Spirit Commercial CSC900 Owner's Manual

Stair climber
Hide thumbs Also See for CSC900:
Table of Contents

Advertisement

Quick Links

Owner's Manual
Model No.
16807949000
CSC900
Stair Climber
- Assembly
- Operation
- Adjustments
- Parts
- Warranty
CAUTION:
Read and
understand this
manual before
operating unit
Retain For Future Reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSC900 and is the answer not in the manual?

Questions and answers

Related Manuals for Spirit Commercial CSC900

Summary of Contents for Spirit Commercial CSC900

  • Page 1 Owner’s Manual Model No. 16807949000 CSC900 Stair Climber - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: Read and understand this manual before operating unit Retain For Future Reference...

  • Page 2: Table Of Contents

    Important Safety Instructions ................... 4 Important Electrical Instructions ..................4 Important Operation Instructions ..................6 Assembly Instructions ...................... 6 Operation of CSC900 Monitor ..................10 Programming the Console ..................... 13 Heart Rate Training......................18 General Maintenance ..................... 20 Exploded View Diagram ....................21 Parts List ........................

  • Page 3: Product Registration

    NEW STAIR CLIMBER AND WELCOME Thank you for your purchase of this Spirit CSC900 Stair Climber from Dyaco Canada Inc. Your new CSC900 Stair Climber was manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available. Through your dealer, Dyaco Canada Inc.
  • Page 4 BEFORE YOU BEGIN Thank you for choosing the SPIRIT CSC900 Stair Climber. We take great pride in producing this quality product and hope it will provide many hours of quality exercise to make you feel better, look better, and enjoy life to its fullest. It's a proven fact that a regular exercise program can improve your physical and mental health.

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING • Always unplug the machine from the electrical outlet before cleaning or servicing. • This machine is not intended to be serviced by the end user, refer servicing to qualified personnel only. • This product will be wired for either 120 VAC nominal power input OR 230 VAC nominal input. It is factory-equipped with a specific electric cord and See at plug to permit connection to the proper electric circuit.
  • Page 6  This equipment is not intended to be used by children. It is not intended to be used by persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge, unless given instruction and under the personal supervision concerning use of the machine by a person responsible for their safety.

  • Page 7: Important Operation Instructions

    These distractions may cause you to lose balance which  may result in serious injury. TOOLS INCLUDED: CSC900 ASSEMBLY INSTRUCTIONS • 5mm Allen Wrench • 6mm Allen Wrench UNPACKING PARTS INCLUDED: 1. Read all instructions before assembling.
  • Page 8 STEP ONE CSC900 Hardware for Step 1 TYPE DESCRIPTION CONSOLE MAST M8 X 20L BOLT M6 X 65L BOLT M8 X 55L BOLT Ø8 WASHER 1. Insert Console Mast wire through Decorative Ring, then connect the Communication Wires between the Main Frame and Console Mast.
  • Page 9 STEP THREE CSC900 Hardware for Step 3 TYPE DESCRIPTION SIDE HANDLEBARS HANDLEBAR GROUP DECORATIVE RINGS REINFORCEMENT PLATE M8 X 20L BOLT M8 X 30L BOLT ø8 WASHER Connect wires with same terminal. Attach side handlebars the Handlebar Group and with the Decorative Rings using M8*20 Blots (4pcs), ø8 Flat Washers (4pcs).
  • Page 10 STEP FOUR CSC900 Hardware For Step 4 TYPE DESCRIPTION CONSOLE SETS HANDRAIL COVERS M8 X 20L BOLT M4 X 25L SCREW ST4.2 X 16L SCREW 1. Connect Console using M8*20L Bolts (4pcs). 2. Secure Handlebars on each side using ST4.2*16L Screws (2pcs).

  • Page 11: Operation Of Csc900 Monitor

    OPERATION OF CSC900 MONITOR BASIC INFORMATION The Dot Matrix, or Profile Window, will display the workout Profile. The Message window displays pertinent exercise data. There are four windows to display a large variety of pertinent data during the workout. A Vertical window measures vertical height climbed along with Heart Rate and METS.
  • Page 12 ENTERING A PROGRAM & CHANGING SETTINGS A safety tether cord is provided with this unit. It is a simple switch design that should always be used. It is for your safety should you fall from the Stair Climber when the Steps Per Minute (SPM) exceeds your capability.
  • Page 13 Vertical distance counts up from 0 to 999 feet or meters then rolls over to 1 to represent 1,000. A light in the decimal space for each increment of 1,000 will also illuminate and changes position with each distance of 1,000 reached. Changing from imperial to meters is accomplished by pressing 1, 2, 3, OK.

  • Page 14: Programming The Console

    PROGRAMMING THE CONSOLE Each of the programs can be customized with your personal information and changed to suit your needs. Some of the information asked for is necessary to ensure the readouts are correct. You will be asked for your Age and Weight. Entering your Weight aides in calculating a more correct Calorie reading.
  • Page 15 FAT BURNING 1. Press the FAT BURNING button. 2. Console displays: Start or Press OK to Set Up. Press OK. 3. Enter Your Age displays on the screen. The default age of 35 will blink repeatedly. Use the Level + or – keys or the numerical Keypad to adjust age. Press OK. 4.
  • Page 16 ROLLING HILLS 1. Press the ROLLING HILLS button. 2. Console displays: Start or Press OK to Set Up. Press OK. 3. Enter Your Age displays on the screen. The default age of 35 will blink repeatedly. Use the Level + or – keys or the numerical Keypad to adjust age. Press OK. 4.
  • Page 17 INTERVAL Press the INTERVAL button. Console displays: Start or Press OK to Set Up. Press OK. Enter Your Age displays on the screen. The default age of 35 will blink repeatedly. Use the Level + or – keys or the numerical Keypad to adjust age. Press OK. Enter Your Weight displays on the screen.
  • Page 18 USER PROGRAM The USER Program allows the user to create their own unique program design, customizing all 24 segments of the dot matrix display. 1. Press the USER PROG button. 2. 30:00 minutes continually blinks in display window indicating Total Program Time.

