Summary of Contents for VStarcam V3
- Page 1 Video Doorbell User Manual 可视门铃使用说明书...
-
Page 2: Video Tutorial
Video Tutorial If it is your first time to use our products, it is recommended to scan the following QR code to watch the video tutorial. -
Page 3: Product Description
Product Description IR LED Infrared light Microphone Audio capture PIR Sensor To detect visitors Lens Lens Video image capture IR LED Speaker Play voice prompt and voice intercom Light Sensor Microphone Reset Button Press 5 seconds to reset factory settings Light Sensor Used to detect environmental brightness value... - Page 4 Sta tus in dica te Anti-theft lig ht Button Spe a ke r Power Switch Co de pa irin g butto n Frequency ：433MHZ Battery 3200mAh lithium battery Rated voltage：AC110-240V 50/60HZ Anti-theft button When someone remove the doorbell forcibly, anti-theft button will trigger alarm, it will send alarm notifications to the app immeadiately.
-
Page 5: Step 1 : Pre-Setup
Step 1 : Pre-Setup Connect your phone to the WiFi network (2.4GHz only). within 2 m Place the doorbell within 2 meters of the router during configuration. Turn the "power switch" on the back cover of the doorbell to "On" mode. If it is your first time to connect the device, there is no need to reset it. - Page 6 Step 2 : APP Download And Registration Click "Register", enter the user name Search for “Eye4”in App Store and password to complete the registration, or Google Play, or scan the QR and also supports the third party such code to download the app. as Facebook to login directly.
- Page 7 Step 3: Add Devices To The APP Open the app, click the "+" in the upper right corner , and scan the QR code on the back of the doorbell, then follow the prompts on the app to complete the adding.(Note: For Android phone, it will pop up some system permission window, please select "Allow")
- Page 8 If you can't find the QR code, click the "+" in the upper right corner, select "Others" --- "Door Cam", select the corresponding model, then follow the prompts on the app to complete the adding.
-
Page 9: You Re Done
You re Done! When you hear the doorbell prompts "Wireless co -nnection is successful", wait for about 30 seconds, the binding page will appear on the app, click "Bind" to complete the adding. Please write down your device information: Eye4 account name: Eye4 account password:... -
Page 10: Hardware Installation Instructions
Hardware Installation Instructions M e tho d 1 M e tho d 2 Install the bottom plate to the doorbell Fix the bottom plate with screws Stick 3M glue on the bottom plate Align the doorbell with the bottom plate and push the doorbell down Stick the doorbell directly on the door Note: Please install the device after the configuration is complete. - Page 11 Indoor Chime Code Pairing When you take the product out of the box, the doorbell and the indoor chime are already paired. Pressing the doorbell, the indoor chime will make "Ding Dong” sound. If the indoor chime does not make "Ding Dong" sound, the code needs to be re-paired.
-
Page 12: Device Usage
Device Usage When nobody rings the doorbell, after 30 seconds, the device will go to sleep mode. When somebody rings the doorbell, the doorbell will wake up and push the message to the mobile app. You can click on the message to enter the visual interface, and talk to the visitor by turning on the voice intercom button. - Page 13 Device Share Click "Setting"--- "Device Sharing"--- "QR Code Sharing". Other users can open the app and click the “+” in the upper right corner of the homepage to scan the QR code to add the device.
- Page 14 Click on "Me" in the lower right corner of the APP. Select "Online Support". Online customer service： AM 8:30-12:00 PM 13:20-17:50 Night 19:00-23:00 on weekdays (Beijing time) Official Mall ：https://shop.vstarcam.com/ : www.vstarcam.com/support F A Q Email : support@vstarcam.com...
- Page 15 操作视频 如果您是第一次安装我们的产品，建议用手机扫一扫以下二维码观看视频教程。...
