8 Specifications
Ninebot Gokart Pro
Product Model N2C432
Vehicle size 55.9 × 33.5 × 23.6 in (1420 × 852 × 600 mm)
Size
Package size 41 × 33.5 × 18 in (1040 × 852 × 459 mm)
Max payload Approx. 220 lbs (100 kg)
Weight
Net weight Approx. 112.9 lbs (51.2 kg)
Age 14+ years old
Driving
Height 51.2–74.8 in (130–190 cm)
Speed limit Approx. 23 mph (37 km/h)
Approx. 1.9 mph (3 km/h)
Reversing speed limit
Typical Range Approx. 15.5 mi (25 km)
[1]
Steering ratio
2.1:1
Ground clearance Approx. 1.8 in (45 mm)
Maximum slope
Main Approx. 15 °
parameters
Traversable
Flat surface, paved road; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm);
Terrain slopes < 15 °
Operating temperature 14–104°F (-10–40°C)
-4–122°F (-20–50°C)
Storage temperature
IP rating IPX4
Approx. 4 hour
Charging time
ECO mode—max. speed: 5 mph (8 km/h); STRADA mode—max. speed: 11 mph (18 km/h);
Speed modes
SPORT mode—max. speed: 17.4 mph (28 km/h); CORSA mode—max. speed: 23 mph (37 km/h).
Nominal Voltage 55.5 V DC
Max. Charging Voltage 59.5 V DC
Battery
Nominal Energy 432 Wh
Charging Temperature 32–104°F (0–40°C)
Battery Management Over-voltage, under-voltage, short circuit, and over-heating protection.
System Auto-sleep and auto-wake.
Nominal Power
500 W × 2
Motors
Max. Power 2400 W × 2
[1] Typical Range: tested while riding under full power, 165.3 lbs (75 kg) load, 77°F (25°C), 60% of max. speed on average on pavement.
* Some of the factors that affect range include: speed, number of starts and stops, ambient temperature, etc.
16
Input Voltage 100-240 V ～ 50/60 Hz
Output Voltage 59.5 V DC
Charger
Nominal Power 120 W
Output Current 2 A
Front
Model/Quantity 6 AA Batteries
compartment
[2]
battery
Braking method Electronic brake + mechanical handbrake
Brake
Braking distance [3] 6 m
Front tire Tire width: 3 in (80 mm); flatness ratio: 60%; hub diameter: 5 in (127 mm)
Tires
Rear tire Tire width: 2.7 in (68 mm); 10 × 2.75 in, hollow solid tire
Headlight 0.2 Watt white LED light bar
The indicator comes in three colors: blue, yellow, and red. Blue means that the vehicle
Light
is in normal condition. Yellow means that the batteries in the front compartment need
Status indicator
to be replaced. Red means that the vehicle has a performance failure, and you need to
open the app to check the cause of the failure and contact the after-sales service.
Taillights Rull-color RGB taillight/brake light
[2] Front compartment battery: The battery compartment inside the frame that is used to power the frame indicator/head-
light. When the battery is low, the blue indicator light turns yellow and blinks. You need to replace the batteries yourself.
[3] Braking distance: Under the circumstances of full power, 154 lbs (70kg) load, and measured on a flat hard road at an
average speed of 12.4 mph (20 km/h).
