ISD91200 Series Technical Reference Manual
®
®
ISD ARM
Cortex
-M0 SoC
ISD91200 Series
Technical Reference Manual
The information described in this document is the exclusive intellectual property of
Nuvoton Technology Corporation and shall not be reproduced without permission from Nuvoton.
Nuvoton is providing this document only for reference purposes of ISD ARM® Cortex®-M0
microcontroller based system design. Nuvoton assumes no responsibility for errors or omissions.
All data and specifications are subject to change without notice.
For additional information or questions, please contact: Nuvoton Technology Corporation.
Release Date: Sep 16, 2019
- 1 -
Revision 2.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISD91200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nuvoton ISD91200 Series

  • Page 1 The information described in this document is the exclusive intellectual property of Nuvoton Technology Corporation and shall not be reproduced without permission from Nuvoton. Nuvoton is providing this document only for reference purposes of ISD ARM® Cortex®-M0 microcontroller based system design. Nuvoton assumes no responsibility for errors or omissions.
  • Page 2: Table Of Contents

    ISD91200 Series Technical Reference Manual Table of Contents- TABLE OF CONTENTS- ......................2 GENERAL DESCRIPTION ....................11 FEATURES ........................12 PART INFORMATION AND PIN CONFIGURATION ............16 Pin Configuration ....................16 Pin Description ....................... 17 BLOCK DIAGRAM ......................22 FUNCTIONAL DESCRIPTION..................23 ®...
  • Page 3 ISD91200 Series Technical Reference Manual 5.7.4 PWM-Timer Operation ..................... 174 5.7.5 PWM Double Buffering, Auto-reload and One-shot Operation ........176 5.7.6 Modulate Duty Cycle....................176 5.7.7 Dead-Zone Generator ....................177 5.7.8 Capture Timer Operation ..................178 5.7.9 PWM-Timer Interrupt Architecture ................179 5.7.10...
  • Page 4 ISD91200 Series Technical Reference Manual 5.13.3 Block Diagram ....................... 289 5.13.4 IrDA Mode ......................291 5.13.5 LIN (Local Interconnection Network) mode ............. 293 5.13.6 Register Map ......................294 5.13.7 Register Description ....................295 5.14 I2S Audio PCM Controller ..................314 5.14.1...
  • Page 5 ISD91200 Series Technical Reference Manual 7.2.1 Functional Description ..................... 390 7.2.2 Features........................390 7.2.3 Block Diagram ......................390 7.2.4 Operation ........................ 391 7.2.5 Register Map ......................392 7.2.6 Register Description ....................393 Audio Class D Speaker Driver (DPWM)..............398 7.3.1 Functional Description .....................
  • Page 6 ISD91200 Series Technical Reference Manual ORDERING INFORMATION ..................471 REVISION HISTORY ..................... 472 IMPORTANT NOTICE ......................473 Release Date: Sep 16, 2019 - 6 - Revision 2.4...
  • Page 7 ISD91200 Series Technical Reference Manual Figure of Contents- Figure 4-1 ISD91200 Block Diagram ..................22 Figure 5-1 Functional Block Diagram ..................23 Figure 5-2 ISD91200 Power Distribution Diagram ...............26 Figure 5-3 Clock generator block diagram ................111 Figure 5-4 System Clock Block Diagram...................112 Figure 5-5 SysTick Clock Control Block Diagram ..............112...
  • Page 8 ISD91200 Series Technical Reference Manual Figure 5-36 SPI Slave Mode Application Block Diagram ............219 Figure 5-37 Word Sleep Suspend Mode ...................221 Figure 5-38 Byte Re-Ordering Transfer..................221 Figure 5-39 Byte Order in Memory ...................222 Figure 5-40 Byte Order in Memory ...................223 Figure 5-41 2-Bit Mode System Architecture ................225...
  • Page 9 ISD91200 Series Technical Reference Manual Figure 5-74 IrDA Block Diagram ....................291 Figure 5-75 IrDA Tx/Rx Timing Diagram ...................292 Figure 5-76 Structure of LIN Frame ..................293 Figure 5-77 I2S Clock Control Diagram ..................315 Figure 5-78 I2S Controller Block Diagram .................315 Figure 5-79 I2S Bus Timing Diagram (Format =0) ..............316 Figure 5-80 MSB Justified Timing Diagram (Format=1) ............316...
  • Page 10 ISD91200 Series Technical Reference Manual Figure 7-26 A/D Controller Interrupt ..................456 Figure 7-27 Conversion Result Mapping Diagram of Single-end Input ........459 Release Date: Sep 16, 2019 - 10 - Revision 2.4...
  • Page 11: General Description

    ISD91200 Series Technical Reference Manual GENERAL DESCRIPTION The ISD91200 series is a system-on-chip product optimized for low power, audio record and playback with an embedded ARM® Cortex™-M0 32-bit microcontroller core. The ISD91200 device embeds a Cortex™-M0 core running up to 50 MHz with 64K/128Kbyte of non- volatile flash memory and 12K-byte of embedded SRAM.
  • Page 12: Features

    ISD91200 Series Technical Reference Manual FEATURES • Core – ARM® Cortex™-M0 core running up to 50 MHz for normal speed. – One 24-bit System tick timer for operating system support. – Supports a variety of low power sleep and power down modes.
  • Page 13 ISD91200 Series Technical Reference Manual • Audio Analog to Digital converter – Sigma Delta ADC with configurable decimation filter and 16 bit output. – 90dB Signal-to-Noise (SNR) performance. – Programmable gain amplifier with 32 steps from -12 to 35.25dB in 0.75dB steps.
  • Page 14 ISD91200 Series Technical Reference Manual – Full duplex synchronous serial data transfer – Variable length of transfer data from 1 to 4 bytes – MSB or LSB first data transfer – 2 slave/device select lines when used in master mode.
  • Page 15 ISD91200 Series Technical Reference Manual – Digital Microphone interface. • Standby current in STOP mode with SRAM retention <=10µA at 25°C. • Operating Temperature: -40C~85C • Package: – All Green package (RoHS) LQFP 64-pin  Release Date: Sep 16, 2019 - 15 - Revision 2.4...
  • Page 16: Part Information And Pin Configuration

    ISD91200 Series Technical Reference Manual PART INFORMATION AND PIN CONFIGURATION Pin Configuration GPIOB<6> GPIOB <5> GPIOB <4> VCCA GPIOB <3> VCCLDO GPIOB<2> VLDOx GPIOB <1> GPIOA <0> GPIOB <0> GPIOA<1> I 91200 GPIOA<2> GPIOA <3> VDDL/ VREG GPIOA<4> GPIOA <11>...
  • Page 17: Pin Description

    ISD91200 Series Technical Reference Manual Pin Description The ISD91200 is a low pin count device where many pins are configurable to alternative functions. All General Purpose Input/Output (GPIO) pins can be configured to alternate functions as described in the table below.
  • Page 18 ISD91200 Series Technical Reference Manual Pin No. Pin Name Pin Type Alt CFG Description LQFP SPI1_SSB Slave Select Bar for SPI1 interface PA.7 General purpose input/output pin; Port A, bit 7 UART0_RX Receive channel of UART 0 I2C0_SCL Serial Clock, I2C interface...
  • Page 19 ISD91200 Series Technical Reference Manual Pin No. Pin Name Pin Type Alt CFG Description LQFP PA.15 General purpose input/output pin; Port A, bit 15 UART1_RX Receive channel of UART 1 MCLK Master clock output for synchronizing external device XO32K 32.768kHz Crystal Oscillator Output ICE_DAT Serial Wire Debug port clock pin.
  • Page 20 ISD91200 Series Technical Reference Manual Pin No. Pin Name Pin Type Alt CFG Description LQFP Operational Amplifier 1 positive input PB.4 General purpose input/output pin, analog capable; Port B, bit 4 I2S0_FS Frame Sync Clock for I2S interface Touch scan channel 4 Operational Amplifier 1 negative input PB.5...
  • Page 21 ISD91200 Series Technical Reference Manual Pin No. Pin Name Pin Type Alt CFG Description LQFP CMP2 Compare 2 Output I2S0_SDO Serial Data Output for I2S interface UART1_RX Receive channel of UART 1 CS11 Touch scan channel 11 SAR3 SARADC channel 3 PB.12...
  • Page 22: Block Diagram

    ISD91200 Series Technical Reference Manual BLOCK DIAGRAM 50MHz Internal Osc. CLK CTRL Debug interface 32kHz RTC Osc 10kHz low power Osc Embedded Flash Cortex M0 128KB 12MHz Crystal Osc 12KB AHB Lite Peripherals with PDMA LDO 3.0V GPIO PDMA LDO 1.5V...
  • Page 23: Functional Description

    ISD91200 Series Technical Reference Manual FUNCTIONAL DESCRIPTION ® Cortex™-M0 core The Cortex™-M0 processor is a multistage, 32-bit RISC processor. It has an AMBA AHB-Lite interface and includes an NVIC component. It also has hardware debug functionality. The processor can execute Thumb code and is compatible with other Cortex-M profile processor.
  • Page 24 ISD91200 Series Technical Reference Manual – Two watchpoints. – Program Counter Sampling Register (PCSR) for non-intrusive code profiling. – Single step and vector catch capabilities. • Bus interfaces: – Single 32-bit AMBA-3 AHB-Lite system interface that provides simple integration to all system peripherals and memory.
  • Page 25: System Manager

    ISD91200 Series Technical Reference Manual System Manager 5.2.1 Overview The following functions are included in system manager section  System Memory Map  System Timer (SysTick)  Nested Vectored Interrupt Controller (NVIC)  System management registers for product ID ...
  • Page 26: System Power Distribution

    ISD91200 Series Technical Reference Manual 5.2.3 System Power Distribution The ISD91200 implements several power domains:  Analog power from VCCA and VSSA provides the power for analog module operation.  Digital power from VCCD and VSSD supplies the power to the IO ring and the internal regulator which provides 1.5V power for digital operation.
  • Page 27: System Memory Map

    ISD91200 Series Technical Reference Manual 5.2.4 System Memory Map The ISD91200 provides 4G-byte address space. The memory locations assigned to each on-chip module is shown in Table 5-1. The detailed register definition, memory space, and programming detailed will be described in the following sections for each on-chip module. The ISD91200 supports little-endian data format.
  • Page 28 ISD91200 Series Technical Reference Manual 0x400B_00A0 - 0x400B_00AF VOLCTRL_BA Volume Control Registers 5.16.2 0x400D_0000 – 0x400D_3FFF CSCAN_BA CAP SENSE Control Registers 7.6.6 0x400E_0000 – 0x400E_FFFF SDADC_BA Analog-Digital-Converter (ADC) Registers 7.1.5 0x400F_0000 – 0x400F_7FFF SBRAM_BA Standby RAM Block Address space System Control Space (0xE000_E000 ~ 0xE000_EFFF) 0xE000_E010 –...
  • Page 29: System Manager Control Registers

    ISD91200 Series Technical Reference Manual 5.2.5 System Manager Control Registers Register Offset Description Reset Value SYS Base Address: SYS_BA = 0x5000_0000 SYS_PDID SYS_BA+0x00 Product ID 0xXXXX_XXXX SYS_RSTSTS SYS_BA+0x04 System Reset Source Register 0x0000_0XXX SYS_IPRST0 SYS_BA+0x08 IP Reset Control Resister0 0x0000_0000...
  • Page 30 ISD91200 Series Technical Reference Manual Product Identifier Register (SYS_PDID) This register provides specific read-only information for software to identify this chip. Register Offset Description Reset Value SYS_PDID SYS_BA+0x00 Product ID 0xXXXX_XXXX PDID[31:24] PDID[23:16] PDID[15:8] PDID[7:0] Table 5-2 System Product Identifier Register (SYS_PDID, address 0x5000_0000) Bit Description.
  • Page 31 ISD91200 Series Technical Reference Manual System Reset Source Register (SYS_RSTSTS) This register provides specific information for software to identify this chip’s reset source from last operation. Register Offset Description Reset Value SYS_RSTSTS SYS_BA+0x04 System Reset Source Register 0x0000_0XXX Reserved Reserved...
  • Page 32 ISD91200 Series Technical Reference Manual Reset Source From CPU The CPURF flag is set by hardware if software writes CPURST (SYS_IPRST0[1]) with a “1” to reset Cortex-M0 CPU kernel and Flash memory controller (FMC). CPURF 0= No reset from CPU.
  • Page 33 ISD91200 Series Technical Reference Manual IP Reset Control Register1(SYS_IPRST0) Register Offset Description Reset Value SYS_IPRST0 SYS_BA+0x08 IP Reset Control Resister0 0x0000_0000 Reserved PDMARST CPURST CHIPRST Table 5-4 IP Reset Control Register 1 (SYS_IPRST0 address 0x5000_0008) Bit Description. Bits Description [31:3] Reserved Reserved.
  • Page 34 ISD91200 Series Technical Reference Manual IP Reset Control Register1 (SYS_IPRST1) Setting these bits “1” will generate an asynchronous reset signal to the corresponding peripheral block. The user needs to set bit to “0” to release block from the reset state.
  • Page 35 ISD91200 Series Technical Reference Manual UART1 Controller Reset [17] UART1RST 0=Normal Operation. 1=Reset. UART0 Controller Reset [16] UART0RST 0=Normal Operation. 1=Reset. [15:14] Reserved DPWM Speaker Driver Reset [13] DPWMRST 0=Normal Operation. 1=Reset. SPI0 Controller Reset [12] SPI0 RST 0=Normal Operation.
  • Page 36 ISD91200 Series Technical Reference Manual GPIOA Input Type Control Register (SYS_GPSMTEN) Register Offset Description Reset Value SYS_GPSMTEN SYS_BA+0x30 GPIOA/B input type control register 0xFFFF_0000 HSGPBG3 SSGPBG3 HSGPBG2 SSGPBG2 HSGPBG1 SSGPBG1 HSGPBG0 SSGPBG0 HSGPAG3 SSGPAG3 HSGPAG2 SSGPAG2 HSGPAG1 SSGPAG1 HSGPAG0 SSGPAG0...
  • Page 37 ISD91200 Series Technical Reference Manual this Register Controls Whether the GPIO Input Buffer Schmitt Trigger Is Enabled and Whether High or Low Slew Rate Is Selected for Output Dr. SSGPBG1 Each bit controls a group of four GPIO pins [26] 1 = GPIOB 7/6/5/4 input Schmitt Trigger enabled.
  • Page 38 ISD91200 Series Technical Reference Manual this Register Controls Whether the GPIO Input Buffer Schmitt Trigger Is Enabled and Whether High or Low Slew Rate Is Selected for Output Dr. HSSGPAG0 Each bit controls a group of four GPIO pins [17] 1 = GPIOA 3/2/1/0 Output high slew rate.
  • Page 39 ISD91200 Series Technical Reference Manual GPIO Alternative Function Control Register (SYS_GPA_MFP, SYS_GPB_MFP) Each GPIO pin can take on multiple alternate functions depending on the setting of this register. Each pin has two bits of alternate function control. Set to 00 the pin is a standard GPIO pin whose attributes are defined by the GPIO control registers (See Section 0).
  • Page 40 ISD91200 Series Technical Reference Manual Alternate Function Setting for PA11MFP 00 = GPIO. [23:22] PA11MFP 01 = PWM0CH1. 10 = TM1. 11 = DPWM_M. Alternate Function Setting for PA10MFP 00 = GPIO. [21:20] PA10MFP 01 = PWM0CH0. 10 = TM0.
  • Page 41 ISD91200 Series Technical Reference Manual Alternate Function Setting for PA2MFP 00 = GPIO. [5:4] PA2MFP 01 = SPI0_SCLK0. 10 = DMIC_DAT. 11 = I2S0_SDI Alternate Function Setting for PA1MFP 00 = GPIO. [3:2] PA1MFP 01 = SPI0_MOSI0. 11 = I2S0_BCLK.
  • Page 42 ISD91200 Series Technical Reference Manual Alternate Function Setting for PB13MFP 00 = GPIO. [27:26] PB13MFP 01 = SPI0_MOSI0. 10 = SPI1_SCLK. 11 = SARADC_TRIG. Alternate Function Setting for PB12MFP 00 = GPIO. [25:24] PB12MFP 01 = SP0_MISO1. 10 = SPI1_MOSI.
  • Page 43 ISD91200 Series Technical Reference Manual Alternate Function Setting for PB2MFP [5:4] PB2MFP 00 = GPIO. 01 = SPI1_SSB. Alternate Function Setting for PB1MFP [3:2] PB1MFP 00 = GPIO. 01 = SPI1_SCLK. Alternate Function Setting for PB0MFP [1:0] PB0MFP 00 = GPIO.
  • Page 44 ISD91200 Series Technical Reference Manual GPIOB0 VCCD SPI1_MOSI O GPIOB1 VCCD SPI1_SCLK O SAR11 GPIOB2 VCCD SPI1_SSB GPIOB3 VCCD SPI1_MISO I GPIOB4 VCCD I2S0_FS SAR10 GPIOB5 VCCD I2S0_BCLK SAR8 GPIOB6 VCCD I2S0_SDI SAR9 GPIOB7 VCCD I2S0_SDO SAR0 GPIOB8 VCCD I2C0_SDA...
  • Page 45 ISD91200 Series Technical Reference Manual Protected Register Lock Key Register (SYS_REGLCTL) Certain critical system control registers are protected against inadvertent write operations which may disturb chip operation. These system control registers are locked after power on reset until the user specifically issues an unlock sequence to open the lock.
  • Page 46 ISD91200 Series Technical Reference Manual Oscillator Trim Control Register (SYS_IRCTCTL) The master oscillator of the I91200 has an adjustable frequency and can be controlled by the SYS_IRCTCTL register. This register contains the current scillator frequency trim value, which depends upon the setting of register CLK_CLKSEL0.HIRCFSEL register. If this register is 0, SYS_OSCTRIM0 trim is active, if 1 then SYS_OSCTRIM1 is active, if 2 then SYS_OSCTRIM2.
  • Page 47 ISD91200 Series Technical Reference Manual 10kHz Oscillator Trim Register (SYS_OSC10KTRIM) Register Offset Description Reset Value SYS_OSC10KTRIM SYS_BA+0x114 R/W 10kHz Oscillator (LIRC) Trim Register 0xXXXX_XXXX TRMCLK Reserved Reserved Reserved TRIM TRIM TRIM Bits Description [31] TRMCLK Must be toggled to( from 0 => 1 => 0) load a new OSC10K_TRIM...
  • Page 48 ISD91200 Series Technical Reference Manual Oscillator Trim 0 Control Register (SYS_OSCTRIM0) Register Offset R/W Description Reset Value SYS_OSCTRIM0 SYS_BA+0x118 R/W Internal oscillator trim register 0 0xXXXX_XXXX EN2MHZ Reserved Reserved TRIM TRIM Table 5-13 Oscillator Frequency Adjust Control Register (OSCTRIM0, address 0x5000_0118).
  • Page 49 ISD91200 Series Technical Reference Manual Oscillator Trim 1 Control Register (SYS_OSCTRIM1) Register Offset R/W Description Reset Value SYS_OSCTRIM1 SYS_BA+0x11C R/W Internal oscillator trim register 1 0xXXXX_XXXX EN2MHZ Reserved Reserved TRIM TRIM Table 5-14 Oscillator Frequency Adjust Control Register (OSCTRIM1, address 0x5000_011C).
  • Page 50 ISD91200 Series Technical Reference Manual Oscillator Trim 2 Control Register (SYS_OSCTRIM2) Register Offset R/W Description Reset Value SYS_OSCTRIM2 SYS_BA+0x120 R/W Internal oscillator trim register 2 0xXXXX_XXXX EN2MHZ Reserved Reserved TRIM TRIM Table 5-15 Oscillator Frequency Adjust Control Register (OSCTRIM, address 0x5000_0120).
  • Page 51 ISD91200 Series Technical Reference Manual XTAL32K Oscillator Control Register (SYS_XTALTRIM) Register Offset R/W Description Reset Value SYS_XTALTRIM SYS_BA+0x124 R/W External Crystal oscillator trim register 0xXXXX_XXXX Reserved Reserved SELXT Reserved LOWPWR Reserved Reserved Reserved Reserved Table 5-16 Xtal Trim Bits Description...
  • Page 52 ISD91200 Series Technical Reference Manual Reserved Register Offset R/W Description Reset Value Reserved R/W System reserved, keep POR value 0xXXXX_XXXX SYS_BA+0x128 Reserved Reserved Reserved Reserved Table 5-17 Factory Default Bits Description [31:0] Reserved This register is loaded with trim from manufacturing – do not modify.
  • Page 53: System Timer (Systick)

    ISD91200 Series Technical Reference Manual 5.2.6 System Timer (SysTick) The Cortex-M0 includes an integrated system timer, SysTick. SysTick provides a simple, 24-bit, clear-on-write, decrementing, wrap-on-zero counter with a flexible control mechanism. The counter can be used in several different ways, for example: ...
  • Page 54 ISD91200 Series Technical Reference Manual SysTick Control and Status (SYST_CSR) Register Offset Description Reset Value SYST_CSR SYSTICK_BA+0x10 R/W SysTick Control and Status Register 0x0000_0000 Table 5-18 SysTick Control and Status Register (SYST_CSR, address 0xE000_E010) Reserved Reserved COUNTFLAG Reserved Reserved CLKSRC...
  • Page 55 ISD91200 Series Technical Reference Manual SysTick Reload Value Register (SYST_RVR) Register Offset Description Reset Value SYST_RVR SYSTICK_BA+0x14 R/W SysTick Reload value Register 0xXXXX_XXXX Table 5-19 SysTick (SYST_RVR, address 0xE000_E014) Reload Value Register Reserved RELOAD[23:16] RELOAD[15:8] RELOAD[7:0] Bits Description [31:24] Reserved...
  • Page 56 ISD91200 Series Technical Reference Manual SysTick Current Value Register (SYST_CVR) Register Offset Description Reset Value SYST_CVR SYSTICK_BA+0x18 R/W SysTick Current value Register 0xXXXX_XXXX Table 5-20 SysTick Current Value Register (SYST_CVR, address 0xE000_E018) Reserved CURRENT [23:16] CURRENT [15:8] CURRENT[7:0] Bits Description...
  • Page 57: Nested Vectored Interrupt Controller (Nvic)

