QUICK START
GUIDE
THE BASIC FEATURES OF AN EASY SET-UP
LUMINODE PRODUCT FAMILY
LumiNode 1 / LumiNode 2 / LumiNode 4 / LumiNode 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LumiNode Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Luminex LumiNode Series

  • Page 1 QUICK START GUIDE THE BASIC FEATURES OF AN EASY SET-UP LUMINODE PRODUCT FAMILY LumiNode 1 / LumiNode 2 / LumiNode 4 / LumiNode 12...
  • Page 2: Mounting The Device

    1. MOUNTING THE DEVICE LumiNode 4 is a device that can be mounted in a truss as well as in a rack. Please read the following instructions to make sure the device is mounted and secured correctly. 1.1 Rack mount In case you want to mount your LumiNode 4 in a standard 19 inch rack, you first have to attach the included mounting ears.
  • Page 3 Use the correct bold, M10x20, with a screw wire no longer as 20mm. You can order this part from Luminex (Part Number: R 90 01042) Screw the bolt, through the LumiNode 4 back ear, into the side M10 insert and tighten...
  • Page 4 1.3 Truss Mount – LumiNode 4 To mount a LumiNode 4 in a truss, you must attach a 10M clamp (G) to the M10 insert (H). After that, you can mount the clamp to the truss bars. Please also secure the device by attaching a safety line directly to the truss bars as well (I).
  • Page 5 1.5 Wall Mount – LumiNode 2 The LumiNode 2 can be mounted to a concrete or wood wall by using applicable screws and anchors. Make sure that the screw head diameter is between 8 – 10mm and the screw length is at least 40mm in order to make a strong wall connection. ≥...
  • Page 6 112mm 139mm...
  • Page 7: Power Up The Device

    To shut it down after use, just un-plug the power cable again. Alternatively, the LumiNode series are 802.3af compliant (PoE), so that each LumiNode will act as a PD (Powered Device), and can be powered by any compliant PSE (Power Sourcing Equipment) such as Ethernet switch, midspan and PoE injector.
  • Page 8 LUMINODE 1 LUMINODE 2...
  • Page 9: Connection To The Network

    LUMINODE 4 LUMINODE 12 3. CONNECTION TO THE NETWORK In order to get the LumiNode online in your system, simply connect either Ethernet 1 (N) or Ethernet 2 (N) port to a computer, or to a port of an Ethernet switch. Only Ethernet 2 port on the rear of the unit can be used to power the unit through PoE.
  • Page 10: Led Indicators

    4. LED INDICATORS There are various LEDs on the LumiNode. Here is a list of the LEDs, the possible colors and the meaning of each color: DMX PORT STATUS MEANING DMX only Cyan Blinking : DMX activity DMX + RDM Blue Blinking : DMX activity NETWORK PORT...
  • Page 11 6. RESET When the device is powered up by default it shows the status screen with the status of the first 4 ports. In order to reset the device please follow the following steps: ƒ Press the jog wheel once to enter the ‘Main menu’ . ƒ...
  • Page 12 LUMINODE, BUILT FOR TODAY, DESIGNED FOR TOMORROW Slamstraat 13 | 3600 Genk | Belgium | T +32 11 812 189 info@luminex.be | www.luminex.world...

This manual is also suitable for:

Luminode 1Luminode 2Luminode 4Luminode 12
