- Page 1 RTSS-X501M User Manual Realtimes Beijing Technology Co., LTD. Fax：+86 010-84284669 / 84280996 / 84278927 Email: info@realtimes.cn Web Page: http://www.realtimes.cn Address: 9th Floor, Block B, 20th Heping Xiyuan, Pingxi Street, Chaoyang District, Beijing 100013,P.R.China...
- Page 2 Revision History Revision Date Reason for change Applicable hardware version V1.0 2017-07 Initial release V1.0 V2.0 2019-03-21 Manual style template update V1.0 RTSS-X501M Reference Manual V2.0...
- Page 3 ⚫ Do not plug and unplug the core board and peripheral modules when power is on; ⚫ Please do not repair or disassemble the product by yourself. In case of any fault, please contact RTSS-X501M Reference Manual V2.0...
- Page 4 3) Burn in verification of all BSP support packages provided by the company; 4) The company released burn environment construction, entry-level use. ; 5) Various peripheral module drivers released by the company; 6) The company's product fault diagnosis and after-sales maintenance services; 2. Scope of technical discussion RTSS-X501M Reference Manual V2.0...
- Page 5 Updates of subsequent documents, BSP, driver files and other official account will be updated in time. We will pay close attention to our developments in order to ensure that your information is up to date. We will push through WeChat public. RTSS-X501M Reference Manual V2.0...
-
Page 6: Table Of Contents
........................... 12 4.6 P OWER SWITCH BUTTON ............................12 4.7 CAN/A UDIO CONNECTOR ............................13 4.8 S ERIAL CONNECTOR ......................14 4.9 GPIO AND FUNCTION BUTTON CONNECTOR 5 PRODUCT SIZE DIAGRAM..........................15 6 SOFTWARE/BSP DETAILS..........................16 TERMS OF WARRANTY............................16 RTSS-X501M Reference Manual V2.0... -
Page 7: Product Presentation
Realtimes Beijing Technology Co.,LTD www.realtimes.cn/en/index.html 1 Product presentation RTSS-X501M is a NVIDIA® Jetson™ TX1/TX2 core module and RTSO-9001 onboard intelligence box system. For industrial deployment application, the hardware board card is protected and the overall reliability of the system is improved. -
Page 8: Ordering Information
WIFI and Bluetooth, 4G modules optional; Power indicator light, power switch button, -25 -- +60℃; Including cable package (network, HDMI, serial port); Provide RtSO-9001 Linux4Tegra software support package, passed the 3C and CE certification Order online: https://shop340963258.taobao.com https://mall.jd.com/index-824786.html RTSS-X501M Reference Manual V2.0... -
Page 9: Cable Kits And Accessories
Realtimes Beijing Technology Co.,LTD www.realtimes.cn/en/index.html 1.1 Cable Kits and Accessories RTSS-X501M matching Cable package order model: RTSS-X501M-Cable. Contains the following components: Component Number Functional Description Serial port connector Convert serial port DB9 interface to two standard DB9 RS232 interface Gigabit... -
Page 10: External Interface Function And Location
Realtimes Beijing Technology Co.,LTD www.realtimes.cn/en/index.html 2 External interface function and location RTSS-X501M FRONT RTSS-X501M BACK RTSS-X501M Reference Manual V2.0... -
Page 11: How To Use Smart Box
Install necessary external cables. (Such as: the display cable connected to the HDMI display, the power input cable to power the system, the USB cable connecting the keyboard and mouse ...) c) RTSS-X501M adopts manual power-on design. Turn on the power and the system starts to work. 3.2 Recovery Mode The Jetson TX1/TX2 core module works in both normal and Recovery mode. -
Page 12: 4Connectors Description
Pin define connector signal definition Signal Signal MDI0+ MDI1+ MDI2+ MDI3+ MDI0- MDI1- MDI2- MDI3- Pin 1 location: The green frame on the right. 4.3 USB3.0 USB3.0 connectors Function USB3.0 marking Dual layer USB3.0 type-a interface Type RTSS-X501M Reference Manual V2.0... -
Page 13: Wifi/Bluetooth Antenna Connector
4.7 CAN/Audio connector CAN bus and audio input/output connection Function marking Can/Audio DB9 interface Type Pin define Signal Signal CAN0H CAN0L CAN1H CAN1L AUDIO_GND MIC_IN AUDIO_HR_R AUDIO_HR_L Pin 1 location: The green frame on the right. RTSS-X501M Reference Manual V2.0... -
Page 14: Serial Connector
COM0 is the default kernel debugging serial port, which is used to output c-boot, U-boot, and Linux kernel information. After Linux kernel is started, it is used as the display terminal serial port. TX1/TX2 default serial port setting is: 115200bps, 8N1. RTSS-X501M Reference Manual V2.0... -
Page 15: Gpio And Function Button Connector
GPIO0 GPIO1 GPIO2 GPIO3 Pin 1 location: The green frame on the right. The sysfs mapping Numbers of GPIO0~GPIO3 in TX1 system are respectively: 187,186,89,202. The SYSFS mapping number in the TX2 system is respectively 388,298,480,486. RTSS-X501M Reference Manual V2.0... -
Page 16: Product Size Diagram
Realtimes Beijing Technology Co.,LTD www.realtimes.cn/en/index.html 5 Product size diagram RTSS-X501M Reference Manual V2.0... -
Page 17: Software/Bsp Details
6 Software/BSP Details RTSS-X501M thinkbox works on systems that are burned using the official original NVIDIA Linux For Tegra (L4T). HDMI, Gigabit Ethernet, USB2.0, serial port, GPIO, SD card, CAN bus are all supported. But USB3.0 doesn't work properly. - Page 18 Rev.C 6/2020 RTSS-X501M Reference Manual V2.0...