    5.2.7.1 Exception Model and System Interrupt Map The following table lists the exception model supported by ISD91200 series. Software can set four levels of priority on certain exceptions as well as on all interrupts. The highest user-configurable priority is denoted as “0” and the lowest priority is denoted as “3”. The default priority of all the user- configurable interrupts is “0”.
  • Page 58 ISD91200 Series Technical Reference Manual Table 5-21 Exception Model Exception Name Vector Number Priority Reset Hard Fault Reserved 4 ~ 10 SVCall Configurable Reserved 12 ~ 13 PendSV Configurable SysTick Configurable Interrupt (IRQ0 ~ IRQ31) 16 ~ 47 Configurable Table 5-22 System Interrupt Map...
  • Page 59 ISD91200 Series Technical Reference Manual TMR1_IRQn TMR1 Timer 1 interrupt Reserved UART1_IRQn UART1 UART1interrupt UART0_IRQn UART0 UART0 interrupt SPI1_IRQn SPI1 SPI1 interrupt SPI0_IRQn SPI0 SPI0 interrupt DPWM_IRQn DPWM DPWM interrupt Reserved Reserved I2C0_IRQn I2C0 I2C0 interrupt Reserved Reserved CMP_IRQn CMP interrupt...
  • Page 60 ISD91200 Series Technical Reference Manual 5.2.7.3 Operation Description NVIC interrupts can be enabled and disabled by writing to their corresponding Interrupt Set-Enable or Interrupt Clear-Enable register bit-field. The registers use a write-1-to-enable and write-1-to-clear policy, both registers reading back the current enabled state of the corresponding interrupts. When an interrupt is disabled, interrupt assertion will cause the interrupt to become Pending, however, the interrupt will not activate.
  • Page 61 ISD91200 Series Technical Reference Manual 5.2.7.4 NVIC Control Registers R: read only, W: write only, R/W: both read and write, W&C: Write 1 clear Register Offset Description Reset Value SCS Base Address: SCS_BA = 0xE000_E100 NVIC_ISER SCS_BA+0x000 IRQ0 ~ IRQ31 Set-Enable Control Register...
  • Page 62 ISD91200 Series Technical Reference Manual ( ) IRQ0 ~ IRQ31 Set-Enable Control Register NVIC_ISER Register Offset Description Reset Value NVIC_ISER SCS_BA+0x000 R/W IRQ0 ~ IRQ31 Set-Enable Control Register 0x0000_0000 If a pending interrupt is enabled, the NVIC activates the interrupt based on its priority. If an interrupt is not enabled, asserting its interrupt signal changes the interrupt state to pending, but the NVIC never activates the interrupt, regardless of its priority.
  • Page 63 ISD91200 Series Technical Reference Manual IRQ0 ~ IRQ31 Clear-Enable Control Register (NVIC_ICER) Register Offset Description Reset Value NVIC_ICER SCS_BA+0x080 R/W IRQ0 ~ IRQ31 Clear-Enable Control Register 0x0000_0000 Table 5-25 Interrupt Clear-Enable Control Register (ICER, address 0xE000_E180) Bit Description Bits Description Clear-enable Control Disable one or more interrupts within a group of 32.
  • Page 64 ISD91200 Series Technical Reference Manual IRQ0 ~ IRQ31 Set-Pending Control Register (NVIC_ISPR) Register Offset Description Reset Value NVIC_ISPR SCS_BA+0x100 R/W IRQ0 ~ IRQ31 Set-Pending Control Register 0x0000_0000 Table 5-26 Interrupt Set-Pending Control Register (ISPR, address 0xE000_E200) Bits Description Set-pending Control Writing 1 to a bit forces pending state of the associated interrupt under software control.
  • Page 65 ISD91200 Series Technical Reference Manual IRQ0 ~ IRQ31 Clear-Pending Control Register (NVIC_ICPR) Register Offset Description Reset Value NVIC_ICPR SCS_BA+0x180 R/W IRQ0 ~ IRQ31 Clear-Pending Control Register 0x0000_0000 Table 5-27 Interrupt Clear-Pending Control Register (ICPR, address 0xE000_E280) Bits Description Clear-pending Control Writing 1 to a bit to clear the pending state of associated interrupt under software control.
  • Page 66 ISD91200 Series Technical Reference Manual IRQ0 ~ IRQ3 Interrupt Priority Register (NVIC_IPR0) Register Offset Description Reset Value NVIC_IPR0 SCS_BA+0x300 R/W IRQ0 ~ IRQ3 Priority Control Register 0x0000_0000 PRI_3 Reserved PRI_2 Reserved PRI_1 Reserved PRI_0 Reserved Table 5-28 Interrupt Priority Register (IPR0, address 0xE000_E400)
  • Page 67 ISD91200 Series Technical Reference Manual IRQ4 ~ IRQ7 Interrupt Priority Register (NVIC_IPR1) Register Offset Description Reset Value NVIC_IPR1 SCS_BA+0x304 R/W IRQ4 ~ IRQ7 Priority Control Register 0x0000_0000 PRI_7 Reserved PRI_6 Reserved PRI_5 Reserved PRI_4 Reserved Table 5-29 Interrupt Priority Register (IPR1, address 0xE000_E404)
  • Page 68 ISD91200 Series Technical Reference Manual IRQ8 ~ IRQ11 Interrupt Priority Register (NVIC_IPR2) Register Offset Description Reset Value NVIC_IPR2 SCS_BA+0x308 R/W IRQ8 ~ IRQ11 Priority Control Register 0x0000_0000 PRI_11 Reserved PRI_10 Reserved PRI_9 Reserved PRI_8 Reserved Table 5-30 Interrupt Priority Register (IPR2, address 0xE000_E408)
  • Page 69 ISD91200 Series Technical Reference Manual IRQ12 ~ IRQ15 Interrupt Priority Register (NVIC_IPR3) Register Offset Description Reset Value NVIC_IPR3 SCS_BA+0x30C R/W IRQ12 ~ IRQ15 Priority Control Register 0x0000_0000 PRI_15 Reserved PRI_14 Reserved PRI_13 Reserved PRI_12 Reserved Table 5-31 Interrupt Priority Register (IPR3, address 0xE000_E40C)
  • Page 70 ISD91200 Series Technical Reference Manual IRQ16 ~ IRQ19 Interrupt Priority Register (NVIC_IPR4) Register Offset Description Reset Value NVIC_IPR4 SCS_BA+0x310 R/W IRQ16 ~ IRQ19 Priority Control Register 0x0000_0000 PRI_19 Reserved PRI_18 Reserved PRI_17 Reserved PRI_16 Reserved Table 5-32 Interrupt Priority Register (IPR4, address 0xE000_E410)
  • Page 71 ISD91200 Series Technical Reference Manual IRQ20 ~ IRQ23 Interrupt Priority Register (NVIC_IPR5) Register Offset Description Reset Value NVIC_IPR5 SCS_BA+0x314 R/W IRQ20 ~ IRQ23 Priority Control Register 0x0000_0000 PRI_23 Reserved PRI_22 Reserved PRI_21 Reserved PRI_20 Reserved Table 5-33 Interrupt Priority Register (IPR5, address 0xE000_E414)
  • Page 72 ISD91200 Series Technical Reference Manual IRQ24 ~ IRQ27 Interrupt Priority Register (NVIC_IPR6) Register Offset Description Reset Value NVIC_IPR6 SCS_BA+0x318 R/W IRQ24 ~ IRQ27 Priority Control Register 0x0000_0000 PRI_27 Reserved PRI_26 Reserved PRI_25 Reserved PRI_24 Reserved Table 5-34 Interrupt Priority Register (IPR6, address 0xE000_E418)
  • Page 73 ISD91200 Series Technical Reference Manual IRQ28 ~ IRQ31 Interrupt Priority Register (NVIC_IPR7) Register Offset Description Reset Value NVIC_IPR7 SCS_BA+0x31C R/W IRQ28 ~ IRQ31 Priority Control Register 0x0000_0000 PRI_31 Reserved PRI_30 Reserved PRI_29 Reserved PRI_28 Reserved Table 5-35 Interrupt Priority Register (IPR7, address 0xE000_E41C)
  • Page 74 ISD91200 Series Technical Reference Manual 5.2.7.5 Interrupt Source Control Registers Along with the interrupt control registers associated with the NVIC, the ISD91200 also implements some specific control registers to facilitate the interrupt functions, including “interrupt source identify”, ”NMI source selection” and “interrupt test mode”. They are described as below.
  • Page 75 ISD91200 Series Technical Reference Manual IRQ23_SRC INT_BA+0x5C IRQ23 (Reserved) Interrupt Source Identity Register 0xXXXX_XXXX IRQ24_SRC INT_BA+0x60 IRQ24 (Reserved) Interrupt Source Identity Register 0xXXXX_XXXX IRQ25_SRC INT_BA+0x64 IRQ25 (SARADC) Interrupt Source Identity Register 0xXXXX_XXXX IRQ26_SRC INT_BA+0x68 IRQ26 (PDMA) Interrupt Source Identity Register...
  • Page 76 ISD91200 Series Technical Reference Manual IRQ0(BOD) Interrupt Source Identify Register (IRQ0_SRC) Register Offset Description Reset Value IRQ0_SRC INT_BA+0x00 IRQ0 (BOD) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 77 ISD91200 Series Technical Reference Manual IRQ1(WDT) Interrupt Source Identify Register (IRQ1_SRC) Register Offset Description Reset Value IRQ1_SRC INT_BA+0x04 IRQ1 (WDT) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 78 ISD91200 Series Technical Reference Manual IRQ2(ENIT0) Interrupt Source Identify Register (IRQ2_SRC) Register Offset Description Reset Value IRQ2_SRC INT_BA+0x08 IRQ2 (EINT0) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 79 ISD91200 Series Technical Reference Manual IRQ3(ENIT1) Interrupt Source Identify Register (IRQ3_SRC) Register Offset Description Reset Value IRQ3_SRC INT_BA+0x0C IRQ3 (EINT1) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 80 ISD91200 Series Technical Reference Manual IRQ4(GPA/B) Interrupt Source Identify Register (IRQ4_SRC) Register Offset Description Reset Value IRQ4_SRC INT_BA+0x10 IRQ4 (GPA/B) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: GPB_INT...
  • Page 81 ISD91200 Series Technical Reference Manual IRQ5(ALC) Interrupt Source Identify Register (IRQ5_SRC) Register Offset Description Reset Value IRQ5_SRC INT_BA+0x14 IRQ5 (ALC) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 82 ISD91200 Series Technical Reference Manual IRQ6(PWM0) Interrupt Source Identify Register (IRQ6_SRC) Register Offset Description Reset Value IRQ6_SRC INT_BA+0x18 IRQ6 (PWM0) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 83 ISD91200 Series Technical Reference Manual IRQ8(TMR0) Interrupt Source Identify Register (IRQ8_SRC) Register Offset Description Reset Value IRQ8_SRC INT_BA+0x20 IRQ8 (TMR0) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 84 ISD91200 Series Technical Reference Manual IRQ9(TMR1) Interrupt Source Identify Register (IRQ9_SRC) Register Offset Description Reset Value IRQ9_SRC INT_BA+0x24 IRQ9 (TMR1) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 85 ISD91200 Series Technical Reference Manual IRQ11(UART1) Interrupt Source Identify Register (IRQ11_SRC) Register Offset Description Reset Value IRQ11_SRC INT_BA+0x2C IRQ11 (UART1) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INTSRC[2:0] Bits Description [31:3] Reserved Interrupt Source Identity Bit2: 0 [2:0]...
  • Page 86 ISD91200 Series Technical Reference Manual IRQ12(UART0) Interrupt Source Identify Register (IRQ12_SRC) Register Offset Description Reset Value IRQ12_SRC INT_BA+0x30 IRQ12 (UART0) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 87 ISD91200 Series Technical Reference Manual IRQ13(SPI1) Interrupt Source Identify Register (IRQ13_SRC) Register Offset Description Reset Value IRQ13_SRC INT_BA+0x34 IRQ13 (SPI1) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description [31:3] Reserved Interrupt Source Identity Bit2: 0 [2:0]...
  • Page 88 ISD91200 Series Technical Reference Manual IRQ14(SPI0) Interrupt Source Identify Register (IRQ14_SRC) Register Offset Description Reset Value IRQ14_SRC INT_BA+0x38 IRQ14 (SPI0) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 89 ISD91200 Series Technical Reference Manual IRQ15(DPWM) Interrupt Source Identify Register (IRQ15_SRC) Register Offset Description Reset Value IRQ15_SRC INT_BA+0x3C IRQ15 (DPWM) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description [31:3] Reserved Interrupt Source Identity Bit2: 0 [2:0]...
  • Page 90 ISD91200 Series Technical Reference Manual IRQ18(I2C0) Interrupt Source Identify Register (IRQ18_SRC) Register Offset Description Reset Value IRQ18_SRC INT_BA+0x48 IRQ18 (I2C0) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 91 ISD91200 Series Technical Reference Manual IRQ21(CMP) Interrupt Source Identify Register (IRQ21_SRC) Register Offset Description Reset Value IRQ21_SRC INT_BA+0x54 IRQ21 (CMP) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 92 ISD91200 Series Technical Reference Manual IRQ22(MAC) Interrupt Source Identify Register (IRQ22_SRC) Register Offset Description Reset Value IRQ22_SRC INT_BA+0x58 IRQ22 (MAC ) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description [31:3] Reserved Interrupt Source Identity Bit2: 0...
  • Page 93 ISD91200 Series Technical Reference Manual IRQ25(SARADC) Interrupt Source Identify Register (IRQ25_SRC) Register Offset Description Reset Value IRQ25_SRC INT_BA+0x64 IRQ25 (SARADC) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 94 ISD91200 Series Technical Reference Manual IRQ26(PDMA) Interrupt Source Identify Register (IRQ26_SRC) Register Offset Description Reset Value IRQ26_SRC INT_BA+0x68 IRQ26 (PDMA) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 95 ISD91200 Series Technical Reference Manual IRQ27(I2S0) Interrupt Source Identify Register (IRQ27_SRC) Register Offset Description Reset Value IRQ27_SRC INT_BA+0x6C IRQ27 (I2S0) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 96 ISD91200 Series Technical Reference Manual IRQ28(CAPS) Interrupt Source Identify Register (IRQ28_SRC) Register Offset Description Reset Value IRQ28_SRC INT_BA+0x70 IRQ28 (CAPS) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 97 ISD91200 Series Technical Reference Manual IRQ29(ADC) Interrupt Source Identify Register (IRQ29_SRC) Register Offset Description Reset Value IRQ29_SRC INT_BA+0x74 IRQ29 (ADC) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 98 ISD91200 Series Technical Reference Manual IRQ31(RTC) Interrupt Source Identify Register (IRQ31_SRC) Register Offset Description Reset Value IRQ31_SRC INT_BA+0x7C IRQ31 (RTC) Interrupt Source Identity Register 0xXXXX_XXXX Reserved Reserved Reserved Reserved INT_SRC[2:0] Bits Description Interrupt Source Identity Bit2: 0 [2:0] INT_SRC Bit1: 0...
  • Page 99 ISD91200 Series Technical Reference Manual NMI Interrupt Source Select Control Register (NMI_SEL) Register Offset Description Reset Value NMI_SEL INT_BA+0x80 NMI Source Interrupt Select Control Register 0x0000_0000 Reserved Reserved Reserved IRQ_TM Reserved NMI_SEL[4:0] Bits Description [31:7] Reserved Reserved IRQ Test Mode...
  • Page 100 ISD91200 Series Technical Reference Manual MCU Interrupt Request Source Test Mode Register (MCU_IRQ) Register Offset Description Reset Value MCU_IRQ INT_BA+0x84 MCU IRQ Number Identify Register 0x0000_0000 Reserved SDADC CAPS I2S0 PDMA SARADC Reserved Reserved Reserved Reserved I2C0 Reserved Reserved DPWM...
  • Page 101 ISD91200 Series Technical Reference Manual IRQ24 (RESERVED) Interrupt Source Identity Register Reserved [24] IRQ23 (RESERVED) Interrupt Source Identity Register Reserved [23] IRQ22 (MAC ) Interrupt Source Identity Register 0: No effect. [22] 1: clear the interrupt IRQ21 (CMP) Interrupt Source Identity Register 0: No effect.
  • Page 102 ISD91200 Series Technical Reference Manual IRQ8 (TMR0) Interrupt Source Identity Register 0: No effect. TMR0 1: clear the interrupt IRQ7 (RESERVED) Interrupt Source Identity Register Reserved IRQ6 (PWM0) Interrupt Source Identity Register 0: No effect. 1: clear the interrupt IRQ5 (ALC) Interrupt Source Identity Register 0: No effect.
  • Page 103: System Control Registers

    ISD91200 Series Technical Reference Manual 5.2.8 System Control Registers Key control and status features of Coterx-M0 are managed centrally in a System Control Block within the System Control Registers. For more detailed information, please refer to the documents “ARM® Cortex™-M0 Technical Reference Manual”...
  • Page 104 ISD91200 Series Technical Reference Manual CPUID Base Register (SYSINFO_CPUID) Register Offset R/W Description Reset Value SYSINFO_CPUID SYSINFO_BA+0x000 CPUID Base Register 0x410C_C200 IMPCODE Reserved PART PARTNO[11:4] PARTNO[3:0] REVISION Bits Description Implementer Code Assigned by ARM [31:24] IMPCODE ARM = 0x41. [23:20] Reserved Reserved.
  • Page 105 ISD91200 Series Technical Reference Manual Interrupt Control State Register (SYSINFO_ICSR) Register Offset Description Reset Value SYSINFO_ICSR SYSINFO_BA+0x004 Interrupt Control State Register 0x0000_0000 NMIPNSET Reserved PPSVISET PPSVICLR PSTKISET PSTKICLR Reserved ISRPREEM ISRPEND Reserved VTPNDING[8:4] VTPEND[3:0] Reserved VTACT[8] VTACT[7:0] Bits Description NMI Pending Set Control...
  • Page 106 ISD91200 Series Technical Reference Manual Vector Active [8:0] VTACT 0: Thread mode Value > 1: the exception number for the current executing exception. Release Date: Sep 16, 2019 - 106 - Revision 2.4...
  • Page 107 ISD91200 Series Technical Reference Manual Application Interrupt and Reset Control Register (SYSINFO_AIRCTL) Register Offset Description Reset Value SYSINFO_AIRCTL SYSINFO_BA+0x00C R/W Application Interrupt and Reset Control Register 0xFA05_0000 VTKEY VTKEY ENDIANES Reserved Reserved SRSTREQ CLRACTVT Reserved Bits Description Vector Key The value 0x05FA must be written to this register, otherwise...
  • Page 108 ISD91200 Series Technical Reference Manual System Control Register (SYSINFO_SCR) Register Offset Description Reset Value SYSINFO_SCR SYSINFO_BA+0x010 System Control Register 0x0000_0000 Reserved Reserved Reserved Reserved SEVNONPN Reserved SLPDEEP SLPONEXC Reserved Bits Description [31:5] Reserved Send Event on Pending Bit 0 = only enabled interrupts or events can wake-up the processor, disabled interrupts are excluded.
  • Page 109 ISD91200 Series Technical Reference Manual System Handler Priority Register2 (SYSINFO_SHPR2) Register Offset Description Reset Value SYSINFO_SHPR2 SYSINFO_BA+0x01C System Handler Priority Register 2 0x0000_0000 PRI11 Reserved Reserved Reserved Reserved Bits Description Priority of System Handler 11 – SVCall [31:30] PRI11 “0” denotes the highest priority and “3” denotes lowest priority...
  • Page 110 ISD91200 Series Technical Reference Manual System Handler Priority Register3 (SYSINFO_SHPR3) Register Offset Description Reset Value SYSINFO_SHPR3 SYSINFO_BA+0x020 System Handler Priority Register 3 0x0000_0000 PRI15 Reserved PRI14 Reserved Reserved Reserved Bits Description Priority of System Handler 15 – SYST [31:30] PRI15 “0”...
  • Page 111: Clock Controller And Power Management Unit (Pmu)

    ISD91200 Series Technical Reference Manual Clock Controller and Power Management Unit (PMU) The clock controller generates the clock sources for the whole device, including all AMBA interface modules and all peripheral clocks. Clock gating is provided on all peripheral clocks to minimize power consumption.
  • Page 112: System Clock & Systick Clock

    ISD91200 Series Technical Reference Manual 5.3.2 System Clock & SysTick Clock The system clock has 4 clock sources from clock generator block. The clock source switch depends on the register HCLKSEL (CLK_CLKSEL0[2:0]). The clock is then divided by HCLKDIV+1 to produce the master clock for the device.
  • Page 113: Peripheral Clocks

    ISD91200 Series Technical Reference Manual 5.3.3 Peripheral Clocks Each peripheral has a selectable clock gate. The register CLK_APBCLK0 determines whether the clock is active for each peripheral. In addition, the CLK_SLEEPCTL register determines whether these clocks remain on during M0 sleep mode. Certain peripheral clocks have selectable sources these are controlled by the CLK_CLKSEL1 &...
  • Page 114 ISD91200 Series Technical Reference Manual enters DPD mode with insufficient time to allow an ICE tool to activate the SWD debug port. Especially during development it is recommended that some checks are placed in the boot sequence to prevent device going to power down. A register bit, CLK_DBGPD.DISPDREQ is included for this purpose that will disable power down features.
  • Page 115: Register Map

    ISD91200 Series Technical Reference Manual 5.3.4.4 Level3: Deep Sleep mode. The Deep Sleep mode is the lowest power state where the Cortex-M0 and all logic state are preserved. In Deep Sleep mode the HIRC oscillator is shut down and a low speed oscillator is selected, if LXT is active this source is selected, if not then LIRC is enabled and selected.
  • Page 116: Register Description

    ISD91200 Series Technical Reference Manual 5.3.6 Register Description System Power Control Register (CLK_PWRCTL) This is a protected register, to write to register, first issue the unlock sequence. Register Offset Description Reset Value CLK_PWRCTL CLK_BA + 0x00 System Power Control Register 0xXX00_000D Table 5-36 System Power Control Register (CLK_PWRCTL, address 0x5000_0200)...
  • Page 117 ISD91200 Series Technical Reference Manual Flash ROM Control Enable/Disable Bit [19]: for Stop mode operation Bit [18]: for Sleep mode operation [19:18] FLASHEN 1: Turn off flash 0: Normal Note: It takes 10us to turn on the flash to normal OSC10k Enabled Control Determines whether OSC10k is enabled in DPD mode.
  • Page 118 ISD91200 Series Technical Reference Manual AHB Device Clock Enable Control Register (CLK_AHBCLK) These register bits are used to enable/disable the clock source for AHB (Advanced High-Performance Bus) blocks. This is a protected register, to write to register, first issue the unlock sequence...
  • Page 119 ISD91200 Series Technical Reference Manual APB Device Clock Enable Control Register (CLK_APBCLK0) These register bits are used to enable/disable clocks for APB (Advanced Peripheral Bus) peripherals. To enable the clocks write ‘1’ to the appropriate bit. To reduce power consumption and disable the peripheral, write ‘0’...
  • Page 120 ISD91200 Series Technical Reference Manual BIQ and ALC Clock Enable Control [18] BIQALCKEN 0=Disable. 1=Enable. SAR Analog-digital-converter (ADC) Clock Enable Control [17] SARADCKEN 0=Disable. 1=Enable. UART0 Clock Enable Control [16] UART0CKEN 0=Disable. 1=Enable. UART1 Clock Enable Control [15] UART1CKEN 0=Disable.
  • Page 121 ISD91200 Series Technical Reference Manual DPD State Register (CLK_DPDSTATE) The Deep Power Down State register is a user settable register that is preserved during Deep Power Down (DPD). Software can use this register to store a single byte during a DPD event. The DPDSTSRD register reads back the current state of the CLK_DPDSTATE register.
  • Page 122 ISD91200 Series Technical Reference Manual Clock Source Select Control Register 0 (CLK_CLKSEL0) Register Offset Description Reset Value CLK_CLKSEL0 CLK_BA + 0x10 Clock Source Select Control Register 0 0x0000_0038 HIRCFSEL STCLKSEL HCLKSEL Table 5-41 Clock Source Select Register 0 (CLK_CLKSEL0, address 0x5000_0210...
  • Page 123 ISD91200 Series Technical Reference Manual Clock Source Select Control Register 1(CLK_CLKSEL1) Clock multiplexors are a glitch free design to ensure smooth transitions between asynchronous clock sources. As such, both the current clock source and the target clock source must be enabled for switching to occur.
  • Page 124 ISD91200 Series Technical Reference Manual TIMER1 Clock Source Select 000 = clock source from LIRC. 001 = clock source from LXT. [14:12] TMR1SEL 010 = clock source from HXT. 011 = clock source from external pin (GPIOA[11]). 1xx = clock source from HCLK.(default)
  • Page 125 ISD91200 Series Technical Reference Manual Clock Divider Register (CLK_CLKDIV0) Register Offset Description Reset Value CLK_CLKDIV0 CLK_BA + 0x18 Clock Divider Number Register 0x0000_1010 SARADCDIV SDADCDIV DPWMDIV UARTDIV BIQDIV HCLKDIV Table 5-43 Clock Divider Register (CLK_CLKDIV0, address 0x5000_0218) Bit Description. Bits...
  • Page 126 ISD91200 Series Technical Reference Manual Clock Source Select Control Register 2(CLK_CLKSEL2) Before changing clock source, ensure that related clock sources (pre-select and new-select) are enabled. Register Offset Description Reset Value CLK_CLKSEL2 CLK_BA + 0x1C R/W Clock Source Select Control Register 2...
  • Page 127 ISD91200 Series Technical Reference Manual Sleep Clock Enable Control Register (CLK_SLEEPCTL) These register bits are used to enable/disable clocks during sleep mode. It works in conjunction with CLK_AHBCLK and CLK_APBCLK0 clock register to determine whether a clock source remains active during CPU Sleep mode.
  • Page 128 ISD91200 Series Technical Reference Manual [19] Reserved BIQ and ALCSleep Clock Enable Control [18] BIQALCKEN 0=Disable. 1=Enable. SARADC Sleep Clock Enable Control [17] SARADCCKEN 0=Disable. 1=Enable. UART0 Sleep Clock Enable Control [16] UART0CKEN 0=Disable. 1=Enable. UART1 Sleep Clock Enable Control 0=Disable.
  • Page 129 ISD91200 Series Technical Reference Manual PDMA Controller Sleep Clock Enable Control PDMACKEN 0=Disable. 1=Enable. CPU Clock Sleep Enable (HCLK) Must be left as ‘1’ for normal operation. HCLKCKEN 0=Disable. 1=Enable. Release Date: Sep 16, 2019 - 129 - Revision 2.4...
  • Page 130 ISD91200 Series Technical Reference Manual Power State Flag Register (CLK_PWRSTSF) Register Offset Description Reset Value CLK_PWRSTSF CLK_BA + 0x24 Power State Flag Register 0x0000_0000 Reserved SPDF STOPF Table 5-46 Power State Flag Register (CLK_PWRSTSF, address 0x5000_0224) Bit Description. Bits Description...
  • Page 131 ISD91200 Series Technical Reference Manual Debug Power Down Register (CLK_DBGPD) Register Offset Description Reset Value CLK_DBGPD CLK_BA + 0x28 Debug Port Power Down Disable Register 0x0000_00XX ICEDATST ICECLKST Reserved DISPDREQ Table 5-47 Debug Power Down Register (CLK_DBGPD, address 0x5000_0228) Bit Description.
  • Page 132 ISD91200 Series Technical Reference Manual Deep Power Down 10K Wakeup Timer (CLK_WAKE10K) Register Offset Description Reset Value CLK_WAKE10K CLK_BA + 0x2C R/W Deep Power Down 10K Wakeup Timer 0x0000_0001 WAKE10KEN Reserved WKTMRSTS WKTMRSTS Reserved SELWKTMR SELWKTMR Table 5-48 Deep Power Down 10K Wakeup Timer (CLK_WAKE10K, address 0x5000_022C) Bit Description.
  • Page 133: General Purpose I/O

