- Page 1 SAFETY INSTRUCTIONS & QUICKSTART GUIDE GIGACORE PRODUCT FAMILY GigaCore 16t/18t/20t Range THANKS FOR CHOOSING LUMINEX...
-
Page 2: Important Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS: Read these instructions. ƒ Keep these instructions. ƒ Pay attention to all warnings. ƒ Follow all instructions. ƒ Do not use this apparatus near water. ƒ Clean only with dry cloth. ƒ Do not block any ventilation openings. Install in accordance with the ƒ... -
Page 3: Précautions Concernant La Sécurité
PRÉCAUTIONS CONCERNANT LA SÉCURITÉ : Lire ces instructions. ƒ Conserver ces instructions. ƒ Tenir compte de tous les avertissements. ƒ Suivre toutes les instructions. ƒ Ne pas utiliser ce produit à proximité d’eau. ƒ Nettoyer uniquement avec un chiffon propre et sec. ƒ... -
Page 4: Ventilation Openings
SWEDEN: Apparaten skall anslutas till jordat uttag NORWAY: Apparatet må tilkoples jordet stikkontakt FINLAND: Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan DENMARK: Apparatets stikprop skal tilsluttes en stikkontakt med jord, som giver forbindelse til stikproppens jord VENTILATION OPENINGS: The system heat vents, located at the front and the rear, dissipate heat. Do not block these openings. -
Page 5: Disconnect Device
WARNING: Use a MAINS power-in cable with a maximum length of 3m and a minimum cable section of 1,5mm . If you use the powerCon TRUE 1 - power out to power secondary devices, the circuit needs to be protected by a residual current pro- tective device with rated current not exceeding 30mA. - Page 6 The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 7 This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Luminex Lighting Control Equipment nv may void your authority, granted by the FCC, to use the product. This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.
- Page 8 This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal. GigaCore 20t Safety & Quickstart Guide (LU 77 00284 rev.1.0.3)
- Page 9 Once the device has been powered up and booted, this QR-code will disappear and not come back on a following bootup. The complete user manual can be found in the download section of our website: www.luminex.be/support-2/product-downloads...
-
Page 10: Mounting The Device
F I R S T A N G L E P R O J E C T I O N on. To shut it down after use, just un-plug the power cable again. GigaCore 20T S C A L E : 1:5... - Page 11 3. DESCRIPTION 3.1 Front Panel (A) Status LEDs: OK: Indicates the general status of the switch. ƒ PoE: Indicates the status of the PoE functionality and the PoE ƒ supplies (GigaCore 16t/18t/20t with PoE only). RLinkX: Indicates the RLinkX status. ƒ...
- Page 12 3.2 Rear Panel (G) EtherCON ports : 4 x 1Gbps EtherCON ƒ (H) RJ45 Ports: 8 x 1Gbps RJ45 ƒ (I) SFP: 4 x SFP+ ƒ (J) LED Extension Port: 1x LED extension port for optional LED panel on USB-C. ƒ...
-
Page 13: Led Indicators
4. LED INDICATORS There are various LEDs on the GigaCore 16t/18t/20t. Here is a list of the LEDs, the possible colours, and the meaning of each colour: SWITCH LED COLOUR DESCRIPTION OK (General status) Green All OK Unit is writing to the flash. Green flashing Do NOT disconnect power. - Page 14 SWITCH LED COLOUR DESCRIPTION Power LED Normal operation by non PoE / Sec- Green ond PSU connected and powered with PoE models No second PSU connected for PoE Orange models Second PSU connected but no mains connected. Red flashing PSU error. PORT LED STATUS DESCRIPTION...
-
Page 15: Installing Sfp+ Transceivers
5. INSTALLING SFP+ TRANSCEIVERS The GigaCore 20t and GigaCore 18t are equiped with SFP+ cages at the rear of the unit. Use with IEC 60825-1 Certified SFP+ tranceivers only. Insert the transceiver entirely into the SFP+ cage gently applying just enough pressure until the module locks in place with an audible “click”. - Page 16 Open the lever to disengage and remove the SFP+ transceiver. Delatch lever For any other model of SFP+ transceiver, please refer to the transceiver manual. For recommended transceivers please visit our website at: www.luminex.be...
-
Page 17: Connecting To The Web Interface
If you need to ask our team for more help or you need to return a device to Luminex for diagnostics or repair, you can also find the option on this page to request an RMA or start a support ticket. - Page 18 Luminex. The information in this docu- mentation is supplied without warranty of any kind, either directly or indirectly, and is subject to change without prior written notice. Luminex, its employees or appointed representatives will not be held responsible for any damages to soft- ware, hardware, or data, howsoever arising as a direct or indirect result of the product(s) mentioned herein.
- Page 20 GigaCore 20t Safety & Quickstart Guide (LU 77 00284 rev.1.0.3) Slamstraat 13 | 3600 Genk | Belgium | T +32 11 812 189 info@luminex.be | www.luminex.be...
