Summary of Contents for VStarcam C90S
-
Page 3: Video Tutorial
Video Tutorial If it is your first time to use our products, it is recommended to scan the following QR code to watch the video tutorial. -
Page 4: Product Description
Product Description Power Interface Power Switch HD Lens Mode Switch Button Microphone TF Card Slot Reset Button IR Light Status Indicator Reset Method: Turn the power switch to "On", hold on the reset button for 5 seconds until you see blue light and red light turn on together , and then blue light flash slowly. -
Page 5: Device Description
Device Description Indicator Status Yellow light: always bright during charging This device has two modes: IP Camera (WiFi) mode and Recorder (DV) mode. Blue light: slow flash---waiting for co Built-in 1500mAh battery. -nnection; fast flash---during connection; always bright ---connection success Support DC5V/1000mAh power supply. -
Page 6: Step 1 : Pre-Setup
Step 1 : Pre-Setup Turn the power switch to “On”mode. DC5V OFF WiFi OFF WiFi Turn the mode switch button to RESET " WiFi " mode. RESET It is recommended to place the camera within 2 meters of the router. Connecting the phone to the WiFi and make sure know the exact WiFi password (only supports 2.4GHz). - Page 7 Step 2 : APP Download and Registration Click "Register", enter the user name Search for "Eye4" in App Store and password to complete the registration, or Google Play, or scan the QR and also supports the third party such code to download the app. as Facebook to login directly.
- Page 8 Step 3: Add Devices to the APP OFF WiFi DC5V RESE T Open the app, click the "+" in the upper right corner , and scan the QR code on the body of the camera, then follow the prompts on the app to complete the adding.
- Page 9 If you can't find the QR code, click the "+" in the upper right corner, select "Others"on the bottom right corner — "IP Camera"--- "AP mode adding", then select "There is a router" or "No router" according to the application environment.
-
Page 10: You Re Done
You re Done! Wait for about 30 seconds, it will prompt "binding successfully" on the APP. Click "Configure WiFi" and enter the WiFi password to complete the configuration. Or enter "Settings" --- "WiFi " to complete the configuration. Please write down your device information: Eye4 account name: Eye4 account password:... -
Page 11: Configuring Wifi
Configuring WiFi Click " Settings"---”WiFi ", select the WiFi you want to connect, enter the WiFi password. About 60 seconds the camera restarts and the configuration is complete. - Page 12 DV Mode Usage DC5V OFF WiFi OFF WiFi RESET RESET Turn the power switch to "ON", the mode switch button to "DV", and insert a TF card for 24 hours of continuous recording. How to view recording videos? Turn the mode switch button to WiFi mode, enter the APP, and go to "TF card"...
- Page 13 Device Share Click "Settings" on the right corner, then select "Device Share"--- "QR Code Sharing". Other users can open the app and click the "+" in the upper right corner of the home page to scan the QR code to add the device.
-
Page 14: Cloud Storage
Cloud Storage The camera supports cloud storage service. After activated the cloud storage service, when the motion detection is triggered, the video will be uploaded to the cloud storage server immediately, and the video can be viewed even if the camera is stolen. -
Page 15: After Sales Service
If you have any questions, please contact our customer service: Click on "Me" in the lower right corner of the APP. Select "Online Customer Service". Online customer service： AM 8:30-12:00 PM 13:20-17:50 Night 19:00-23:00 on weekdays (UTC+8) Official Mall：https://shop.vstarcam.com/ F A Q : www.vstarcam.com/support Email : support@vstarcam.com... - Page 17 物料编号：3-05-01-007-3038 封面材质：128g铜版纸（封面/封底覆光膜） 内页材质：128g铜版纸 尺寸：120x80mm 颜色：四色印刷 装订方式：骑马钉（一个钉）...