    ISD91200 Series Technical Reference Manual General Purpose I/O 5.4.1 Overview and Features Up to 32 General Purpose I/O pins are available on the I91200 series. These are shared peripheral special function pins under control of the alternate configuration registers. These 32 pins are arranged in 2 ports named with GPIOA, and GPIOB.
  • Page 134 ISD91200 Series Technical Reference Manual 5.4.2.3 Open-Drain Mode For Px_MODEn = 10b the GPIOx port [n] pin is in Open-Drain mode. The GPIO pin supports a digital output function but only with sink current capability, an additional pull-up resister is needed for defining a high state.
  • Page 135: Gpio Control Register Map

    ISD91200 Series Technical Reference Manual 5.4.3 GPIO Control Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value GPIO Base Address: GPIO_BA = 0x5000_4000 PA_MODE GPIO_BA+0x000 GPIO Port A Pin I/O Mode Control...
  • Page 136: Register Description

    ISD91200 Series Technical Reference Manual 5.4.4 Register Description GPIO Port [A/B] I/O Mode Control (Px_MODE) Register Offset Description Reset Value PA_MODE GPIO_BA+0x000 R/W GPIO Port A Pin I/O Mode Control 0xFFFF_FFFF PB_MODE GPIO_BA+0x040 R/W GPIO Port B Pin I/O Mode Control...
  • Page 137 ISD91200 Series Technical Reference Manual GPIO Port [A/B] Input Disable (Px_DINOFF) Register Offset Description Reset Value PA_DINOFF GPIO_BA+0x004 R/W GPIO Port A Pin Input Disable 0x0000_0000 PB_DINOFF GPIO_BA+0x044 R/W GPIO Port B Pin Input Disable 0x0000_0000 Table 5-50 GPIO Input Disable Register...
  • Page 138 ISD91200 Series Technical Reference Manual GPIO Port [A/B] Data Output Value (Px_DOUT) Register Offset Description Reset Value PA_DOUT GPIO_BA+0x008 R/W GPIO Port A Data Output Value 0x0000_FFFF PB_DOUT GPIO_BA+0x048 R/W GPIO Port B Data Output Value 0x0000_FFFF Table 5-51 GPIO Data Output Register (Px_DOUT)
  • Page 139 ISD91200 Series Technical Reference Manual GPIO Port [A/B] Data Output Write Mask (Px _DATMSK) Register Offset Description Reset Value PA_DATMSK GPIO_BA+0x00C R/W GPIO Port A Data Output Write Mask 0xXXXX_0000 PB_DATMSK GPIO_BA+0x04C R/W GPIO Port B Data Output Write Mask...
  • Page 140 ISD91200 Series Technical Reference Manual GPIO Port [A/B] Pin Value (Px _PIN) Register Offset Description Reset Value PA_PIN GPIO_BA+0x010 R GPIO Port A Pin Value 0x0000_XXXX PB_PIN GPIO_BA+0x050 R GPIO Port B Pin Value 0x0000_XXXX Table 5-53 GPIO PIN Value Register (Px_PIN)
  • Page 141 ISD91200 Series Technical Reference Manual GPIO Port [A/B] De-bounce Enable (Px _DBEN) Register Offset Description Reset Value PA_DBEN GPIO_BA+0x014 R/W GPIO Port A De-bounce Enable 0xXXXX_0000 PB_DBEN GPIO_BA+0x054 R/W GPIO Port B De-bounce Enable 0xXXXX_0000 Table 5-54 GPIO Debounce Enable Register (Px_DBEN)
  • Page 142 ISD91200 Series Technical Reference Manual GPIO Port [A/B] Interrupt Mode Control (Px _INTTYPE) Register Offset Description Reset Value PA_INTTYPE GPIO_BA+0x018 R/W GPIO Port A Interrupt Trigger Type 0xXXXX_0000 PB_INTTYPE GPIO_BA+0x058 R/W GPIO Port B Interrupt Trigger Type 0xXXXX_0000 Table 5-55 GPIO Interrupt Mode Control (Px_INTTYPE)
  • Page 143 ISD91200 Series Technical Reference Manual GPIO Port [A/B] Interrupt Enable Control (Px _INTEN) Register Offset Description Reset Value PA_INTEN GPIO_BA+0x01C R/W GPIO Port A Interrupt Enable 0x0000_0000 PB_INTEN GPIO_BA+0x05C R/W GPIO Port B Interrupt Enable 0x0000_0000 Table 5-56 GPIO Interrupt Enable Control Register (Px_INTEN)
  • Page 144 ISD91200 Series Technical Reference Manual GPIO Port [A/B] Interrupt Source Flag(Px _INTSRC) Register Offset Description Reset Value PA_INTSRC GPIO_BA+0x020 R/W GPIO Port A Interrupt Source Flag 0x0000_0000 PB_INTSRC GPIO_BA+0x060 R/W GPIO Port B Interrupt Source Flag 0x0000_0000 Table 5-57 GPIO Interrupt Source Flag Register (Px_INTSRC)
  • Page 145 ISD91200 Series Technical Reference Manual Interrupt De-bounce Control (GPIO_DBCTL ) Register Offset Description Reset Value DBCTL GPIO_BA+0x180 R/W Interrupt De-bounce Control 0x0000_0020 Table 5-58 GPIO Interrupt De-bounce Control Register (GPIO_DBCTL ) Reserved ICLKON DBCLKSRC DBCLKSEL Bits Description [31:6] Reserved Reserved.
  • Page 146: Brownout Detection And Temperature Alarm

    ISD91200 Series Technical Reference Manual Brownout Detection and Temperature Alarm The I91200 is equipped with a Brown-Out voltage detector. The Brown-Out detector features a configurable trigger level and can be configured by flash to be active upon reset. The Brown-Out detector also has a power saving mode where detection can be set up to be active for a configurable on and off time.
  • Page 147: Brownout Register Description

    ISD91200 Series Technical Reference Manual 5.5.2 Brownout Register Description This register is initialized by user flash configuration bits config0[22:18]. Brown-Out Detector Select Register (BOD_BODSEL) Register Offset Description Reset Value BOD_BODSEL BOD_BA+0x00 Brown Out Detector Select Register 0x0000_0000 Table 5-59 Brownout Detector Select Register (BOD_BODSEL, address 0x4008_4000)
  • Page 148 ISD91200 Series Technical Reference Manual Brown-Out Detector Enable Register (BOD_BODCTL) This register is initialized by user flash configuration bit config0[23]. If config0[23]=1, then reset value of is 0x7. The effect of this is to generate a NMI interrupt (default NMI interrupt is BOD BOD_BODCTL interrupt) if BOD circuit detects a voltage below 2.1V.
  • Page 149 ISD91200 Series Technical Reference Manual BOD Interrupt Enable BODINTEN 0= Disable BOD Interrupt. 1= Enable BOD Interrupt. BOD Enable 1xb = Enable continuous BOD detection. [1:0] BODEN 01b = Enable time multiplexed BOD detection. See BOD_BODDTMR register. 00b = Disable BOD Detection.
  • Page 150: I2C Serial Interface Controller (Master/Slave)

    ISD91200 Series Technical Reference Manual Detection Time Multiplex Register (BOD_BODDTMR) The BOD detector can be set up to take periodic samples of the supply voltage to minimize power consumption. The circuit can be configured and used in Standby Power Down (SPD) mode and can wake up the device if a BOD is event detected.
  • Page 151 ISD91200 Series Technical Reference Manual Re pe a te d S TOP S TART S TOP S TART S DA LO W S CL HIG H HD;S TA S U;S TA S U;S TO HD;DAT S U;DAT Figure 5-9 I2C Bus Timing The device’s on-chip I2C logic provides the serial interface that meets the I2C bus standard mode...
  • Page 152 ISD91200 Series Technical Reference Manual 3 - 7 NACK A4 - A1 D5 - D1 Figure 5-10 I2C Protocol 5.6.1.2 Data transfer on the I2C-bus A master-transmitter always begins by addressing a slave receiver with a 7-bit address. For a transaction where the master-transmitter is sending data to the slave, the transfer direction is not changed, master is always transmitting and slave acknowledges the data.
  • Page 153 ISD91200 Series Technical Reference Manual START condition STOP condition Figure 5-13 START and STOP condition 5.6.1.4 Slave Address Transfer The first byte of data transferred by the master immediately after the START signal is the slave address. This is a 7-bits calling address followed by a RW bit. The RW bit signals the slave the data transfer direction.
  • Page 154: Modes Of Operation

    ISD91200 Series Technical Reference Manual clock pulse for acknowledgement SCL FROM MASTER DATA OUTPUT BY TRANSMITTER not acknowledge DATA OUTPUT BY RECEIVER acknowledge START condition Figure 5-15 Acknowledge on the I2C bus 5.6.2 Modes of Operation The on-chip I2C ports support five operation modes, Master transmitter, Master receiver, Slave transmitter, Slave receiver, and GC call.
  • Page 155: Data Transfer Flow In Five Operating Modes

    ISD91200 Series Technical Reference Manual 5.6.3 Data Transfer Flow in Five Operating Modes The five operating modes are: Master/Transmitter, Master/Receiver, Slave/Transmitter, Slave/Receiver and GC Call. Bits STA, STO and AA in I2C_CTL register will determine the next state of the SIO hardware after SI flag is cleared.
  • Page 156 ISD91200 Series Technical Reference Manual Set STA to generate a START. From Slave Mode (C) A START has been transmitted. (STA,STO,SI,AA)=(0,0,1,X) SLA+W will be transmitted; ACK bit will be received. From Master/Receiver (B) SLA+W will be transmitted; ACK bit will be received.
  • Page 157 ISD91200 Series Technical Reference Manual Set STA to generate a START. From Slave Mode (C) A START has been transmitted. (STA,STO,SI,AA)=(0,0,1,X) SLA+R will be transmitted; ACK bit will be received. From Master/Transmitter (A) SLA+R has been transmitted; SLA+R has been transmitted;...
  • Page 158 ISD91200 Series Technical Reference Manual Set AA Own SLA+R has been received; ACK has been return. Arbitration lost SLA+R/W as master; Own SLA+R has been received; ACK has been return. (STA,STO,SI,AA)=(0,0,1,0) (STA,STO,SI,AA)=(0,0,1,1) Last data byte will be transmitted; Data byte will be transmitted;...
  • Page 159 ISD91200 Series Technical Reference Manual Set AA Own SLA+W has been received; ACK has been return. Arbitration lost SLA+R/W as master; Own SLA+W has been received; ACK has been return. (STA,STO,SI,AA)=(0,0,1,0) (STA,STO,SI,AA)=(0,0,1,1) Data byte will be received; Data byte will be received;...
  • Page 160 ISD91200 Series Technical Reference Manual Set AA Reception of the general call address and one or more data bytes; ACK has been return. Arbitration lost SLA+R/W as master; and address as SLA by general call; ACK has been return. (STA,STO,SI,AA)=(X,0,1,0) (STA,STO,SI,AA)=(X,0,1,1) Data byte will be received;...
  • Page 161: I2C Protocol Registers

    ISD91200 Series Technical Reference Manual 5.6.4 I2C Protocol Registers The CPU interfaces to the SIO port through the following thirteen special function registers: I2C_CTL (control register), I2C_STATUS (status register), I2C_DAT (data register), I2C_ADDRn (address registers, n=0~3), I2C_ADDRMSKn (address mask registers, n=0~3), I2C_CLKDIV (clock rate register) and I2C_TOCTL (Time-out counter register).
  • Page 162 ISD91200 Series Technical Reference Manual I2C Data Register: DATA.7 DATA.6 DATA.5 DATA.4 DATA.3 DATA.2 DATA.1 DATA.0 shifting direction Figure 5-22 I2C Data Shift Direction 5.6.4.3 Control Register (I2C_CTL) The CPU can read from and write to this 8-bit field of I2C_CTL[7:0]. Two bits are affected by hardware: the SI bit is set when the I2C hardware requests a serial interrupt, and the STO bit is cleared when a STOP condition is present on the bus.
  • Page 163 ISD91200 Series Technical Reference Manual with any clock frequency up to 1M Hz from master I2C device. Data Baud Rate of I2C = PCLK /(4x(I2C_CLKDIV[7:0]+1)). If PCLK=16MHz, the I2C_CLKDIV[7:0] = 40 (28H), data baud rate of I2C = 16MHz/(4x(40 +1)) = 97.5Kbits/sec.
  • Page 164: Register Mapping

    ISD91200 Series Technical Reference Manual 5.6.5 Register Mapping R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value I2C Base Address: I2C_BA = 0x4002_0000 I2C_CTL I2C_BA+0x00 I2C Control Register 0x0000_0000 I2C_ADDR0 I2C_BA+0x04 I2C Slave address Register0...
  • Page 165: Register Description

    ISD91200 Series Technical Reference Manual 5.6.6 Register Description I2C CONTROL REGISTER (I2C_CTL) Register Offset Description Reset Value I2C_CTL I2C_BA+0x00 I2C Control Register 0x0000_0000 INTEN I2CEN Reserved Bits Description [31:8] Reserved Reserved. Enable Interrupt INTEN 0 = Disable interrupt. 1 = Enable interrupt CPU.
  • Page 166 ISD91200 Series Technical Reference Manual I2C DATA REGISTER (I2C_DAT) Register Offset Description Reset Value I2C_DAT I2C_BA+0x08 I2C DATA Register 0x0000_0000 DAT[7:0] Bits Description [31:8] Reserved Reserved. I2C Data Register During master or slave transmit mode, data to be transmitted is written to this [7:0] register.
  • Page 167 ISD91200 Series Technical Reference Manual I2C STATUS REGISTER (I2C_STATUS ) Register Offset Description Reset Value I2C_STATUS I2C_BA+0x0C I2C Status Register 0x0000_00F8 STATUS[7:0] Bits Description [31:8] Reserved Reserved. I2C Status Register The status register of I2C: The three least significant bits are always 0. The five most significant bits contain the status code.
  • Page 168 ISD91200 Series Technical Reference Manual I2C DATA BAUD RATE CONTROL REGISTER (I2C_CLKDIV) Register Offset Description Reset Value I2C_CLKDIV I2C_BA+0x10 I2C clock divided Register 0x0000_0000 DIVIDER[7:0] Bits Description [31:8] Reserved Reserved. I2C Clock Divided Register [7:0] DIVIDER The I2C clock rate bits: Data Baud Rate of I2C = PCLK /(4x(I2C_CLKDIV+1)).
  • Page 169 ISD91200 Series Technical Reference Manual I2C TIME-OUT COUNTER REGISTER (I2C_TOCTL) Register Offset Description Reset Value I2C_TOCTL I2C_BA+0x14 I2C Time out control Register 0x0000_0000 Reserved TOCEN TOCDIV4 TOIF Bits Description [31:3] Reserved Reserved. Time-out Counter Control Bit 0 = Disable. TOCEN 1 = Enable.
  • Page 170 ISD91200 Series Technical Reference Manual I2C SLAVE ADDRESS REGISTER (I2CADDRx) Register Offset Description Reset Value I2C_ADDR0 I2C_BA+0x04 I2C Slave address Register0 0x0000_0000 I2C_ADDR1 I2C_BA+0x18 I2C Slave address Register1 0x0000_0000 I2C_ADDR2 I2C_BA+0x1C I2C Slave address Register2 0x0000_0000 I2C_ADDR3 I2C_BA+0x20 I2C Slave address Register3...
  • Page 171 ISD91200 Series Technical Reference Manual I2C SLAVE ADDRESS MASK REGISTER (I2CADMx) Register Offset Description Reset Value I2C_ADDRMSK0 I2C_BA+0x24 I2C Slave address Mask Register0 0x0000_0000 I2C_ADDRMSK1 I2C_BA+0x28 I2C Slave address Mask Register1 0x0000_0000 I2C_ADDRMSK2 I2C_BA+0x2C I2C Slave address Mask Register2 0x0000_0000...
  • Page 172: Pwm Generator And Capture Timer

    ISD91200 Series Technical Reference Manual PWM Generator and Capture Timer 5.7.1 Introduction The I91200 has two PWM generators which can be configured as 4 independent PWM outputs, PWM0CH0, PWM0CH1, PWM0CH2 and PWM0CH3, or as a complementary PWM pairs with programmable dead-zone generator. Each PWM Generator has an 8-bit pre-scaler, a clock divider...
  • Page 173 ISD91200 Series Technical Reference Manual 5.7.2.2 Capture Function Features:  Timing control logic shared with PWM Generators.  2 Capture input channels shared with 2 PWM output channels.  Each channel supports a rising latch register (RCAPDAT), a falling latch register...
  • Page 174: Pwm Generator Architecture

    ISD91200 Series Technical Reference Manual 5.7.3 PWM Generator Architecture The following figures illustrate the architecture of the PWM. PWM0CH01SEL(CLK_CLKSEL1[29:28]) PWM0CH01EN(CLK_APBCLK0[20]) PWM0CH01_CLK CLK48M HCLK CLK32K CLK10K Figure 5-24 PWM Generator Clock Source Control DZI01 Dead Zone Generator 0 CSR0(CSR[2:0]) CNR0, CMR0, PWM- PA.12/PWM0...
  • Page 175 ISD91200 Series Technical Reference Manual  CMP < PERIOD: PWM low width= (PERIOD-CMP) unit ; PWM high width=(CMP+1) unit.  CMP = 0: PWM low width = (PERIOD) unit; PWM high width=1 unit Note: 1. Unit = one PWM clock cycle.
  • Page 176: Pwm Double Buffering, Auto-Reload And One-Shot Operation

    ISD91200 Series Technical Reference Manual 5.7.5 PWM Double Buffering, Auto-reload and One-shot Operation The I91200 series PWM Timers are double buffered, the reload value is updated at the start of next period without affecting current timer operation. The PWM counter reset value can be written into PWM_PERIOD0~1 and current PWM counter value can be read from PWM_CNT0~1.
  • Page 177: Dead-Zone Generator

    ISD91200 Series Technical Reference Manual 5.7.7 Dead-Zone Generator The I91200 PWM generator includes a Dead Zone generator. This is used to ensure neither PWM output is active simultaneously for power device protection. The function generates a programmable time gap between rising PWM outputs. The user can program PPRx.DZI to determine the Dead Zone interval.
  • Page 178: Capture Timer Operation

    ISD91200 Series Technical Reference Manual 5.7.8 Capture Timer Operation Instead of using the PWM generator to output a modulated signal, it can be configured as a capture timer to measure a modulated input. Capture channel 0 and PWM0CH0 share one timer and Capture channel 1 and PWM0CH1 share another timer.
  • Page 179: Pwm-Timer Interrupt Architecture

    ISD91200 Series Technical Reference Manual 5.7.9 PWM-Timer Interrupt Architecture There are two PWM interrupts, PWM0_INT, PWM1_INT, which are multiplexed into PWM0_IRQ. PWM 0 and Capture 0 share one interrupt, PWM1 and Capture 1 share the same interrupt. Figure 5-32 PWM- Timer Interrupt Architecture Diagram demonstrates the architecture of PWM-Timer interrupts.
  • Page 180: Capture Start Procedure

    ISD91200 Series Technical Reference Manual • 5.7.12 Capture Start Procedure Setup clock selector (PWM_CLKDIV) Setup prescaler (PWM_CLKPSC) Setup channel enable, rising/falling interrupt enable and input signal inverter on/off (PWM_CAPCTL01, PWM_CAPCTL23) Setup PWM down-counter (PERIOD) Set Capture Input Enable Register (PWM_CAPINEN)
  • Page 181: Register Map

    ISD91200 Series Technical Reference Manual 5.7.13 Register Map R: read only, W: write only, R/W: both read and write Register Offset R/W Description Reset Value PWM Base Address: PWM_BA = 0x4004_0000 PWM_CLKPSC PWM_BA+0x000 R/W PWM Prescaler Register 0x0000_0000 PWM_CLKDIV R/W PWM Clock Select Register...
  • Page 182 ISD91200 Series Technical Reference Manual PWM_FCAPDAT3 Capture Falling Latch Register (Channel 3) PWM_BA+0x074 0x0000_0000 PWM_CAPINEN R/W Capture Input Enable Register PWM_BA+0x078 0x0000_0000 PWM_POEN R/W PWM0 Output Enable Register for CH0~CH3 PWM_BA+0x07C 0x0000_0000 Release Date: Sep 16, 2019 - 182 -...
  • Page 183: Register Description