  • Page 19: Heart Rate Training

    HEART RATE TRAINING A word about Heart Rate: The old motto, “no pain, no gain”, is a myth that has been overpowered by the benefits of exercising comfortably. A great deal of this success has been promoted by the use of heart rate monitors. With the proper use of a heart rate monitor, many people find that their usual choice of exercise intensity was either too high or too low and exercise is much more enjoyable by maintaining their heart rate in the desired benefit range.
  • Page 20 RATE OF PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot of advantages. There are more variables involved in how hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humidity, the time of day, the last time you ate and what you ate, all contribute to the intensity at which you should workout.

  • Page 21: General Maintenance

    GENERAL MAINTENANCE Wipe down all areas in the sweat path with a damp cloth after each workout. If a squeak, thump, clicking or rough feeling develops the main cause is most likely the following reason: The hardware was not sufficiently tightened during assembly. All bolts that were installed during assembly need to be tightened as much as possible.

  • Page 22: Exploded View Diagram

    EXPLODED VIEW DIAGRAM Customer service: 1-888-707-1880 Dyaco Canada Inc 2020 Email: customerservice@dyaco.ca...
  • Page 23 EXPLODED VIEW DIAGRAM Customer service: 1-888-707-1880 Dyaco Canada Inc 2020 Email: customerservice@dyaco.ca...
  • Page 24 EXPLODED VIEW DIAGRAM Customer service: 1-888-707-1880 Dyaco Canada Inc 2020 Email: customerservice@dyaco.ca...

  • Page 25: Parts List

    PARTS LIST KEY NO DESCRIPTION Q’TY Main Frame Support Frame(L) Support Frame(R) Base Frame Upright Support Tube Step Frame (L) Step Frame (R) Top Sprocket Bottom Sprocket Horizontal Support Frame 1.10 Top Horizontal Support Frame 1.11 Drive Train Frame 1.11.1 Drive Train Support Frame 1.11.2 Alternator Mounting Arm...
  • Page 26 KEY NO DESCRIPTION Q’TY 1.11.25 Brake 1.11.26 Speed Reducer 1.11.27 5 x 5 x 10 Woodruff Key 1.11.28 Φ6 Flat Washer 1.11.29 M6 x 20 Bolt 1.11.30 Φ6 Split Washer 1.11.31 Magnetic Switch 1.11.32 M4 x 10 Screw 1.12 Chain 1.13 Reducer Chain 1.14...
  • Page 27 KEY NO DESCRIPTION Q’TY 1.34 Bottom Cover 1.35 Decorative Ring 1.36 Stand Pad (L) 1.37 Stand Pad (R) 1.38 Leveling Foot 1.39 Transport Wheel 1.40 Φ11 Screw Hole Cap 1.41 Bearing UCP204 1.42 Bearing 608-2Z 1.43 M12 x 70 Screw 1.44 M12 Nylon Nut 1.45...
  • Page 28 DESCRIPTION Q’TY Handlebar Assembly Handlebar Heart Rate Front Shell Heart Rate Back Shell Button Shroud Light Button Base Button Button Cover Start/Stop Button Emergency Stop Top Shell 3.10 Emergency Stop Bottom Shell 3.11 Safety Switch 3.11.1 Tension Spring 3.11.2 Safety Switch Lever 3.11.3 Safety Switch Actuator 3.11.4 Switch Top Shell 3.11.5 Switch Bottom Shell...
  • Page 29 DESCRIPTION Q’TY Handrail Foam Right Handrail Right Handrail Tube Handrail Foam Console Mast Console Assembly Console Mounting Frame Console Front Shell Console Back Shell Console back cover Cup Holder Console Front Cover Left Fan Duct Right Fan Duct Air Vent 8.10 Cup holder Cover 8.11...
  • Page 30 DESCRIPTION Q’TY 14.4 M8 x 20 Bolt 14.5 M8 x 30 Bolt 14.6 M8 x 20 Bolt 14.7 M8 x 20 Screw 14.8 M4 x 30 Screw 14.9 ST4.2 x 16 Screw 14.10 Φ8 Flat Washer 14.11 Φ8 Curved Washer Customer service: 1-888-707-1880 Dyaco Canada Inc 2020 Email: customerservice@dyaco.ca...

  • Page 31: Manufacturer's Limited Warranty

    MANUFACTURER’S LIMITED WARRANTY Dyaco Canada Inc. warrants all its Stair Climber parts for a period of time listed below, from the date of retail sale, as determined by a sales receipt. Dyaco Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s option, and technical support to our independent dealers and servicing organizations.
  • Page 32 Customer service: 1-888-707-1880 Dyaco Canada Inc 2020 Email: customerservice@dyaco.ca...
