Genesys Spynamics SD Series User Instructions

USER INSTRUCTIONS FOR SD CHAIR
When you are sat in your chair there are 3 levers and a rod on the right side of your seat
and a bar under the front edge.
The bar under the front
edge is for sliding the seat
forward or back.
The rod at the front right
hand corner pulls in or out
to control the forward (-ve)
tilt of the seat.
The 3 levers to the side:
The front lever controls
the seat tilt
The middle lever controls
the gas lift for seat height
adjustment
The back lever adjusts the
angle of the backrest.
There is wording on the handles to help
Our recommended order of adjustments for the user is as

Seat height: `

To raise the seat up lift the gas lift lever when not seated.
To lower the seat, lift the lever with your weight in the chair.

Seat depth:

Use the bar at the front of the seat similarly to the mechanism in car seats; lift the bar and slide
your bottom forward or back to increase or decrease the seat depth.

The Mechanism

follows:
The tension of the tilt is controlled
by the handwheel under the seat.
