  • Page 1 Controller CT/L-14 ASSEMBLY AND OPERATION MANUAL...
  • Page 2 CT/L-14 Controller Assembly & Operation Manual...
  • Page 3 TRANSPORTATION AND STORAGE................... 30 Appendix 1. Instruction on connection of the card capture reader ..........31 Appendix 2. Instruction on connection of the CT/L-14 through PoE-splitter ........33 Appendix 3. Instruction on connection of the controller for lock-chamber management ....34...
  • Page 4 Embedded PERCo-Web system limitations: number of employees – up to 500, visitors – up to 500, departments – up to 100, events – up to 1 mln, maximum number of controllers in the system – 10. Use PERCo-Web access control system that can be installed on a separate server for a wider range of options.
  • Page 5 Operation Manual up to two boom barriers or automatic gates of vehicle checkpoint; • • turnstile / gate or boom barrier (automatic gate) in combination with locks: the total number of ODs is max. 3 ODs. The controller also supports the ability to control OD double-check combinations (see Appendix 3). OPERATING CONDITIONS The controller, with regard to resistance to environmental exposure complies to GOST 15150-69 category NF4 (operation in premises with climate control).
  • Page 6 • connection via Ethernet (IEEE 802.3) interface; • support of TCP/IP protocol suite (ARP, IP, ICMP, TCP, UDP, DHCP); • support of application layer of communications protocol of PERCo-Web system; • updating of embedded software via Ethernet. By default, the controller features: •...
  • Page 7 Operation Manual As a part of ACS, the controller provides: • operation in ACM: “Open”, “Control”, “Security” , “Closed”; • saving the set mode in the non-volatile memory in order to avoid the turn-off of the mode in case of power failure; •...
  • Page 8 CT/L-14 Controller XP4 – power indicator connector on the controller housing; • • XP5.1, XP5.2 – XP8.1, XP8.2 – connectors (in pairs) to select the type of connected lock (see Sect. 8.2.2): − jumpers are removed – standard electromechanical or electromagnetic lock is to be connected to the corresponding output, jumpers are installed –...
  • Page 9 Operation Manual Contact name in the Contact Designation Web-interface XT7 (OUT2 )connector normally open contact “Relay control output OD #2” or central contact NO2/C2/NC2 “Additional output OUT #2” normally closed contact XT8 (OUT3) connector normally open contact “Relay control output OD #3” or central contact NO3/C3/NC3 “Additional output OUT #3”...
  • Page 10 (IN #5, IN #6). Signals activation depends on description of their default status in Normal status of contact parameter in PERCo-Web software: If the input is described as Open, it is activated by a turn-on of low-level signal relative to •...
  • Page 11 Operation Manual “Relay contact” control element is to provide following signals characteristics: Minimum commutating current .................. max. 1 mA Closed contact resistance (with resistance of the connection cable) ....max. 300 Ohm Circuit control element with open collector output is to provide following signals characteristics: Voltage at the closed contact (low-level signal at input of the controller) ....
  • Page 12 CT/L-14 Controller In potential mode of OD: In case of single passage relay output is activated for a period of time, set in software by • Holding in unlocked state period software parameter or till the moment of end of passage.
  • Page 13 Operation Manual When connecting to RS-485 interface, follow the instructions of the connected device and the layout presented in Fig. 3. To connect a communication line of RS-485 to the controller, the #2 cable type is to be applied (Table 3). Following variants of reader connection are possible (Fig.
  • Page 14 CT/L-14 Controller Attention! All connections and jumper installations should be carried out only when the equipment • is powered off and power supply is disconnected. • During mounting use only proper tools. Cabling should be performed in accordance with general requirements for electrical •...
  • Page 15 Operation Manual Crossing of all cables with power cables is allowed only at a right angle. • • Cable growth is to be performed by soldering only. All cables, entering controllers, should be fixed with plastic ties to self-adhesive cable tie •...
