditions Including Product Limited Warranty And Product Installation Requirements For WhisperKOOL Slimline Series ATTENTION: PLEASE READ THESE TERMS OF USE CAREFULLY BEFORE INSTALLING YOUR WHISPERKOOL COOLING SYSTEM. INSTALLING YOUR WHISPERKOOL COOLING SYSTEM INDICATES THAT YOU ACCEPT AND AGREE TO EACH OF THE TERMS AND CONDITIONS SET FORTH HEREIN (“TERMS OF USE”). - Page 27 installation requirements stated herein and in the Owner’s Manual. 9. Removing the rivets from the Product’s unit housing without prior authorization from WhisperKOOL voids this limited warranty. 10. The End User must first contact WhisperKOOL Customer Service by telephone (at 1-800-343-9463) prior to attempting service on any Product still under the limited warranty;...
- Page 28 5. Additional End User Costs And Responsibilities The following items are not covered under any warranty and are the sole responsibility of the End User: A. End Users should satisfy themselves that the Product they are purchasing is suitable for their particular needs and requirements, and thus no responsibility will be placed with WhisperKOOL for the End User’s decisions in this regard.
- Page 29 9. Questions, Additional Information And Technical Assistance A. Questions: If you have any questions regarding these Terms and Conditions or wish to obtain additional information, contact us via phone at 1-800-343-9463 or please send a letter via U.S. Mail to: Customer Service WhisperKOOL Corporation 1738 E Alpine Ave...
- Page 30 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 1(800) 343-9463 www.whisperkool.com...
