Savage LED-SB-UP Usage Instructions

RGB PORTRAIT KIT
USAGE INSTRUCTIONS
®
®
LIGHT STANDS
Unpack each light stand and loosen leg locks. Pull the upright section
upwards while pushing the leg bracket down to extend the tripod legs.
Tighten the knob on the leg bracket to secure the base. Loosen and
extend each upright section to your desired height, then tighten to lock.
Set the light on the top pin of the stand, and tighten the side knob of
the light stand adapter to secure the light in place.
AC POWER CORD
Thread the included AC power cord into the AC receiver on the back of
the light. Plug into nearby wall plug. Switch the "On/Off" button to the
"On" position. The LED back z should illuminate.
ATTACH AC POWER CORD
OPEN LIGHT STANDS
& MOUNT LIGHT HEAD
SOFTBOX ATTACHMENT
Unpack and open each softbox with care.
Softboxes will open rapidly after tight packaging.
OPEN & UNFOLD SOFTBOX
Line up softbox opening with LED light head, and stretch and pull over
the light head until it fits snugly over the light.
STRETCH SOFTBOX OPENING OVER LIGHT HEAD
Attach diffusion sheet to the front of the softbox by aligning the
Velcro edges to the corners of the softbox, and press firmly to
attach all edges.
ATTACH FRONT DIFFUSER TO SOFTBOX VELCRO EDGES