  • Page 16 CT/L-14 Controller 4. Fix the controller with three screws through holes in the controller housing (use dowels from the delivery set, if necessary). 5. Select the way to set IP-address of the controller (Sect. 5.3) and install a jumper on XP1 connector in accordance with the Table 2), if necessary.
  • Page 17 Operation Manual 9. Connect the rest of necessary equipment: • electromechanical (electromagnetic) locks (Sect. 8.2.2); • turnstile (Sect. 8.2.3); • vehicle checkpoint (Sect. 8.2.4); • RC-panel (WRC) (Sect. 8.2.5); • emergency unlocking devices Fire Alarm (Sect. 8.2.6); • other optional equipment (Sect. 8.2.7). 8.2.2 Door control configuration Figure 4.
  • Page 18 CT/L-14 Controller When connecting the lock (latch) to the controller, follow the next recommendations: 1. To dissipate static electricity, it is recommended to ground the housing or locking bar of the lock. In case of lock installation on a metal door, it is recommended to ground the door leaf. It is necessary to use the cable with cross section of min.
  • Page 19 Operation Manual 8.2.3 Turnstile and electromechanical gates configuration Figure 6. Connection layouts of “Turnstile control” configuration...
  • Page 20 CT/L-14 Controller Note: The Device output operating mode OD parameter is to be in Potential for PERCo • turnstiles. The Registration of the passage after ID card presentation OD parameter is to be in • Yes for WMD-05S and WMD-06 swing gate.
  • Page 21 Operation Manual 8.2.4 Vehicle checkpoint configuration When installing a controller, it is necessary to correspond with operation logic of control unit of vehicle checkpoint (in parentheses – the output number for vehicle checkpoint #2): • Operation of control unit of vehicle checkpoint is performed via two relays – when passage is allowed OUT1 (OUT3) relay is activated and held, sending “Open”...
  • Page 22 CT/L-14 Controller Figure 8. Connection layouts of boom barriers to the controller of vehicle checkpoint Figure 9. Connection layout of intrusion detectors...
  • Page 23 Operation Manual 8.2.5 RC-panel connection The controller in the relevant configuration allows connecting up to two RC-panels to control turnstiles, swing gates or vehicle checkpoint ODs. To connect each RC-panel to the controller the following inputs can be used: Three inputs to control the passage: DUA, DUSt, DUB; •...
  • Page 24 CT/L-14 Controller Attention! To connect the optional equipment with inductive load (Rn) to the outputs, it is necessary to use spark protection diode (VD1 in Fig. 12). For example, Schottky diode for operating current of min. 1A (1N5819). Figure 11. Connection layout of optional equipment to controller inputs...
  • Page 25 Operation Manual Figure 12. Connection layout of optional equipment to relay outputs Figure 13. Connection layout of optional equipment to “Open collector” outputs CONFIGURATION The principal controller configuration (setting the configuration, adding and removing controllers of the second level and optional readers) is possible only via the controller Web-interface (Appendix 4).
  • Page 26 Embedded PERCo-Web system limitations: number of employees – up to 500, visitors – up to 500, departments – up to 100, events – up to 1 mln, maximum number of controllers in the system – 10. Use PERCo-Web access control system that can be installed on a separate server for a wider range of options.
  • Page 27 Operation Manual 10 UPDATE OF EMBEDDED SOFTWARE Update the embedded software and format the memory is possible using the controller Web- interface in the Diagnostic section (Appendix 4, p.9). 11 OPERATION When operating the controller, follow the safety measures indicated in Sect. 7.2. After the configuration, the controller can operate in the following modes: Without connection to the security system server.
  • Page 28 CT/L-14 Controller Protected zone is armed including the selected OD. • • Passage through the OD (forced entry) sets the system into the “Alarm” mode. 11.2 Indication of ACM, events and controller configurations Connected to the controller remote readers and indication blocks display the indication of ACMs, states and responses of the controller upon presented identifiers.
