THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
Please Recycle
Recicle Por Favor
0
29986 59328
3
Recommended # of people needed for assembly: 1
(however it is always better to have an extra hand.)
Estimated assembly time is 2 hours.
Se localizan las traducciones españolas en el centro de este
manual.
5998222W
DO NOT RETURN PRODUCT TO THE STORE
STOP
Individual stores do not stock parts.
Date of Purchase
___ / ___ / ___
If a part is missing or damaged, visit our website or call our toll-free
customer service line. We will gladly ship your replacement parts
FREE of charge.
Need Parts or Assistance?
WWW.AMERIWOOD.COM/PARTS
or call toll free:
1-800-489-3351
For prompt, reliable service please have your assembly manual ready.
B345998222W0 0

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5998222W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriwood HOME 5998222W

Summary of Contents for Ameriwood HOME 5998222W

  • Page 1 5998222W 29986 59328 DO NOT RETURN PRODUCT TO THE STORE STOP Individual stores do not stock parts. Date of Purchase ___ / ___ / ___ If a part is missing or damaged, visit our website or call our toll-free customer service line. We will gladly ship your replacement parts FREE of charge.
  • Page 3 Parts Parts shown are the base cabinet of your model. Please note, most parts are labeled with a sticker or have a letter stamped on a raw edge. Parts List ITEM PART NUMBER DESCRIPTION This piece is of paperboard construction. It is not made from LEFT PANEL 35998222010 wood, but is required for the assembly of your unit.
  • Page 4 Hardware HARDWARE COMPARTMENT LAYOUT handle nail #A50690 7/8" pan screw cam bolt 7/16" flat screw 1-1/4" screw #A21110 #A12700 Qty: 4 #A22510 #A11080 #A11600 Qty: 20 Qty: 8 Qty: 12 Qty: 40 Qty: 16 cam lock 7/16" pan screw wood dowel angle bracket #A22570 #A12120...
  • Page 5 This illustration shows how the cam fastening system works. Esta ilustración muestra el sistema de fijación de leva y como funciona. Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 6 Screw four cam bolts (1) into the top (C). Fasten the safety bracket (13a) to the top (C) with screw (13b). raw edge borde crudo B345998222W0 0 6 /20...
  • Page 7 Insert four cam locks (2) and two wood dowels (4) into the bottom (D). Fasten the kick panel (E) to the bottom (D) with four angle brackets (6) and eight screws (10). proper orientation of cam lock posición correcta de la cerradura de leva raw edge borde crudo proper orientation of cam lock...
  • Page 8 Insert two cam locks (2) and two wood dowels (4) into the brace (J) and the solid back (K). proper orientation of cam lock posición correcta de la cerradura de leva proper orientation of cam lock posición correcta de la cerradura de leva B345998222W0 0 8 /20...
  • Page 9 Insert two cam locks (2) and one wood dowel (4) into the left panel (A). Screw four cam bolts (1) into the left panel (A). Fasten four metal slides (11a) to the left panel (A) with screws (3). proper orientation of cam lock posición correcta de la cerradura de leva marked with a "CL"...
  • Page 10 Insert two cam locks (2) and one wood dowel (4) into the right panel (B). Screw four cam bolts (1) into the left panel (B). Fasten four metal slides (11b) to the left panel (B) with screws (3). proper orientation of cam lock posición correcta de la cerradura de leva marked with a "CR"...
  • Page 11 5998222W No regrese el producto a esta tienda, tiendas individuales no almacenan partes. Si le falta una parte o esta danada, llame al numbero gratis a la lineas de servicio al cliente. Nosotros con gusto le mandaremos la parte sin ningun costo adicional.