    ISD91200 Series Technical Reference Manual 5.7.14 Register Description PWM Pre-Scale Register (PWM_CLKPSC) Register Offset Description Reset Value PWM_CLKPSC PWM_BA+0x000 R/W PWM Prescaler Register 0x0000_0000 DTCNT23 DTCNT01 CLKPSC23 CLKPSC01 Table 5-62 PWM Pre-Scaler Register (PWM_CLKPSC, address 0x4004_0000). Bits Description Dead Zone Interval Register for Pair of PWM0CH2 and PWM0CH3...
  • Page 184 ISD91200 Series Technical Reference Manual PWM Clock Select Register (PWM_CLKDIV) Register Offset Description Reset Value PWM_CLKDIV PWM_BA+0x004 R/W PWM Clock Select Register 0x0000_0000 Reserved CLKDIV3 Reserved CLKDIV2 Reserved CLKDIV1 Reserved CLKDIV0 Table 5-63 PWM Clock Select Register (PWM_CLKDIV, address 0x4004_0004).
  • Page 185 ISD91200 Series Technical Reference Manual PWM Control Register (PWM_CTL) Register Offset Description Reset Value PWM_CTL PWM_BA+0x008 R/W PWM Control Register 0x0000_0000 Reserved CNTMODE3 PINV3 Reserved CNTEN3 Reserved CNTMODE2 PINV2 Reserved CNTEN2 Reserved CNTMODE1 PINV1 Reserved CNTEN1 Reserved DTEN23 DTEN01 CNTMODE0...
  • Page 186 ISD91200 Series Technical Reference Manual [15:12] Reserved Reserved. PWM-timer 1 Auto-reload/One-shot Mode 0 = One-Shot Mode. [11] CNTMODE1 1 = Auto-load Mode. Note: A rising transition of this bit will cause PWM_PERIOD1 and PWM_CMPDAT1 to be cleared. PWM-timer 1 Output Inverter ON/OFF...
  • Page 187 ISD91200 Series Technical Reference Manual PWM Counter Register 1-0 (PWM_PERIOD1-0) Register Offset Description Reset Value PWM_PERIOD0 PWM_BA+0x00C R/W PWM Counter Register 0 0x0000_0000 PWM_PERIOD1 PWM_BA+0x018 R/W PWM Counter Register 1 0x0000_0000 PWM_PERIOD2 PWM_BA+0x024 R/W PWM Counter Register 2 0x0000_0000 PWM_PERIOD3...
  • Page 188 ISD91200 Series Technical Reference Manual PWM Comparator Register 1-0 (PWM_CMPDAT) Register Offset Description Reset Value PWM_CMPDAT0 PWM_BA+0x010 R/W PWM Comparator Register 0 0x0000_0000 PWM_CMPDAT1 PWM_BA+0x01C R/W PWM Comparator Register 1 0x0000_0000 PWM_CMPDAT2 PWM_BA+0x028 R/W PWM Comparator Register 2 0x0000_0000 PWM_CMPDAT3 PWM_BA+0x034 R/W...
  • Page 189 ISD91200 Series Technical Reference Manual PWM Data Register 1-0 (PWM_CNT) Register Offset Description Reset Value PWM_CNT0 PWM_BA+0x014 R PWM Data Register 0 0x0000_0000 PWM_CNT1 PWM_BA+0x020 R PWM Data Register 1 0x0000_0000 PWM_CNT2 PWM_BA+0x02C R PWM Data Register 2 0x0000_0000 PWM_CNT3...
  • Page 190 ISD91200 Series Technical Reference Manual PWM Interrupt Enable Register (PWM_INTEN) Register Offset Description Reset Value PWM_INTEN PWM_BA+0x040 R/W PWM Interrupt Enable Register 0x0000_0000 Reserved PIEN3 PIEN2 PIEN1 PIEN0 Table 5-68 PWM Interrupt Enable Register (PWM_INTEN, address 0x4004_0040). Bits Description [31:4] Reserved Reserved.
  • Page 191 ISD91200 Series Technical Reference Manual PWM Interrupt Flag Register (PWM_INTSTS) Register Offset Description Reset Value PWM_INTSTS PWM_BA+0x044 R/W PWM Interrupt Flag Register 0x0000_0000 Reserved PIF3 PIF2 PIF1 PIF0 Table 5-69 PWM Interrupt Flag Register (PWM_INTSTS, address 0x4004_0044). Bits Description [31:4] Reserved Reserved.
  • Page 192 ISD91200 Series Technical Reference Manual Capture Control Register (PWM_CAPCTL01) Register Offset Description Reset Value PWM_CAPCTL01 PWM_BA+0x050 R/W Capture Control Register For Pair Of PWM0CH0 And 0x0000_0000 PWM0CH1 Reserved CFLIF1 CRLIF1 Reserved CAPIF1 CAPEN1 CFLIEN1 CRLIEN1 CAPINV1 Reserved CFLIF0 CRLIF0 Reserved...
  • Page 193 ISD91200 Series Technical Reference Manual Channel 1 Inverter ON/OFF [16] CAPINV1 0 = Inverter OFF. 1 = Inverter ON. Reverse the input signal from GPIO before Capture timer [15:8] Reserved Reserved. PWM_FCAPDAT0 Latched Indicator Bit When input channel 0 has a falling transition, PWM_FCAPDAT0 was latched with...
  • Page 194 ISD91200 Series Technical Reference Manual Capture Control Register (PWM_CAPCTL23) Register Offset Description Reset Value PWM_CAPCTL23 PWM_BA+0x054 R/W Capture Control Register For Pair Of PWM0CH2 And 0x0000_0000 PWM0CH3 Reserved CFLIF3 CRLIF3 Reserved CAPIF3 CAPEN3 CFLIEN3 CRLIEN3 CAPINV3 Reserved CFLIF2 CRLIF2 Reserved...
  • Page 195 ISD91200 Series Technical Reference Manual Channel 3 Rising Latch Interrupt Enable 0 = Disable rising edge latch interrupt. [17] CRLIEN3 1 = Enable rising edge latch interrupt. When enabled, capture block generates an interrupt on rising edge of input. Channel 3 Inverter ON/OFF...
  • Page 196 ISD91200 Series Technical Reference Manual Capture Rising Latch Register n (PWM_RCAPDATn) Register Offset Description Reset Value PWM_RCAPDAT0 PWM_BA+0x058 Capture Rising Latch Register (Channel 0) 0x0000_0000 PWM_RCAPDAT1 PWM_BA+0x060 Capture Rising Latch Register (Channel 1) 0x0000_0000 PWM_RCAPDAT2 PWM_BA+0x068 Capture Rising Latch Register (Channel 2)
  • Page 197 ISD91200 Series Technical Reference Manual Capture Falling Latch Register n(PWM_FCAPDATn) Register Offset Description Reset Value PWM_FCAPDAT0 PWM_BA+0x05C R Capture Falling Latch Register (Channel 0) 0x0000_0000 PWM_FCAPDAT1 PWM_BA+0x064 R Capture Falling Latch Register (Channel 1) 0x0000_0000 PWM_FCAPDAT2 PWM_BA+0x06C R Capture Falling Latch Register (Channel 2)
  • Page 198 ISD91200 Series Technical Reference Manual Capture Input Enable Register (PWM_CAPINEN) Register Offset Description Reset Value PWM_CAPINEN PWM_BA+0x078 R/W Capture Input Enable Register 0x0000_0000 Reserved CAPINEN[3:0] Table 5-74 Capture Input Enable Register (PWM_CAPINEN, address 0x4004_0078). Bits Description [31:4] Reserved Reserved. Capture Input Enable Register...
  • Page 199 ISD91200 Series Technical Reference Manual PWM Output Enable Register (PWM_POEN) Register Offset Description Reset Value PWM_POEN PWM_BA+0x07C PWM0 Output Enable Register for CH0~CH3 0x0000_0000 Reserved POEN3 POEN2 POEN1 POEN0 Table 5-75 PWM Output Enable (PWM_POEN, address 0x4004_007C). Bits Description [31:4] Reserved Reserved.
  • Page 200: Real Time Clock (Rtc) Overview

    ISD91200 Series Technical Reference Manual Real Time Clock (RTC) Overview Real Time Clock (RTC) unit provides real time clock, calendar and alarm functions. The clock source of the RTC is an external 32.768 kHz crystal connected at pins XI32K and XO32K or from an external 32.768 kHz oscillator output fed to pin XI32K.
  • Page 201: Rtc Block Diagram

    ISD91200 Series Technical Reference Manual 5.8.2 RTC Block Diagram Time Alarm Calendar Alarm ALMIEN(INTEN[0]) Register (TAR) Register (CAR) ALMIF(INTSTS[0]) Alarm Compare Interrupt Operation Time Load Calendar Load Register (TLR) Register (CLR) Wakeup CPU from Power-down mode (sec) 1/128 change Leap Year Indicator (LIP)
  • Page 202 ISD91200 Series Technical Reference Manual Table 5-76 RTC Frequency Compensation Example Example 1: Frequency Counter Measurement : 32773.65Hz ( > 32768 Hz) Integer Part: 32773 = 0x8005 RTC_FREQADJ. INTEGER= (32773 – 32761) = 12 = 0x0C Fractional Part: 0.65 X 60 = 39 = 0x27 RTC_FREQADJ.
  • Page 203 ISD91200 Series Technical Reference Manual RTC_TALM 00:00:00 (hour : minute : second) RTC_CLKFMT 1 (24 hr. mode) RTC_WEEKDAY 6 (Saturday) RTC_INTEN RTC_INTSTS RTC_LEAPYEAR RTC_TICK PWRTOUT 5555 4. In RTC_TIME and RTC_TALM, only 2 BCD digits are used to express “year”. It is assumed that 2 BCD digits of xY denote 20xY, but not 19xY or 21xY.
  • Page 204: Register Map

    ISD91200 Series Technical Reference Manual 5.8.4 Register Map R: read only, W: write only, R/W: both read and write, C: Only value 0 can be written Register Offset Description Reset Value RTC Base Address: RTC_BA = 0x4000_8000 RTC_INIT RTC_BA+0x000 RTC Initialization Register...
  • Page 205: Register Description

    ISD91200 Series Technical Reference Manual 5.8.5 Register Description RTC Initiation Register (RTC_INIT) Register Offset Description Reset Value RTC_INIT RTC_BA+0x000 R/W RTC Initialization Register 0x0000_0000 INIT INIT INIT INIT ATVSTS Table 5-77 RTC Initialization Register (RTC_INIT, address 0x4000_8000). Bits Description RTC Initialization...
  • Page 206 ISD91200 Series Technical Reference Manual RTC Access Enable Register (RTC_RWEN) Register Offset Description Reset Value RTC_BA+0x004 R/W RTC_RWEN RTC Access Enable Register 0x0000_0000 Reserved RWENF RWEN RWEN Table 5-78 RTC Access Enable Register (RTC_RWEN, address 0x4000_8004). Bits Description [31:17] Reserved Reserved.
  • Page 207 ISD91200 Series Technical Reference Manual RTC Frequency Compensation Register (RTC_FREQADJ) Register Offset Description Reset Value RTC_BA+0x008 R/W RTC_FREQADJ RTC Frequency Compensation Register 0x0000_0700 Reserved Reserved Reserved INTEGER Reserved FRACTION Table 5-80 RTC Frequency Compensation Register (RTC_FREQADJ, address 0x4000_8008). Bits Description...
  • Page 208 ISD91200 Series Technical Reference Manual RTC Time Load Register (RTC_TIME) This register is Read Only until access enable password is written to RTC_RWEN register. The register returns the current time. Register Offset Description Reset Value RTC_BA+0x00C R/W RTC_TIME Time Load Register...
  • Page 209 ISD91200 Series Technical Reference Manual RTC Calendar Load Register (RTC_CAL) This register is Read Only until access enable password is written to RTC_RWEN register. The register returns the current date. Register Offset Description Reset Value RTC_BA+0x010 R/W RTC_CAL Calendar Load Register...
  • Page 210 ISD91200 Series Technical Reference Manual RTC Time Scale Selection Register (RTC_CLKFMT) Register Offset Description Reset Value RTC_BA+0x014 R/W RTC_CLKFMT Time Scale Selection Register 0x0000_0001 Table 5-83 RTC Time Scale Selection Register (RTC_CLKFMT, address 0x4000_8014). Reserved 24HEN Bits Description [31:1] Reserved Reserved.
  • Page 211 ISD91200 Series Technical Reference Manual RTC Day of the Week Register (RTC_WEEKDAY) Register Offset Description Reset Value RTC_BA+0x018 R/W RTC_WEEKDAY Day of the Week Register 0x0000_0000 Reserved WEEKDAY Table 5-84 RTC Day of Week Register (RTC_WEEKDAY, address 0x4000_8018). Bits Description...
  • Page 212 ISD91200 Series Technical Reference Manual RTC Time Alarm Register (RTC_TALM) Register Offset Description Reset Value RTC_BA+0x01C R/W RTC_TALM Time Alarm Register 0x0000_0000 Reserved Reserved TENHR Reserved TENMIN Reserved TENSEC Table 5-85 RTC Time Alarm Register (RTC_TALM, address 0x4000_801C). Bits Description...
  • Page 213 ISD91200 Series Technical Reference Manual RTC Calendar Alarm Register (RTC_CALM) Register Offset Description Reset Value RTC_BA+0x020 R/W RTC_CALM Calendar Alarm Register 0x0000_0000 Reserved TENYEAR YEAR Reserved TENMON Reserved TENDAY Table 5-86 RTC Calendar Alarm Register (RTC_CALM, address 0x4000_8020). Bits Description...
  • Page 214 ISD91200 Series Technical Reference Manual RTC Leap year Indication Register (RTC_LEAPYEAR) Register Offset Description Reset Value RTC_LEAPYEAR RTC_BA+0x024 R Leap year Indicator Register 0x0000_0000 Reserved LEAPYEAR Table 5-87 RTC Leap Year Indicator Register (RTC_LEAPYEAR, address 0x4000_8024). Bits Description [31:1] Reserved Reserved.
  • Page 215 ISD91200 Series Technical Reference Manual RTC Interrupt Enable Register (RTC_INTEN) Register Offset Description Reset Value RTC_BA+0x028 R/W RTC_INTEN RTC Interrupt Enable Register 0x0000_0000 Reserved TICKIEN ALMIEN Table 5-88 RTC Interrupt Enable Register (RTC_INTEN, address 0x4000_8028). Bits Description [31:2] Reserved Reserved.
  • Page 216 ISD91200 Series Technical Reference Manual RTC Interrupt Indication Register (RTC_INTSTS) Register Offset Description Reset Value RTC_BA+0x02C R/W RTC_INTSTS RTC Interrupt Indicator Register 0x0000_0000 Reserved TICKIF ALMIF Table 5-89 RTC Interrupt Indication Register (RTC_INTSTS, address 0x4000_802C). Bits Description [31:2] Reserved Reserved.
  • Page 217 ISD91200 Series Technical Reference Manual RTC Time-Tick Register (RTC_TICK) Register Offset Description Reset Value RTC_BA+0x030 R/W RTC_TICK RTC Time Tick Register 0x0000_0000 Reserved TWKEN TICKSEL Table 5-90 RTC Time-Tick Register (RTC_TICK, address 0x4000_8030). Bits Description [31:4] Reserved Reserved. RTC Timer Wakeup CPU Function Enable Bit If TWKE is set before CPU is in power-down mode, when a RTC Time-Tick or Alarm Match occurs, CPU will wake up.
  • Page 218: Serial 0 Peripheral Interface (Spi0) Controller

    ISD91200 Series Technical Reference Manual Serial 0 Peripheral Interface (SPI0) Controller 5.9.1 Overview The Serial Peripheral Interface (SPI) is a synchronous serial data communication protocol which operates in full duplex mode. Devices communicate in master/slave mode with 4-wire bi-directional interface. The I91200 series contains an SPI controller performing a serial-to-parallel conversion of data received from an external device, and a parallel-to-serial conversion of data transmitted to an external device.
  • Page 219: Spi0 Function Descriptions

    ISD91200 Series Technical Reference Manual 5.9.4 SPI0 Function Descriptions 5.9.4.1 SPI Engine Clock and SPI Serial Clock The SPI controller derives its clock source from the system HCLK as determined by the CLKSEL1 register. The frequency of the SPI master clock is determined by the divisor ratio SPI0_CLKDIV.
  • Page 220 ISD91200 Series Technical Reference Manual 5.9.4.3 Slave Select In master mode, the SPI controller can address up to two off-chip slave devices through the slave select output pins SPI0_SSB0 and SPI0_SSB1. Only one slave can be addressed at any one time. If more slave address lines are required, GPIO pins can be manually configured to provide additional SSB lines.
  • Page 221 ISD91200 Series Technical Reference Manual edge of serial clock SPI0_SCLK. If RXNEG=1 then data is clocked in on the falling edge of SPI0_SCLK. If RXNEG=0 data is clocked in on the rising edge of SPI0_SCLK. Note that RXNEG should be the inverse of TXNEG for standard SPI operation.
  • Page 222 ISD91200 Series Technical Reference Manual transmission out the SPI port. The CortexM0 stores data in a little endian format; that is the LSB of a multi-byte word or half-word are stored first in memory. Consider how the CortexM0 stores the following arrays in memory: 1.
  • Page 223 ISD91200 Series Technical Reference Manual unsigned char ucSPI_DATA[]={0x01, 0x02, 0x03, 0x04, 0x05, 0x06, 0x07, 0x08}; unsigned int *uiSPI_DATA = (unsigned int *)ucSPI_DATA[]; RAM Address RAM Contents Byte0 Byte1 Byte2 Byte3 0x20000014 Byte0 Byte1 Byte2 Byte3 0x20000010 0x08 0x07 0x06 0x05...
  • Page 224 ISD91200 Series Technical Reference Manual 2. If the slave select active but there is no any serial clock input, the SLVBEIF also active when the slave select goes to inactive state.  Slave Under-run and Slave Error 1 interrupts In Slave mode, if there is no any data is written to the SPI0_TX register, the under-run event, TXUFIF (SPI0_STATUS[19]) will active when the slave select active and the serial clock input this controller.
  • Page 225 ISD91200 Series Technical Reference Manual SPI0_MOSI0 and SPI0_MOSI1 pin, same as Master mode. SPICLKx SCLK MISOx[0] MISOx[1:0] MISO Slave 0 MOSIx[0] MOSIx[1:0] MOSI SPI Controller Master SPISSx0 SPISSx1 SCLK MISOx[1] MISO Slave 1 MOSIx[1] MOSI Figure 5-41 2-Bit Mode System Architecture...
  • Page 226 ISD91200 Series Technical Reference Manual I/O transfer. The QDIODIR bit (SPI0_CTL[20]) is used to define the direction of the transfer data. When the QDIODIR bit is set to 1, the controller will send the data to external device. When the QDIODIR bit is set to 0, the controller will read the data from the external device.
  • Page 227 ISD91200 Series Technical Reference Manual SPI0_MISO1, SPI0_MOSI0 and SPI0_MOSI1 will be set as data input ports. SPICLKx SCLK MISOx[1] MISOx[0] MISOx[1:0] HOLDB MISO Quad SpiFlash MOSIx[0] MOSIx[1:0] MOSI SPI Controller MOSIx[1] Master SPISSx0 SPISSx1 Figure 5-45 Quad Mode System Architecture...
  • Page 228 ISD91200 Series Technical Reference Manual transmission logic unit draws out the last datum of the transmit FIFO buffer, so that the 4-level transmit FIFO buffer is empty, the TXEMPTY bit will be set to 1. Notice that the TXEMPTY flag is set to 1 while the last transaction is still in progress.
  • Page 229: Spi Timing Diagram

    ISD91200 Series Technical Reference Manual transmission will start when the slave device receives clock signal from master. Data can be written to SPI0_TX register as long as the TXFULL flag is 0. After all data have been drawn out by the SPI transmission logic unit and the SPI0_TX register is not updated by software, the TXEMPTY flag will be set to 1.
  • Page 230 ISD91200 Series Technical Reference Manual SS_LVL=1 SPI_SS SS_LVL=0 CLKP=0 SPICLK CLKP=1 MOSI Tx0[6] Tx0[5] Tx0[4] Tx0[3] Tx0[2] Tx0[1] Tx0[7] Tx0[0] MISO Rx0[6] Rx0[5] Rx0[4] Rx0[3] Rx0[2] Rx0[1] Rx0[7] Rx0[0] Master Mode: CNTRL[SLVAE]=0, CNTRL[LSB]=0, CNTRL[Tx_NUM]=0x0, CNTRL[Tx_BIT_LEN]=0x08 1. CNTRL[CLKP]=0, CNTRL[Tx_NEG]=1, CNTRL[Rx_NEG]=0 or 2.
  • Page 231 ISD91200 Series Technical Reference Manual SS_LVL=1 SPI_SS SS_LVL=0 CLKP=0 SPICLK CLKP=1 MISO Tx0[6] Tx0[0] Tx1[7] Tx1[6] Tx0[7] Tx1[0] MOSI Rx0[6] Rx0[0] Rx1[7] Rx1[6] Rx0[7] Rx1[0] Slave Mode: CNTRL[SLVAE]=1, CNTRL[LSB]=0, CNTRL[Tx_NUM]=0x01, CNTRL[Tx_BIT_LEN]=0x08 1. CNTRL[CLKP]=0, CNTRL[Tx_NEG]=1, CNTRL[Rx_NEG]=0 or 2. CNTRL[CLKP]=1, CNTRL[Tx_NEG]=0, CNTRL[Rx_NEG]=1...
  • Page 232: Spi Configuration Examples

    ISD91200 Series Technical Reference Manual 5.9.6 SPI Configuration Examples  Example 1, SPI controller is set as a master to access an off-chip slave device with following specifications:  Data bit latched on positive edge of serial clock  Data bit driven on negative edge of serial clock ...
  • Page 233 ISD91200 Series Technical Reference Manual To configure the SPI interface to the above specifications perform the following steps: 1) Configure the SPI0_SSCTL register. SPI0_SSCTL.SSACTPOL=1 for active high slave select, SPI0_SSCTL.SS_LTRIG=1 for level sensitive trigger. 2) Configure SPI0_CTL register. SPI0_CTL.SLAVE=1 slave mode, SPI0_CTL.CLKPOL=1 for SCLK polarity idle high, set SPI0_CTL.TXNEG=1 so that data changes...
  • Page 234: Register Map

    ISD91200 Series Technical Reference Manual 5.9.7 Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value SPI Base Address: SPI0_BA = 0x4003_0000 SPI0_CTL SPI0_BA + 0x00 Control and Status Register 0x0000_0034 SPI0_CLKDIV...
  • Page 235: Register Description