  • Page 29 11.3 Troubleshooting The elimination of possible malfunctions listed below is made by the Client. If the fault persists, we recommend you to contact one of the service centers of PERCo company. A list of service centers is given in the Certificate.
  • Page 30 If the controller still does not detect connection to Ethernet network or the communication is not reestablished, contact PERCo service in order to repair this controller. 12 MAINTENANCE Technical staff performing maintenance of the controller should be acquainted with construction and operating procedures of the controller.
  • Page 31 Operation Manual Devices, Norms and Work Procedure instrument, events equipment 1.3 Remove dust, dirt, corrosion from the There should not Rags, flat brush, surface of terminal blocks, jumpers and be corrosion and grease fuses. dirt 1.4 Verify compliance of the denomination and the condition of the fuses It should conform to the layout of the...
  • Page 32 CT/L-14 Controller APPENDICES Appendix 1. Instruction on connection of the card capture reader Figure 15. IC-05 card capture reader connection layout...
  • Page 33 Administrator’s Guide of these systems and also in the IC05 Operation Manual. An example of connection of the PERCo card capture readers is shown in Fig. 15. Any available inputs and outputs are used in the current controller configuration.
  • Page 34 Con 3 – power output for controller power cable connection. Note: For some models of splitters output voltage is chosen with a switch. Operating PERCo equipment it is necessary to place the switch in “12V” mode. Requirements for connecting devices...
  • Page 35 While there is a person in the lock-chamber zone, external readers (RC buttons) are blocked until the person leaves the lock-chamber. CT/L-14 controller can operate different types of lock-chambers: 1. Two-lock lock-chamber (double-sided locks). 2. RTD-15, RTD-16, RTD-20 full-height rotor turnstile lock-chamber.
  • Page 36 CT/L-14 Controller Types of lock-chambers operated by the CT/L-14 controller 1. Two-lock lock-chamber is intermediate space with a free passage through two doors. Each lock-chamber door is operated by two internal and external readers (in regard to the lock- chamber). Reader can be replaced or duplicated by the RC button (see below the lock- chamber OD settings).
  • Page 37 Operation Manual settings). To operate the lock-chamber passageway control sensors are activated: PASS A for direction of the passage 1 through OD1, PASS B for direction of the passage 2 through OD1 and the door sensor (for both directions through OD2). Figure 20.
  • Page 38 CT/L-14 Controller Web-Interface Appendix 4. CT/L-14 Controller Web-interface. User Manual CONTENTS WEB-INTERFACE OPPORTUNITIES ................... 38 CONNECTION TO WEB-INTERFACE OF THE CONTROLLER ........... 38 SETTINGS ..........................39 Change of controller system time ..................39 Change of controller network setting ................40 Change of server settings ....................
  • Page 39 User Manual 1. WEB-INTERFACE OPPORTUNITIES Using Web-interface without installation of additional software allows performing following steps for the controller and connected devices: Change network settings, access password and time of built-in clocks of the controller. • • Configure settings of operating device, readers and other equipment of the controller. Set ACM for operation devices.
  • Page 40 On the page the user can select the following elements: 1. The page title bar contains PERCo trademark and buttons to select the language of Web- interface. By clicking on the PERCo company logo the user will navigate to the main page from other sections of Web-interface.
  • Page 41 User Manual Change of controller network setting The controller has the following configurations by default (they are specified in the certificate of the device and on the labels on the controller): MAC-address 00-25-0B-xx-xx-xx, where xx – is a number from 00 to FE; •...
  • Page 42 CT/L-14 Controller Web-Interface When connecting to the controller operating under software of PERCo systems, the • current format may not be shown (nothing is selected from the formats). In this case change of the card identifiers reading format is PROHIBITED.
