AUTOMAZIONE PER CHIUSURA INDUSTRIALE
CONTROL PANEL FOR 400V GEARMOTORS
Z
SERIES
INSTALLATION MANUAL
ZA2S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CAME Z Series

  • Page 1 AUTOMAZIONE PER CHIUSURA INDUSTRIALE CONTROL PANEL FOR 400V GEARMOTORS SERIES INSTALLATION MANUAL ZA2S...
  • Page 2: Reference Standards

    “IMPORTANT SAFETY INSTRUCTIONS FOR INSTALLATION” “CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY” “THIS MANUAL IS ONLY FOR PROFESSIONAL INSTALLERS OR QUALIFIED PERSONS” 1 Legend This symbol indicates sections to be read with particular care. This symbol indicates sections concernig safety. This symbol indicates notes to communicate to users.
  • Page 3: Main Components

    4.2 Dimensions, distance between centres and fixing holes 4.3 Main components 1) Main switch 2) Cut-off switch 3) Power meter 4) Safety switch for 1st motor 5) Safety switch for 2nd motor 6) 400-24V Transformer 7) Terminal for connecting to power source 8) Terminal for connecting gearmotors and flashing lamp.
  • Page 4: Installation

    5 Installation 5.1 Preliminary checks Before proceeding with the installation, it is necessary to: • Make sure that the control panel is attached in a protected and impact-free area, that the surface it is attached is solid, and that it is attached to the surface with proper tools (screws, anchor lugs, and so on); •...
  • Page 5: Electrical Connections

    5.4 Cable list and minimum thickness Connections Type of cable Length of cable 1 < 10 m L. of cable 10 < 20 m L. of cable 20 < 30 m 230/400V 3F power supply 4G x 1,5 mm 4G x 2,5 mm 4G x 4 mm 230/400V 3F motor power supply 4G x 1 mm...
  • Page 6 24V A.C. output for powering accessories 30W max. Stop button (N.C. contact) - Stops movement, excludes the automatic closing functions. To restart the automated kit, press a command button or a remote control button. Opening Button (N.O. contact) – Gate opening button Closing button (N.O.
  • Page 7 (N.C. Contact for “re-opening during closing” - Input for photocells, sensiti- ve profi les and other devices complying with EN 12978 standards. During the closing phase, operating the device will invert the motion until complete opening is achieved. If this contact is not used, bridge the terminals amongst themselves. (N.C.) Contact for “re-closing during opening”...
  • Page 8: Function Selection

    5.6 Function selection 1 ON - Pre-fl ashing upon opening and closing – Following an opening or closing command, the fl ashing light connected on E1-E2, fl ashes for 5 seconds before the cycle begins. 2 ON - Automatic closing – the timer for the automatic closing is activated when the door completes its opening cycle. The set time is adjustable, and it is any how conditioned by the possible intervention of the safety devices and dies not activate after a total safety ‘stop’...
  • Page 9: Demolition And Disposal

    31030 Dosson di Casier - Treviso - ITALY In full compliance with the Machinery Directive 98/37/EC tel (+39) 0422 4940 - fax (+39) 0422 4941 internet: www.came.it - e-mail: info@came.it Declares under its own responsibility that the equipments for automatic garage doors and gates listed below: CONTROL PANEL FOR ZA2S SWING GATES …...
  • Page 10 CAME UNITED KINGDOM LTD UNIT 3, ORCHARD BUSINESS PARK TOWN STREET, SANDIACRE NOTTINGHAM - NG10 5BP - U.K. Tel 0044 115 9210430 Fax 0044 115 9210431...
