- Page 1 USER MANUAL ASIN Pool INTELLIGENT NETWORK CONTROLLER to Control the Pool Technology with Smartphone ASIN Pool VS Pump Module REL 1 REL 2 REL 3 REL 4 REL 5 REL 6 REL 7 n1 n2 n3 STOP SENSOR POWER www.aseko.com...
-
Page 2: General Safety Information
General Safety Information This user manual has basic information that should be observed during assembly, start-up, operation, and maintenance. Therefore, this user manual must be read by installers and operators prior to assembly and start/up, and must be accessible to every user of this unit. Additionally, all further safety information in this document absolutely must be observed. - Page 3 consequence: gravest degree of injury, heavy material damage. • Read all informational text carefully. • Cancel the process if you are unable to exclude all potential hazards. Use of Device New Functions Because of the continued development, a ASIN Aqua® unit may contain functions, which are not completely described in this version of the user manual.
-
Page 4: Box Content
Box Content ASIN Pool REL 1 REL 2 REL 3 REL 4 REL 5 REL 6 REL 7 n1 n2 n3 SENSOR POWER Power supply 110-240 VAC / 50 Hz / 60 Hz Input power 10 VA Overvoltage category Protection degree... -
Page 5: Accessories Available For Purchase
Accessories Available for Purchase VS Pump Module REL 1 REL 2 REL 3 REL 4 REL 5 REL 6 REL 7 n1 n2 n3 STOP SOR POWER Water thermometer with well #12010 Air thermometer Solar collector thermometer 5-way BESGO valve 3-way BESGO valve Pressure-type level sensor #12086... - Page 6 STOP The ASIN Pool network controller is able to control and adjust all the pool technology elements. The ASIN Pool can be adjusted and controlled by means of the perfectly designed user friendly application via the internet.
- Page 7 REL 1 REL 2 REL 3 REL 4 REL 5 REL 6 REL 7 n1 n2 n3 STOP Solar collector SENSOR POWER Pool blind/ cover Gutter Automatic Pool nozzle refilling Water level Bottom outlet Equalisation tank or sensorr skimmer 5-way BESGO valve for filter backwashing 3-way BESGO valve for gutter/outlet...
-
Page 8: Terminal Board
REFILLING DOPOUŠTĚNÍ FILTRATION FILTRACE FILTER WASHING PRANÍ FILTRU (Besgo) (BESGO) BOTTOM/GUTTER DNO / ŽLÁBEK (Besgo) (BESGO) SOLAR COLLECTOR SOLÁRNÍ KOLEKTOR POOL LIGHTING OSVĚTLENÍ BAZÉNU Connection Propojení of ASIN Pool ASIN Pool and VS Pump a VS Pump module modulu STOP... -
Page 9: Electrical Connection
Electrical Connection POWER SUPPLY NAPÁJENÍ HEATING TOPENÍ L is logic signal L je logický signál Independent logic Nezávislý logický HEATING TOPENÍ signal signál HEATING TOPENÍ Refilling Solenoid REFILLING DOPOUŠTĚNÍ solenoid dopouštění Filtration Relé filtrace FILTRATION relay FILTRACE Filtration pump Čerpadlo filtrace 230 Vac FILTER WASHING BESGO... -
Page 10: Control And Settings
Control and Settings Manual Button Operation For easier installation and necessary events... POWER: On/Off AUTO: automatic mode / manual REL 1 REL 2 REL 3 REL 4 REL 5 REL 6 REL 7 n1 n2 n3 STOP mode (testing) WIFI DIRECT: On/Off Relay status indication: ON/OFF... - Page 11 Click "Connect via Wifi Direct" to open the iPool Connect window. Click on „Go to settings Wifi“. A list of Wifi networks will show up, find your ASIN Pool serial number, select it and connect. Return to the iPool Control application.
- Page 12 Current status The screen provides all the important information about the current status of your pool and the connected components controlled by ASIN Pool. Water temperature, air temperature, solar panel temperature Current mode Pool components status ASIN AQUA paired device status...
- Page 13 Control The screen serves to switch between operation modes of your pool controlled via ASIN Pool. The slider serves to control your pool operation modes. Switches Turns the on the filter lights on/off washing process...
- Page 14 Settings The screen serves to set the ASIN Pool and characteristic of each mode in- cluding the filtration timer.
- Page 15 SMART Heating Heating Time Adjustment This function allows to adjust time of heating operation. This is particularly useful for switching on the heat pumps that have higher efficiency during the day time when outdoor temperature is higher. Adjustment of Temperature above/below which Heating is in Operation This function allow you to customize the pool heating and achieve the highest possible efficiency of the heat pump.
- Page 16 Measuring the level and Automatic water Refilling The water level is measured by the pressure-dependent level sensor. This allows very easy installation by inserting the sensor into the storage reservoir or skimmer. Water Level is controlled at four adjustable height levels that are easily entered in centimetres.
-
Page 17: Variable Speed Pump Control
Variable speed Pump Control The ASIN Pool with the additional ASIN Pump module enable to control the circulating pumps with a SPECK and PENTAIR variable drive. Power of such pump (1 or 2) can be selected at preset periods in individual modes. In case of backwashing, the pump is running at speed 3. - Page 18 Solar The ASIN Pool allows control of the solar heating. To enable this function is necessary to install the outdoor thermometer to the solar collector. At the preset temperature of the solar collector, e.g. 40°C will solar system circulating pump (relay No. 6) as well as the filter pump start on. This start takes absolute priority over other settings in order to prevent the solar collector from being overheated.
