- Page 1 Bringing Colors To Life! HDMI Extender Over Single CAT5e/6 Cable Up To 40M ELE8020 USER MANUAL...
- Page 2 1 Introduction The ELE8020 HDMI Extender transmits over one Cat5e/6 cable to extend your HDTV display up to 70m at 1080i and 40m at 1080p. It’s equipped with HDMI connections. It also supports DVI equipment when using an HDMI to DVI adapter. It provides an easy and affordable cabling solution for integrating home theater components.
- Page 3 page 2 Cable Use High Quality Cat5e UTP or Cat6 UTP Cable (Terminated T568-B Format). Cat6 Is Recommended For Distances Over 30m. Distance May Vary Based On Different HDMI Equipment & Cable Quality. Default EDID Setup 1. Move DIP Switch 1 off (up). 2.
- Page 4 page 3 Receiver LED Functionality Blue External Power Adapter In Use Green Power & HDMI Signal from Tx Unit Yellow No Data Input or Weak Signal RJ45 Video Link (TIA/EIA-568-B) 1. Orange-white TMDS DATA2 + 2. Orange TMDS DATA2 - 3.