    ISD91200 Series Technical Reference Manual 5.9.8 Register Description SPI Control and Status Register (SPI0_CTL) Register Offset Description Reset Value SPI0_CTL SPI0_BA + 0x00 R/W Control and Status Register 0x0000_0034 Reserved RXMODEEN RXTCNTEN QUADIOEN DUALIOEN QDIODIR REORDER SLAVE UNITIEN TWOBIT Reserved...
  • Page 236 ISD91200 Series Technical Reference Manual Byte Reorder Function Enable 0 = Byte reorder function Disabled. 1 = Byte reorder function Enabled. A byte suspend interval will be inserted between each byte. The period of the byte suspend interval depends on the setting of SUSPITV.
  • Page 237 ISD91200 Series Technical Reference Manual Suspend Interval (Master Only) The four bits provide configurable suspend interval between two successive transmit/receive transactions in a transfer. The definition of the suspend interval is the interval between the last clock edge of the preceding transaction word and the first clock edge of the following transaction word.
  • Page 238 ISD91200 Series Technical Reference Manual SPI Divider Register (SPI0_CLKDIV) Register Offset Description Reset Value SPI0_CLKDIV SPI0_BA + 0x04 R/W Clock Divider Register (Master Only) 0x0000_0000 Reserved Reserved Reserved DIVIDER Table 5-92 SPI Clock Divider Register (SPI0_CLKDIV, address 0x4003_0004) Bits Description...
  • Page 239 ISD91200 Series Technical Reference Manual SPI Slave Select Register (SPI0_SSCTL) Register Offset Description Reset Value SPI0_SSCTL SPI0_BA + 0x08 R/W Slave Select Register 0x0000_0000 SLVTOCNT[15:8] SLVTOCNT[7:0] Reserved SSINAIEN SSACTIEN Reserved SLVUDRIEN SLVBCEIEN Reserved SLVTORST SLVTOIEN SLV3WIRE AUTOSS SSACTPOL Table 5-93 SPI Slave Select Register (SPI0_SSCTL, address 0x4003_0008)
  • Page 240 ISD91200 Series Technical Reference Manual 0 = Slave mode time-out interrupt Disabled. 1 = Slave mode time-out interrupt Enabled. Slave 3-wire Mode Enable This is used to ignore the slave select signal in Slave mode. The SPI controller can work with 3-wire interface consisting of SPI0_CLK, SPI0_MISO, and SPI0_MOSI.
  • Page 241 ISD91200 Series Technical Reference Manual SPI DMA Control Register (SPI0_PDMACTL) Register Offset R/W Description Reset Value SPI0_PDMACT SPI0_BA + 0x0C SPI PDMA Control Register 0x0000_0000 Table 5-94 SPI0_PDMACTL Control Register (address SPI0_BA + 0x0C) Reserved PDMARST RXPDMAEN TXPDMAEN Bits Description...
  • Page 242 ISD91200 Series Technical Reference Manual SPI FIFO Control Register (SPI0_FIFOCTL) Register Offset R/W Description Reset Value SPI0_FIFOCTL SPI0_BA + 0x10 R/W FIFO Control/Status Register 0x4400_0000 Table 5-95 SPI FIFO Control Register SPI0_FIFOCTL (address SPI0_BA + 0x10) Reserved TXTH Reserved RXTH...
  • Page 243 ISD91200 Series Technical Reference Manual to report the transmit under-run data out. Receive FIFO Overrun Interrupt Enable RXOVIEN 0 = Receive FIFO overrun interrupt Disabled. 1 = Receive FIFO overrun interrupt Enabled. Slave Receive Time-out Interrupt Enable RXTOIEN 0 = Receive time-out interrupt Disabled.
  • Page 244 ISD91200 Series Technical Reference Manual SPI Status Register (SPI0_STATUS) Register Offset R/W Description Reset Value SPI0_STATU SPI0_BA + 0x14 R/W Status Register 0x0005_0110 Table 5-96 SPI Status Register SPI0_STATUS (address SPI0_BA + 0x14) TXCNT RXCNT TXRXRST Reserved TXUFIF TXTHIF TXFULL...
  • Page 245 ISD91200 Series Technical Reference Manual SPI Enable Bit Status (Read Only) 0 = Indicate the transmit control bit is disabled. 1 = Indicate the transfer control bit is active. [15] SPIENSTS Note: The clock source of SPI controller logic is engine clock, it is asynchronous with the system clock.
  • Page 246 ISD91200 Series Technical Reference Manual Slave Select Line Bus Status (Read Only) 0 = Indicates the slave select line bus status is 0. SSLINE 1 = Indicates the slave select line bus status is 1. Note: If SPI0_SSCTL.SSACTPOL is set 0, and the SSLINE is 1, the SPI slave select is in inactive status.
  • Page 247 ISD91200 Series Technical Reference Manual SPI Receive Transaction Count (SPI0_RXTSNCNT) Register Offset Description Reset Value SPI0_RXTSNCNT SPI0_BA + 0x18 Receive Transaction Count Register 0x0000_0000 Table 5-97 SPI Receive Transaction Count (address SPI0_BA + 0x18) RXTSNCNT RXTSNCNT Table 5-98 SPI Receive Transaction Count (SPI0_RXTSNCNT, address SPIx_BA + 0x18)
  • Page 248 ISD91200 Series Technical Reference Manual SPI Data Transmit Register (SPI0_TX) Register Offset Description Reset Value SPI0_TX SPI0_BA + 0x20 FIFO Data Transmit Register 0x0000_0000 Table 5-99 SPI Data Transmit Register (SPI0_TX, address SPIx_BA + 0x20) Bits Description Data Transmit Register A write to the data transmit register pushes data onto into the 8-level transmit FIFO buffer.
  • Page 249 ISD91200 Series Technical Reference Manual SPI Data Receive Register (SPI0_RX) Register Offset Description Reset Value SPI0_RX SPI0_BA + 0x30 FIFO Data Receive Register 0x0000_0000 Table 5-100 SPI Data Receive Register (SPI0_RX, address SPIx_BA + 30) Bits Description Data Receive Register [31:0] A read from this register pops data from the 8-level receive FIFO.
  • Page 250: Serial 1 Peripheral Interface (Spi1) Controller

    ISD91200 Series Technical Reference Manual 5.10 Serial 1 Peripheral Interface (SPI1) Controller 5.10.1 Overview The Serial Peripheral Interface (SPI) is a synchronous serial data communication protocol which operates in full duplex mode. Devices communicate in master/slave mode with 4-wire bi-directional interface.
  • Page 251: Spi1 Function Descriptions

    ISD91200 Series Technical Reference Manual 5.10.4 SPI1 Function Descriptions 5.10.4.1 SPI Engine Clock and SPI Serial Clock The SPI controller derives its clock source from the system HCLK as determined by the CLKSEL1 register. The frequency of the SPI master clock is determined by the divisor ratio SPI1_CLKDIV.
  • Page 252 ISD91200 Series Technical Reference Manual SCLK SCLK MISO MISO Master I91200 MOSI MOSI SPI1 Controller Slave Figure 5-54 SPI1 Slave Mode Application Block Diagram 5.10.4.3 Slave Select In master mode, the SPI controller can address up to one off-chip slave devices through the slave select output pins SPI1_SSB.
  • Page 253 ISD91200 Series Technical Reference Manual Word suspend CLK = 0 SPICLK CLK = 1 Tx 0 [ 30 ] Tx 0 [ 0 ] Tx 1 [ 31 ] Tx 1 [ 30 ] MISO Tx 0 [ 31 ]...
  • Page 254 ISD91200 Series Technical Reference Manual 5.10.4.13 Byte Endian APB access to the SPI controller is via the 32bit wide TX and RX registers. When the transfer is set as MSB first (SP1I_CTL.LSB = 0) and the SPI1_CTL.BYTEENDIAN bit is set, the data stored in the TX buffer and RX buffer will be rearranged such that the least significant physical byte is processed first.
  • Page 255 ISD91200 Series Technical Reference Manual It can be seen from Figure 5-58 Byte Order in Memory that byte order for an array of bytes is different than that of an array of words. Now consider if this data were to be sent to the SPI port; the user could: 3.
  • Page 256 ISD91200 Series Technical Reference Manual 5.10.4.15 Interrupt The SPI controller can generate a CPU interrupt when data transfer is finished. When a transfer request triggered by EN is finished, the interrupt flag (SPI_CTL.IF) will be set by hardware. If the SPI interrupt is enabled (SPI1_CTL.IE) this will also generate a CPU interrupt.
  • Page 257: Spi Timing Diagram

    ISD91200 Series Technical Reference Manual determined by setting of SPI1_CLKDIV, if the bit content of VARCLK is ‘1’, the output period for that bit is determined by the SPI1_ CLKDIV.DIV1 register. The following figure shows the timing relationships of serial clock (SCLK), to the VARCLK, the DIV0 and the DIV1 registers. A two-bit combination in the VARCLK defines one clock cycle.
  • Page 258 ISD91200 Series Technical Reference Manual SS.LVL=1 SPI->SS SS.LVL=0 CLKP=0 SPICLK CLKP=1 Tx0[1] Tx0[2] Tx0[3] Tx0[4] Tx0[5] Tx0[6] MOSI Tx0[0] Tx0[7] MISO Rx0[1] Rx0[2] Rx0[3] Rx0[4] Rx0[5] Rx0[6] Rx0[0] Rx0[7] Master Mode: CTL.SLVAE=0, CTL.LSB=1, CTL.TXNUM=0x0, CTL.TXBITLEN=0x08 1. CTL.CLKP=0, CTL.TXNEG=0, CTL.RXNEG=1 or 2.
  • Page 259 ISD91200 Series Technical Reference Manual SS.LVL=1 SPI->SS SS.LVL=0 CLKP=0 SPICLK CLKP=1 MISO Tx0[1] Tx0[7] Tx1[0] Tx1[6] Tx0[0] Tx1[7] MOSI Rx0[1] Rx0[7] Rx1[0] Rx1[6] Rx0[0] Rx1[7] Slave Mode: CTL.SLVAE=1, CTL.LSB=1, CTL.TXNUM=0x01, CTL.TXBITLEN=0x08 1. CTL.CLKP=0, CTL.TXNEG=0, CTL.RXNEG=1 or 2. CTL.CLKP=1, CT.LTXNEG=1, CTL.RXNEG=0...
  • Page 260: Spi Configuration Examples

    ISD91200 Series Technical Reference Manual 5.10.6 SPI Configuration Examples  Example 1, SPI controller is set as a master to access an off-chip slave device with following specifications:  Data bit latched on positive edge of serial clock  Data bit driven on negative edge of serial clock ...
  • Page 261 ISD91200 Series Technical Reference Manual To configure the SPI interface to the above specifications perform the following steps: 8) Configure the SPI1_ SSCTL register. SPI1_ SSCTL.SSLVL=1 for active high slave select, SPI1_ SSCTL.SSR.SSLTRIG=1 for level sensitive trigger. 9) Configure the SPI1_CTL register. Set SPI1_CTL.SLAVE=1 for slave mode, set SPI1_CTL.CLKP=1 for SCLK polarity idle high, set SPI1_CTL.TXNEG=1 so that data changes on falling edge of SCLK,...
  • Page 262: Register Map

    ISD91200 Series Technical Reference Manual 5.10.7 Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value SPI1 Base Address: SPI1_BA = 0x4003_8000 SPI1_CTL SPI1_BA + 0x00 Control and Status Register 0x0500_0004 SPI1_CLKDIV...
  • Page 263: Register Description

    ISD91200 Series Technical Reference Manual 5.10.8 Register Description SPI Control and Status Register (SPI_CTL) Register Offset Description Reset Value SPI1_CTL SPI1_BA + 0x00 R/W Control and Status Register 0x0500_0004 Reserved DMABURST TXFULL TXEMPTY RXFULL RXEMPTY VARCLKEN TWOB FIFO BYTEENDIAN BYTESLEEP...
  • Page 264 ISD91200 Series Technical Reference Manual TWOB Two Bits Transfer Mode 1 = Enable two-bit transfer mode. 0 = Disable two-bit transfer mode. [22] Note that when enabled in master mode, MOSI data comes from SPI1_TX0 and MOSI data from SPI1_TX1. Likewise SPI1_RX0 receives bit stream from MISO0 and SPI1_RX1 from MISO1.
  • Page 265 ISD91200 Series Technical Reference Manual LSB First 0 = The MSB is transmitted/received first (which bit in SPI1_TX0/1 and SPI1_RX0/1 register that is depends on the TXBITLEN field). [10] 1 = The LSB is sent first on the line (bit 0 of SPI1_TX0/1), and the first bit received from the line will be put in the LSB position in the Rx register (bit 0 of SPI1_RX0/1).
  • Page 266 ISD91200 Series Technical Reference Manual TXBITLEN Transmit Bit Length This field specifies how many bits are transmitted in one transmit/receive. Up to 32 bits can be transmitted. 00001 = 1 bit 00010 = 2 bit 00011 = 3 bit 00100 = 4 bit...
  • Page 267 ISD91200 Series Technical Reference Manual RXNEG Receive At Negative Edge 0 = The received data input signal is latched at the rising edge of SCLK. 1 = The received data input signal is latched at the falling edge of SCLK.
  • Page 268 ISD91200 Series Technical Reference Manual Clock Divider Register (master only) [15:0] CLKDIV0 The value in this field is the frequency division of the system clock, PCLK, to generate the serial clock on the output SCLK. The desired frequency is obtained according to the following equation:...
  • Page 269 ISD91200 Series Technical Reference Manual Slave Select Level Trigger (Slave only) 0 = The input slave select signal is edge-trigger. This is the default value. SSLTRIG 1 = The slave select signal will be level-trigger. It depends on SSLVL to decide the signal is active low or active high.
  • Page 270 ISD91200 Series Technical Reference Manual Table 5-104 SPI Data Receive Register (SPI1_RX1, address 0x4003_8010) Bits Description Data Receive Register The Data Receive Registers hold the value of received data of the last executed transfer. Valid bits depend on the transmit bit length field in the [31:0] SPI1_CTL register.
  • Page 271 ISD91200 Series Technical Reference Manual Table 5-106 SPI Data Transmit Register (SPI1_TX0, address 0x4003_8020) Bits Description Data Transmit Register The Data Transmit Registers hold the data to be transmitted in the next transfer. Valid bits depend on the transmit bit length field in the SPI1_CTL register.
  • Page 272 ISD91200 Series Technical Reference Manual Data Transmit Register The Data Transmit Registers hold the data to be transmitted in the next transfer. Valid bits depend on the transmit bit length field in the SPI1_CTL register. For example, if TXBITLEN is set to 0x08 and the TXNUM is set to [31:0] 0x0, the bit SPI1_TX0[7:0] will be transmitted in next transfer.
  • Page 273 ISD91200 Series Technical Reference Manual Reserved Reserved Reserved RXMDAEN TXMDAEN Reserved Table 5-109 SPI DMA Control Register (DMA, address 0x4003_8038) Bits Description [31:2] Reserved Reserved Receive DMA Start 1 = Enable RXMDAEN 0 = Disable Set this bit to 1 will start the receive DMA process. SPI module will issue request to DMA module automatically.
  • Page 274: Timer Controller

    ISD91200 Series Technical Reference Manual 5.11 Timer Controller 5.11.1 General Timer Controller The I91200 provides two general 24bit timer modules, TIMER0 and TIMER1. They allow the user to implement event counting or provide timing control for applications. The timer can perform functions such as frequency measurement, event counting, interval measurement, clock generation and delay timing.
  • Page 275: Register Map

    ISD91200 Series Technical Reference Manual SYSCLK->CLKSEL1.TMRx_S SYSCLK->APBCLK.TMRx_EN HCLK TMx(GPIO) TMRx_CLK OSC12M OSC32K OSC10K Figure 5-68 Clock Source of Timer Controller 5.11.4 Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value TMR Base Address:...
  • Page 276: Register Description

    ISD91200 Series Technical Reference Manual 5.11.5 Register Description Timer Control Register (TIMERn_CTL) Register Offset Description Reset Value TMRn_CTL TMRn_BA+0x00 R/W Timer Control and Status Register 0x0000_0005 Reserved CNTEN INTEN OPMODE[1:0] RSTCNT ACTSTS Reserved Reserved CNTDATEN Reserved PSC[7:0] Table 5-110 Timer Control and Status Register (TIMERx_CTL, address 0x4001_0000 + x *0x20).
  • Page 277 ISD91200 Series Technical Reference Manual Timer Active Status Bit (Read Only) This bit indicates the counter status of timer. [25] ACTSTS 0 = Timer is not active. 1 = Timer is active. [24:17] Reserved Reserved. Data Latch Enable When CNTDATEN is set, TIMERx_CNT (Timer Data Register) will be updated continuously with the 24-bit up-counter value as the timer is counting.
  • Page 278 ISD91200 Series Technical Reference Manual Timer Compare Register (TIMERn_CMP) Register Offset Description Reset Value TMRn_CMP TMRn_BA+0x04 R/W Timer Compare Register 0x0000_0000 Reserved CMPDAT[23:16] CMPDAT [15:8] CMPDAT[7:0] Table 5-111 Timer Compare Register (TIMERx_CMP, address 0x4001_0004 + x * 0x20) Bits Description...
  • Page 279 ISD91200 Series Technical Reference Manual Timer Interrupt Status Register (TIMERn_INTSTS) Register Offset Description Reset Value TMRn_INTSTS TMRn_BA+0x08 R/W Timer Interrupt Status Register 0x0000_0000 Reserved Reserved Reserved Reserved Table 5-112 Timer Interrupt Status Register (TIMERx_INTSTS, address 0x4001_0008 + x * 0x20)
  • Page 280 ISD91200 Series Technical Reference Manual Timer Data Register (TIMERn_CNT) Register Offset Description Reset Value TMRn_CNT TMRn_BA+0x0C R/W Timer Data Register 0x0000_0000 Reserved CNT[23:16] CNT[15:8] CNT[7:0] Table 5-113 Timer Data Register (TIMERx_CNT, address 0x4001_000C + x *0x20). Bits Description [31:24] Reserved Reserved.
  • Page 281: Watchdog Timer

    ISD91200 Series Technical Reference Manual 5.12 Watchdog Timer The purpose of Watchdog Timer is to perform a system reset if software is not responding as designed. This prevents system from hanging for an infinite period of time. The watchdog timer includes a 18-bit free running counter with programmable time-out intervals.
  • Page 282 ISD91200 Series Technical Reference Manual WDT_CTL.RSTCNT Watchdog Reset WDT Counter WDT_CTL.IF Interrupt 18-bit WDT Counter WDT_CTL.INTEN …... Delay Watchdog Time- 1024 Reset select clocks WDT_CTL.RSTEN WDT_CLK WDT_CTL.WDTEN WDT_CTL.RSTF WDT_CTL.TOUTSEL Note: 1. Watchdog timer resets CPU and lasts 64 WDT_CLK. Figure 5-70 Watchdog Timer Block Diagram...
  • Page 283: Register Map

    ISD91200 Series Technical Reference Manual 5.12.1 Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value WDT Base Address: WDT_BA = 0x4000_4000 WDT_CTL WDT_BA+0x00 Watchdog Timer Control Register 0x0000_0700 Release Date: Sep 16, 2019 - 283 - Revision 2.4...
  • Page 284: Register Description

    ISD91200 Series Technical Reference Manual 5.12.2 Register Description Watchdog Timer Control Register (WDT_CTL) This is a protected register, to write to register, first issue the unlock sequence (refer to SYS_REGLCTL). Only flag bits, IF and RSTF are unprotected and can be write-cleared at any time.
  • Page 285 ISD91200 Series Technical Reference Manual Watchdog Timer Reset Flag When the Watchdog timer initiates a reset, the hardware will set this bit. This flag can be read by software to determine the source of reset. Software is responsible to clear it manually by writing 1 to it. If RSTEN is disabled, then the Watchdog timer RSTF has no effect on this bit.
  • Page 286: Uart Interface Controller

    ISD91200 Series Technical Reference Manual 5.13 UART Interface Controller The I91200 includes a Universal Asynchronous Receiver/Transmitter (UART). The UART supports high speed operation and flow control functions as well as protocols for Serial Infrared (IrDA) and Local interconnect Network (LIN).
  • Page 287 ISD91200 Series Technical Reference Manual Table 5-115 UART Baud Rate Equation Mode BAUDM1 BAUDM0 EDIVM1[3:0] BRD[15:0] Baud Rate Equation UART_CLK / [16 * (A+2)] UART_CLK / [(B+1) * (A+2)] , B ≥ 8 UART_CLK / (A+2), A ≥ 3 Don’t care Table 5-116 UART Baud Rate Setting Table System Clock = 49.152MHz...
  • Page 288: Features Of Uart Controller

    ISD91200 Series Technical Reference Manual 5.13.2 Features of UART controller • UART supports 8 byte FIFO for receive and transmit data payloads. • PDMA access support. • Auto flow control function (/CTS, /RTS) supported. • Programmable baud-rate generator. • Fully programmable serial-interface characteristics: 5-, 6-, 7-, or 8-bit character.
  • Page 289: Block Diagram

    ISD91200 Series Technical Reference Manual 5.13.3 Block Diagram The UART clock control and block diagram are shown as following. CLK_APBCLK0->UARTx_EN UARTx_CLK HCLK 1/(UARTDIV+1) CLK_CLKDIV0->UARTDIV Figure 5-71 UART Clock Control Diagram APB BUS Status & control Status & control Control and...
  • Page 290 ISD91200 Series Technical Reference Manual TX_FIFO The transmitter is buffered with an 8 byte FIFO to reduce the number of interrupts presented to the CPU. RX_FIFO The receiver is buffered with an 8 byte FIFO (plus three error bits per byte) to reduce the number of interrupts presented to the CPU.
  • Page 291: Irda Mode

    ISD91200 Series Technical Reference Manual 5.13.4 IrDA Mode The UART supports IrDA SIR (Serial Infrared) Transmit Encoder and Receive Decoder. IrDA mode is selected by setting the UART_FUNCSEL.IRDAENbit. When in IrDA mode, the UART_BAUD.BAUDM1 register must be zero and baud rate is given by: Baud Rate = UART_CLK / (16 * BRD), where BRD is Baud Rate Divider in the UART_BAUD.BRD...
  • Page 292 ISD91200 Series Technical Reference Manual STOP BIT START BIT SOUT (from uart TX) Timing IR_SOUT (encoder output) 3/16 bit width IR_SIN (decorder input) Timing 3/16 bit width (To uart RX) START BIT STOP BIT Bit pulse width Figure 5-75 IrDA Tx/Rx Timing Diagram...
  • Page 293: Lin (Local Interconnection Network) Mode

    ISD91200 Series Technical Reference Manual 5.13.5 LIN (Local Interconnection Network) mode The UART supports a Local Interconnection Network (LIN) function. LIN mode is selected by setting the UART_FUNCSEL.LINEN bit. In LIN mode, each byte field is initiated by a start bit with value zero...
  • Page 294: Register Map

    ISD91200 Series Technical Reference Manual 5.13.6 Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value UART Base Address: UARTn_BA = 0x4005_0000 + (n*0x8000) n=0,1 UARTn_DAT UARTn_BA+0x00 UART Receive/Transfer FIFO Register. 0x0000_0000...
  • Page 295: Register Description

