4 Assembling Your S-Max

Install the steering bar
1 Insert the steering bar into the 2 Tighten the two screws.
S-Max body. (See Accessories No. 3)
Adjust the knee pad height
Lift the knee pads to the desired
1 Rotate the height adjustment knob 2 2
height. Rotate the height adjustment
counter-clockwise.
knob clockwise to tighten.
24
3 Put the cap on.
* Lift the guide bar to help steer the
S-Max without a rider when powered
on.
Warning:
DO NOT use to lift or carry the S-Max.
Tire Replacement
* Tires are subject to wear and need to be purchased separately.
Remove the six screws from the tire.
1
Remove the hubcaps and then remove the outer tire.
3
* The steps above are only applicable to the replacement of rear tires.
The comfortable tire is only for S-Max.
Remove the hubcaps and then remove the outer tire.
2
The side with printing should face outwards.
