Code WingMan Flex Series Installation And Operation Instructions Manual

Interior lighting system

Advertisement

Quick Links

IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury, and/
or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understood the safety information
contained in this manual.
1.
Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2.
Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3.
This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including fire.
4.
Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of
the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without
losing eye contact with the roadway.
5.
It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),
people, vehicles or other obstructions.
6.
The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.
Never take the right-of-way for granted. It is the vehicle operator's responsibility to be sure they can proceed safely before entering an
intersection, drive against traffic, respond at a high rate of speed, or walk on or around traffic lanes.
7.
This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specifications:
Options:
18 LED Multi Color:
Size:
LONG VERSION:
SHORT VERSION:
MINI VERSION:
Weight:
LONG VERSION:
SHORT VERSION:
MINI VERSION:
Input Voltage:
Installation and Operation Instructions
Red/Blue,
Red/Amber,
Blue Amber,
Red/White,
Blue/White
43.00"L X1.38"H X8.00" D
22.13"L X1.38"H X8.00" D
11.25"L X1.38"H X8.00" D
7.5 lbs
5.5 lbs
4.0 lbs
12VDC
WingMan Flex™ Series
Interior Lighting System
Input Current
(8) Light Hd
@ Startup:
LONG VERSION:
(6) Light Hd
LONG VERSION:
(4) Light Hd
SHORT VERSION:
(2) Light Hd
MINI VERSION:
Input Current
(8) Light Hd
@ Power:
LONG VERSION:
(6) Light Hd
LONG VERSION:
(4) Light Hd
SHORT VERSION:
(2) Light Hd
MINI VERSION:
Input Current
(8) Light Hd
@ Max:
LONG VERSION:
(6) Light Hd
LONG VERSION:
(4) Light Hd
SHORT VERSION:
(2) Light Hd
MINI VERSION:
0.007 Amps
0.007 Amps
0.007 Amps
0.007 Amps
0.005 Amps
0.005 Amps
0.005 Amps
0.005 Amps
11.30 Amps
9.20 Amps
6.60 Amps
3.40 Amps
Page 1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WingMan Flex Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Code WingMan Flex Series

  • Page 1 Installation and Operation Instructions WingMan Flex™ Series Interior Lighting System IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user. WARNING! Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury, and/ or death to those you are seeking to protect! Do not install and/or operate this safety product unless you have read and understood the safety information contained in this manual.
  • Page 2: Installation And Mounting Instructions

    Bracket Identification: SHORT VERSION MINI VERSION MOUNTING BRACKET ALL VERSIONS LONG VERSION Installation and Mounting Instructions: CAUTION! When drilling into any vehicle surface, make sure that the area is free from any electrical wires, fuel lines, vehicle upholstery, etc. that could be damaged.
  • Page 3: Wiring Instructions

    Wiring Instructions: It is advisable to leave an extra loop of cable when installing the light bar to allow for future changes or reinstallations.Connect the wires in the cable for the WingMan Flex Version you are installing as shown in the following diagrams. Notes: Larger wires and tight connections will provide longer service life for components.
  • Page 4: Driver Side

    8 Lighthead Single Color Independent Flashing Version: ALL COLORED WIRES BELOW CONNECT TO +12VDC BLACK WIRE CONNECTS TO -GROUND "DO NOT CONNECT UNUSED WIRES TO POWER" PURPLE BROWN/WHITE BROWN LIGHT BLUE RED/WHITE ORANGE DRIVER SIDE PASSENGER SIDE WHITE GREEN/WHITE WIRING DIAGRAM 6 Lighthead Single Color Independent Flashing Version: (8) LIGHT HEAD VERSION - SINGLE COLOR INDEPENDANT FLASHING ALL COLORED WIRES BELOW CONNECT TO +12VDC...
  • Page 5: Passenger Side

    2 Lighthead Single Color Flashing and 2 Lighthead Single Color Independent Flashing Version: RED----------------CONNECT TO +12VDC BLACK------------CONNECT TO - GROUND WHITE-------------CONNECT TO +12VDC FOR DIMMING FUNCTION DRIVER SIDE PASSENGER SIDE WIRING DIAGRAM 8 Lighthead Single Color Narrowstik Controlled Version & (2) LIGHT HEAD - SINGLE COLOR FLASHING VERSION &...
  • Page 6 Fusing Instructions (Independent Flashing Units): LED Fusing Considerations Although the average current draw per module is very low, due to the type of circuit used to power each module, the instantaneous peak current to a module can be significantly higher during low voltage conditions. To avoid prematurely blowing ATO style fuses or tripping breakers it is recommended the following rule-of-thumb be used to size fuses or breakers.
  • Page 7 Scene Steady ArrowStik Pattern ArrowStik Speed All Primary Build - DEFAULT All Secondary - DEFAULT Build 3 Flash Travel 3 Flash Build / Collapse ArrowStik Overrides All Other functions Scene Steady Overrides L1 & L2 Flashing Changing Flash Patterns: To change the flash patterns on the LED Light Heads, remove the mounting screws that attach the Cover to gain access to the printed circuit boards inside (see the exploded view on page 11).
  • Page 8: Troubleshooting

    Troubleshooting: All WingMan Rear Bars are thoroughly tested prior to shipment. However, should you encounter a problem during installation or during the life of the product, follow the guide below for information on repair and troubleshooting. Additional information may be obtained from the factory technical help line at 314-996-2800.
  • Page 9 Chassis SHORT Version 220-0681-00 Chassis MINI Version 220-0680-00 18LED Multi Color Light Head Module Contact Code 3, Inc for P/N Up to 8 9LED Single Color Light Head Module Contact Code 3, Inc for P/N Up to 8 6LED Single Color Light Head Module...
  • Page 10 Notes: Page 10 of 12...
  • Page 11 Notes: Page 11 of 12...
  • Page 12: Exclusion Of Other Warranties

    *Code 3®, Inc. reserves the right to repair or replace at its discretion. Code 3®, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring service and/or repair.;...