    ISD91200 Series Technical Reference Manual 5.13.7 Register Description Receive FIFO Data Register (UARTn_DAT) Register Offset Description Reset Value UARTn_DAT UARTn_BA+0x00 R/W UART Receive/Transfer FIFO Register. 0x0000_0000 Reserved Reserved Reserved Table 5-117 UART Receive FIFO Data Register (UARTn_DAT, address 0x4005_0000) Bits...
  • Page 296 ISD91200 Series Technical Reference Manual Interrupt Enable Register (UARTn_INTEN) Register Offset Description Reset Value UARTn_INTEN UARTn_BA+0x04 R/W UART Interrupt Enable Register. 0x0000_0000 Reserved Reserved DMARXEN DMATXEN ATOCTSEN ATORTSEN TOCNTEN Reserved LINIEN Reserved BUFERRIEN RXTOIEN MODEMIEN RLSIEN THREIEN RDAIEN Table 5-118 UART Interrupt Enable Register (UARTn_INTEN, address 0x4005_0004)
  • Page 297 ISD91200 Series Technical Reference Manual Buffer Error Interrupt Enable BUFERRIEN 0 = Mask off BUFERRINT. 1 = Enable IBUFERRINT. Receive Time Out Interrupt Enable RXTOIEN 0 = Mask off RXTOINT. 1 = Enable RXTOINT. Modem Status Interrupt Enable MODEMIEN 0 = Mask off MODEMINT.
  • Page 298 ISD91200 Series Technical Reference Manual FIFO Control Register (UARTn_FIFO) Register Offset Description Reset Value UARTn_FIFO UARTn_BA+0x08 R/W UART FIFO Control Register. 0x0000_0000 Reserved Reserved RTSTRGLV Reserved RFITL Reserved TXRST RXRST Reserved Table 5-119 UART FIFO Control Register (UARTn_FIFO, address 0x4005_0008)
  • Page 299 ISD91200 Series Technical Reference Manual Receive FIFO Reset When RXRST is set, all the bytes in the receive FIFO are cleared and receive internal state machine is reset. RXRST 0 = Writing 0 to this bit has no effect. 1 = Writing 1 to this bit will reset the receiving internal state machine and pointers.
  • Page 300 ISD91200 Series Technical Reference Manual Line Control Register (UARTn_LINE) Register Offset Description Reset Value UARTn_LINE UARTn_BA+0x0C R/W UART Line Control Register. 0x0000_0000 Reserved Table 5-120 UART Line Control Register (UARTn_LINE, address 0x4005_000C) Bits Description [31:7] Reserved Reserved. Break Control Bit When this bit is set to logic 1, the serial data output (Tx) is forced to the ‘Space’...
  • Page 301 ISD91200 Series Technical Reference Manual MODEM Control Register (UARTn_MODEM) Register Offset Description Reset Value UARTn_MODEM UARTn_BA+0x10 R/W UART Modem Control Register. 0x0000_0000 Reserved Reserved Reserved RTSSTS Reserved RTSACTLV Reserved Reserved LBMEN Reserved Reserved Table 5-121 UART Modem Control Register (UARTn_MODEM, address 0x4005_0010)
  • Page 302 ISD91200 Series Technical Reference Manual Modem Status Register (UARTn_MODEMSTS) Register Offset R/W Description Reset Value UARTn_MODEMSTS UARTn_BA+0x14 R/W UART Modem Status Register. 0x0000_0010 Reserved Reserved Reserved CTSACTLV Reserved CTSSTS Reserved CTSDETF Table 5-122 UART Modem Status Register (UARTn_MODEMSTS, address 0x4005_0014)
  • Page 303 ISD91200 Series Technical Reference Manual FIFO Status Register (UARTn_FIFOSTS) Register Offset Description Reset Value UARTn_FIFOSTS UARTn_BA+0x18 R/W UART FIFO Status Register. 0x1040_4000 Reserved TXEMPTYF Reserved TXOVIF TXFULL TXEMPTY TXPTR RXFULL RXEMPTY RXPTR Reserved Reserved RXOVIF Table 5-123 UART FIFO Status Register (UARTn_FIFOSTS, address 0x4005_0018)
  • Page 304 ISD91200 Series Technical Reference Manual Receive FIFO Full (Read Only) [15] RXFULL This bit indicates whether the Rx FIFO is full or not. This bit is set when Rx FIFO is full; otherwise it is cleared by hardware. Receive FIFO Empty (Read Only) This bit indicates whether the Rx FIFO is empty or not.
  • Page 305 ISD91200 Series Technical Reference Manual Interrupt Status Register (UARTn_INTSTS) Register Offset Description Reset Value UARTn_BA+0x1C R/W UART Interrupt Status Register. UARTn_INTSTS 0x0000_0002 DLININT Reserved DBERRINT DRXTOINT DMODEMI DRLSINT Reserved DLINIF Reserved DBERRIF DRXTOIF DMODEMIF DRLSIF Reserved LININT Reserved BUFERRINT RXTOINT...
  • Page 306 ISD91200 Series Technical Reference Manual DMA MODE Buffer Error Interrupt Flag (Read Only) This bit is set when either the Tx or Rx FIFO overflows (UART_FIFOSTS.TXOVIF or UART_FIFOSTS.RXOVIF is set). When BUFERRIF is set, the serial transfer may be [21] DBERRIF corrupted.
  • Page 307 ISD91200 Series Technical Reference Manual Buffer Error Interrupt Flag (Read Only) This bit is set when either the Tx or Rx FIFO overflows (UART_FIFOSTS.TXOVIF or UART_FIFOSTS.RXOVIF is set). When BUFERRIF is set, the serial transfer may be BUFERRIF corrupted. If UART_INTEN.BUFERRIEN is enabled a CPU interrupt request will be generated.
  • Page 308 ISD91200 Series Technical Reference Manual When the DMA controller is used to transmit or receive data to the UART, an alternate set of flags and interrupt indicators are generated. These are equivalent to the normal mode set above and are summarized in below tables.
  • Page 309 ISD91200 Series Technical Reference Manual Time Out Register (UARTn_TOUT) Register Offset Description Reset Value UARTn_BA+0x20 R/W UART Time Out Register UARTn_TOUT 0x0000_0000 Reserved Reserved Reserved Reserved TOIC Table 5-127 UART Time Out Register (UARTn_TOUT, address 0x4005_0020) Bits Description [31:7] Reserved Reserved.
  • Page 310 ISD91200 Series Technical Reference Manual Baud Rate Divider Register (UARTn_BAUD) Register Offset Description Reset Value UARTn_BA+0x24 R/W UART Baud Rate Divisor Register UARTn_BAUD 0x0F00_0000 The baud rate generator takes the UART master clock UART_CLK and divides it to produce the baud rate (bit rate) clock.
  • Page 311 ISD91200 Series Technical Reference Manual IrDA Control Register (UARTn_IRDA) Register Offset Description Reset Value UARTn_IRDA UARTn_BA+0x28 R/W UART IrDA Control Register. 0x0000_0040 Reserved RXINV TXINV Reserved LOOPBACK TXEN Reserved Table 5-129 UART IrDA Control Register (UARTn_IRDA, address 0x4005_0028) Bits Description...
  • Page 312 ISD91200 Series Technical Reference Manual UART LIN Network Control Register (UARTn_ALTCTL) Register Offset Description Reset Value UARTn_ALTCTL UARTn_BA+0x2C R/W UART LIN Control Register. 0x0000_0000 Reserved Reserved Reserved LINTXEN LINRXEN Reserved BRKFL Table 5-130 UART LIN Network Control Register (UARTn_ALTCTL, address 0x4005_002C)
  • Page 313 ISD91200 Series Technical Reference Manual UART Function Select Register (UARTn_FUNCSEL) Register Offset Description Reset Value UARTn_FUNCSEL UARTn_BA+0x30 R/W UART Function Select Register. 0x0000_0000 Reserved Reserved Reserved Reserved IRDAEN LINEN Table 5-131 UART Function Select Register (UARTn_FUNCSEL, address 0x4005_0030) Bits Description...
  • Page 314: I2S Audio Pcm Controller

    ISD91200 Series Technical Reference Manual 5.14 I2S Audio PCM Controller 5.14.1 Overview The I2S controller is a peripheral for serial transmission and reception of audio PCM (Pulse-Code Modulated) signals across a 4-wire bus. The bus consists of a bit clock (I2S_BCLK) a frame synchronization clock (I2S_FS) and serial data in (I2S_SDI) and out (I2S_SDO) lines.
  • Page 315: I2S Block Diagram

    ISD91200 Series Technical Reference Manual 5.14.3 I2S Block Diagram I2S0SEL(CLK_CLKSEL2[1:0] I2S0CKEN(CLK_APBCLK0[29] OSC10K I2S_CLK OSC32K HCLK OSC48M Figure 5-77 I2S Clock Control Diagram I2S_MCLK I2S_CLK_GEN I2S_FS Transmit Contrl I2S_SDO Tx Shift Register & TXFIFO Interface I2S_BCLK & Shift Clock dma_req Control...
  • Page 316: I2S Operation

    ISD91200 Series Technical Reference Manual 5.14.4 I2S Operation I2S_BCLK I2S_FS I2S_SDI I2S_SDO Word N-1 Word N Word N Right Channel Left Channel Right Channel Figure 5-79 I2S Bus Timing Diagram (Format =0) I2S_BCLK I2S_FS I2S_SDI I2S_SDO Word N-1 Word N...
  • Page 317: Fifo Operation

    ISD91200 Series Technical Reference Manual 5.14.5 FIFO operation Mono 16-bit data mode Stereo 16-bit data mode LEFT RIGHT Mono 24-bit data mode Stereo 24-bit data mode LEFT RIGHT Mono 32-bit data mode Stereo 32-bit data mode LEFT RIGHT Figure 5-81 FIFO contents for various I2S modes...
  • Page 318: Register Map

    ISD91200 Series Technical Reference Manual 5.14.6 Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value I2S Base Address: I2S_BA = 0x400A_0000 I2S_CTL I2S_BA + 0x00 I2S Control Register 0x0000_0000 I2S_CLK I2S_BA + 0x04...
  • Page 319: Register Description

    ISD91200 Series Technical Reference Manual 5.14.7 Register Description I2S Control Register (I2S_CTL) Register Offset Description Reset Value I2S_CTL I2S_BA + 0x00 I2S Control Register 0x0000_0000 Reserved Reserved Reserved RXPDMAEN TXPDMAEN RXCLR TXCLR LZCEN RZCEN MCLKEN RXTH TXTH SLAVE FORMAT MONO...
  • Page 320 ISD91200 Series Technical Reference Manual Right Channel Zero Cross Detect Enable If this bit is set to 1, when right channel data sign bit changes, or data bits are all zero, the RZCIF flag in I2S_STATUS register will be set to 1.
  • Page 321 ISD91200 Series Technical Reference Manual Receive Enable RXEN 0 = Disable data receive. 1 = Enable data receive. Transmit Enable TXEN 0 = Disable data transmit. 1 = Enable data transmit. Enable I2S Controller I2SEN 0 = Disable. 1 = Enable.
  • Page 322 ISD91200 Series Technical Reference Manual I2S Clock Divider (I2S_CLKDIV) Register Offset Description Reset Value I2S_CLKDIV I2S_BA + 0x04 I2S Clock Divider Register 0x0000_0000 BCLKDIV Reserved MCLKDIV Table 5-133 I2S Clock Divider Register (I2S_CLKDIV, address 0x400A_0004) Bits Description [31:16] Reserved Reserved.
  • Page 323 ISD91200 Series Technical Reference Manual I2S Interrupt Enable Register (I2S_IEN) Register Offset Description Reset Value I2S_IEN I2S_BA + 0x08 I2S Interrupt Enable Register 0x0000_0000 Reserved LZCIEN RZCIEN TXTHIEN TXOVIEN TXUDIEN Reserved RXTHIEN RXOVIEN RXUDIEN Table 5-134 I2S Interrupt Enable Register (I2S_IEN, address 0x400A_0008)
  • Page 324 ISD91200 Series Technical Reference Manual Receive FIFO Underflow Interrupt Enable If software read receive FIFO when it is empty then RXUDIF flag in I2SSTATUS register is set to 1. RXUDIEN 0 = Disable interrupt. 1 = Enable interrupt. Release Date: Sep 16, 2019 - 324 - Revision 2.4...
  • Page 325 ISD91200 Series Technical Reference Manual I2S Status Register (I2S_STATUS) Register Offset Description Reset Value I2S_STATUS I2S_BA + 0x0C I2S Status Register 0x0014_1100 TXCNT RXCNT LZCIF RZCIF TXBUSY TXEMPTY TXFULL TXTHIF TXOVIF TXUDIF Reserved RXEMPTY RXFULL RXTHIF RXOVIF RXUDIF Reserved RIGHT...
  • Page 326 ISD91200 Series Technical Reference Manual Transmit FIFO Threshold Flag (Read Only) When data word(s) in transmit FIFO is less than or equal to the threshold value set in TXTH[2:0] the TXTHIF bit becomes to 1. It remains set until transmit FIFO level is greater than TXTH[2:0].
  • Page 327 ISD91200 Series Technical Reference Manual I2S Transmit Interrupt (Read Only) This indicates that there is an active transmit interrupt source. This could be TXOVIF, TXUDIF, TXTHIF, LZCIF or RZCIF if corresponding interrupt enable bits TXIF are active. To clear interrupt the corresponding source(s) must be cleared.
  • Page 328 ISD91200 Series Technical Reference Manual I2S Transmit FIFO (I2S_TX) Register Offset Description Reset Value I2S_TX I2S_BA + 0x10 I2S Transmit FIFO Register 0xXXXX_XXXX Table 5-136 I2S Transmit FIFO Register (I2S_TX, address 0x400A_0010) Bits Description Transmit FIFO Register (Write Only) A write to this register pushes data onto the transmit FIFO. The transmit FIFO is [31:0] eight words deep.
  • Page 329 ISD91200 Series Technical Reference Manual I2S Receive FIFO (I2S_RX) Register Offset Description Reset Value I2S_RX I2S_BA + 0x14 I2S Receive FIFO Register 0xXXXX_XXXX Table 5-137 I2S Receive FIFO Register (I2S_RX, address 0x400A_0014) Bits Description Receive FIFO Register (Read Only) A read of this register will pop data from the receive FIFO. The receive FIFO is eight [31:0] words deep.
  • Page 330: Pdma Controller

    ISD91200 Series Technical Reference Manual 5.15 PDMA Controller 5.15.1 Overview The I91200 incorporates a Peripheral Direct Memory Access (PDMA) controller that transfers data between SRAM and APB devices. The PDMA has four channels of DMA PDMA CH0~CH3). PDMA transfers are unidirectional and can be Peripheral-to-SRAM,SRAM-to-Peripheral or SRAM-to-SRAM.
  • Page 331: Function Description

    ISD91200 Series Technical Reference Manual 5.15.4 Function Description The PDMA controller has four channels of DMA, each channel can be configured to one of the following transfer types: Peripheral-to-SRAM SRAM-to-Peripheral or SRAM-to-SRAM. The SRAM and the AHB- APB bus bridge each have an AHB bus arbiter that allows AHB bus access to occur either from the CPU or the PDMA controller.
  • Page 332: Register Map

    ISD91200 Series Technical Reference Manual 5.15.5 Register Map R: read only, W: write only, R/W: both read and write, C: Only value 0 can be written Register Offset R/W Description Reset Value PDMA Base Address: PDMAn_BA = 0x5000_8000 +(n*0x100) n=0,1,2,3...
  • Page 333: Register Description

    ISD91200 Series Technical Reference Manual 5.15.6 Register Description PDMA Control Register (PDMA_CTLn) Register Offset Description Reset Value PDMA_CTLn PDMAn_BA+0x00 R/W PDMA Control Register of Channel n 0x0000_0000 Reserved TXEN Reserved TXWIDTH Reserved WAINTSEL Reserved DASEL SASEL MODESEL SWRST CHEN Table 5-138 PDMA Control and Status Register (...
  • Page 334 ISD91200 Series Technical Reference Manual Wrap Interrupt Select x1xx: If this bit is set, and wraparound mode is in operation a Wrap Interrupt can be generated when half each PDMA transfer is complete. For example if PDMA_TXCNTn = 32 then an interrupt could be generated when 16 bytes were sent.
  • Page 335 ISD91200 Series Technical Reference Manual PDMA Channel Enable Setting this bit to 1 enables PDMA’s operation. If this bit is cleared, PDMA will ignore CHEN all PDMA request and force Bus Master into IDLE state. Note: SWRST will clear this bit.
  • Page 336 ISD91200 Series Technical Reference Manual PDMA Transfer Source Address Register (PDMA_SADDRn) Register Offset R/W Description Reset Value PDMA_SADDRn PDMAn_BA+0x04 R/W PDMA Transfer Source Address Register of Channel n 0x4000_0000 SADDR SADDR SADDR SADDR Table 5-139 PDMA Source Address Register (PDMA_DADDRn, address 0x5000_8004 + n*0x100)
  • Page 337 ISD91200 Series Technical Reference Manual PDMA Transfer Destination Address Register (PDMA_DADDRn) Register Offset R/W Description Reset Value PDMA_DADDRn PDMAn_BA+0x08 R/W PDMA Transfer Destination Address Register of Channel n 0x4000_0000 Table 5-140 PDMA Address Register (PDMAT_DADDRn, address 0x5000_8008 + n*0x100) Destination...
  • Page 338 ISD91200 Series Technical Reference Manual PDMA Transfer Byte Count Register (PDMA_TXCNTn) Register Offset Description Reset Value PDMA_TXCNTn PDMAn_BA+0x0C R/W PDMA Transfer Byte Count Register of Channel n 0x0000_0000 Reserved Reserved CNT [15:8] CNT [7:0] Table 5-141 PDMA (PDMA_TXCNTn, address 0x5000_800C + n*0x100)
  • Page 339 ISD91200 Series Technical Reference Manual PDMA Internal Buffer Pointer Register (PDMA_INTPNTn) Register Offset Description Reset Value PDMA_INTPNTn PDMAn_BA+0x10 R PDMA Internal Buffer Pointer Register of Channel n 0xXXXX_XX00 Reserved Reserved Reserved Reserved POINTER Table 5-142 PDMA Internal Buffer Point Register (PDMA_INTPNTn, address 0x5000_8010 + n*0x100)
  • Page 340 ISD91200 Series Technical Reference Manual PDMA Current Source Address Register (PDMA_CURSADDRn) ) Register Offset Description Reset Value PDMA_CURSADDRn PDMAn_BA+0x14 R PDMA Current Source Address Register of Channel n 0xFFFF_FFFF Table 5-143 PDMA Current Source Address Register (PDMA_CURSADDRn, address 0x5000_8014 +...
  • Page 341 ISD91200 Series Technical Reference Manual PDMA Current Destination Address Register (PDMA_CURDADDRn) Register Offset Description Reset Value PDMA_CURDADDRn PDMAn_BA+0x18 R PDMA Current Destination Address Register of Channel n 0xFFFF_FFFF Table 5-144 PDMA Current Destination Address Register (PDMA_CURDADDRn, address 0x5000_8018 + n*0x100)
  • Page 342 ISD91200 Series Technical Reference Manual PDMA Current Transfer Byte Count Register (PDMA_CURTXCNTn) Register Offset Description Reset Value PDMA_CURTXCNTn PDMAn_BA+0x1C R PDMA Current Transfer Byte Count Register of Channel n 0x0000_0000 Reserved Reserved Table 5-145 PDMA (PDMA_CURTXCNTn, address 0x5000_801C + Current Byte Count Register...
  • Page 343 ISD91200 Series Technical Reference Manual PDMA Interrupt Enable Control Register (PDMA_INTENn) Register Offset Description Reset Value PDMA_INTENn PDMAn_BA+0x20 R/W PDMA Interrupt Enable Control Register of Channel n 0x0000_0001 Reserved Reserved Reserved Reserved WRAPIEN TXIEN ABTIEN Table 5-146 PDMA (PDMA_INTENn, address 0x5000_8020 + n*0x100)
  • Page 344 ISD91200 Series Technical Reference Manual PDMA Interrupt Status Register (PDMA_INTSTSn) Register Offset Description Reset Value PDMA_INTSTSn PDMAn_BA+0x24 R/W PDMA Interrupt Status Register of Channel n 0x0000_0000 INTSTS Reserved Reserved Reserved WRAPIF Reserved TXIF ABTIF Table 5-147 PDMA Interrupt Enable Status Register (PDMA_INTSTSn, address 0x5000_8024 +...
  • Page 345 ISD91200 Series Technical Reference Manual PDMA Span Increment Register (PDMA_SPANn) Register Offset R/W Description Reset Value PDMA_SPANn PDMAn_BA+0x34 PDMA Span Increment Register of Channel n 0x0000_0000 Reserved Reserved Reserved SPAN Table 5-148 PDMA Register (PDMA_SPANn, address 0x5000_8034 + n*0x100) Span Increment...
  • Page 346 ISD91200 Series Technical Reference Manual PDMA Current Span Increment Register (PDMA_CURSPANn) Register Offset R/W Description Reset Value PDMA_CURSPANn PDMAn_BA+0x38 R/W PDMA Current Span Increment Register of Channel n 0x0000_0000 Reserved Reserved Reserved SPAN Table 5-149 PDMA Current Register (PDMA_CURSPANn, address 0x5000_8038 +...
  • Page 347 ISD91200 Series Technical Reference Manual PDMA Global Control Register (PDMA_GCTL) Register Offset Description Reset Value PDMA_GCTL PDMA_GCR_BA+0x00 PDMA Global Control Register 0x0000_0000 Reserved Reserved Reserved CH3CKEN CH2CKEN CH1CKEN CH0CKEN Reserved SWRST Table 5-150 PDMA (PDMA_GCTL, address 0x5000_8F00) Global Control Register...
  • Page 348 ISD91200 Series Technical Reference Manual PDMA Service Selection Control Register 0(PDMA_SVCSEL0) Register Offset Description Reset Value PDMA_SVCSEL0 PDMA_GCR_BA+0x04 PDMA Service Selection Control Register 0 0xFFFF_FFFF PDMA peripherals have transmit and/or receive request signals to control dataflow during PDMA transfers. These signals must be connected to the PDMA channel assigned by software for use with that peripheral.
  • Page 349 ISD91200 Series Technical Reference Manual PDMA SPI0 Receive Selection [3:0] SPI0RXSEL This field defines which PDMA channel is connected to SPI0 peripheral receive (PDMA source) request. Release Date: Sep 16, 2019 - 349 - Revision 2.4...
  • Page 350 ISD91200 Series Technical Reference Manual PDMA Service Selection Control Register 1(PDMA_SVCSEL1) Register Offset Description Reset Value PDMA_SVCSEL1 PDMA_GCR_BA+0x08 PDMA Service Selection Control Register 1 0xFFFF_FFFF PDMA peripherals have transmit and/or receive request signals to control dataflow during PDMA transfers. These signals must be connected to the PDMA channel assigned by software for use with that peripheral.
  • Page 351 ISD91200 Series Technical Reference Manual PDMA Global Interrupt Status Register (PDMA_GINTSTS) Register Offset Description Reset Value PDMA_GINTSTS PDMA_GCR_BA+0x0C PDMA Global Interrupt Status Register 0x0000_0000 Reserved Reserved Reserved Reserved CH3INTSTS CH2INTSTS CH1INTSTS CH0INTSTS Table 5-153 PDMA (PDMA_GINTSTS, address 0x5000_8F0C) Global Interrupt Status Register...
  • Page 352: Volume Control

    ISD91200 Series Technical Reference Manual 5.16 Volume Control 5.16.1 Overview and feature The volume control function is digital domain gain control and supports both side of SDADC and DPWM. The audio signal can be changed from 36 dB to -108dB if using this feature.
  • Page 353: Volume Control Register Description

    ISD91200 Series Technical Reference Manual 5.16.3 Volume Control register Description Volume Control Enable Register (VOLCTRL_EN) Register Offset R/W Description Reset Value VOLCTRL_EN VOLCTRL_BA+0x00 R/W Volume Control Enable Register 0x0000_0000 Reserved Reserved Reserved Reserved DPWMZCEN SDADCZCEN DPWMVOLEN SDADCVOLE Bits Description [31:4]...
  • Page 354 ISD91200 Series Technical Reference Manual ADC Volume Control Value(VOLCTRL_ADCVAL) Register Offset R/W Description Reset Value VOLCTRL_ADCVAL VOLCTRL_BA+0x04 R/W ADC Volume Control Value 0x0004_0000 Reserved VALUE VALUE VALUE Bits Description [31:24] Reserved Reserved Delta-Sigma ADC Signal Volume Control Value Format <6,18>, gain range from -108.3dB to 36.1dB 0x00_0001 --- -108.3dB...
  • Page 355 ISD91200 Series Technical Reference Manual DAC Volume Control Value (VOLCTRL_DPWMVAL) Register Offset R/W Description Reset Value VOLCTRL_DPWMVAL VOLCTRL_BA+0x08 R/W DPWM Volume Control Value 0x0004_0000 Reserved VALUE VALUE VALUE Bits Description [31:24] Reserved DPWM Audio Signal Volume Control Value Format <6,18>. Gain range from 108.3dB to 36.1dB 0x00_0001 ---- -108.3dB...
  • Page 356: Flash Memory Controller (Fmc)

    ISD91200 Series Technical Reference Manual FLASH MEMORY CONTROLLER (FMC) Overview The I91200 series is available with 64K/128K bytes of on-chip embedded Flash EEPROM for application program and data flash memory. The memory can be updated through procedures for In- Circuit Programming (ICP) through the ARM Serial-Wire Debug (SWD) port or via In-System Programming (ISP) functions under software control.
  • Page 357: Flash Memory Controller Block Diagram

    ISD91200 Series Technical Reference Manual Flash Memory Controller Block Diagram The flash memory controller consist of AHB slave interface, ISP control logic, writer interface and flash macro interface timing control logic. The block diagram of flash memory controller is shown as...
  • Page 358: Flash Memory Organization

    ISD91200 Series Technical Reference Manual Flash Memory Organization The I91200 flash memory consists of Application Program (APROM) memory (128/64KB), data flash (DATAF), ISP boot loader (LDROM) program memory (4KB), user configuration (CONFIG). User configuration block provides 2 words that control system configuration, like flash security lock, boot select, brown out voltage level and data flash base address.
  • Page 359: Data Flash (Dataf)

    ISD91200 Series Technical Reference Manual UART, SPI or I2C to fetch new application code. The memory area from which the I91200 boots is controlled by the CBS bit in Config0 register. Data Flash (DATAF) The I91200 provides a data flash partition for user to store non-volatile data such as audio recordings. It accessed through ISP procedures via the Flash Memory Controller (FMC).
  • Page 360: User Configuration (Config)

