  • Page 1 English 2-Wire Video Outdoor Station User Manual DT-ENG-610-V1 190107...

  • Page 2: Parts And Functions

    1.Parts and Functions Camera Lens LED_UNLOCK LED_CAM Speaker LED_KEY KEY_CALL Microphone 2.Terminal Descriptions DIP: Bit 1&2: to set door station address, total 4 door stations ON(1) OFF(0) can be supported. Please refer to door station address set- ting. Bit 3&4: to set unlock time for door station. Please refer to unlock time setting.
  • Page 3 3.Mounting 1. Installation height for door station usually is 145~160cm. 2. Use screws to fix the back panel to the wall after connect the cable correctly. 3. Attach the front panel to the back panel, then use the screw to fix it.

  • Page 4: System Wiring And Connections

    4.System Wiring and Connections Basic Connection Code=00, DIP6=on PC6A BUS(IM) BUS(DS) L2 LK+ LK- DIP Switches 1 2 3 4 5 6 Doorbell Button Switch Electric Lock Connection Door Lock Controlled with Internal Power Note: This mode only supports electromagnetic locks.

  • Page 5: Door Lock Controlled With Dry Contact

    Door Lock Controlled with Dry Contact Note: The external power supply must be used according Jumper position to the lock. The inside relay contact is restricted to AC or DC 24V/1A. L2 LK+ LK- Setup the Unlock Mode of Monitor for different lock types.

  • Page 6: Basic In-Out Wiring Mode

    Multi Monitors Connection Basic IN-OUT Wiring Mode Code=15 Code=14 Code=0 100~240VAC PC6A BUS(IM) BUS(DS) (Device Address:0) NOTE:Here we take DT47MG(the monitor) for example.
  • Page 7 With DBC4A1 Wiring Mode Impedance Code=14 Code=15 OFF ON switch Code=13 Code=12 Code=2 Code=3 Impedance OFF ON switch Code=1 Code=0 100~240VAC PC6A BUS(IM) BUS(DS) (Device Address:0) NOTE:Here we take DT47MG(the monitor) for example.

  • Page 8: Pan-Tilt & Zoom

    5. Pan-tilt & Zoom Note that this function requires the monitor with fish-eye function to support. It is available to adjust the display mode for viewing images at a fish-eye door station by using the 5 direction pad button. When an image at a door station is displayed,move to the desired position by touching on the screen to view the image in zoom mode.

  • Page 9: Led Status

    6. LED status Different LEDs ON to represent different states. Please refer to the figure below. LEDs LED_UNLOCK LED_CAM LED_KEY Status (by default) (by default) Monitoring Auto (by default) Calling Auto Flash quickly (by default) Talking Auto Flash slowly Unlock Upgrad Setup/ Initilization...
  • Page 10 7. Door station address setting ON(1) OFF(0) Total 2 bits on the DIP switches can be configured.The switches can be modified either before or after installation. Bit state Descriptions Default setting, ID = 0(00), set to the first Door Station. ID = 1(01), set to the second Door Station.
  • Page 11 8. Setup Set bit 6 to ON or connect power, and within 10s, press and hold KEY_CALL to get into set- ting state. Switch Language Voice Press KEY_CALL to switch Press KEY_CALL to switch Press KEY_CALL to switch language voice prompt mode. language voice prompt mode.

  • Page 12: Specifications

    9. Specifications • Power Supply : DC 24V ; • Power Consumption: Standby 14mA; Working status 122mA; • Camera: Color CMOS, 2.0 Mega pixel • 1/2.7’’ fisheye camera,155 wide angle; • Lock Power supply: 12Vdc, 250mA(Internal Power); • Mounting: Surface mounting •...

  • Page 13: Cables Requirements

    11. Cables Requirements The maximum distance of the wiring is limited in the DT system. Using different cables may also affect the maximum distance which the system can reach. The farest monitor monitor with two or four monitors monitor monitor DBC4A1 100~240VAC When Monitor quantity <...
  • Page 14 Note...
  • Page 15 Note...
  • Page 16 The design and specifications can be modified without notice to the user. Right to interpret and copyright of this manual are reserved. DT-ENG-610-V1 190118...