  • Page 43 User Manual 2. Select the desired configuration option. Changing the configuration template can take up to 30 seconds. Configuration of the controller resources settings 4.2.1 Operating devices To configure settings of the controller resources to control OD: 1. Click consistently Configuration  Edit  Operating devices in the Web-interface menu. The page with working area will be opened: 2.
  • Page 44 CT/L-14 Controller Web-Interface The page lists all the controller inputs and outputs. When selecting the template (p. 4.1) the inputs and outputs that are involved in the OD control of this template, corresponding functions are stated (for inputs – PASS / RC, for outputs – OD control / RC-panel indication) and the number and OD direction, which the physical contact is attached to, are to be set.
  • Page 45 When adding optional readers, they are configured similarly to card capture readers attached to the same OD directions. In this regard, added readers are not shown in network and local software of PERCo-Web system. To configure the reader settings: 1. Click consistently Configuration  Edit  Readers in the Web-interface menu. The page with working area will be opened: 2.
  • Page 46 CT/L-14 Controller Web-Interface 3. In the opened window make the necessary changes of the settings: Number parameter sets the number of the added reader; • Communication interface parameter sets the interface or reader type; • Connection port parameter sets the port of the interface or the address on the bus (RS- •...
  • Page 47 User Manual 3. In the opened window make the necessary changes of the settings: • Number parameter sets the response number in the controller database (from 1 to 40); • Source type parameter sets the launch condition of the controller response; •...
  • Page 48 CT/L-14 Controller Web-Interface 2. To add a new filter, click the Add button; to change parameters or delete a filter, click the title bar in the page working area. The Filter window will be opened. 3. In the opened window set the necessary values for the event parameters that need to be filtered from the general list.
  • Page 49 User Manual 3. In the opened window effect all necessary changes of the parameters: Zone number parameter sets the time zone number; • Beginning of period parameter sets the beginning of period; • End of period parameter sets the end of period. •...
  • Page 50 CT/L-14 Controller Web-Interface 3. In opened window select the date and the Type of the holiday. 4. To save all changes and send the set parameters to the controller, click the Save button. The Holidays window will be closed. 5. To exit the Holidays window without saving the changes, select the Cancel button. Also, it is possible to close it by clicking Close 6.
  • Page 51 User Manual 3. In the opened window perform the necessary changes for the parameters: Schedule number parameter sets the schedule number; • Day parameter sets the day of the week; • Time zone parameter sets the time zone number for the selected schedule. •...
  • Page 52 CT/L-14 Controller Web-Interface flexible weekly flexible 2. To add a new schedule, click the Add button; to change or delete the weekly schedule parameters, click the title bar in the working area. The Flexible weekly schedule window will be opened: 3.
  • Page 53 User Manual In the opened window in the Main, General rights, Individual rights tabs perform the all necessary changes. Using the Cards tab assign to the user an identifier. For this purpose: Input of reader identifiers: • Present the card to one of the readers included in the controller configuration. The Input card window will be opened.
  • Page 54 CT/L-14 Controller Web-Interface 2. Click the OD bar in the page working area, to which it is necessary to issue the control command. The control window with selected OD will be opened: 3. Using the buttons at the bottom part of the window, give the necessary command. The control window will be closed;...
  • Page 55 User Manual 3. There is possibility of selection in the report of events by categories and time. To do this, click the Filter button, the Filter window will be opened: 4. In the drop-down Selected categories list tick the event categories boxes which should be reported.
  • Page 56 CT/L-14 Controller Web-Interface 9. SERVICE For maintenance of the controller: 1. Click Service in the Web-interface menu. The page with working area will be opened: 2. To restart the controller, click the Restart button. 3. To delete all fingerprints from Morpho, click the Delete all fingerprints from Morpho button.
  • Page 57 PERCo Polytechnicheskaya str., 4, block 2 194021, Saint Petersburg Russia Tel: +7 812 247 04 64 E-mail: export@perco.com support@perco.com www.perco.com...