    ISD91200 Series Technical Reference Manual User Configuration (CONFIG) Config0 (ISP Address = 0x0030_0000) Reserved CBODEN Reserved Reserved Reserved LOCK DFEN Table 6-2 User Configuration Register 0 (Config0, address 0x0030_0000 accessible through ISP only) Config0 Address = 0x0030_0000 Bits Description [31:23]...
  • Page 361 ISD91200 Series Technical Reference Manual Config1 (Address = 0x0030_0004) Reserved Reserved DFBA DFBA DFBA Table 6-3 User Configuration Register 1 (Config1, address 0x0030_0004 accessible through ISP only) Config1 Address = 0x0030_0004 Bits Description [31:20] Reserved Reserved It is mandatory to program 0x00 to these Reserved bits...
  • Page 362: In-System Programming (Isp)

    ISD91200 Series Technical Reference Manual In-System Programming (ISP) The program and data flash memory support both in hardware In-Circuit Programming (ICP) and firmware based In-System programming (ISP). Hardware ICP programming mode uses the Serial-Wire Debug (SWD) port to program chip. Dedicated ICE Debug hardware or ICP gang-writers are available to reduce programming and manufacturing costs.
  • Page 363 ISD91200 Series Technical Reference Manual Power CBS = 1 ? Enable ISPEN Write ISPADR/ ISPCMD/ Fetch code from Fetch code from ISPDAT LDROM APROM Set ISPTRIG = 1 Update LD-ROM or Execute ISP? write DataFlash End of Flash Operation (Read ISPDAT)
  • Page 364 ISD91200 Series Technical Reference Manual Read Company ID 0x0B Returns 0x0000_00DA Read Device ID 0x0C 0x00000 FLASH Page Erase 0x22 A[20] A[19:0] FLASH Program 0x21 A[20] A[19:0] Data input FLASH Read 0x00 A[20] A[19:0] Data output CONFIG Page Erase 0x22...
  • Page 365: Register Map

    ISD91200 Series Technical Reference Manual Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value FMC Base Address: FMC_BA=0x5000_C000 FMC_ISPCTL FMC_BA+0x00 ISP Control Register 0x0002_0000 FMC_ISPADDR FMC_BA+0x04 ISP Address Register 0x0000_0000 FMC_ISPDAT...
  • Page 366: Register Description

    ISD91200 Series Technical Reference Manual 6.10 Register Description ISP Control Register (FMC_ISPCTL) The FMC_ISPCTL register is a protected register, user must first follow the unlock sequence to gain access. Register Offset Description Reset Value FMC_ISPCTL FMC_BA+0x00 ISP Control Register 0x0002_0000...
  • Page 367 ISD91200 Series Technical Reference Manual Reserved Reserved. Boot Select 0 = APROM. 1 = LDROM. Modify this bit to select which ROM next boot is to occur. This bit also functions as MCU boot status flag, which can be used to check where MCU booted from. This bit is initialized after power-on reset with the inverse of CBS in Config0;...
  • Page 368 ISD91200 Series Technical Reference Manual ISP Address Register (FMC_ISPADDR) Register Offset Description Reset Value FMC_ISPADDR FMC_BA+0x04 ISP Address Register 0x0000_0000 ISPADDR ISPADDR ISPADDR ISPADDR Table 6-7 ISP Address Register (FMC_ISPADDR, address 0x5000_C004) Bits Description ISP Address Register This is the memory address register that a subsequent ISP command will access.
  • Page 369 ISD91200 Series Technical Reference Manual ISP Data Register (FMC_ISPDAT) Register Offset Description Reset Value FMC_ISPDAT FMC_BA+0x08 ISP Data Register 0x0000_0000 ISPDAT ISPDAT ISPDAT ISPDAT Table 6-8 ISP Data Register (FMC_ISPDAT, address 0x5000_C008) Bits Description ISP Data Register [31:0] ISPDAT Write data to this register before an ISP program operation.
  • Page 370 ISD91200 Series Technical Reference Manual ISP Command (FMC_ISPCMD) Register Offset Description Reset Value FMC_ISPCMD FMC_BA+0x0C ISP Command Register 0x0000_0000 Reserved Reserved Reserved Reserved Table 6-9 ISP Data Register (FMC_ISPCMD, address 0x5000_C00C) Bits Description [31:6] Reserved Reserved. ISP Command Operation Mode : CMD...
  • Page 371 ISD91200 Series Technical Reference Manual ISP Trigger Control Register (FMC_ISPTRG) The FMC_ISPTRG register is a protected register, user must first follow the unlock sequence to gain access. Register Offset Description Reset Value FMC_ISPTRG FMC_BA+0x10 ISP Trigger Control Register 0x0000_0000 Reserved...
  • Page 372 ISD91200 Series Technical Reference Manual Data Flash Base Address Register (FMC_DFBA) Register Offset Description Reset Value FMC_DFBA FMC_BA+0x14 Data Flash Base Address 0xXXXX_XXXX DFBA DFBA DFBA DFBA Table 6-11 Data Flash Base Address Register (FMC_DFBA, address 0x5000_C014) Bits Description Data Flash Base Address This register reports the data flash starting address.
  • Page 373: Analog Signal Path Blocks

    ISD91200 Series Technical Reference Manual ANALOG SIGNAL PATH BLOCKS This section describes the functional blocks that perform analog signal functions on the ISD91200. This includes the ADC, DPWM Speaker Driver, PGA Gain Amplifier, Automatic Gain Control and a variety of auxiliary analog functional blocks.
  • Page 374: Operation

    ISD91200 Series Technical Reference Manual 7.1.4 Operation The SDADC is an audio Sigma-Delta converter that operates by oversampling the analog input at low resolution and decimating the result by an over-sampling ratio to obtain a high resolution output which is pushed into the FIFO. The ultimate data rate is determined by the converter clock frequency, and the oversampling ratio.
  • Page 375 ISD91200 Series Technical Reference Manual 2.048MHz 16KHz 6.166MHz 4.096MHz 2.048MHz 1.024MHz 8KHz 3.072MHz 2.048MHz 1.024MHz 512KHz Table 7-2 Sample Rates for MCLK 12.288MHz SD_CLK CLKDIV SDADC_CTL.DSRATE BIQ_CTL.SDADCWNSR 48KHz 3.072MHz 32KHz 2.048MHz 16KHz 2.048MHz 1.024MHz 8KHz 3.072MHz 2.048MHz Release Date: Sep 16, 2019 - 375 - Revision 2.4...
  • Page 376 ISD91200 Series Technical Reference Manual 1.024MHz 512KHz Table 7-3 Sample Rates for SINC CHIP Decimator Output SINC down factor Low pass filter BIQ BS sample rate Software down sample Sample Rate ( get one out of 40/20/10/5/8 ) 384Hz order, 5 stage 9.6Hz...
  • Page 377 ISD91200 Series Technical Reference Manual 10000;//1.000000 10000;//1.000000 10000;//1.000000 10000;//1.000000 10000;//1.000000 6061e;//-1.976105 60c6b;//-1.951500 61b10;//-1.894287 63ef0;//-1.754158 06151;//0.380135 0fa45;//0.977615 0f505;//0.957108 0ea8d;//0.916214 0d6e9;//0.839493 0a46c;//0.642273 00070;//0.001709 0008a;//0.002111 000f5;//0.003744 00298;//0.010124 062df;//0.385269 7ff49;//-0.002789 7ff84;//-0.001886 00068;//0.001579 003c5;//0.014725 0c107;//0.752182 00070;//0.001709 0008a;//0.002111 000f5;//0.003744 00298;//0.010124 062df;//0.385269 10000;//1.000000 10000;//1.000000 10000;//1.000000 10000;//1.000000 10000;//1.000000 608e1;//-1.965317...
  • Page 378 ISD91200 Series Technical Reference Manual • Setup FIFO data width SDADC_CTL.FIFOBITS • Setup down ampling rate, set SDADC_CTL.RATESEL=0 then set SDADC_CTL.DSRATE & BIQ_CTL.SDADCWNSR for expected DSR & sampling rate(refer to Table 7-1) • Setup PDMA channel to receive data from SDADC.
  • Page 379: Adc Register Map

    ISD91200 Series Technical Reference Manual 7.1.4.5 Peripheral DMA Request Normal use of the SDADC is with PDMA. In this mode ADC requests PDMA service whenever data is in FIFO. PDMA channel will copy this data to a buffer and alert the CPU when buffer is full. In this way an entire buffer of data can be collected without any CPU intervention.
  • Page 380: Adc Register Description

    ISD91200 Series Technical Reference Manual 7.1.6 ADC Register Description SD ADC FIFO Data Register(SDADC_DAT) Register Offset R/W Description Reset Value SDADC_DAT SDADC_BA+0x00 SD ADC FIFO Data Read Register 0xxxxx_xxxx Reserved Reserved RESULT[15:8] RESULT[7:0] Bits Description Delta-Sigma ADC DATA FIFO Read...
  • Page 381 ISD91200 Series Technical Reference Manual SD ADC Enable Register(SDADC_EN) Register Offset Description Reset Value SDADC_EN SDADC_BA+0x04 R/W SD ADC Enable Register 0x0000_0000 Reserved Reserved Reserved Reserved Reserved DINEDGE SDADCEN Bits Description [31:3] Reserved Reserved. Reserved Reserved ADC data input clock edge selection (for DMIC only, default 0 for AMIC)
  • Page 382 ISD91200 Series Technical Reference Manual SD ADC Clock Divider Register (SDADC_CLKDIV) Register Offset Description Reset Value SDADC_CLKDIV SDADC_BA+0x08 R/W SD ADC Clock Divider Register 0x0000_0000 Reserved Reserved Reserved CLKDIV[7:0] Bits Description [31:8] Reserved Reserved. SD_CLK Clock Divider SDADC internal clock divider. CLKDIV should be set to give a SD_CLK frequency in the range of 1.024-6.144MHz.
  • Page 383 ISD91200 Series Technical Reference Manual SD ADC Control Register (SDADC_CTL) Register Offset Description Reset Value SDADC_CTL SDADC_BA+0x0C R/W SD ADC Control Register 0x0000_0000 Reserved Reserved Reserved RATESEL Reserved DMICEN THIE FIFOTH FIFOBITS DSRATE Bits Description [31:12] Reserved Reserved. [11] RATESEL...
  • Page 384 ISD91200 Series Technical Reference Manual SD ADC FIFO Status Register(SDADC_FIFOSTS) Register Offset Description Reset Value SDADC_FIFOSTS SDADC_BA+0x10 R/W SD ADC FIFO Status Register 0x0000_0002 BISTEN Reserved Reserved Reserved POINTER Reserved THIF EMPTY FULL Bits Description BIST Enable 1 = Enable SDADC FIFO BIST testing SDADC FIFO can be testing by Cortex-M0...
  • Page 385 ISD91200 Series Technical Reference Manual SD ADC PDMA Control Register(SDADC_PDMACTL) Register Offset Description Reset Value SDADC_PDMACTL SDADC_BA+0x14 R/W SD ADC PDMA Control Register 0x0000_0000 RESVERVED RESVERVED RESVERVED RESVERVED PDMAEN Bits Description [31:1] Reserved Reserved. Enable SDADC PDMA Receive Channel PDMAEN 1 = Enable SDADC PDMA.
  • Page 386 ISD91200 Series Technical Reference Manual A/D Compare Register 0 ( SDADC_CMPR0 Register Offset Description Reset Value SDADC_CMPR0 SDADC_BA+0x18 R/W SD ADC Comparator 0 Control Register 0x0000_0000 CMPOEN CMPD CMPD CMPD CMPMATCNT CMPF CMPCOND CMPIE Reserved Bits Description Compare Match output FIFO zero...
  • Page 387 ISD91200 Series Technical Reference Manual A/D Compare Register 1 ( SDADC_CMPR1 Register Offset Description Reset Value SDADC_CMPR1 SDADC_BA+0x1C R/W SD ADC Comparator 1 Control Register 0x0000_0000 CMPOEN CMPD CMPD CMPD CMPMATCNT CMPF CMPCOND CMPIE Reserved Bits Description Compare Match output FIFO zero...
  • Page 388 ISD91200 Series Technical Reference Manual SD Analog Block Control Register(SDADC_SDCHOP) Register Offset Description Reset Value SDADC_SDCHOP SDADC_BA+0x20 R/W Sigma Delta Analog Block Control Register 0x001c_1021 AUDIOPATHSEL Reserved Reserved Reserved Reserved Reserved Reserved Reserved PGAADCDC PGAADCUP PGABYPS PGACLASSA PGACMLCKADJ PGACMLCK PGADISCH...
  • Page 389 ISD91200 Series Technical Reference Manual Common mode Threshold lock adjust. Action takes effect when PGA_CMLCK=0 00---0.98 (default) 01---0.96 [17:16] PGA_CMLCKADJ 10---1.01 11---1.04 default=00 Common mode Threshold lock adjust enable [15] PGA_CMLCK 0 = Enable 1 = Disable Charge inputs selected by PGA_ACDC[1:0] to VREF...
  • Page 390: Bridge Sense

    ISD91200 Series Technical Reference Manual Bridge Sense 7.2.1 Functional Description The Bridge Sense block consists of three parts, a low noise bandgap, an LDO and an Instrumentation Amplifier (IA). See Figure 3 for the block diagram. The bandgap circuit generates a reference voltage, VBG. The LDO uses VBG to make a stable voltage that can be used to bias a Wheatstone bridge.
  • Page 391: Operation

    ISD91200 Series Technical Reference Manual Figure 4. Block diagram of instrumentation amplifier (IA). 7.2.4 Operation 7.2.4.1 Startup To power on the bridge sense part of the I92160B the bridge sense bandgap and the LDO have to be turned on first.
  • Page 392: Register Map

    ISD91200 Series Technical Reference Manual Following are compensation examples for Offset Minimum Calibration. Step1: Set bit INSTRAMP[10] =1 (BS Instrumentation Amplifier offset negative input opamp enable), (note INSTRAMP[11] =0 ) Step2: Set bit INSTRAMP[9:4] = 0x3f ,code 0x20 doesn’t exist Step3: Ignore the next 64 output cycles, for signal stable Step4: Capture 64 cycles of output data and average store them in an array ;...
  • Page 393: Register Description

    ISD91200 Series Technical Reference Manual Register Offset Description Reset Value BS_BANDGPLDO SDADC_BA+0x24 R/W Bridge Sense Bandgap and LDO Control Register 0x0000_400e BS_INSTRAMP SDADC_BA+0x28 R/W Bridge Sense Instrumentation Amplifer Control Register 0x000c_0c00 7.2.6 Register Description Bridge Sense Bandgap and LDO Control Register(BS_BANDGP_LDO)
  • Page 394 ISD91200 Series Technical Reference Manual BS set LDO output voltage 0000 = 1.5 0001 = 1.8 0010 = 2.1 0011 = 2.4 0100 = 2.7 [19:16] LDOSET 0101 = 3.0 0110 = 3.3 0111 = 3.6 1000 = 3.9 1001 = 4.2 1010 = 4.5...
  • Page 395 ISD91200 Series Technical Reference Manual BS Bandgap TRIM 0000 = bandgap +0 0001 = bandgap+(1*12)mV 0010 = bandgap+(2*12)mV 0011 = bandgap+(3*12)mV 0100 = bandgap+(4*12)mV 0101 = bandgap+(5*12)mV 0110 = bandgap+(6*12)mV [7:4] BTRIM 0111 = bandgap+(7*12)mV 1000 = bandgap-(8*12)mV 1001 = bandgap-(7*12)mV...
  • Page 396 ISD91200 Series Technical Reference Manual Bridge Sense Instrumentation Amplifer Control Register(BS_INSTRAMP) Register Offset R/W Description Reset Value R/W Bridge Sense Instrumentation Amplifer Control Register 0x000c_0c00 BS_INSTRAMP BS_BA+0x04 Reserved SCHOPPH SCHOPF CHOPF CHOPOPH CHOPNPH CHOPPPH CHOPPDIS CHOPNDIS OFFSETTRIM SYSCHOPEN CHOPEN OFFSETP...
  • Page 397 ISD91200 Series Technical Reference Manual BS Instrumentation Amplifer chopper positive disable When OFFSETTRIM bit is high [22] CHOPPDIS 1 = disable chopper in positive input opamp 0 = Enable chopper in positive input opamp BS Instrumentation Amplifer chopper negative disable...
  • Page 398: Audio Class D Speaker Driver (Dpwm)

    ISD91200 Series Technical Reference Manual Audio Class D Speaker Driver (DPWM) 7.3.1 Functional Description The ISD91200 includes a differential Class D (PWM) speaker driver capable of delivering 0.5W into an 8Ω load at 5V supply voltage. The driver works by up-sampling and modulating a PCM input to differentially drive the SPK+ and SPK- pins.
  • Page 399 ISD91200 Series Technical Reference Manual 7.3.4.1 DPWM switch frequecy HCLK DPWM_CLK= Switch frequency HCLK/DPWMDIV 49.152MHz 24.576MHz 614.4KHz 12.288MHz 307.2KHz 8.192MHz 204.8KHz 6.144MHz 153.6KHz 7.3.4.2 DPWM Clock Generator DPWMCKSEL(CLK_CLKSEL1[5:4]) DPWMCKEN(CLK_APBCLK0[13]) HCLK 1/(DPWMDIV + 1) DPWMDIV (CLK_CLKDIV0[15:12]) DPWM_CLK CLK12M Note: Before clock switching, both the pre-selected and newly selected clock sources must be turned on and stable.
  • Page 400 ISD91200 Series Technical Reference Manual 16KHz 8KHz 7.3.4.4 Configuring Speaker Driver To operate the speaker driver the following configuration is recommended: • Enable DPWM clock source (CLK_APBCLK0.DPWMCKEN, CLK_CLKSEL1.DPWMCKSEL). • Reset DPWM IP block. (SYS_IPRST1.DPWMRST) • Select sample rate based on current DPWM_CLK frequency.
  • Page 401: Dpwm Register Map

    ISD91200 Series Technical Reference Manual 7.3.5 DPWM Register Map R: read only, W: write only, R/W: both read and write. Register Offset Description Reset Value DPWM Base Address: DPWM_BA = 0x4007_0000 DPWM_CTL DPWM_BA+0x00 DPWM Control Register 0x0000_0000 DPWM_STS DPWM_BA+0x04 DPWM DATA FIFO Status Register...
  • Page 402: Dpwm Register Description

    ISD91200 Series Technical Reference Manual 7.3.6 DPWM Register Description DPWM Control Register (DPWM_CTL) Register Offset Description Reset Value DPWM_CTL DPWM_BA+0x00 R/W DPWM Control Register 0x0000_0000 Reserved Reserved RXTH RXTHIE Reserved Reserved DPWMDRVEN DPWMEN Reserved DEADTIME Reserved FIFOWIDTH Bits Description [31:16] Reserved Reserved.
  • Page 403 ISD91200 Series Technical Reference Manual DPWM FIFO DATA WIDTH SELETION From PDMA 00 = PDMA MSB 24bits PWDATA[31:8] [1:0] FIFOWIDTH 01 = PDMA 16 bits PWDATA[15:0] 10 = PDMA 8bits PWDATA[7:0] 11 = PDMA 24bits PWDATA[23:0] Release Date: Sep 16, 2019 - 403 - Revision 2.4...
  • Page 404 ISD91200 Series Technical Reference Manual DPWM FIFO Status Register (DPWM_STS) Register Offset Description Reset Value DPWM_STS DPWM_BA+0x04 R DPWM DATA FIFO Status Register 0x0000_0002 BISTEN Reserved Reserved Reserved FIFOPTR Reserved RXTHIF EMPTY FULL Table 7-2 (DPWM_STS, address 0x4007_0004) DPWM FIFO Status Register...
  • Page 405 ISD91200 Series Technical Reference Manual DPWM PDMA Control Register(DPWM_DMACTL) Register Offset Description Reset Value DPWM_DMACTL DPWM_BA+0x08 R/W DPWM PDMA Control Register 0x0000_0000 Reserved Reserved Reserved Reserved DMAEN Table 7-3 (DPWM_DMACTL, address 0x4007_0008) DPWM PDMA Control Register Bits Description [31:1] Reserved Reserved.
  • Page 406 ISD91200 Series Technical Reference Manual DPWM FIFO Input (DPWM_DATA) Register Offset Description Reset Value DPWM_DATA DPWM_BA+0x0C W DPWM DATA FIFO Input 0x0000_0000 INDATA INDATA INDATA INDATA Table 7-4 (DPWM_DATA, address 0x4007_000C) DPWM FIFO Input Bits Description DPWM FIFO Audio Data Input...
  • Page 407 ISD91200 Series Technical Reference Manual DPWM ZOH Division (DPWM_ZOHDIV) Register Offset Description Reset Value DPWM_ZOHDIV DPWM_BA+0x10 R/W DPWM Zero Order Hold Division Register 0x0000_0006 Reserved Reserved Reserved ZOHDIV Table 7-5 (DPWM_ZOHDIV, address 0x4007_0010) DPWM Zero Order Hold Division Register Bits...
  • Page 408: Analog Functional Blocks

    ISD91200 Series Technical Reference Manual Analog Functional Blocks 7.4.1 Overview The ISD91200 contains a variety of analog functional blocks that facilitate audio processing, enable analog GPIO functions (current source, relaxation oscillator, and comparator), adjust and measure internal oscillator and provide voltage regulation. These blocks are controlled by registers in the analog block address space.
  • Page 409: Vmid Reference Voltage Generation

    ISD91200 Series Technical Reference Manual 7.4.4 VMID Reference Voltage Generation The analog path and blocks require a low when off. noise, mid-rail, Voltage reference for operation, the VMID generation block provides this. Control of this block allows user to power down the block, select its power down condition and control over the reference impedance.
  • Page 410: Ldo Power Domain Control

    ISD91200 Series Technical Reference Manual VMID Control Register (ANA_VMID) Register Offset Description Reset Value ANA_VMID ANA_BA+0x00 VMID Reference Control Register 0x0000_0007 Reserved PDHIRES PDLORES PULLDOWN Table 7-6 VMID Control Register (ANA_VMID, address 0x4008_0000). Bits Description [31:3] Reserved Reserved. Power Down High (360kΩ) Resistance Reference 0= Connect the High Resistance reference to VMID.
  • Page 411 ISD91200 Series Technical Reference Manual LDO Voltage Control Register (ANA_LDOSEL) Register Offset Description Reset Value ANA_LDOSEL ANA_BA+0x20 LDO Voltage Select Register 0x0000_0000 Reserved LDOSEL Table 7-7 , address 0x4008_0020). LDO Voltage Control Register ANA_LDOSEL Bits Description [31:3] Reserved Reserved. Select LDO Output Voltage Note that maximum I/O pad operation speed only specified for voltage >2.4V.
  • Page 412: Microphone Bias (Replaced By Bridge Sense Adc)

    ISD91200 Series Technical Reference Manual LDO Power Down Register (ANA_LDOPD) Register Offset Description Reset Value ANA_LDOPD ANA_BA+0x24 LDO Power Down Register 0x0000_0001 Reserved DISCHAR Table 7-8 Register (ANA_LDOPD, address 0x4008_0024). LDO Power Down Control Bits Description [31:2] Reserved Reserved. Discharge DISCHAR 0 = Don’t discharge VD33.
  • Page 413: Oscillator Frequency Measurement And Control

