Procedure for the Installation of the

RADF Paper Feed Maintenance Kit

Step 1

Unit Disassembly, Part Replacement

Step 2

PM Counter Reset

PN: 45735719

DF-KIT-3018

KIT: PERIODICAL MAINTENANCE

DF-KIT-3018

ES9465/ES9475 MFP

Pick up roller

Feed roller

Separation roller

ASYS-ROL-FEED

ASYS-ROL-RET

Need help?

Do you have a question about the ES9465 MFP and is the answer not in the manual?

Page 1 Procedure for the Installation of the RADF Paper Feed Maintenance Kit ES9465/ES9475 MFP Step 1 Unit Disassembly, Part Replacement Step 2 PM Counter Reset Pick up roller ASYS-ROL-FEED PN: 45735719 Feed roller ASYS-ROL-FEED DF-KIT-3018 KIT: PERIODICAL MAINTENANCE DF-KIT-3018 Separation roller ASYS-ROL-RET...
Page 2 Step 1 – Unit Disassembly, Part Replacement Open the jam access cover. Remove Remove 1 clip and slide 2 Take off the paper feeder unit. 2 screws and take off the bracket. bushings. Remove 1 clip and pull out the shaft. Take off the pickup roller and replace it.
Page 3 Step 2 - PM Counter Reset (1)Enter PM Support Mode Enter Service Mode [6]+[START]+[POWER]ON (2)Authentication screen If a service password has been registered enter the service password and select “OK”. If a service password has NOT been registered leave password blank and select “OK”. (3)Use the page down to go to page 3 of 4.
Page 4 (4)Select “INITIALIZE”. This function resets: • Pick up Roller • Feed Roller • Separation Roller (5) Once completed turn the main power switch OFF/ON.
