Page 2
SIPP Oil Cell ....................... 11 Warranty ......................... 12 Support ........................13 Appendix I – SIPP Node 400 parts ..................14 Appendix II – SIPP Node filter change ................15 Appendix III – Status of a SIPP Node filter ................ 16 Appendix IV –...
Page 3
Manual SIPP Node EN, Juni 2, 2015 Beneath a field power transformer there is an oil catch pit, used in case of a transformer breakdown followed by heavy leakage of cooling oil. The pit secures the leaked oil and protects the surrounding environment.
Page 4
The flowmeter ensures that there is a flow through the measuring cell during the discharge. Valves The valves’ main task is to ensure that clean water is pumped out of the pit and oily water is returned to the pit. See appendix I for an overview of the SIPP Node 400 parts.
Page 5
Note : If the device after a hard or soft reset meet the requirements to start a discharge that is done instead of purge . At each discharge a functional test is performed. The SIPP Node 400 tries to start a discharge up to three times before it enters alarm mode.
Page 6
Manual SIPP Node EN, Juni 2, 2015 When SIPP Node starts a discharge, data regarding start time and date is stored. It also stores information about the identity of the SIPP and identity information for the station and pit. The entire discharge process is then logged with minute resolution.
Page 7
Manual SIPP Node EN, Juni 2, 2015 A Basic Service and Support agreement is signed by the buyer of the SIPP Node 400 unit with Industriarmatur (IA). The following services are included in the agreement: Access to the SIPP Warehouse for one (1) user.
Page 8
The address to the web interface is: http://swh.apps.iowa.se http://www.industriarmatur.se/ and click on SIPP Warehouse login All customers get their own login to their connected products. Trained service technicians get their own login to those products the service technician is responsible for.
Page 9
Only authorised personnel are allowed to open the unit’s electronic device. The maintenance for the SIPP Node 400 should be done on a regular basis. We recommend that the condition of the unit and pit is controlled at each inspection of the station and documented according to appendix V.
Page 10
Manual SIPP Node EN, Juni 2, 2015 Filter Filter change unit Push the upper part on top of the black connector and the filter and remove the gray angeled connectors. Remove the filter from holder pulling outwards. Attache the new filter in the holder. Check the flow direction –...
Page 11
Install a prefilter to solve the problem. Contact Industriarmatur for support. Check the status of the filter. If the SIPP Node does not start, make sure that the SIPP Node 400 is connected to the main power and that all start criteria are met.
Page 12
Manual SIPP Node EN, Juni 2, 2015 Table 1. Specification for SIPP Node 400 Parameter Specification Power supply 230 V, 50/60 Hz, 2 A Protection class IP 56 Type approvals Pump capacity 5 l/min Temperature range Water 1-60C Temperature range SIPP -20..40C...
Page 13
Manual SIPP Node EN, Juni 2, 2015 Industriarmatur Sweden AB gives 12 months warranty for production and material faults if such fault is given to Industriarmatur Sweden AB within 12 months from delivery. Faults caused by wrong handling and maintenance or over voltages are not included in warranty.
Page 14
Manual SIPP Node EN, Juni 2, 2015 Industriarmatur Sweden AB Kämpegatan 16 411 04 Göteborg SWEDEN Phone: +46 31 80 95 50 E-mail: support@industriarmatur.se Web: www.industriarmatur.se...
Page 15
Manual SIPP Node EN, Juni 2, 2015 1. Mounting plate 2. Mounting bracket 3. Control unit 4. Angled bracket 5. Filter clamp 6. Filter unit 7. Hook 8. Circuit breaker 9. Cable gland PG13 10. Flow unit 11. Mounting post 12.
Page 16
7. Verify that there is no leakage in the system and that the unit after the start up sequence discharge through the GREEN hose. 8. For questions or problems contact support! Contact us at support@industriarmatur.se eller or +46 31-80 95 50.
Page 17
Manual SIPP Node EN, Juni 2, 2015 Filter example 3 Filter example 4 Filter example 1 Filter example 2 1. A filter that works well. The water level in the filter after pumping is under the edge. 2. To the left, a used filter that needs to be replaced, to the right a brand new filter. 3.
Page 18
8. Verify that there is no leakage in the system and that the unit after the start up sequence discharge through the GREEN hose. 9. For questions or problems contact support! Contact us at support@industriarmatur.se eller or +46 31-80 95 50.
Page 19
Manual SIPP Node EN, Juni 2, 2015 Unit ID: Date: 1. Visual control Unit dry inside Unit wet inside Gray and red hose Pass Fail Not clamped, fitted with proper inclination and outlet in pit without risk of ending up under water Green hose Pass Fail...
