  • Page 1 HiVi DIY2.2-A Speaker Kit Manual Designed by HiVi Acoustics, Inc.
  • Page 2 Please read the manuals carefully first. If you ever have any problems, feel free to email us at support@hivi.com. There is also a great community of DIY builders at www.reddit.com/r/diyaudio/. If you’re ever looking for completely built speakers please check out our website at www.swanspeakers.com.
  • Page 3 1) 1.5Ohm resistor (R2) 4) 6.8uF capacitor (C1) 2) 6.8Ohm resistor (R1) 5) 1.5mH air inductor (L2) 3) 8uF capacitor (C2) 6) 0.35mH air inductor (L1) 7) HiVi LB-D6.8-IIB woofer 8) HiVi LB-Q1R tweeter 9) Vent tube and paper tube...
  • Page 4 Enclosure Division Front Side Side Back Bottom 10) Cabinet front (x2), Back (x2) Bottom (x2), Side (x4), Division (x2) 11) Grill and frame 12) Cushions for drivers 13) Screws A. Screws for woofer/ tweeter/ terminal box 32 PCS D. Male threads 8PCS B.
  • Page 5 14) PCB(Printed Circuit Board) 15) Veneer surface 16) Terminal box 17) Cotton acoustic stuffing 18) Speaker wire 19) Rubber feet 8 PCS 20) Swan tape 21) Double sided foam tape 4 PCS 22) Swan logo and label...
  • Page 6 II、Crossover Assembly 1. Arrange the components as illustrated in the figure below. With a soldering iron, apply solder to the connections between the components and the board. Remove the excess components legs and secure the inductors with cable ties. Note: Remove the coating on either end of the inductors to ensure good contact.
  • Page 7 I 、Enclosure Assembly 1. Set the enclosure parts out on a flat level surface. Apply some wood glue to the locating groove in the side panel and install the division panel into the groove. Then apply glue to all the contact surfaces between the panels. And place all the other panels in place.
  • Page 8 4. Turn the 4 holding pegs onto the retainers or just knock the nails into the them. Then install 4 female threads into the holes on front panel which will be later used to hold the grill. 5. Insert crossover through woofer hole and install it onto the holding pegs on the bottom panel.
  • Page 9 7. There are two sets of lugs on one side of the terminal box and two sets of connected terminals on the other. Weld the input wire on crossover to either set of lugs through the terminal box hole. Again the polarity must be correct. (red = positive) Make sure that there is no short circuit or false welding.
  • Page 10 9. Apply a layer of glue to the frame of the grill and tuck the grill fabric into the groove in the frame cut the excess fabric. Knock the 4 male threads into the holes in the frame. If you wish, attach the logo on the bottom edge in the circle slot.
  • Page 11 E-mail: sales@swanspeaker.com https://swanspeakers.com HiVi China Zhuhai HiVi Technology co., Ltd. NO.1, South Dongcheng Road, Liangang Industrial Zone, Zhuhai, Guangdong, P.R.China Due to the reasons in the change of design or others, product information contained here may not be in conformity with product itself. We reserve the right of no prior notice before change.
