Thank you very much for purchasing PR5300 soft starter.
This User's Manual provides the users with the instructions on the installation,
parameter setting, error diagnosis, remote control software instruction, routine
maintenance and necessary precautions. Please read the Manual carefully before the
installation of the product in order to ensure that it can be correctly installed and
operated.
Please contact Powtran's dealers or directly contact with the company if you have
difficult questions during the use of the soft starter , our professional staff is willing to
serve for you.
Please leave this manual to the end user and keep it in good condition for the future
maintenance and other application occasions . Please fill in the warranty card then fax to
the distributor or fax to Powtran if there is quality problem during the warranty period.
During this product updating period, some details may be changed without prior
notice. If you want to get the latest information, please visit our website.
For other products' information, Please visit our homepage:
http://www.powtran.com
Foreword
Powtran
January , 2018
Advertisement
Table of Contents
Related Manuals for Powtran PR5300
Summary of Contents for Powtran PR5300
- Page 1 . Please fill in the warranty card then fax to the distributor or fax to Powtran if there is quality problem during the warranty period. During this product updating period, some details may be changed without prior notice.
-
Page 2: Table Of Contents
Chapter 1 The introduction of PR5300 soft starter ..........1 1-1. The feature of the PR5300 soft starter ........... 1 1-2. The main function of the PR5300 soft starter ........1 1-3. The main features of the PR5300 soft starter ........1 Chapter 2 Product model description and open - package inspection .... - Page 3 Safety precautions Thank you very much for purchasing PR5300 soft starter. Under the soft starter installation, using and maintenance of process must pay attention to the following. Please be sure to read the instructions before installation. the soft starter must be installed by the professional technical personnel.
-
Page 5: Chapter 1 The Introduction Of Pr5300 Soft Starter
Chapter 1 The introduction of PR5300 soft starter 1-1.The feature of the PR5300 soft starter PR5300 series intelligent motor soft starter is the integration of new equipment for the new motor control theory and specialized motor protection technology and advanced software technology, is early for starting motor star /delta conversion and self coupling voltage, magnetron step-down starting equipment, the ideal alternative products;... - Page 6 Chapter 1 The introduction of PR5300 soft starter Proprietary motor starting and protection technology. Unique testing debugging equipment and process. ● Swift thoughtful after-sales service: Reliable performance and quality lay the foundation of excellent service. Provide excellent perfect supporting design scheme.
-
Page 7: Chapter 2 Product Model Description And Open - Package Inspection
500: 500kW 2-2.The steps of open - package inspection Each PR5300 series soft starter is under strict inspection and testing before they leave the factory. Users received the products and unpacked, please follow the inspection steps , if found problem, please contact the supplier promptly. -
Page 8: Chapter 3 The Conditions Of Use And Installation Requirements
Chapter 3 The conditions of use and installation requirements PR5300 series soft starter should comply with the following conditions of use and installation requirements; otherwise, the performance will not guarantee, it can shorten life of soft starter even damage. 3-1.The conditions of use of the soft starter 3-1-1. -
Page 9: The Appearance And Installation Dimension Of The Soft Starter
3-3.The appearance and installation dimension of the soft starter PR5300 series 132kW-500kW soft starter appearance and installation dimensions are as follows. PR5300 series 132kW-500kW soft start, its factory standard configuration for three-six. The rated power and rated current is max rated value of soft starter. Usually, matching the corresponding parameter of motor shall not be more than this value. - Page 10 Chapter 3 The conditions of use and installation requirements G2 series Rated Rated Dimension(mm) Installation(mm) Model Power current Net (kg) (kW) ＜7.8 PR5300 7R5G2 242.5 188.5 ＜7.8 PR5300 011G2 242.5 188.5 ＜7.8 PR5300 015G2 242.5 188.5 ＜7.8 PR5300 018G2 18.5 242.5...
- Page 11 Chapter 3 The conditions of use and installation requirements Shape and mounting dimension for PR5300G3 132-500kW: G2 series Rated Rated Dimension(mm) Installation(mm) Model Power current (kg) (kW) ＜40 PR5300 075G2 ＜40 PR5300 090G2 ＜40 PR5300 115G2 ＜40 PR5300 132G2 ＜49 PR5300 160G2 ＜49 PR5300 185G2 ＜49 PR5300 200G2...
- Page 12 Chapter 3 The conditions of use and installation requirements G4 series Rated Rated Dimension(mm) Installation(mm) Model Power current (kg) (kW) ＜40 PR5300 132G4 ＜40 PR5300 160G4 ＜40 PR5300 185G4 ＜40 PR5300 200G4 ＜40 PR5300 250G4 ＜49 PR5300 280G4 ＜49 PR5300 320G4 ＜80...
-
Page 13: Chapter 4 Main Circuit And Terminal Wiring
Chapter 4 Main circuit and terminal wiring PR5300 series soft starter has two kinds of wiring: The main circuit wiring: Three phase power input and output to the motor wiring and coil in line circuit breaker, bypass contactor wiring. - Page 14 K stop Figure 4- 3 The main circuit and secondary wiring diagram of PR5300 series soft starter are shown in Figure 4.4 below. Soft starter terminals R, S and T are connected with three-phase power supply, and soft starter...
- Page 15 Chapter 4 Main circuit and terminal wiring Figure 4- 4...