  • Page 12: Lista De Partes

    LISTA DE PARTES ITEM DESCRIPCION CANTIDAD ITEM DESCRIPCION CANTIDAD panel izquierdo perno de la leva panel derecho cerradura de la leva tornillo 7/16” cima fondo clavija de madera panel de protección tornillo 1-1/4” frente de cajon anaquel del Angulo tornillo 7/8” trasero de cajon lado izquierdo de cajon clavo...
  • Page 13 PASO 2 Insertar cuatro Cerraduras de la Leva (2) y dos Clavijas de Madera (4) dentro el Fondo (D) Fijar el Panel de Protección (F) al Fondo (D) con cuatro Anaqueles del Angulo (6) y ocho Tornillos (10) PASO 3 Insertar dos Cerraduras de la Leva (2) y dos Clavijas de Madera (4) dentro el Soporte (J) y Panel Trasero Sólido (K) PASO 4 Insertar dos Cerraduras de la Leva (2) y una Clavija de Madera (4) dentro el Panel Izquierdo (A)
  • Page 14 PASO 9 Opción 1: Atornille (13c) a través del anaquel de seguridad (13a) y en una área sólida de la pared. Si usted no puede atornillar en algo el sólido, use opción 2 Opción 2: Taladre un agujero de 3/16" de diámetro (5mm) en la pared. Golpea la ancla de pared (13d) en el agujero hasta que sea parejo.
  • Page 15 Attach bottom (D), brace (J), and solid back (K) to the left and right panel (A&B) and tighten the cam locks. LOCK APRETAR all finished edges and surfaces are facing upwards todos los bordes y superficies acabadas estén mirando hacia arriba B345998222W0 0 11 /20...
  • Page 16 Attach top (C) to the left and right panel (A&B) and tighten the cam locks. LOCK APRETAR all finished edges and surfaces are facing upwards todos los bordes y superficies acabadas estén mirando hacia arriba B345998222W0 0 12 /20...
  • Page 17 First, attach the back panel (M) to the solid back (K) with six screws (10). DO NOT tighten firmly. Then, making sure that the unit is square, attach the other three sides of the back panel (M) to the unit with nails (8). Once complete, tighten all screws (10) firmly.
  • Page 18 place the unit upright colocar la unidad en posición vertical hole agujero stud montante wallboard muro Option 1: Screw (13c) through the safety bracket (13a) and into a solid area of the wall. If you cannot screw into something solid, use option 2. Option 2: Drill a 3/16"...
  • Page 19 Lay the drawer sides (H&I) down on a flat hard surface. Carefully line up the drawer bracket (12) with the holes in the drawer sides (H&I) as shown. Using a hammer, tap each drawer bracket stem part way into each hole. Repeat this process until the drawer bracket is fully seated on the drawer side.
  • Page 20 Fasten the drawer sides (H&I) to the drawer front (F) with screws (10). marked "LEFT" marcado "LEFT" marked "RIGHT" marcado "RIGHT" raw edge borde crudo B345998222W0 0 16 /20...
  • Page 21 Slide the drawer bottom (L) into the grooves of the drawer sides (H&I) and the drawer front (F). Fasten the drawer back (G) to the drawer sides (H&I) with screws (5). marked "BACK" marcado "BACK" raw surface superficie crudo raw edge borde crudo B345998222W0 0 17 /20...
  • Page 22 Fasten the metal slides (11c & 11d) to the drawer sides (H&I) with screws (3). Fasten a handle (9) to each drawer front (F) with screws (7). marked with a "DL" marcado con un "DL" marked with a "DR" marcado con un "DR" B345998222W0 0 18 /20...
  • Page 23 Slide all four Drawers into the Cabinet. roller cabinet member rodillo corredera de mueble drawer runner deslizador de cajon roller rodillo Notice, the drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and retightening screws. B345998222W0 0 19 /20...
  • Page 24 Call our toll free number for any assistance you should need or visit our Weight Limits website: Limites de peso 1-800-489-3351 www.Ameriwood.com/parts Clean the product with your favorite furniture polish and a soft cloth. DO NOT USE harsh chemicals or abrasive cleaners. Move your new furniture carefully with two people.