- Page 16 产品外观说明 红外灯 环境光线不够时，启用红外灯，开启夜视模式 用来采集环境亮度值，当照度为0.3lux时，启 光敏传感 用红外灯 高清镜头 麦克风 红外灯 采集环境声音和实现语音对讲 光敏传感 麦克风 按键 门铃按键 探测是否有人经过 PIR人体感应 按键 镜头 采集图像视频 PIR人体感应 喇叭 发出系统提示音和实现语音对讲 USB充电口 当电池电量低时，可使用5V电源适配器直接充电 喇叭 指示灯 复位键 长按2~5秒恢复出厂设置 指示灯 红灯常亮：用户已经连上设备热点 蓝灯常亮：设备当前已连接上路由器，可正常工作 蓝灯每隔0.5s闪烁0.5s：设备当前正在连接路由器 复位键 充电口 蓝灯闪烁，每隔2s闪烁2s: 设备当前连接路由器失败 红灯闪烁，每隔2s闪烁2s: 设备当前处于等待WiFi配 置中...
- Page 17 状态指示灯 防拆按钮 喇叭 开关 对码按扭 电池 3200mAh锂电池 工作频率：433MHZ 防拆按钮 当有人强行取走门铃，马上 额定电压：AC110-240V 50/60HZ 会有报警信息推送到APP...
- Page 18 第一步 安装前准备 将手机连接到路由器无线网络（只支持2.4GHz）。 2米内 建议将门铃放置于路由器2米之内。 请将门铃后盖上的电源开关调到“On”档。 首次使用门铃，不需要复位。若门铃启动后，没有听到“请使用 APP进行WIFI配置”提示音，请将门铃复位。（复位方法：按住 Reset 键5秒左右，复位成功后会有提示音“复位完成，即将重 复位键 启设备”）...
- Page 19 第二步 APP下载和注册 请在手机商城直接搜索“Eye4”下 点击“注册”，输入用户名、密码完成注 载APP，或者扫描以上二维码下载。 册，同时支持QQ、微博、微信直接登陆。...
- Page 20 第三步 添加设备到APP 打开APP点击“+”去添加设备，扫描门铃机身标贴上的二维码。然后根据APP指引完成 添加动作。(注：安卓手机会弹出一些系统权限的窗口，请选择“允许”。 ）...
- Page 21 如果找不到二维码，点击右上角“+”，选择右下角“其他添加方式”，“可视门铃”， 选择相应的型号，然后根据APP指引完成添加动作。...
- Page 22 恭喜，您已完成安装 ! 当你听到门铃提示“无线连接成功”后，等待30秒左右， APP将会出现绑定界面，点击“绑定”完成添加。 请记住您的设备信息： Eye4 账号 ： Eye4 密码 ：...
- Page 23 硬件安装说明 方法一 方法二 将底板扣在门铃上 用螺丝固定底板 贴3M 胶在底板上 将机身与底板挂钩对准，向下推机身 将门铃直接粘贴在门上 注意：安装设备前，请先完成配网。...
- Page 24 呼叫器对码 设备出厂时室内呼叫器和门铃就已经配对，按门铃室内呼叫器会发出“叮咚”声，若按门 铃室内呼叫器没有发出“叮咚”声，则需要重新对码。 对码方法:设备通电状态下，先短按一下室内呼叫器对码按钮，指示灯会亮 ,然后再短按一 下门铃按钮即可完成配对，如果对码成功，按门铃室内呼叫器会发出“叮咚”声。...
- Page 25 设备使用 当没有人按门铃时，30秒左右设备会进入休眠状态。当有人按门铃时，门铃会被唤醒并推送 消息至手机APP ,点击消息进入可视画面。打开语音对讲按钮就可以跟访客通话。...
- Page 26 设备分享 进入门铃“参数设置”，点开“设备分享”，选择“二维码分享”。其他用户可打开APP， 点击首页右上角“+”符号，扫描此二维码添加设备。...
- Page 27 售后咨询 如有疑问请联系客服：在 APP 右下角点击“我的” 选择“在线客服” 在线客服：上午 8:30-12:00 下午 13:20-17:50 夜间 19:00-23:00 ( 周一至周五 ) 官方商城 ：http://shop.vstarcam.com/ F A Q : www.vstarcam.cn/support 邮 箱 : support@vstarcam.com 客服热线 ：400-602-9990...
- Page 29 物料编号：3-05-01-007-3046 封面材质：128g铜版纸（封面/封底覆光膜） 内页材质：128g铜版纸 尺寸：120x80mm 颜色：四色印刷 装订方式：骑马钉（一个钉）...