    ISD91200 Series Technical Reference Manual Reserved Table 7-10 Register (ANA_, address 0x4008_0028). Microphone Bias Voltage Level Selection Bits Description [31:3] Reserved Reserved. LVL controls the voltage output of the MICBIAS generator, voltages are encoded as following: 0 - 1.5V 1 - 1.8V 2 - 1.95V...
  • Page 414 ISD91200 Series Technical Reference Manual ANA_FQMMCTL. FQMMEN = TRUE; while( (ANA_FQMMCTL.MMSTS != 1) && (Timeout++ < 0x100000)); Timeout >= 0x100000) return(E_DRVOSC_MEAS_TIMEOUT); Freq = ANA_FQMMCNT; ANA_FQMMCTL.FQMMEN = FALSE; Freq = Freq*32768 /DRVOSC_NUM_CYCLES; Release Date: Sep 16, 2019 - 414 - Revision 2.4...
  • Page 415 ISD91200 Series Technical Reference Manual Oscillator Trim Register (ANA_TRIM) Register Offset Description Reset Value ANA_TRIM ANA_BA+0x84 Oscillator Trim Register 0x0000_XXXX Reserved Reserved COARSE OSCTRIM Table 7-11 Oscillator Trim Register (ANA_TRIM, address 0x4008_0084). Bits Description [31:16] Reserved Reserved. COARSE [15:8] COARSE Current COARSE range setting of the oscillator.
  • Page 416 ISD91200 Series Technical Reference Manual Frequency Measurement Control Register (ANA_FQMMCTL) Register Offset Description Reset Value ANA_FQMMCTL ANA_BA+0x94 Frequency Measurement Control Register 0x0000_0001 FQMMEN Reserved CYCLESEL Reserved Reserved MMSTS CLKSEL Table 7-12 Frequency Measurement Control Register (ANA_FQMMCTL, address 0x4008_0094). Bits Description...
  • Page 417 ISD91200 Series Technical Reference Manual Frequency Measurement Count (ANA_FQMMCNT) Register Offset Description Reset Value ANA_FQMMCNT ANA_BA+0x98 Frequency Measurement Count Register 0x0000_0000 Reserved Reserved FQMMCNT FQMMCNT Table 7-13 Frequency Measurement Count Register (ANA_FQMMCNT, address 0x4008_0098). Bits Description [31:16] Reserved Reserved. Frequency Measurement Count When MMSTS = 1 and FQMMEN = 1, this is number of PCLK periods counted for frequency measurement.
  • Page 418 ISD91200 Series Technical Reference Manual Frequency Measurement Cycle (ANA_FQMMCYC) Register Offset Description Reset Value ANA_FQMMCYC ANA_BA+0x9C Frequency Measurement Cycle Register 0x0000_0000 Reserved FQMMCYC FQMMCYC FQMMCYC Table 7-14 Frequency Measurement Cycle Register (ANA_FQMMCYC, address 0x4008_009C). Bits Description [31:24] Reserved Reserved. Frequency Measurement Cycles Number of reference clock periods plus one to measure target clock (PCLK).
  • Page 419: Automatic Level Control (Alc)

    ISD91200 Series Technical Reference Manual Automatic Level Control (ALC) 7.5.1 Overview and Features The SDADC audio signal digital path is supported by digital automatic level control function. The ALC monitors the output of the SDADC biquad output when that filter is enabled in the SDADC path, or the output of the SINC filter otherwise.
  • Page 420 ISD91200 Series Technical Reference Manual In Normal mode, the MAXGAIN bits set the maximum level for the PGA but in the Limiter mode MAXGAIN has no effect because the maximum level is set by the initial PGA gain setting upon enabling of the ALC.
  • Page 421 ISD91200 Series Technical Reference Manual In limiter mode, the PGA gain is constrained to be less than or equal to the gain setting at the time the limiter mode is enabled. In addition, attack and decay times are faster in limiter mode than in normal mode as indicated by the different lookup tables for these parameters for limiter mode.
  • Page 422 ISD91200 Series Technical Reference Manual PGA Input PGA Output PGA Gain Figure 7-14: ALC Operation with Noise Gate disabled PGA Input Noise Gate Threshold PGA Output PGA Gain Figure 7-15: ALC Operation with Noise Gate Enabled 7.5.1.7 Zero Crossing The PGA gain comes from either the ALC block when it is enabled or from the PGA gain register setting when the ALC is disabled.
  • Page 423: Register Map

    ISD91200 Series Technical Reference Manual 7.5.2 Register Map R: read only, W: write only, R/W: both read and write Register Offset Description Reset Value ALC Base Address: ALC_BA = 0x400B_0090 ALC_CTL ALC_BA+0x00 ALC Control Register 0x0000_0000 ALC_GAIN ALC_BA+0x04 ALC GAIN Control Register...
  • Page 424: Register Description

    ISD91200 Series Technical Reference Manual 7.5.3 Register Description ALC Control Register (ALC_CTRL) Register Offset Description Reset Value ALC_CTL ALC_BA+0x00 ALC Control Register 0x0000_0000 Table 7-15 ALC Control Register (ALC_CTL, address 0x400B_0090) PKLIMEN PKSEL NGPKSEL ALCEN MAXGAIN MINGAIN[2] MINGAIN[1:0] ALCRANGES HOLDTIME...
  • Page 425 ISD91200 Series Technical Reference Manual ALC Minimum Gain 0 = -12 dB. 1 = -6 dB. 2 = 0 dB. [24:22] MINGAIN 3 = 6 dB. 4 = 12 dB. 5 = 18 dB. 6 = 24 dB. 7 = 30 dB.
  • Page 426 ISD91200 Series Technical Reference Manual Noise Gate Threshold 000 --- -39dB 001--- -45dB 010---- -51dB [2:0] NGTHBST 011 --- -57dB 100 --- -63dB 101 --- -69dB 110 --- -75dB 111 --- -81dB ALC Gain Control Register (ALC_GAIN) Register Offset Description...
  • Page 427 ISD91200 Series Technical Reference Manual ALC Initial Gain Set ALC initial gain. [5:0] INITGAIN Selects the PGA gain setting from -12dB to 35.25dB in 0.75dB step size. 0x00 is lowest gain setting at -12dB and 0x3F is largest gain at 35.25dB...
  • Page 428 ISD91200 Series Technical Reference Manual ALC Status Register (ALC_STATUS) Register Offset Description Reset Value ALC_STS ALC_BA+0x08 ALC Status Register 0x0100_0000 Table 7-17 ALC Status Register (ALC_STS, address 0x400B_0098) Reserved ALCGAIN ALCGAIN PEAKVAL[8:5] PEAKVAL[4:0] P2PVAL[8:6] P2PVAL[5:0] NOISEF CLIPF Bits Description [31:26] Reserved Reserved.
  • Page 429 ISD91200 Series Technical Reference Manual Reserved GMINIE GMAXIE GDECIE GINCIE NGIE PLMTIE Bits Description ALC Interrupt flag This interrupt flag asserts whenever the interrupt is enabled and the PGA gain is [31] ALCIF updated, either through an ALC change with the ALC enabled or through a PGA gain write with the ALC disabled.
  • Page 430: Capacitive Sensing Scan (Cscan) And Operational Amplifiers

    ISD91200 Series Technical Reference Manual Capacitive Sensing Scan (CSCAN) and Operational Amplifiers 7.6.1 Overview and Features Capacitive Sensing Scanner has the ability to set up a capacitive sensing on up to 16 GPIO pins. The block can do a single measurement or be set up to scan a defined set of GPIO before interrupting the CPU.
  • Page 431 ISD91200 Series Technical Reference Manual A0PSEL 00: no connection 01: from VH1 (0.9×V 10: from VM (0.5×V 11: from VL1 (0.1×V no connection A0O2A1N A0O2N A0NS A0O2A1P OPA1 Connect To OPA0 SAR ADC8 A0PS A0OEN Figure 7-16 Operational Amplifier 0 Switch Control The following diagram and table illustrate the OPA1 switch control setting and the corresponding connections.
  • Page 432 ISD91200 Series Technical Reference Manual A1PSEL 00: no connection 01: from VH1 (0.9×V 10: from VM (0.5×V 11: from VL1 (0.1×V no connection A1O2N PGAEN 560k A1NS Connect To OPA1 SAR ADC9 A1PS A1OEN A0O2A1N OPA0 A0O2A1P Figure 7-17 Operational Amplifier 1 Switch Control The following diagram is OPAs bias setting, If the OPBIASEN is set to “1”, that will turn on the resistor DC path,...
  • Page 433: Comparator

    ISD91200 Series Technical Reference Manual 7.6.5 Comparator The ISD91200 contains two analog comparators are contained within the devices. These functions offer flexibility via their register controlled features such as power-down, interrupt etc. Sharing their pins with normal I/O pins, the comparators do not waste precious I/O pins if there functions are otherwise unused.
  • Page 434: Register Description

    ISD91200 Series Technical Reference Manual 7.6.7 Register Description CSCAN Control Register (CSCAN_CTRL) Register Offset Description Reset Value CSCAN_CTRL CSCAN_BA+0x00 R/W CSCAN Control Register 0x8000_0000 Table 7-19 CSCAN Control Register (CSCAN_CTRL, address 0x400D_0000) Reserved Reserved DUR_CNT MODE1 MODE0 SLOW_CLK INT_EN Reserved...
  • Page 435 ISD91200 Series Technical Reference Manual CSCAN Enable Interrupt [20] INT_EN 0 = Interrupt disabled. 1 = Interrupt enabled. [19:18] Reserved Keep with 0 CSCAN Oscillator current [17:16] CURRENT Controls the analog bais current of the capacitive relaxation oscillator. 0:300nA 1:450nA 2:600nA 3:1200nA...
  • Page 436 ISD91200 Series Technical Reference Manual CSCAN Cycle Count Number of cycles to time a CapSense even over 4 bit value decoded to 1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 768, 1024, 1536, 2048, 2560, 3072 CYCLE_CNT Cycles...
  • Page 437 ISD91200 Series Technical Reference Manual Table 7-22 CSCAN Interrupt Register (CSCAN_INT, address 0x400D_000C) Reseverd Reserved Reserved Reserved Bits Description [31:1] Reserved CSCAN Interrupt active Write ‘1’ to clear. CSCAN Analog GPIO Register (CSCAN_AGPIO) Register Offset Description Reset Value CSCAN_AGPIO CSCAN_BA+0x10 R/W...
  • Page 438 ISD91200 Series Technical Reference Manual 7.6.7.1 Operational Amplifier Control Register (OPACTRL) Register Offset Description Reset Value CSCAN_OPACTL CSCAN_BA+0x14 Operational Amplifier Control Register 0x0000_0000 Reserved A1O2CIN A0O2CIN LPWREN A0O2A1N A0O2A1P Reserved VREFEN PGAEN PGA_GAIN A1O2N A1PSEL A1PS A1NS A1OEN A1EN A0O2N...
  • Page 439 ISD91200 Series Technical Reference Manual OPA1 Gain Control Bits 000 = 1. 001 = 8. 010 = 16. [18:16] 011 = 24. 100 = 32. 101 = 40. 110 = 48. 111 = 56. [15] Operational amplifier 1 output; positive logic This bit is read only...
  • Page 440 ISD91200 Series Technical Reference Manual OPA0 Output Enable or Disable Control Bit A0OEN 0 = disable. 1 = enable. OPA0 Enable or Disable Control Bit A0EN 0 = disable. 1 = enable. Comparator Control Register (CMPCTRL) Register Offset R/W Description...
  • Page 441 ISD91200 Series Technical Reference Manual Comparator 2 interrupt control C2INTEN: 0= disable [11] 1= enable Comparator 2 output pin control bit C2OUTEN 0= disable [10] 1= enable Comparator 2 inverting input control C2PSEL: 0= from VL0 1= from C2P pin...
  • Page 442: Biquad Filter (Biq)

    ISD91200 Series Technical Reference Manual Biquad Filter (BIQ) 7.7.1 Overview and Features A coefficient programmable 6-stage Biquad filter (12 -Order IIR filter) is available which can be used on either SDADC path or DPWM path to further reduce unwanted noise or filter the signal. Each biquad filter has the transfer function as H(z) and is implemented in Direct Form II Transpose structure as.
  • Page 443: Register Map

    ISD91200 Series Technical Reference Manual Configuring Coefficient 1. BIQ function work on 6 stages, set BIQ_CTL.STAGE=0, BIQ function will call 30 coefficients from BIQ_BA+0x0 ~0x074 2. BIQ function work on 5 stages, set BIQ_CTL.STAGE=1, BIQ function will call 25 coefficients from BIQ_BA+0x00 ~0x060 3.
  • Page 444 ISD91200 Series Technical Reference Manual Coefficient b0 In H(z) Transfer Function BIQ_COEFF10 BIQ_BA + 0x28 0x0000_0000 (3.16 format) - 3 stage BIQ Coefficients Coefficient b1 In H(z) Transfer Function BIQ_COEFF11 BIQ_BA+0x02c 0x0000_0000 (3.16 format) - 3 stage BIQ Coefficients Coefficient b2 In H(z) Transfer Function...
  • Page 445: Register Description

    ISD91200 Series Technical Reference Manual 7.7.3 Register Description BIQ Coefficient Register (BIQ_COEFFn) Register Offset Description Reset Value Coefficient b0 In H(z) Transfer Function BIQ_COEFF0 BIQ_BA+0x00 0x0000_0000 (3.16 format) - 1 stage BIQ Coefficients Coefficient b1 In H(z) Transfer Function BIQ_COEFF1...
  • Page 446 ISD91200 Series Technical Reference Manual Coefficient a2 In H(z) Transfer Function BIQ_COEFF19 BIQ_BA+0x04c 0x0000_0000 (3.16 format) - 4 stage BIQ Coefficients Coefficient b0 In H(z) Transfer Function BIQ_COEFF20 BIQ_BA + 0x50 0x0000_0000 (3.16 format) - 5 stage BIQ Coefficients Coefficient b1 In H(z) Transfer Function...
  • Page 447 ISD91200 Series Technical Reference Manual BIQ Control Register (BIQ_CTL) Register Offset Description Reset Value BIQ_CTL BIQ_BA+0x080 BIQ Control Register 0x0000_0110 Table 7-24 BIQ Control Register (BIQ_CTL, address 0x400B_0080) Reserved SRDIV[12:8] SRDIV[7:0] Reserved STAGE DPWMPUSR PRGCOEFF SDADCWNSR DLCOEFF PATHSEL HPFON BIQEN...
  • Page 448 ISD91200 Series Technical Reference Manual Move BIQ Out of Reset State 0 = BIQ filter is in reset state. DLCOEFF 1 = When this bit is on, the default coefficients will be downloaded to the coefficient ram automatically in 32 internal system clocks. Processor must delay enough time before changing the coefficients or turn the BIQ on.
  • Page 449 ISD91200 Series Technical Reference Manual BIQ Status Register (BIQ_STATUS) Register Offset Description Reset Value BIQ_STS BIQ_BA+0x084 BIQ status Register 0x8000_0000 Table 7-25 BIQ Status Register (BIQ_STATUS) RAMINITF Reserved Reserved Reserved Reserved BISTDONE BISTFAILED BISTEN Bits Description Coefficient Ram Initial Default Done Flag...
  • Page 450: Successive Approximation Analog-To-Digital Convertor (Saradc)

    ISD91200 Series Technical Reference Manual Successive Approximation Analog-to-Digital Convertor (SARADC) 7.8.1 Overview and Features – Analog input voltage range: 0~VREF – Up to 12 single-end analog input channels – Three operating modes • Single mode: A/D conversion is performed one time on a specified channel.
  • Page 451: Block Diagram

    ISD91200 Series Technical Reference Manual 7.8.2 Block Diagram VALID & OVERRUN PDMA request Digital Control Logics ADC_INT STADC & ADC Clock Generator RSLT[11:0] Successive Approximations Register 12-bit DAC ADC0 ADC1 Analog Control Logics Comparator ADC11 Sample and Hold Analog Macro Figure 7-20 SARADC Block Diagram 7.8.3...
  • Page 452 ISD91200 Series Technical Reference Manual 7.8.3.1 SARADC Clock Generator The SARADC engine has four clock sources selected by 2 bits SARADCSEL, the SARADC clock divided by 8 bits prescaler with the formula. The SARADC clock frequency = (SARADC clock source frequency)/(SARADCDIV+1).
  • Page 453 ISD91200 Series Technical Reference Manual ADC_CLK SWTRG sample ADDRx[11:0] ADDRx[11:0] ADEF Figure 7-22 Single Mode Conversion Timing Diagram 7.8.3.3 Single-Cycle Scan Mode In single-cycle scan mode, A/D conversion will sample and convert the specified channels once in the sequence from the smallest number enabled channel to the largest number enabled channel.
  • Page 454 ISD91200 Series Technical Reference Manual ADC_CLK SWTRG chsel[3:0] 0000b 0010b 0011b 0111b sample SAR[15:0] ADDR0 ADDR2 ADDR3 ADDR7 ADEF Single-cycle scan on channel 0, 2, 3 and 7 (SARADC_CHEN[15:0] = 0010001101b) Figure 7-23 Single-Cycle Scan on Enabled Channels Timing Diagram 7.8.3.4...
  • Page 455 ISD91200 Series Technical Reference Manual 28 55 56 112 1 28 ADC_CLK SWTRG Software clear SWTRG chsel[3:0] 0000b 0010b 0011b 0111b 0000b 0010b 0011b 0111b 0000b sample ADDR0 ADDR2 ADDR3 ADDR7 ADEF Continuous scan on channel 0, 2, 3 and 7 (SARADC_CHEN[15:0] =...
  • Page 456 ISD91200 Series Technical Reference Manual CMPCOND(ADCMPRx[2]) CMPCH(CMPx[6:3]) Channel CMPMATCNT Addr. (CMPx[11:8]) CHANNEL(STATUS[7:4]) RSLT < CMPD ADCMPFx ADDRx[11:0] (STATUS[2:1]) 12-bit Match AIN[0] Comparator Counter RSLT >=CMPD analog macro Note: AIN[11] CMPD=CMPx[27:16] RSLT=ADDRx[11:0] CMPD(CMPx[27:16]) Figure 7-25 A/D Conversion Result Monitor Logics Diagram 7.8.3.7...
  • Page 457: Register Map

    ISD91200 Series Technical Reference Manual 7.8.4 Register Map R: read only, W: write only, R/W: read/write Register Offset Description Reset Value SARADC Base Address: SARADC_BA = 0x4006_0000 SARADC_DAT0 SARADC_BA+0x00 SAR ADC Data Register 0 0x0000_0000 SARADC_DAT1 SARADC_BA+0x04 SAR ADC Data Register 1...
  • Page 458: Register Description

    ISD91200 Series Technical Reference Manual 7.8.5 Register description SAR ADC Data Register (SARADC_DATx) Register Offset Description Reset Value SARADC_DAT0 SARADC_BA+0x00 SAR ADC Data Register 0 0x0000_0000 SARADC_DAT1 SARADC_BA+0x04 SAR ADC Data Register 1 0x0000_0000 SARADC_DAT2 SARADC_BA+0x08 SAR ADC Data Register 2...
  • Page 459 ISD91200 Series Technical Reference Manual Overrun Flag (Read Only) 0 = Data in RESULT[11:0] is recent conversion result. 1 = Data in RESULT[11:0] is overwritten. [16] Note: If converted data in RESULT[11:0] has not been read before new conversion result is loaded to this register, OV is set to 1 and previous conversion result is gone.
  • Page 460 ISD91200 Series Technical Reference Manual SAR ADC Status Register ( SARADC_STATUS Register Offset R/W Description Reset Value SARADC_ST SARADC_BA+0x40 R/W SAR ADC status Register 0x0000_0000 ATUS Reserved VALID[15:8] VALID[7:0] CHANNEL BUSY ADCMPF1 ADCMPF0 ADEF Bits Description [31:24] Reserved Reserved. Data Valid Flag (Read Only)
  • Page 461 ISD91200 Series Technical Reference Manual SAR ADC PDMA Current Transfer Data Register (SARADC_PDMADAT) Register Offset R/W Description Reset Value SARADC_PD SARADC_BA+0x50 SAR ADC PDMA Current Transfer Data 0x0000_0000 MADAT Reserved Reserved DATA[17:16] DATA[15:8] DATA[7:0] Bits Description [31:18] Reserved Reserved. SAR ADC PDMA Current Transfer Data Register (Read Only) When PDMA transferring, read this register can monitor current PDMA transfer data.
  • Page 462 ISD91200 Series Technical Reference Manual SAR ADC Analog Control Register(SARADC_ACTL) Register Offset R/W Description Reset Value SARADC_A SARADC_BA+0x5C R/W SAR ADC analog control register 0x0000_0000 Reserved Reserved Reserved SAR_VREF Reserved Reserved Reserved Reserved SAR_SE_MODE Bits Description [31:18] Reserved reserved VREF selection...
  • Page 463 ISD91200 Series Technical Reference Manual SAR ADC Control Register(SARADC_CTL) Register Offset Description Reset Value SARADC_CTL SARADC_BA+0x60 R/W SAR ADC Control Register 0x0000_0000 Reserved Reserved Reserved Reserved SWTRG Reserved PDMAEN HWTRGEN HWTRGCOND HWTRGSEL OPMODE ADCIE ADCEN Bits Description [31] Reserved Reserved...
  • Page 464 ISD91200 Series Technical Reference Manual External Trigger Condition These two bits decide external pin STADC trigger event is level or edge. The signal must be kept at stable state at least 8 PCLKs for level trigger and 4 PCLKs at high and low state for edge trigger.
  • Page 465 ISD91200 Series Technical Reference Manual SAR ADC Channel Enable Register ( SARADC_CHEN Register Offset Description Reset Value SARADC_CH SARADC_BA+0x64 SAR ADC Channel Enable Register 0x0000_0000 Reserved Reserved Reserved Reserved CHEN[15:8] CHEN[7:0] Bits Description [31:12] Reserved Reserved. Reserved [23:20] Reserved [19:17]...
  • Page 466 ISD91200 Series Technical Reference Manual SAR ADC Compare Register 0/1 (SARADC_CMP0/SARADC_CMP1) Register Offset R/W Description Reset Value SARADC_CM SARADC_BA+0x68 R/W SAR ADC Compare Register 0 0x0000_0000 SARADC_CM SARADC_BA+0x6C R/W SAR ADC Compare Register 1 0x0000_0000 Reserved CMPDAT CMPDAT Reserved CMPMCNT...
  • Page 467 ISD91200 Series Technical Reference Manual Compare Channel Selection 0000 = Channel 0 conversion result is selected to be compared. 0001 = Channel 1 conversion result is selected to be compared. 0010 = Channel 2 conversion result is selected to be compared.
  • Page 468: Application Diagram

    ISD91200 Series Technical Reference Manual APPLICATION DIAGRAM VCCD 5 VDDBS VCCD 0.1uF VSSD PA.4/SPI0_MISO0 PA.3/SPI0_SSB0 6 VDDB VCCD PA.2/SPI0_SCLK0 VCCSPKL PA.1/SPI0_MOSI0 VCCSPKR HOLDB VSSSPK VSSSPK 22 W25Q SPK+ ISD91260 SPK- DMIC_CLK LQFP64 0.1uF DMIC_DAT XI32K 32.768K 20pF DMIC XO32K 31 20pF 4.7uF...
  • Page 469: Package Dimensions

    ISD91200 Series Technical Reference Manual PACKAGE DIMENSIONS 9.1 64L LQFP (7x7x1.4mm footprint 2.0mm) Release Date: Sep 16, 2019 - 469 - Revision 2.4...
  • Page 470: Qfn 32L 4X4 Mm2, Thickness: 0.8Mm (Max), Pitch: 0.40Mm

    ISD91200 Series Technical Reference Manual 9.2 QFN 32L 4X4 mm2, Thickness: 0.8mm (Max), Pitch: 0.40mm Release Date: Sep 16, 2019 - 470 - Revision 2.4...
  • Page 471 ISD91200 Series Technical Reference Manual ORDERING INFORMATION 1 x x x x x x Temperature ISD Audio Product Family I: -40°C ~ +85°C Product Series 1: Cortex-M0 Package R: LQFP-64 Family ID Y: QFN-32 2: Family Series ID Feature Blank: Standard...
  • Page 472 ISD91200 Series Technical Reference Manual 11 REVISION HISTORY PAGE/ VERSION DATE DESCRIPTION CHAP. V0.2 Sep 1, 2017 Preliminary Release. Add CSCAN feature and operation, fix Table & Figure reference V0.21 Sep 5, 2017 errors V0.22 Sep 7, 2017 Add SAR_VREF bit and description - Rename flash sector size as page size V0.23...
  • Page 473 Nuvoton customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Nuvoton for any damages resulting from such improper use or sales.

Table of Contents