-
Page 16: Chapter 5 Control Panel And Operation
Chapter 5 Control panel and operation PR5300 series soft starter has 5 kinds of working state: Preparation, operation, fault, start and stop. Different indicate light show at preparation, operation and fault. When starting to show XXXX, soft stop display: -XXX, XXXXX means motor current. -
Page 17: Function Parameters Setting And Description
Chapter 5 Control panel and operation 5-2.Function parameters setting and description Function parameters code in the following table Code Setting Description Range of Factory Code Name Explanation set value setting Voltage slope model is effective, the Starting voltage 30-70% starting voltage of current mode is 40%. -
Page 18: Programmable Relay Output Functions
Chapter 5 Control panel and operation Code Setting Description Range of Factory Code Name Explanation set value setting limit Rated Used to input motor nominal is rated Motor rated current 11-998A value current. Bypass delay 0-40S Used to set the delay time of Bypass Allowed three-phase 0 or 1 0:Forbid,1:Allow... -
Page 19: Other Settings Description
Chapter 5 Control panel and operation closed state before power on, soft starter will not respond the command , you must cancel the running command by one time ,then give it run command again to make the soft starter work. When soft starter fault reset, continuous running command is valid. -
Page 20: Chapter 6 Protection And Description
These time parameters are from tested effective signal to a tripping protection instructions, and the parameters just for reference. All the protection functions of PR5300 series soft starter can be verified through the actual or simulation method. If it can't meet the user's requirements, special protection device should be added to ensure safety. - Page 21 Chapter 6 Protection and description Diagram 6.1 PA setting Description (Primary) (Light load) (Standard) (Heavy load) (High grade) Running According to overload 2 level 10 level 20 level 10 level IEC60947-4-2 Level of Standard rotection Starting Start over- current for current more than 3 seconds...
-
Page 22: Chapter 7 Test Runing And Application
Chapter 7 Test runing and application Double-check before power running according to the following terms: Whether the soft starter power match with the motor rated power. Whether the motor insulation satisfy the requirements. Whether the Input and output main circuit wiring is correct. Whether all the terminal screws are tightened. -
Page 23: Pr5300 Series Soft Starter Starting Mode And Application
7-2.PR5300 Series soft starter starting mode and application PR5300 series soft starter has six models to suit a variety of complex starter motor and load conditions, the user can choose it as different application. PR5300 series soft starter has six models to suit a variety of complex starter motor and load conditions, the user can choose it as different application. -
Page 24: Pr5300 Series Soft Starter's Stop Mode And Application
7-3.PR5300 series soft starter's stop mode and application PR5300 series soft starters, there are two stop modes, soft-stop mode and free stop mode. 7-3-1.Soft stop mode When Setting item P2 is not zero, set the stop mode for this mode. -
Page 25: Special Application
7-4-2.Two-speed motor start: PR5300 series soft starter can start with two-speed motor, before changing from low speed to high speed, must be solved by delayed magnetic period, to avoid a very large reverse current between the line and the motor. - Page 26 Chapter 7 Test runing and application Mixer Crusher Screw compressor Screw conveyor Light load motor Belt conveyors Heat pump...
-
Page 27: Chapter 8 Rs485 Communication
Chapter 8 RS485 communication Powtran PR5300 series soft starter with built-in RS485 standard interface which can be communicated with the PC and PLC host . It Can be controlled by the host command of soft starter run/stop, monitoring the running state of soft starter and modify its function data, and so on. -
Page 28: Exception Reponse
Chapter 8 RS485 communication Keep the mold To reset the starter 3-15 Unused Example: Starting from the soft starter of standing 02, the controller sends 02 06 00 01 00 01, such as command execution, normal return 02 06 00 01 00 01.Starter can normal starting to view the status register, if there is a failure, should send 02 06 00 01 00 04 to reset 0002 Status register Digit... -
Page 29: Using The Matters Need Attention
Chapter 8 RS485 communication 8-3-1.Illegal function code 01 The main inquiry message format: Start Start Register Register Sub station Function address address number number address code check low byte low byte high 0x01 0x08 0x00 0x80 0x00 0x0d This agreement is not used 0 x08 function code, so the subordinate standing response: Sub station address Function code Abnormal code... -
Page 30: Chapter 9 Fault Causes And Treatment
Chapter 9 Fault causes and treatment Fault codes and treatment as following table: Display Description Problems and treatment methods Just happened undervoltage, overvoltage or overheating, Failure has been Err00 instantaneous stop terminals are open, such failures, now has solved been normal, this time to prepare lights, reset to start the motor. External terminal Short-circuit connection with the external Instantaneous stop Err01... -
Page 31: Chapter 10 Soft Starting Model Specifications And Options
Chapter 10 Soft starting model specifications and options PR5300 soft starter list of external accessories specifications reference: Rated Rated By-pass MCCB Model power curre contactor A line size model (QF) (kW) nt(A) model (KM) PR5300 011G3 6mm² Cable PR5300 015G3 10mm²... -
Page 32: Chapter 11 Warranty
4. About the repair fee, according to our company latest price list as a standard. 5. When the products is broken, please complete the form and warranty card, shipping with the failure machine to our company. 6. Dalian Powtran Technology Co.,Ltd reserve the right to explain the terms of the event. - Page 33 Thank you for your attention and purchasing POWTRAN technology products! In order to serve you better, we hope to get your personal general information about using POWTRAN technology products, your now and future demand on POWTRAN technology products, gain for your valuable feedback.
